Page 1
4
Adjusting
Adjust the panel track to the width needed. Be careful not to
over extend the track and cause it to separate completely.
DOUBLE RAIL SLIDING
PANEL SYSTEM
INSTRUCTION
PREPARATION
1
Check the Hardware
Panel Sets 2 x
Panel Sets 2
(Each roll contains 2 panels)
Wands 2 x
5a
Position the track to where you would like to hang it on the
wall (using a level is recommended). Mark the screw position
of the L Brackets (use the top tip of the L bracket opening, as
that is where the track will hang from).
Wall Mount
Insert Screws-3 and Screw-2 through the track to connect
it to L Brackets (see diagrams below).
2
3
Gather other necessary tools
Getting Started
Snap the guide rails into the slider clips. Be sure to follow the correct number
sequence. Make sure the Velcro side faces the front (the fabric panels will
attach to this velcro).
Drill Screws into the wall (using
anchors is recommended).
Use 2/8 in drill bit for
drilling anchor holes
5b
Ceiling Mount
Once screws are in place, hang the track to the wall using L brackets.
You may need two people for this step.
Take screw-1 (see step 1) and screw up through the 2 fixed brackets (see below) on the
outside and one through the middle roaming bracket of the head rail up into the ceiling
(using anchors is recommended).
Page 2
6
Installing Panels
Measure the length needed for the panels. For accuracy, measure from the top of the guide
rail down to the floor and substract 1/4 in. So the fabric does not drag on the floor.
Cut the panels along the side opposite to the velcro strip.
VELCRO
Ready-Made Products Warranty
Limited One Year Warranty from the Date of Purchase
What is Covered :
• All of our Cordless Roman Shades are warranted against manufacturer defects in materials or
PLEASE CUT FROM THE BOTTOM SIDE
OPPOSITE TO THE VELCRO STRIP.
workmanship provided that you are the original purchaser of the product, and the product was installed
according to our instructions.
What is Not Covered :
• Normal wear and tear.
• Consumer damages caused by accidents, alterations, abuse of the product, exposure to salt air,
misuse, or damages from pets or insects.
• Damages resulting from removal and reinstallation in the same or any other window or application,
or failure to follow instructions, such as measurement, installation, cleaning, and maintenance.
• Any products that, with the passage of time, has yellowing or cracking of plastic parts
• Wrong measurements are not covered by the warranty and are not refundable.
To report shipping damages :
If damage occurred during shipping, please email [email protected] immediately and report within
14 calendar days or else you may be denied for your damaged product.
Obligations to the consumer :
7
Insert wands
Attach 2 wands to the leading and ending
guide rails.
Attach all 4 fabric panels to the guide rails.
How-to-use
OPENING OPTIONS
LEFT | CENTER | RIGHT3
The obligations of Chicology are limited to the repair or replacements of parts or products found to
be defective. Chicology will determine if the product is defective or not and may replace the product.
If the product is found to have manufacture defects, we will repair or replace the product. Colors do
vary from lot to lot, and may not match original product exactly. Discontinued items will be replaced
with the most current product of the same price.
Your Rights under State law :
This limited warranty gives you specific legal rights, and you may have other rights, which vary from
state to state.
