Zephyr ZVE-E36S, ZVE-E30S User Manual

Venezia
ZVE-E30S ZVE-E36S ZVE-E42S
www.zephyronline.com
Model number:
Serial number:
Use, Care, and Installation Guide
MAY07.0101 © Zephyr Corporation.
SAFETY NOTICE ..............................................
LIST OF MATERIALS .......................................
INSTALLATION
Ducting Calculation Sheet ...............................
Mounting Height and Clearance .....................
Ducting ..................................................................
Specifications .......................................................
Mounting the Hood and Duct Cover................
Ductless Recirculating ........................................
FEATURES & CONTROLS
Touch Controls & Features .................................
Charcoal Filter Change Indicator ......................
Metal Filter Clean Indicator ................................
MAINTENANCE
Cleaning .................................................................
Lights .......................................................................
2 3
4 5 6 7 8 9
10 11 12
13 14
Table of Contents
TROUBLE SHOOTING ......................................
LIST OF ACCESSORIES/PARTS .......................
15
16
1
READ AND SAVE THESE INSTRUCTIONS
www.zephyronline.com
WARNING
TO RE DUCETH E R IS K O F F IR E O R E LE CTR IC SHOC K, DO N OT US E THIS FAN W ITH ANY S O LID-S TATE SP E ED C O NTRO L DEV IC E.
WARNING
TO RE DUCE TH E R IS K O F FIR E, E LE CTR IC SH O C K, O R INJU RY TO P ER SON S, O B S E RVE TH E FO LLOW ING:
a. Use this unit only in the manner intended by the manufacturer, If you have questions, contact the manufacturer. b. Before servicing or cleaning unit, switch power o at service panel and lock the service disconnecting means to prevent power from being
switched on accidentally. When the service disconnecting means cannot be locked, securely fasten a prominentwarning device, such as tag, to the service panel.
CAUTION
For General VentilatingUse Only. Do not Use to Exhaust Hazardous or Explosive Materials and Vapors.
Take care when using cleaning agents or detergents.Suitable for use in household cooking area.
WARNING
DUCE
TO RE
a. Never leave surface units unattendedat high settings. Boilovers cause smoking and greasy spillovers that may ignite. Heat oils slowly on low
or medium settings.
b. Always turn hood ON when cooking at high heat or when cooking ambeing food (i.e. Crepes Suzette, Cherries Jubilee, Peppercorn
Beef Flambe)
c. Clean ventilatingfans frequently. Grease should not be allowed to accumulate on fan or lter.
Important safety Notice
d. Use proper pan size. Always use cookware appropriate for the size of the surface element.
TH E R IS K O F A RA NG E TO P GR EAS E FIR E:
WARNING
TO RE DU C E TH E R IS K O F INJU RY TO PERSON S IN T H E EV E NT O F A RA NG E TO P G R EAS E FIR E, O B S E RVE TH E FO LLOW ING :
a. SM OTHE R F LAMES with a close-tting lid, cookie sheet, or metal tray, then turn o the burner. B E CARE F UL TO P REV ENT BUR N S.
If the ames do not go out immediately,E VACUATE AND C ALL TH E F IR E DE PARTME NT. b. NEV E R PIC K UP A FLAMI NG PAN - You may be burned. c. DO NOT US E WATE R, including wet dishcloths or towels - a violent steam explosion will result. d. Use an extinguisher ONLY if:
1. You know you have a class AB C extinguisher, and you already know how to operate it.
2. The re is small and contained in the area where it started.
3. The re departmentis being called.
4. You can ght the re with your back to an exit.
5. Based on “Kitchen Fire Sa fety Tips” published by NF PA.
WARNING
TO R EDUC E TH E R IS K OF FIR E, ELEC TR IC SHOCK OR INJUR Y TO PER SONS, OB SE RVE THE FOLLOW ING :
a. Installation Work and Electrical Wiring Must be Done by Qualied Person (s) In Accordance with all Applicable Codes and Standards,
IncludingFire-Rated Construction. b. Sucient air is needed for proper combustionand exhausting of gases throughthe ue (chimney) of fuel burningequipmentto prevent back
drafting. Follow the heating equipmentmanufacturer’s guideline and safety standards such as those published by the National Fire Protection
Association (N F PA), and the American S ociety for Heating, Refrigeration, and Air ConditioningEngineers (AS HR AE) and the local code authorities. c. When cutting or drillinginto wall or ceiling, do not damage electrical wiring and other hiddenutilities. d. Ducted fans must always vent to the outdoors.
