ZIP HydroTap G4

User Guide

Affix model number label

here

802258UK

802258UK G4 Boiling (& ambient) residential, user guide - August 2015 - V2.01 Page 1 of 24

3. Table of contents

• Boiling and boiling ambient tap models Page 2

• T

ap safety ................................................. Page 3

• Tap operation ........................................... Pages 4 to 7

• Safety sensor calibration ........................ Page 8

• Tap lights .................................................. Page 8 to 9

• LCD screen & menu ................................. Pages 10 to 22

• Filter maintenance ................................... Pages 22 to 23

• Home menu icons .................................... Page 24

• Contact details ......................................... Page 24

• Date of installation.........

Boiling and boiling ambient tap models

HydroTap®G4 colour identification Classic and Elite

Red BOILING

Blue AMBIENT

Boiling ambient models Boiling only models

Red BOILING

Red BOILING

Page 2 of 24 802258UK G4 Boiling (& ambient) residential, user guide - August 2015 - V2.01

3. Tap safety

The safety lock feature is provided to
prevent boiling water flowing if the red
BOILING control is inadvertently activated.
This function can be activated and
deactivated from either the tap or from
the touch screen display (located on the
Command-CentreTM).

To activate the safety lock
(from the tap) Classic and Elite

boiling ambient models only.
(Ensure ‘Allow safety settings change’ is
selected, see page 21).
First place a finger over the safety lock,
then depress the blue AMBIENT lever
(Classic) or touch the AMBIENT button
(Elite), keep both fingers in position for a period of approximately ten seconds.
The safety lock indicator light will illuminate (Classic) flash momentarily (Elite).

Safety Lock

Classic

To deactivate the safety lock
(from the tap) Classic and Elite

boiling ambient models only.
First place a finger over the safety lock,
then depress the blue AMBIENT lever,
(Classic) or touch the AMBIENT button
(Elite) while keeping both fingers in
position for a period of approximately ten
seconds. The safety lock indicator light
will extinguish (Classic) flash momentarily
(Elite).
.

Safety Lock

Elite

• To allow the safety setting to be changed using the touch screen,

Classic and Elite (see page 21).

• To enable or disable the tap safety lock, all models (see page 21).

• For hot isolation, Classic and Elite (see page 21).

Arc / Cube

The safety lock can only be enabled / disabled from the LCD touch screen ,
see page 21.

802258UK G4 Boiling (& ambient) residential, user guide - August 2015 - V2.01 Page 3 of 24

3. Tap operation

To dispense boiling water (with the safety lock off)

Classic

Depressing the red BOILING lever allows the
dispensing of boiling water.
Pulling forward the red BOILING lever allows the
tap to operate in a “no-touch” mode.
Water will flow from between 5 and 15 seconds
(this is user adjustable, see page 22).
To reset, return the lever to the “off” position and
repeat the step. (The lever has to be manually
returned to the “off” position).

Classic

Elite

Touching the red BOILING button allows the
dispensing of boiling water.

Arc / Cube

Touch the SELECT button until the indicator and
select lights illuminate red. Rotating the control
when the indicator lights are illuminated red allows
the dispensing of boiling water.

To dispense boiling water (with the
safety lock on)

Elite

Indicator light

Classic

Depress the red BOILING lever, while
simultaneously covering the safety lock button with
a second finger. These two actions need to occur
within 2 seconds for the successful dispensing of
boiling water.

Elite

Place a finger on the safety lock, then touch the
boiling button, while keeping both fingers in position.

Safety Lock

Select
button

Arc / Cube

Arc / Cube

Touch the select button until the indicator, select and safety buttons illuminate
red, then touch the safety button twice until the three red lights flash (the lights
will flash for approx. 2 seconds if the tap control is not rotated, then the select,
safety and indicator lights will return to continually illuminated red (and after a
short period the select and indicator lights will return to continually illuminated
blue as a safety precaution).
Boiling water may be dispensed by rotating the control while the three red
illuminated lights are flashing.
While dispensing boiling water, all three red illuminated lights will continue to
flash.

Page 4 of 24 802258UK G4 Boiling (& ambient) residential, user guide - August 2015 - V2.01

3. Tap operation

To dispense ambient water

Classic

Depressing the blue AMBIENT lever allows the dispensing of AMBIENT water.
Pulling forward the blue AMBIENT lever allows the tap to operate in a “no­touch” mode. Water will flow from between 5 and 15 seconds (this is user
adjustable, see page 22).
To reset, return the lever to the “off” position and repeat the step. The lever
has to be manually returned to the “off” position.

