eu ropa power breeze
C
savona wall
Savona’s semi-circular surfaces accentuate this range hood’s European design with delicate reflections
of light and shadows. Underneath the 11” tall body, Savona features a robust 685-CFM fan that operates
at an ultra quiet 1 sone on normal working speed. ICON Touch™ controls with 5 speeds and our exclusive
ACT™ technology make this hood a standout choice. Also available in powder-coated black and white.
INTERNAL BLOWER
STANDARD
Min.-Max. CFM 200 - 685
Min.-Max. Sones 1 - 6
TM
INTERNAL BLOWER with
AIRFLOW CONTROL TECHNOLOGY™
Min.-Max. CFM 200 - 390 200 - 290
Min.-Max. Sones 1 - 4 1 - 3
ACT™ is a feature b uilt into specifi c Zephyr hoods a llowing you to l imit the maximum
blowe r CFM to meet local c ode requireme nts.
savona wall | euro pa
9”
ZSA-E30CB / ZSA-E30CS / ZSA-E30CW
ZSA-M9 0CB / ZSA-M90 CS / ZSA-M90C W
PERF ORMANCE
INTERNAL , MIN.-MAX. BLOWER CFM 200 - 685
INTERNAL , MIN.-MAX. SONES 1 - 6
ZSA-E30CB / ZSA-M90CB
ZSA-E30CS / ZSA-M90CS
ZSA-E30CW / ZSA-M90CW
SIZE
COLOR
30”
36”
Black
Stainless Steel
White
eu ropa power breeze
1”
5 MINUTE AUTO DEL AY-OFF Yes
DUAL LEVEL LIGHTING Yes
RECIRCULATING OPTION Yes
DUCT COVER EXTENSION OPTION Yes, Up to 12’ Ceiling
DUCT SPECIFICATIONS
VERTICAL - INTERNAL 6” Round
HORIZONTAL - INTER NAL NA
OPTIONAL ACCESSORIES
RECIRCULATING KIT ZRC-00SV
DUCT COVER EXTENSION
ZSA-E30CB / ZSA-M90CB
ZSA-E30CS / ZSA-M90CS
ZSA-E30CW / ZSA-M90CW
UNIVERSAL MAKE-UP AIR K IT M UA008A
FEATURES
ACT™ Yes
CONT ROLS ICON Touch™
SPEED LEVELS 5*
LIGHTING Halogen, 50W x 2
FI LTER S Aluminum Mesh x 2
AC POWER 120V, 60Hz at Max. 3.5A
Z1C-01SAB
Z1C-01SA
Z1C-01SAW
29 15/16”, 35 7/16”
FRONT
7 1/2”
19 1/2”
SIDE
CL
6
”
1/2”
STANDARD
min. ducted - 28 ”
min. re circ. - 32”
max. - 4 5”
Z1C- 01SA, Z 1C-01SA B,
Z1C- 01SAW
min. du cted - 45 1/2 ”
min. re circ. - 5 0”
max. - 8 0”
11”
4”
1”
MOUNTING HEIGHT* 26” - 34”
TOP
WA RR AN TY 3 Years Parts, 1 Year Labor
Specifications subject to change, check zephyronline.com for up-to-date information.
CEILING HEIGHT 8’ 8.5’ 9’ 9.5’ 10’ 10.5’ 1 1’ 12’
STA NDAR D
DUCT COVER
EXT ENSION
DUCT COVER
*Wh en ACT™ is ena bled the maxi mum speed lev els will chan ge. ACT 390 CFM = 4 s peeds and ACT 29 0 CFM = 3 speed s.
**Mount ing height refe rs to distance b etween top of a 3 6” tall cooki ng surface an d bottom of hoo d.
MAR14.0301 Zephyr Venti lation | 2277 H arbor Bay Pa rkway Ala meda, CA 94 502 | 888.8 80.VEN T | zephyronl ine.com
Ducted Mou nting Height* 26”- 32” 26”- 34” 27”-3 4” 33”-3 4” NA NA NA NA
Recir c. Mounting Height * 26”-2 8” 26”-3 4” 27”-3 4” 33”-3 4” NA NA NA NA
Ducted Mou nting Height* NA NA 26”-26.5” 26”-32.5” 26”-3 4” 2 6”-34” 2 6”-34” 28 ”-34”
Recir c. Mounting Height * NA NA NA 2 6” - 28” 26”-3 4” 2 6”-34” 2 6”-34” 28 ”-34”