WARNING
TO REDUCETH E R IS K O F F IR E, USE O NLY ME TAL DU C TW OR K.
CAUTION
To reduce risk of re and to properly exhaust air, be sure to duct air outside - Do not vent exhaust air into spaces within walls or ceilings or into attics, crawl spaces or garages.
WARNING
TO REDUCE THE RISK OF SHOCK, THIS FAN MUST BE INSTALLED WITH AN ISOLATING WALL CONTROL/SWITCH.
2
1 - Hood 2 - Metallic lters (3 - ZVE-E36, E42) 2 - Halogen light bulbs (4 - ZVE-E36, E42) 1 - Duct cover assembly (2 pieces) 1 - Hardware bag
1 - Duct cover mounting bracket 1 - Packet of mounting screws w/anchors
1 - Buttery damper
NO DUCTING IS INCLUDED
* Note: Zephyr recommends using 50LB EZ anchors if mounting hood onto drywall. These are not provided.
but are readily available of most hardware stores.
List of Materials
3
Duct pieces
3 1/4” x 10” Rect., straight
7” Round, straight
7” Round, straight
3 1/4” x 10”
0
Rect. 90 elbow
3 1/4” x 10”
0
Rect. 45 elbow
3 1/4” x 10”
0
Rect. 90 at elbow
3 1/4” x 10” Rect. wall cap with damper
Equivalent number length x used =
1 Ft. x ( ) =
1 Ft. x ( ) =
1 Ft. x ( ) =
15 Ft. x ( ) =
9 Ft. x ( ) =
24 Ft. x ( ) =
30 Ft. x ( ) =
To t a l
Ft.
Ft.
Ft.
Ft.
Ft.
Ft.
Ft.
Duct pieces
6” Round wall cap with damper
6” Round, roof cap
6” round to 31/4”x10” rect. transition
6” round to 31/4”x10” rect. transition
0
elbow
90
7” Round, 900elbow
7” Round, 450elbow
7” Round wall cap with damper
Equivalent number length x used =
30 Ft. x ( ) =
30 Ft. x ( ) =
1 Ft. x ( ) =
16 Ft. x ( ) =
15 Ft. x ( ) =
9 Ft. x ( ) =
30 Ft. x ( ) =
To t a l
Ft.
Ft.
Ft.
Ft.
Ft.
Ft.
Ft.
3 1/4” x 10” Rect. to 6” round transition
3 1/4” x 10” Rect. to 6” round transition
0
elbow
90
5 Ft. x ( ) =
15 Ft. x ( ) =
Installation - Ductwork Calculation Sheet
6” Round,
0
elbow
90
6” Round,
0
elbow
45
Maximum Duct Length:
the total duct length ofa31/4”x10”rectangular, 6” or 7” diameter round duct
should not exceed 100 equivalent feet.
15 Ft. x ( ) =
9 Ft. x ( ) =
Subtotal column 1 =
For satisfactory air movement,
Ft.
Ft.
Ft.
Ft.
Ft.
7” Round, roof cap
7” round to 31/4”x10” rect. transition
7” round to 31/4”x10” rect. transition 900elbow
30 Ft. x ( ) =
8 Ft. x ( ) =
15 Ft. x ( ) =
Subtotal column 2 =
Subtotal column 1 =
Total ductwork =
Ft.
Ft.
Ft.
Ft.
Ft.
Ft.
4
min. ducted - 32 1/2” min recirc. - 36” max. 51”
9-27/32"
Minimum mount height between range top to hood bot­tom should be no less than 28".
Maximum mount height should be no higher than 36".
It is important to install the hood at the proper mounting height. Hoods mounted too low could result in heat
damage and re hazard; while hoods mounted too high will be hard to reach and will loose its performance and eciency.
min. 28" - max. 36"
*min. 97"
** max. 123"
36"
DUCTING
A minimum of 6" round or 3-1/4 x 10" rectangular duct must be used to maintain maximum air ow eciency.
Always use rigid type metal ducts only. Flexible ducts could restrict air ow by up to 50%.
