HYDROTAP® CUBE FOR HOME
BRUSHED NICKEL
01034440
The stylish HydroTap Cube BC will elevate your drinking water, with on demand boiling and chilled water,
advanced smart technology, beautiful design and high ltration for healthier living. Unbottle the future. Choose
sustainable hydration instead with HydroTap by Zip Water - the world’s most advanced drinking water system.
HYDROTAP® CUBE FOR HOME
3
°
TOP VIEW
1
2
0
°
1
2
0
°
hole for bowl
3-off 10 ( ") holes @ 155mm (6 ") PCD equispaced
hole for Arc or
Cube tap
Cutting Detail: Arc/Cube & Stand-Alone Font
183
8
(199mm)
13
16
7 "
3 "
7
8
6 "
(174mm)
(35mm)
3
8
1 "
(176mm)
(140mm)
1
2
5 "
6 "
(162mm)
3
8
7
8
6
"
7
8
3
4
7
8
13 "
6 "
1
2
5 "
(140mm)
(174mm)
(176mm)
(223mm)
(225mm)
15
16
16 "
8 "
8 "
FRONT VIEW
RHS VIEW
FONT VIEW
8
1
4 "
7
8
3
8
6 "
(353mm)
(225mm)
(115mm)
(162mm)
"
13
16
1 "
9
16
1 "
5
16
7
8
1 "
(40mm)
(33mm)
(47mm)
(20mm)
TAP SPECS
Style
Hole Size
Available Finishes
Installation
Flow rate
Hydrotap Cube-includes child safety lock
1 3/8”
Chrome, Brushed Chrome, Matte Black, Rose Gold, Brushed Gold, Nickel & Brushed Nickel
Over Sink or On Drip Tray (Optional Font - see accessories)
Max 1.8gpm
ORDER CODES FOR PRODUCTS
01034434
01034435
01034436
01034437
01034438
01034439
01034440
BC100/75 - Cube (Chrome)
BC100/75 - Cube (Brushed Chrome)
BC100/75 - Cube (Matte Black)
BC100/75 - Cube (Rose Gold)
BC100/75 - Cube (Brushed Gold)
BC100/75 - Cube (Nickel)
BC100/75 - Cube (Brushed Nickel)
ORDER CODES FOR SCALE FILTER KITS
01037874
01037875
01037876
01037877
Zip Scale Filter Installation Kit G4 2250 Liter (595gal) - FL250G4
Zip Scale Filter Installation Kit G4 3750 Liter (990gal) - FL500G4
Zip Scale Filter Installation Kit G4 7000 Liter (1850gal) - FL1000G4
Zip Scale Filter Installation Kit G4 10000 Liter (2640gal) - FL1500G4
ORDER CODES FOR REPLACEMENT FILTERS
01034276
01034278
Filter,Zip,0.2 Micron, 1 Size - 93701
Filter,Zip,3 Micron, 1.5 Size - 93703
ORDER CODES FOR OPTIONAL FONTS
01034269
01034270
01034271
01034272
01034273
01034274
01034275
Drip Tray, Design Range Font (Chrome)
Drip Tray, Design Range Font (Brushed Chrome)
Drip Tray, Design Range Font (Matte Black)
Drip Tray, Design Range Font (Rose Gold)
Drip Tray, Design Range Font (Brushed Gold)
Drip Tray, Design Range Font (Nickel)
Drip Tray, Design Range Font (Brushed Nickel)
HYDROTAP® CUBE FOR HOME
A
A
1
8
SECTION A-A
3mm ( )
buffer pad
air space
(461mm)
18.1"
IEC Flex & Plug
230-240V, 50Hz
power outlet
Position the Tap to dispense into the sink
bowl with ample clearance for a cup or a carafe.
Alternatively, the Tap may be mounted away from
the sink using a Zip Font, available as an accessory.
Sample
Tap
Clearance
Envelope
Mains cold water
isolation valve
(not supplied)
1
8
8
"
DETAIL B: CABINET FLOOR CUT-OUT
VENTILATION DETAIL
See Detail B
(333mm)
13.1"
min
7.9"
min
(200mm)
1 "
hole
Sink shown only
3
8
(35mm)
11
16
" max
15
16
12
"
(326mm)
3
16
"
(5mm)
(43mm)
2.0"
min
(50mm)
2.0"
min
(50mm)
13.4"
min
(339mm)
COMMAND CENTER SPECS
Water Pressure
Water Connection
Integral Water Values
Water Supply Requirements
Total Dissolved Solids (TDS)
Integral Water Filter
Power Rating
Power Supply Requirements
Dimensions (WxDxH)
Minimum Air Gap
Dry Weight
Product Approvals
Warranty
Min 30psi – Max 75psi with a minimum ow rate of 1 gpm
½” BSP - isolation valve is required within 3’ of the installation
HydroTaps are tted with a Dual check valve and a 50psi Pressure Limiting Valve
Potable drinking water supply
TDS Min 50ppm – Max 120ppm
0.2 micron, 1 size - Replace every 1,500 gallons or 12 months
220-240V, 50 Hz, 2.05kW
220-240V, 50/60Hz 15 amp power supply with a NEMA 6-15 outlet
13.4” x 18.1” x 13.1”
Clearances are required - 2” Left side , 2” Right side , 8”above
53lbs
WQA - NSF/ANSI 372, 42 & 53, cUL, CEC
2 years (1 year Limited Warranty plus additional 1 year warranty is available on product registration)
SINGLE
PHA SE
240V
240V
POWER
Installation and connection of your HydroTap must be carried out by a qualied person, observing all local, state & federal regulations. You will require suitable 220 -240V 50/60Hz 15 amp power supply with a NEMA
6-15 electrical outlet within 3’ of the product. The HydroTap is an air-cooled system so discrete cabinetry cut-outs are required for ventilation. Installation on most counter tops is straightforward however some stone
counter tops may require a specialized cutting service. If using a drip tray (font) accessory suitable drainage to a trapped waste is required within 3’ of the installation. If you live in an area with hard water (more than
120ppm), we recommend installation of a scale ltration kit. Sufcient space and clearance to install the HydroTap as detailed in the product installation guidelines is required. Installation by Zip Professional Service
can be arranged with a phone call to 1-833-233-2358 or through www.us.zipwater.com
