Zipato Zipabox Quick Installation Manual

1 | P a g e

Zipabox

QUICK INSTALLATION GUIDE

v.1.1

Copyright

2 | P a g e

© 2012 Tri plus grupa d.o.o. All Rights Reserved.
Copyright by Tri plus grupa d.o.o.. No part of this manual may be
reproduced or transmitted in any form without the expressed, written
permission of Tri plus grupa d.o.o.

Trademarks

Zipato and the Zipato logo are registered Trademarks All other product
names mentioned herein may be trademarks or registered trademarks
of their respective companies.

Notice

Although Zipato has attempted to ensure the accuracy of the content
of this manual, it is possible that this document may contain technical
inaccuracies, typographical, or other errors. Zipato assumes no liability
for any error in this publication, and for damages, whether direct,
indirect, incidental, and consequential or otherwise, that may result
from such error, including, but not limited to loss of data or profits.

Zipato provides this publication “as is” without warranty of any kind,

either express or implied, including, but not limited to implied
warranties of merchantability or fitness for a particular purpose.
The published information in the manual is subject to change without
notice.
Zipato reserves the right to make changes in the product design,
layout, and driver revisions without notification to its users.
This version of the Installation guide supersedes all previous versions.

3 | P a g e

Important Safety Information

To avoid contact with electrical current:
 Never install an Ethernet connection in wet locations unless that

connector is specifically designed for wet locations.

 Do not place Ethernet wiring or connections in any conduit, outlet

or junction box containing electrical wiring.

 Installation of inside wire may bring you close to electrical wire,

conduit, terminals and other electrical facilities. Extreme caution
must be used to avoid electrical shock from such facilities. Avoid
contact with all such facilities.

 Ethernet wiring must be at least 2 m from bare power wiring or

lightning rods and associated wires, and at least 15 cm from
other wire (antenna wires, doorbell wires, wires from
transformers to neon signs), steam or hot water pipes, and
heating ducts.

Electromagnetic compatibility

In proper state and when operated properly, the product complies with
all the requirements in respect of interference radiation according to
EN 301 489-17, EN 301 489-1 and EN 300 328. The connections
conducting HF signals must neither be manipulated nor damaged.

4 | P a g e

Table of Contents

INTRODUCTION .................................................................. 5

CONTENTS OF PACKAGE ................................................ 13

CONNECT THE ZIPABOX .................................................. 14

CREATE A USER ACCOUNT AND REGISTER YOUR

SYSTEM ............................................................................. 17

INSTALLATION/MOUNTING ZIPABOX .............................. 22

ADDING DEVICES ............................................................. 25

REMOVING DEVICES ........................................................ 26

TROUBLESHOTING........................................................... 27

SPECIFICATIONS .............................................................. 32

LIMITED PRODUCT WARRANTY ...................................... 33

DECLARATION OF CONFORMITY .................................... 38

DISPOSING AND RECYCLING YOUR PRODUCT ............ 39

5 | P a g e

INTRODUCTION

Thank you for purchasing Zipabox smart home automation
controller. This guide describes how to install, program and
operate your Zipabox. Zipabox makes every hoe smart by
using advanced technology to hide the complexity of home
networking - delivering a simple smart home. It plugs into any
outlet in the home and automatically talks to all the connected
devices in the house, connecting them to the cloud so that
consumers can control them using tablets, smart phones,
computers or TVs— at home or on the go.

The Zipabox Gateway supports variety of communication
standards including Z-WAVE, ZIGBEE, KNX, ONVIF, and
UPnP.

The Zipabox’s capabilities can easily be expanded using
“snap-in” expansion modules that will add support for new

interfaces and functionalities, communication standards and
protocols, etc.

Once configured, the gateway works stand-alone, but also
features cloud support for advanced monitoring, messaging
and programming services.

6 | P a g e

Intuitive graphical user interface allows customers to program
their own home rules without any previous programming
experience.

