Zephyr AK7554BS, AK7542BS, AK7548BS, AK7536BS, AK7500BS Diagram

AK7500BS
AK7536BS
AK7542BS
AK7548BS
AK7554BS

Tempest II

AK7500BS, AK7536BS, AK7542BS, AK7548BS, AK7554BS
Ref # Part # Description Qty.

1 54050078 Collar w/Damper, 8" Round 1
2 11030071 Wiring, Electrical 1
4 54200011 Box, Junction 1
5 54190041 Plate, Single Internal Blower 1
7 50120071 Panel, Rear (30") 1
7 50120072 Panel, Rear (36") 1
7 50120091 Panel, Rear (42") 1
7 50120073 Panel, Rear (48") 1
7 50120112 Panel, Rear (54") 1
8 54140167 Bracket, Filter, Rear (30") 1
8 54140140 Bracket, Filter, Rear (36") 1
8 54140195 Bracket, Filter, Rear (42") 1
8 54140168 Bracket, Filter, Rear (48") 1
8 54140215 Bracket, Filter, Rear (54") 1
9 54140029 Filter Spring Clip (36" & 42" x 3) (48" & 54" x 4) 2
10 12120070 Blower 1
13 50210015 Baffle Filter (30" x 2) (36" & 42" x 3) 2
13 50210021 Baffle Filter (48" & 54") 4
14 50120074 Panel, Side (30") 2
14 50120092 Panel, Side (42" & 54") 2
16 11000086 Switch Assembly 1
17 54140169 Bracket, Filter, Front (30") 1
17 54140142 Bracket, Filter, Front (36") 1
17 54140196 Bracket, Filter, Front (42") 1
17 54140143 Bracket, Filter, Front (48") 1
17 54140216 Bracket, Filter, Front (54") 1
18 50110135 Panel, Light (30") 1
18 50110136 Panel, Light (36") 1
18 50110161 Panel, Light (42") 1
18 50110137 Panel, Light (48") 1
18 50110201 Panel, Light (54") 1
