Hanshow 24.0 Inch
Shelf Edge Digital Signage
Specification
Hanshow Technology Co.,
Ltd.
HS-AT2401
OVERVIEW
Hanshow Smart Marketing – an integrated retail-oriented
new marketing and promotion solution, which includes
software, hardware, system and etc. The solution can be
applied to price tag management, ad distribution and
interaction management. We aim to better demonstrate the
features of products via colorful HD display screen and offer
diversified business service, so as to empower new retail.
Application scenario: supermarket, convenience store,
boutique, pharmacy store and etc.
Supermarket Boutique Pharmacy StoreMedium and
Small Convenience
Store
FEATURES
Fit the size of shelf standard size
One screen for multiple display or multi-screen for one
display.
Large-sized and wide-angle TFT-LCD display screen.
Support high speed wireless communication via Wi-Fi.
Equipped with Mini USB and TF card interface.
Display ad to realize perfect match between commodity
and advertisement.
Realize precision marketing, the most customer-oriented
marketing model.
Support the play of local content and the distribution of
online content.
FUNCTIONS
Ads
Contents
Display
Price
Labels
Display
Device
Bind
Flexible
Display
Mode
Easy
Configuration
Heartbeat
Function
Multi-Screen
Sync
Interactive
Function
Status
Monitoring
Logging
Function
2-Way
Communic
ation
FUNCTIONS
SPECIFICATIONS
Components Configuration HS-AT2401
System
CPU ARM Cortex-A7
RAM 1G
Memory 8G
Operation System Android 6.0
Display
LCD Screen 24inch Shelf edge digital signage
Resolution 1920*360
Visible Area 597.8mm (H)* 112.1mm (V)
Visible Angle 89/89/89/89
Display Mode Normally Black IPS
Network
Wi-Fi
802.11b/ g/ n
Interface
USB Host USB Host 2.0
Power Supply DC 12V Power input
Media Display
Video Format MP4, AVI, 3gp
Image Format
JPG, PNG, GIF
Others
Screen Type Bar Screen
Case Color Black
Operating
Temperature
0-40 degrees
Power 30W
Components
AC-DC Power
Adaptor
Power Adaptor (12V/3A)/Power rail
Installation
Requirement
◉ Shelf material: metal, wooden shelf needs customized
installation.
◉ Shelf application scenario and commodity display: black is the
standard color, and customization is needed for other colors.
◉ Distance between top and bottom sheets of the shelf: 35-40
mm is suggested to show the effect.
◉ The screen: 12V power supply mode is adopted and equipped
with a switch power supply to transfer electricity power to 12V.
◉ Conduction track is used for shelf to supply power to the
screen of each layer.
◉ Standard interface of the screen power supply for easy
installation and dismounting.
◉ Centralized power supply control of the screen can be realized
if needed.
Statement
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired operation.
Attention that changes or modification not expressly
approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
Note: This product has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This product generates, uses, and can
radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this product does cause harmful interference to
radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the
following measures:
Statement
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and
receiver.
—Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician
for help.
Please take attention that changes or modification not
expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
This equipment complies with FCC/IC RSS-102 radiation
exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.
Storage Path
Step1: Power on and connecting the mouse through the USB.
Click button of application, then enter the display interface as
shown below, and click Root Explorer.
Step2: Scroll down with the mouse to find the folder of ETC, and
click the folder;
Step3: Scroll down with the mouse to find the file of FCC
Statement, and click the file to view the warning words of FCC;
400-0365-305
Room 1803, Ruipu Building C, No 15 Hongjunying South Road,
Chaoyang District, Beijing