Elite

Touching the blue AMBIENT button allows the dispensing of AMBIENT

water.

Arc / Cube

Rotating the control when the indicator light is illuminated blue allows the
dispensing of AMBIENT water.
If illuminated red, touch the SELECT button until the indicator light illuminates
blue.

Elite

The Elite tap uses
touch sensitive
controls to dispense
boiling and ambient
water.
When operating the
tap ensure the touch
surface is dry as
moisture may
interfere with the
sensor touch
control.

Boiling button

Ambient button

Safety Lock

The safety lock can
be controlled from
either the tap or from
the touch screen
display in a similar
manner to the
Classic tap (See
page 21).

Elite

802258UK G4 Boiling (& ambient) residential, user guide - August 2015 - V2.01 Page 5 of 24

3. Tap operation

Arc / Cube

On powerup, wait
30secs. for the
unit to calibrate
before selecting
either the red
illuminated
BOILING with
safety, or
blue illuminated
AMBIENT water
mode, by touching
the select button.

The Arc / Cube
control may
be rotated in a
forward or reverse
direction to
dispense boiling
or ambient water.
The rotary control
is spring loaded
in the forward
direction and
when released,
will return to the
OFF position.
When rotated in the
reverse direction the
tap operates in a POT FILL mode. Water will flow from
between 5 and 15 seconds (This is user adjustable, see page 22). To reset,
return the control to the OFF position and repeat the step. The control has to
be manually returned to the OFF position.

Rotary control

Select button

Safety button

Cube

To dispense boiling water, with safety lock on and with safety lock off, see
pages 3-4.

To dispense ambient water see page 5.

When unattended, the control light will automatically default to the AMBIENT
(blue illuminated) mode after a short period.

Page 6 of 24 802258UK G4 Boiling (& ambient) residential, user guide - August 2015 - V2.01

3. Tap operation

Classic mixer tap

Lifting the lever up will
increase the flow rate
and lowering the lever will
decrease the flow rate.
Lower the lever all the way
down to close the tap.

When the lever is moved in
the direction of the blue dot,
the temperature is
decreased and when moved
in the direction of the red dot,
the temperature is increased.
The final temperature
will be dependant on the
temperature of the incoming
cold water.

Decrease flow

Increase flow

Classic mixer

Cold

Hot

Cube mixer

Arc mixer

Arc / Cube mixer taps

Moving the lever away from the tap will increase the flow rate and moving
the lever towards the tap will decrease the flow rate. Move the lever to the
vertical position to close the tap.

When the lever is moved in the direction of the blue dot, the temperature is
decreased and when moved in the direction of the red dot, the temperature is
increased. The final temperature will be dependant on the temperature of the
incoming cold water.

802258UK G4 Boiling (& ambient) residential, user guide - August 2015 - V2.01 Page 7 of 24

Safety sensor calibration

Light intensity varies from site to site, therefore it is recommended that a
recalibration be performed at the time of the installation.
All direct sunlight must be shaded from the HydroTap
calibration. This can be achieved by closing any nearby curtains, blinds, etc.

®

G4, during the

Procedure

• Shield the HydroTap

direct sunlight.

®

G4 from any

• With the Command-Centre

normal operating mode turn the
power off.

TM

in

Pull both levers forward

Safety
sensor

• Pull both tap levers to the forward

position.

• Turn the power on.

• The Command-Centre

the safety switch.

TM

will calibrate

• Return the levers to the neutral

position.

Tap lights

Red BOILING water lights

Continually illuminated

This indicates that the boiling water is ready.

all models

Red lights

Flashing slowly

This indicates that the boiling water is below
the set dispense temperature.
Wait for the light to stop flashing before
dispensing water. The light will typically flash
after switching on, or coming out of sleep
mode.

Blue AMBIENT water lights (not

available on Elite).

Continually illuminated

This indicates that the temperature of the
ambient water is within the set temperature
range.

Blue lights

Flashing slowly

This indicates that the ambient water is not
within the set temperature range. When the
ambient water is at the set temperature, the
light will stop flashing. This could take several
minutes.
During heavy usage, the temperature can rise
out of this range.