Use calculation worksheet to compute total duct work.
If available, also refer range manufacturer'sheight clearance requirements and recommended hood mounting height above range. Always check your local codes for any differences.
*Minimum ceiling height of 97”. Hood
mounted at 28” above cooking surface.
** Maximum ceiling height of 123". Hood
mounted at 36" above cooking surface.
Minimum Duct Size:
Round- 6" minimum Rectangular- 3-1/4 x 10” minimum (requires a 6” to 3-1/4 x 10” adapter not supplied)
DAMAGE-SHIPMENT / INSTALLATION:
• Please fully inspect unit for damage before installation.
-noitallatsnI ecnaraelC&thgieHgnitnuoM
ALWAYS, when possible, reduce the number or transitions and turns. If long duct run is required, increase duct size from 6" to 7 or 8". If a reducer is used, install a long reducer instead of a pancake reducer. Reduce duct size as far away from opening as possible.
If turns or transitions are required: Install as far away from opening and as far apart, between 2, as possible.
If the unit is damaged in shipment , return the unit to the store in which it was bought for repair or replacement.
If the unit is damaged by the customer , repair or replacement is the responsibility of the customer.
If the unit is damaged by the installer (if other than the customer), repair of replace ment must be made by arrangement between customer and installer.
5
e
WARNING FIRE HAZARD
NEVER exhaust air or terminate duct work into spaces between walls, crawl spaces, ceiling,attics or garages. All exhaust must be ducted to the outside, unless using the recirculating option.
Use single wall rigid Metal ductwork only.
Fasten all connections with sheet metal screws and tape all joints w/ certied Silver Tape or Duct Tape.
Some Ducting Options:
Installation - Ducting
side wall cap w/ gravity damper
Roof Pitch w/ Flashing & Cap
side wall cap w/ gravity damp
Sot or crawl space
air recirculating
6
6.5" 6"
10.37"
13.87"
2.78"
1.87"
0.5"
3/4" Elec. K.O.
Cable Lock
1-19/32”
30”, 36”, 42”
10-5/8”
14-3/16”
19-11/16”
21-21/32”
9-27/32”
24”
min. ducted - 32 1/2” min. recirc. - 36” max. - 51”
-noitallatsnI snoitacificepS
ELECTRICAL - WARNING
All Electrical work must by performed by qualied electrician or person with similar technical know how and background.
For personal safety, remove house fuse or open circuit breaker before beginning installation. Do not use extension cord or adapter plug with this appliance.
Follow National electrical codes or prevailing local codes and ordinances.
Electrical Supply:
This appliance requires a 120V 60Hz electrical supply., and connected to an individual, properly grounded branch circuit, protected by a 15 or 20 ampere circuit breaker or time delay fuse. Wiring must be 2 wire w/ ground. Please refer to Electrical Diagram labeled on product.
Cable Lock:
A cable locking connector (not supplied) might also required by local codes. Check with local requirements and codes, purchase and install appropriate connector if necessary.
7
1. Measure from range top to hood bottom (28” min) Level and mark line A.
2. Plum and mark center line.
3. Mark mounting height line B. (10-3/8” from line A)
4. Mark mounting spread from C/L (9-7/16”)
5. Fasten E-Z anchors to wall (see below) as marked.
6. Fasten screws provided onto EZ anchors, do not fasten screws all the way.
7. Hang hood onto screws and hand tighten (g A).
MOUNTING THE DUCT COVER
1. Center and attach duct cover mount bracket on wall below ceiling or sot.
2. Mount telescopic duct covers onto hood and extend inner duct cover and fasten to bracket.
C/L
Du c t Co v er Br a c k e t
9-7/ 16"
B
10-3/ 8"
A
28" min
C/L
-noitallatsnI revoCtcuD&dooHehtgnitnuoM
fig. A
EZ A NCHORS
Tap EZ anchor tip into marked drywall locations, turn with screw­driver until seated ush.
Note:whenever possible, the hood should be secured to wall studs.
Use EZ anchors only on hollow drywall applications (minimum drywall thickness 1/2”). If a stud or wood surface is present, fasten screws directly into stud or plywood. For all other wall types (concrete, brick, tiles, etc), use appropriate anchors for mounting.