Security and safety

• unlimited number of virtual alarms (partitions)

• up to 233 two-way, wireless zones

• trigger alarms in case of:

o intruder (motion sensors and door/window

sensors),

o fire (smoke sensors),
o flood (water leakage sensors),
o gas (CO sensors)
o panic button,
o duress (if someone force you to disarm your

system)

o health care (in case of missing actions during

particular time e.g. motion, door opening,
laying on bed...)

• remote arm/disarm and status-info with any smartphone

• vandal proof - Zipabox is 24/7 monitored by central

station which triggers alarm in case of connection loss

• include arm/disarm commands in automation scenes
and rules

7 | P a g e

• integration with existing alarm systems (DSC,
Honeywell...)

• easy online setup and configuration through web based
interface

• use of same sensors for security and automation
purposes

Lighting

• easy installation of wireless modules

• Z-Wave and ZigBee lighting modules pre-configured for

even easier setup

• support remote dimming and on/off switching with any

smartphone

• automatically turn lights on at sunset and off at sunrise

• unlimited number of scenes supported

• turn lights on during emergencies

• advanced event based rules configuration

• auto-pilot lighting programs to discourage intruders while

home is empty

8 | P a g e

Climate

• multi-room heating and cooling control with any
smartphone

• advanced programming scheduler online, accessible
over web browser

• easily create unlimited number of custom zones
(thermostats)

• multi-zone humidity control by using standard humidifiers
and dehumidifiers

• use Internet weather feeds to program your home
climate conditions

• create advanced event based rules to automate home
climate based on other environmental and home events

• include climate control in automation scenes together
with alarm, lighting, shades, etc

• Notification and automated actions in case of over-
temperature events, power outages, and other
incidents…

Sun shading

• control blinds, roller-shutters, curtains and pergolas
using any smartphone

• automate motors by using fun and easy programming
tool online

9 | P a g e

• add your sun shading commands into home scenarios
together with lights, climate, alarms...

• automate your shades to react to outside weather
conditions

• easy installation using pre-configured wireless modules

Irrigation

• control unlimited number of irrigation zones

• use advanced programming options online to setup

perfect irrigation process

• automate irrigation system based on Internet weather
forecast

• integrate your irrigation scheme together with your
complete home automation scenarios

Access

• remotely lock/unlock your door with any smartphone

• remotely open/close your garage door or gate over any

smartphone

• get video notification when door is open

• use RFID tags to open doors and get detailed statistics

about exits/entries

10 | P a g e

• automate doors/locks using scenarios and event based
programming tool

• trigger automation events when door lock user codes are
entered

• automatically unlock doors in the event of an emergency

Multimedia

• remotely control your audio/video equipment with any
smartphone

• automatically turn on favorite shows when they air and
get alerts

• automatically turn off A/V equipment at pre-set time or
when room is unoccupied

• automatically turn on equipment to discourage intruders

Video monitoring

• access live and recorded video via the web and from
any smartphone

• support for most of the available IP cameras – ONVIF
support

11 | P a g e

• get email and SMS notifications with pictures and live
video attached

• remotely adjust pan-tilt cameras

• create advanced event based recording and video

notification rules

Energy Metering

• real-time monitoring energy consumption and notification
right on smartphone

• compare energy usage and cost with others in the area

• automatically turn on/off your appliances in accordance

with electricity prices

• see detailed analysis of your energy consumption

• save energy by automating lights, thermostats, sun

shades...

Take care of your safety

Display extreme caution when using ladders or steps, please
follow manufacturer’s instructions. Be careful when using
hand and power tools and follow the manufacturer’s
guidelines when using them. Take care that the correct tools
are used. Wear goggles or protective clothing where required.

12 | P a g e

Technical support

Having trouble installing your new product? Zipato’s website
contains the latest user documentation and software updates
for Zipato products and services.

www.zipato.com

Call support: + 385 1 444 444 00
(Mon-Fri) 9.00am-06.00pm
