ZVO-E30AG
ZVO-M90AG
30-2
30-3
30-1
30-5
30-4
Verona
ZVO-E30AG, ZVO-M90AG
Ref # Part # Description Qty.
1 54110079 Bracket, Duct Cover 1
2 50050122 Duct Cover, Upper 1
3 50050123 Duct Cover, Lower 1
4 54050080 Collar, 8" Round w/Damper 1
5 11030070 Wires, Electrical 1
6 56200080 Box, Electrical 1
7 54140183 Plate, Electrical 1
8 56200079 Box, LED Control Board 1
9 11010049 Control Board, LED 1
10 56210066 Cover, LED Control Board Box 1
11 11010043 Control Board (SN <24) 1
11 11010051 Control Board (SN 24+) 1
12 54200019 Box, Component 1
14 54140109 Bracket, Wiring 1
15 12120064 Motor 1
16 54140110 Bracket, LED, Side 2
17 54140111 Bracket, LED, Corner 2
18 54140112 Bracket, LED, Front 1
19 50300089 Glass Canopy (ZVO-E3AG) 1
19 50300088 Glass Canopy (ZVO-M90AG) 1
20 50500104 Assembly, LED Lighting 1
21 50130105 Panel, Bottom 1
22 54140096 Bracket, Switch 1
23 11000066 Switch Assembly 1
24 50200045 Filter, Aluminum Mesh 2
25 50500105 Light Panel Assembly (SN <24) 1
25 50110150 Light Panel Assembly (SN 24+) 1
25-1 11040020 Button Switch, Lighted Glass 1
25-2 54190031 Plate, Button 1
25-3 54140114 Bracket, Button 1
25-4 52170050 Cover, Button 1
26 Z0B0032 Bulb, Bloom LED 3W (SN <24) 3
26 Z0B0034 Bulb, Bloom LED 6W (SN 24+) 2
30 05000078 Hardware Packet 1
30-1 01090001 Screw, M6 x 1" 2
30-2 01090002 Screw, M6 x 1 1/2" 3
30-3 15000002 Wire Nut 3
30-4 02170001 Washer 1
30-5 01060004 Screw, M3 x 8mm 2
FEB15.0201