8
Ductless recirculating is intended for applications where an exhaust duct work is not possible to be installed. When converted, the hood functions as a "purifying" hood rather than an exhaust hood. Fumes and exhaust from cooking is drawn and ltered by a set of optional charcoal lters. The air is then puried and re-circulated back within the home.
We recommend to ALWAYS exhaust air outside of the home by employing existing or installing new duct work, if possible. The hood is most eective and ecient as an Exhaust unit. Only when the exhaust option is not possible should you recourse to converting the hood into a "purifying"unit.
When converted to be a "purifying" unit, a set of charcoal lters are required on top of its standard Metal Filter set. Order according to its Part number below. The standard Metal Filters are intended to capture residue from cooking and the optional charcoal lters help to purify fumes exhausted from cooking for re-circulation.
RECIRCULATING KIT (Required)
1. Kit includes charcoal lters and air diverter plate:
Hood Model: Part No. Filters in pkg.
ZVE-E30S ZRC-0050 2 ZVE-E36S ZRC-0051 3 ZVE-E42S ZRC-0051 3
2. Remove metal lters on hood. Clip chacoal lters onto difuser panels.
3. Re-install metal lters.
4. Turn on lter change indicator on control panel (refer details pg. 7)
5. Charcoal lters must be replaced after every 120 hours of use (or approximately every 2 to 3 months based on the average of 1-2 hrs. of daily cooking time). The microprocessor in the controls when set, will elapsed and count usage time and indicate when carbon lter replacement is required every 120 hrs.
air diverter plate
6" straight pipe
wall pipe strap
Installation - Ductless Recirculating
Charcoal Filter Dimensions:
9 in x 6.4 in 228 mm x 162 mm
Ducting
1. Install a 6" straight pipe attached to the air diverter plate to divert air through louvers on duct cover.
9
1. Blower On/O
By pressing , the blower is switched On and O. When switched on, the blower starts up on speed level 3.
2. Speed Selection
The 6 speed levels are selected by presing to decrease and to increase speed level. The display indicates
level selected.
3. Delay O
This is used for programmed shut down of blower and lights 15 minutes after the function is activated. Press once, a dot ashes in the lower right hand side of display indicating the function is on. The hood will completely shut down in 15 minutes.
4. Lights On/O/Dim
Switch lights On and O by pressing key once. To dim lights, press and hold for 2 seconds.
5. Advance Display Functions
Filters Clean Reminder (Metal):
After every 30 hours of use, the display will start ashing an reminding you to clean the metal lters from residue and possible clogs.
The standard Metal Filters are required to be cleaned frequently and as recommended in order to maintain blower eciency. If improperly maintained, residue from cooking will sift though lters and cause damage to hood blowers and other sensitive components; and possibly clog duct work and create a re hazard.
Filters Change Reminder (Charcoal, if tted):
Features & Controls - Touch Controls & Features
When your hood is installed as “Recirculating” (Ductless) unit, it is tted with a set of Chacoal Filters to purify any exhaust and fumes from cooking, and re-circulates the air within the home. These Charcoal Filters are required to be replaced after every 120 hours of use. The microprocessor in the controls when set, will elapsed and count usage time and indicate when charcoal lter replacement is needed every 120 hrs.
Filter Change Reminder function in the microprocessor needs to be switched on. The
10
Filter Change Reminder (Charcoal, if tted):
>
When your hood is installed as a 'Recirculating' (Ductless) unit, it is tted with a set of Charcoal Filters to purify exhaust and fumes from cooking, then re-circulate the air within the home.These Charcoal Filters are required to be replaced after every 120 hours of use. The Filter Change Reminder function in the microprocessor needs to be switched on. The microprocessor in the controls when set, will elapse and count usage time and indicate by a ashing when charcoal lter replacement is needed.
Setting the Filter Change Reminder:
When O, hold for approx. 5 seconds. The display will change from (exhaust mode) to , (purifying mode/ carbon lters used) this indicates that the elapse timer function is switched on and Charcoal Filters are used.
Set Mode
hold 5 secs.
display from <--> to <C
Filter Replace Indicator:
When the display starts ashing, the Charcoal Filters require replacement.
Re-setting Function:
Once lters are replaced, with hood o, press and hold , the display will appear; hold for approximately 5 seconds until on display disappears . The Filter Change Reminder is now re-set and a new 120 hours elapse cycle is initiated.
