Zephyr PRB24C01AS-OD Exploded View Diagram

PRB24C01AS-OD

Presrv™ Outdoor Single Zone Beverage Cooler

PRB24C01AS-OD

Presrv™

Ref # Part # Description Qty.

1 56300003 Dryer Filter 1

2 11030137 Power Cord 1

3 56220035 Anti Vibration Gasket 1

4 56130035 Drip Tray 1

5 12160006 Compressor 1

6 11030119 Compressor Ground Wire 1

7 50330010 Sealing Tube 1

8 56200108 Main PCB Box 1

9 11010119 Main Power Control Board 1

10 11010110 Display Control Board 1

12 56210093 Decorative Hole Cover 3

13 54180032 Upper Right Hinge 1

14 54240001 Evaporator 1

15 11050007 Sensor 1

16 56180015 Evaporator Foam 1

17 12130032 Fan 1

18 54170017 Air Duct Board 1

19 54210017 Fan Cover 1

20 12010012

21 52150014 LED Light Cover 5

22 56200110 Electrical Box 1

23 52050023 Display Panel 1

24 54190062 Door Axis Plate 1

25 54220014 Door Magnet 1

LED Light Board

5

26 50180005 Door Locking Hook 1

27 50230014 Door 1

27 56220047 Door Gasket 1

27 50280008 Door Handle 1

28 50150025 Glass Shelf 1
