BTR011
Bluetooth audio receiver
User’s manual
Content
Brief introduction………………… ………………………….…....….1
1. Bluetooth wireless communication technology………….……………1
2. About BTR011………………………………………………………..…1
Basic operation………………………………………………….....…..1
1. Overview…………………………………………………...…...………1
2. The steps of operation………………….…………………….…………2
3. Paired with Bluetooth device……………………………………...……2
1) How to enter paired mode…………………………………………...….2
2) Pairing with Bluetooth phone……………………………………….….2
3) Pairing with Bluetooth transmitter………………………………..…...3
4. Supply power for other device charging………………… ……………3
5. LED indicator…………………………………………………………...4
Care and maintenance……………………………..………..………4
……………………………………………………..…………..….5
FAQs
Specifications
………………………………………………………….5
Welcome to use this Bluetooth audio receiver BTR011. Please read this
user’s manual carefully before use.
Brief introduction
1. Bluetooth wireless communicat ion technology
Bluetooth is a standard of close range wirel ess communication technology
that was drawn up by Ericsson, IBM, Intel, Nokia and Toshiba in May, 1998.
With Bluetooth technology, we can achieve the highest transmission rate
among cell phones, computers, printers, PDAs and other devices. The max
transmission range of class II is 10 meters while the max transmission
ranges of class I can reach up to 100 meters.
2. About BTR011
BTR011 is a stereo Bluetooth receiver with power pin, it has following
features:
Enjoy stereo music wireless with device which support Bluetooth A2DP
profile;
It can supply DC5V-1A to other devi ce for charging.
Basic operation
1. Overview
1
1 USB charging jack
2 Power pin
3 Status indicator light
2. The steps of operation
The receiver will turned on automatically when plug it into stan dard AC
Paired with Bluetooth phone or Bluetooth transmitter
Connected receiver and external audio device through 3.5 to 3.5mm
It can transfer music from phone or transmitter to ex ternal audio device
3. Paired with Bluetooth device
1) How to enter pairing mode
Entering pairing
mode
Remarks:
The pairing mode will last 2 minutes, BTR011 will switch to standby mode
automatically, if no devices can be connected after 2 minutes
2) Pairing with Bluetooth phone
Prior to using the receiver for the first time, you have to pair it with a
Bluetooth phone. Please make sure your phon e has Bluetooth function and it
is available. The pairing procedures are subject to different models of cell
phones. Please refer to your cell phone user’s manual for further information.
The general pairing procedures are as follows:
Keep your receiver and phone within 1 meter when pairing;
Make the receiver enter pairing mode(please refer to “How to enter
Activate your cell phone’s Bluetooth function and set your cell phone to
According to the indication, enter password or PIN No: “0000”, and
4 3.5mm audio line-out jack
socket, and it will enter pairing mode
audio line
Function Operation LED indicator
After turned on, it will
enter pairing mode
automatically
Blue LED flash
continuously
pairing mode”)
search for Bluetooth devices within range, and select “BTR011” from the
list of devices shown;
press “YES” or “Confirm”;
2
If prompted by your cell phone to connect, select “Yes” (this will vary
among cell phone models). After successful connecting, blue LED will
flash twice every 4 seconds.
Remarks:
The receiver can remember 8 paired devices. When the number of
devices exceeds 8, the first one will be replaced.
If the phone and receiver over range, the receiver will disconnect and
enter standby mode. It will connect automatically if phone and receiver
back to available range in 5 minutes. You also can select BTR011 on the
phone after 5 minutes.
3) Pairing with Bluetooth transmitter
You can pair receiver with Bluetooth transmitter to enjoy wirelessly music.
Hereby take BTT001 (Bluetooth transmitter for iPod, not included) for
example. The pairing steps are as follows:
Keep the Bluetooth transmitter and the receiver within 1 meter when
pairing;
Make the receiver enter pairing mode (please refer to “How to enter
pairing mode);
Plug the Bluetooth transmitter into cell phone and activate it. The
transmitter will search device aut omatically and start pairing;
When the receiver requests PIN No., the Bluetooth transmitter will
respond “0000” automatically;
After successful pairing and connecting, blue LED of the receiver blinks
twice every 4 seconds.
Note:
The pairing password of the receiver is “0000”. So, the receiver can only
pair with a Bluetooth transmitter whose pairing password is “0000”.
If pairing still fails after several tries, please refer to the Bluetooth
transmitter’s user’s manual for further information.
4. Supply power for other device charging
The USB port of receiver can provide DC5V-1A for other device charging.
You also can charge your device by BTR011 through USB cable.
3
Remarks:
Please use standard USB cable which compatible with your device
The USB port can only provide DC5V-1A, please make sure the charging
voltage of your device is DC5V and the max charging current no higher
than 1A
5. LED indicator
Care and maintenance
Read the following recommendations carefully before using BTR011.
Following these you will be able to enjoy this product for many years.
Keep it dry and don’t put it in moist place to avoid the product’s internal
Keep the product away from direct sunlight or hot places. High
Don’t expose the product to cold areas. It may damage the internal circuit
Don’t try to disassemble the product as it may get damaged if you are not
Don’t let it fall down onto the floor or other hard surfaces. The internal
Don’t use intensive chemical products or detergent to clean the product.
Don’t scratch the surface with sharp things.
In case the product doesn’t function properly, send it to the store you bought
it. The staff will help you to solve the problem
Status of receiver LED indicator
Pairing mode Blue LED flash continuously
Standby mode(not connect device) Blue LED flash once every 2
Standby mode(has already connected
device)
seconds
Blue LED flash twice every
four seconds
circuit being affected.
temperatures will shorten the life of electronic devices, destroy the
battery or distort certain plastic parts.
board.
professional.
circuit might get damaged.
4
FAQs
1. Why the receiver can not paired with phone?
Please make sure the receiver is in pairing mode.
The pairing mode will last 2 minutes, it will enter standby mode
automatically if overtim e .
Disconnect the receiver and socket, and reconnect them, after the receiver
turned on, it will enter pairing mode automatically.
2. Why it can not connect with phone automatically after over range
and come back?
If it over range, you should come back in 5 minutes, and them the receiver
will connect with phone automatically. If over 5 minutes, you can connect it
by operate your phone.
Specifications
Bluetooth version Bluetooth V2.1+EDR
Bluetooth profiles A2DP
Operating distance Up to 10meters
Power supply demand AC100~240V
USB output DC 5V 1A MAX
Dimension 38.5*38.5*67.5mm
Weight About 43.8g
ambient temperature 40℃ MAX
Warning: Changes or modifications to this unit not expressly approved by
the
Party responsible for compliance could void the us er’s authority to operate
the equipment.
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmfu l interference to radio
communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
_ Reorient or relocate the receiving antenna.
_ Increase the separation between the equipment and receiver.
_ Connect the equipment into an outlet o n a circuit different from that to
which the receiver is connected.
_ Consult the dealer or an experienced radio/TV technician for help.
Notes:
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
The main plug is used as disconnect devi ce, th e socket -outl et shoul d be n ear
the product and it should be easily accessible.