Change Filters
To Reset
hold 5 secs.
display <C> ashes
display from <C> to < >
Features & Controls - Charcoal Filters Change Indicator
11
Filter Clean Reminder (Standard Metal Filters tted):
Whether your hood is installed as an Exhaust or Purifying unit, a set of metal lters are tted by the factory. These Metal Filters are intended to lter out residue from cooking. They need not be replaced on a regular basis but are required to be kept clean. The Filter Change Reminder function in the microprocessor will automatically indicate by a ashing when the metal lters need to be cleaned after every 30 hrs. of use. Filters can be cleaned by hand with non-abrasive soap or in a dishwasher. Heavily soiled lters should also be soaked in grease cutting detergent such as Formula '409' or its equivalent, prior to cleaning.
Filter Clean Reminder:
When ashes on display, the metal lters installed are required to be cleaned. This will occur after every 30 hours of use.
Re-setting Function:
Reset the Filter Clean Reminder timer when lters are cleaned and re-installed (with hood o). Press and hold for approx. 5 seconds, the display will appear; hold for approximately 5 seconds until on dis­play disappears . The Filter Clean Reminder function is now re-set and a new 30 hours elapse cycle is initiated.
Clean Filters
To Reset
hold 5 secs.
display <A> ashes
display from <C> to < >
Features & Controls - Metal Filters Clean Indicator
12
Surface Maintenance:
Clean periodically with hot soapy water and clean cotton cloth. Do not use corrosive or abrasive detergent , or steel wool/scouring pads which will scratch and damage surface.
For heavier soil use liquid degreaser.
After cleaning, you may use non-abrasive stainless steel polish/ cleaners, to polish and bu out the stainless luster and grain. Always scrub lightly, with clean cotton cloth, and with the grain.
Do not use any product containing chlorine bleach. Do not use “orange” cleaners.
Metal Filters
The Metal Filters tted by the factory are intended to lter out residue and grease from cooking. They need not be replaced on a regular basis but are required to be kept clean.
Filters should be cleaned after every 30 hours of use. Use the Filter Clean Reminder function on the controls to determine when lters require cleaning.
Remove and clean by hand or in dishwasher. Spray degreasing detergent and leave to soak if heavily soiled.
Maintenance - Cleaning
Dry lters and re-install before using hood.
Replacing Metal Filters
Should lters wear out due to age and prolonged use, replace with following part number:
Hood Model: Part No. Filters in pkg.
ZVE-E30S Z0F-MO42 2 ZVE-E36S Z0F-MO43 3 ZVE-E42S Z0F-MO43 3
Also replace any damaged lter that has punctured or broken mesh, bent or broken frame.
Metal Filter Dimensions:
16.12 in x 9.12 in 409 mm x 232 mm
13
Replacing Light Bulbs
CAUTION: Light bulb becomes extremely hot when turned on. DO NOT touch bulb until switched o and cooled.
Touching hot bulbs could cause serious burns.
Make sure all power is turned o and bulbs are not hot.
Remove by turning bulb counter clockwise.
If bulbs are dicult to turn due to prolonged use, rmly attach a glass suction cup approx. the diameter of the bulb or use a rubber/
Maintenance - Lights
latex glove and turn counter clockwise.
Replacement bulbs are available at specialty lighting stores. Purchase type JDR E27 50W halogen bulbs.
Or to order bulbs, please call our service center: 888-880-8368 or online parts store:
www.zephyronline.com
14
After installation, the unit doesn’t work?
1. The power source is not turned ON.
2. The power line and the cable locking connector is not connecting properly.
odottahWesuaCeussI
1. Make sure the circuit breaker and the unit’s power is ON.
2. Check the power connection with the unit is connected properly.
Light works, but motor is not turning.
The unit is vibrating.
The motor is working, but the lights are not.
The hood is not venting out properly.
3. The switch board and control board wirings are disconnected.
4. The switch board or control board is defective.
1. The motor is defective, possible seized.
2. The thermally protected system detects if the motor is too hot to operate and shuts the motor down.
3. Damaged condenser.
1. The motor is not secure in place.
2. Damaged blower wheel.
3. The hood is not secured in place.
1. Defective halogen bulb.
2. The light bulb is loose.
3. The light bulb is not making a full contact.
1. The hood might be hanging to high from the cook top.
2. The wind from the opened windows or opened doors in the surrounding area are aecting the ventilation of the hood.
3. Blocking in the duct opening or ductwork.
4. The direction of duct opening is against the wind.
3. Make sure the wirings between the switch board and control board are connected properly.
4. Change the switch board or control board.
1. Change the motor.
2. The motor will function properly after the thermally protected system cool down.
3. Change the condenser.
1. Tighten the motor in place.
2. Change the blower wheel.
3. Check the installation of the hood.
1. Change the halogen bulb.
2. Tighten the light bulb.
3. Remove the bulb and disable power to the hood. Bend the two metal brackets inside the bulb opening and bend them outwards to lower the socket and make a complete contact.
1. Adjust the distance between the cook top and the bottom of the hood within 24” and 32” range.
2. Close all the windows and doors to eliminate the outside wind ow.
3. Remove all the blocking from the duct work or duct opening.
4. Adjust the duct opening direction.
Trouble Shooting
Metal lter is vibrating.
5. Using the wrong size of ducting.
1. Metal lter is loose.
5. Change the ducting to at least 8” or higher.
1. Change the metal lter.
15
Description Part#
Light Bulb (JDR-E27) Z0B-0011
Metallic Filters (2 pk) Z0F-M042
Metallic Filters (3 pk) Z0F-M043
Telescopic Back Splash 30” Z0S-0013
Telescopic Back Splash 36” Z0S-0016
Telescopic Back Splash 42” Z0S-0012
Wire Spice Rack 30” Z0R-0013
Wire Spice Rack 36” Z0R-0016
Wire Spice Rack 42” Z0R-0012
List of Parts and Accessories
To order parts, visit us online at : www.zephyronline.com and go to the parts store. Or call us at : 888-880-8368
16
www.zephyronline.com
TO OBTAIN SERVICE UNDER WARRANTY
or any Service Related Questions, please call:
1-888-880-8368
Staple your receipt here.
Proof of the original purchase
date is needed to obtain service
under the warranty.
Warranty
TO OBTAIN SERVICE UNDER WARRANTY: You must present proof of original purchase date.
Please keep a copy of your dated proof of purchase (sales slip) in order to obtain service under warranty.
One Year Service Repair Warranty:
For one year from date of original purchase, we will provide free of charge, service labor to repair any failed parts or components due to manufacturing defects.
One Year Parts Warranty:
For one year from date of original purchase, we will provide free of charge, nonconsumable replacement parts or components that failed due to manufacturing defects. Consumable parts not covered by this warranty include: Light Bulbs,
Metal and Charcoal Filters.
Who is Covered:
This warranty is extended to the original purchaser for products purchased for ordinary home use in the 48 mainland states, Hawaii and Washington D.C. In Canada and Alaska, this warranty is Limited. There might be costs associated with shipping the products to our designated service locations or you might need to pay service technician's travel costs, to have the appliance repaired in-home.
This Warranty will be Voided when:
Product damaged through negligence, misuse, abuse, accident. Improper installation and failure to follow installation instruc­tions. When product is used commercially or other than its intended purpose. Damaged because of improper connection with equipment of other manufacturers. Repaired or modified by anyone other than Zephyr's Authorized Agents.
What is Not Covered:
Consumable parts such as light bulbs, filters, and fuses. Services outside of service area and the labor cost incurred in connection with the removal, shipping and reinstallation cost, nor does it cover any other contingent expenses. The natural wear of finish, and wear due to improper maintenance, use of corrosive and abrasive cleaning products, pads, and oven cleaner products. Chips, dents or cracks due to abuse, misuse, freight damage, or improper installation. Service trips to your home to teach you how to use the product. Damage of product caused by accident, fire, floods or act of God.
This warranty is valid in the United States and Canada. It is non-transferable and applies only to the original purchaser and does not extend to subsequent owners of this product. Any applicable implied waranties, including the warranty of
merchantability, are limited in duration to a period of express warranty as provided herein beginning with the date of original purchase at retail
Have your product proof of purchase with date ready for warranty issues. Or write to:
and, no warranties, whether express or implied, shall apply to this product thereafter.
Zephyr Corporation Service and Warranty Department 395 Mendell Street San Francisco, CA 94124
JAN07.0101
Loading...
