Zenoah SRTZ2601F User Manual

SRTZ2601F

848F4293A1 (705)

OWNER’S MANUAL

SHORT REACH TRIMMER

G

G
B

B

SRTZ2601F

GB-1

SRTZ2601F

EC DECLARATION OF COMFORMITY

We, ZENOAH CO., LTD.

1-9, Minamidai, Kawagoe, Saitama, Japan

declare in sole responsibility that the following products referred to

in this declaration conform with

DIRECTIVE 89/336/EEC, 98/37/EC, 2000/14/EC, 97/68/EC,

2002/88/EC, 2002/44/EC, prEN774[2001]

The products referred are :

DESIGNATION : SHORT REACH TRIMMERS

MODELS : SRTZ2601F

SERIAL NUMBERS : 70300001 and up

The company named above will keep on file the following technical

documentation for any inspection furpose.

· Operation instructions as confirmed

· Plans and Drawings

· Description of measures designed to ensure conformity

· Other technical documentation :

Saitama, Japan, 1st April 2007

Specification sheet

Inspection standard

:

Masahiko GOUDA

General Manager, Quality Assurance Department

EXPLANATION OF SYMBOLS AND SAFETY WARNINGS

WARNING!!!

RISK OF DAMAGING HEARING

Wear head, eye and ear protection.

MODEL SOUND LEVEL VIBRATION LEVEL

2002/44/EC

prEN774[2001]

hv,eq

A(8)

2

SRTZ2601F 25.4 cm

APPROVAL NUMBER OF CE EXHAUST EMISSION REGULATION

DIRECTIVE 97/68/EC AMENDED 2002/88/EC

prEN774[2001]

3

94 dB(A) 110 dB(A) 12.6 m/s26.3 m/s

L

pAav

2000/14/EC

ISO 11094

LwA(guaranteed) a

e13*97/68SH2G3*2002/88*0094*03

GB-2

SRTZ2601F

SAFETY FIRST

Instructions contained in warnings within this manual marked
with a symbol concern critical points which must be taken
into consideration to prevent possible serious bodily injury, and
for this reason you are requested to read all such instructions
carefully and follow them without fail.

WARNINGS IN THE MANUAL

WARNING

This mark indicates instructions, which must be followed in or­der to prevent accidents, which could lead to serious bodily in­jury or death.

IMPORTANT

This mark indicates instructions, which must be followed, or it
leads to mechanical failure, breakdown, or damage.

NOTE

This mark indicates hints or directions useful in the use of the
product.

Information

This machine is equipped with an Overload Cancellation Mechanism.
When the cutting blades have got into metal wires or twigs difficult to cut, the mechanism works as a shock absorber,
and protects the gears and the blades from severe reaction which could give damage to those parts.
When the blades are frequently caught by twigs, please check the following points:

1. Size of the twigs --> Never try to cut twigs thicker than 5 mm.

2. Condition of the blade edges --> Replace the worn-out blades.
Thank you for choosing our product.

Contents

1. Parts location .................................................. 3

2. Specifications ................................................. 4

3. Warning labels on the machine ...................... 4

4. Symbols on the machine ................................ 4

5. For safe operation ........................................... 5

6. Set up ............................................................. 8

7. Fuel ................................................................. 9

8. Operation ...................................................... 10

9. Maintenance ................................................. 12

10. Storage ......................................................... 14

11. Disposal ........................................................ 14

12. Troubleshooting guide .................................. 15

G
B

1. Parts location

(1) Loop handle
(2) Sholder strap hanger
(3) Ignition switch
(4) Throttle cable
(5) Throttle lever
(6) Drive shaft housing
(7) Spark arrester
(8) Starter knob

(9) Fuel tank
(10) Primer pump
(11) Choke lever
(12) Air cleaner cover
(13) Blade
(14) Gear case

12

11

10

13

7

1

3

2

4

9

8

14

5

6

GB-3

SRTZ2601F

2. Specification

Model SRTZ2601F

Overall size (LxWxH) mm 1734 x 338 x 254
Dry weight * kg 6.4
Engine Type Air-cooled 2-stroke gasoline

Model Zenoah GZ25N
Max output rpm 1.2Hp (0.9kW) at 7500min
Idle speed rpm 3000± 200min
Displacement cm
Fuel
Carburetor Walbro Diaphragm type

Spark plug NGK CMR7A
Fuel tank capacity L 0.65
Transmission Centrifugal clutch, Spiral bevel gear, Cam crank
Reduction ratio 4.25

Specifications are subject to change without notice.

* Shoulder strap and protective cover are not included.

3

Mixture (Gasoline 50 : Oil 1) (when using ZENOAH genuine oil)

25.4

-1

-1

3. Warning labels on
the machine

(1) Warning / Attention

(2) Read owner’s manual before op­erating this machine.

(3) Wear head, eye and ear protec­tion.

If warning label peels off or becomes soiled and
impossible to read, you should contact the
dealer from which you purchased the product
to order new labels and affix them in the required
location(s).

Never modify your machine.
We won’t warrant the machine, if you use the
remodeled trimmer or if you don’t observe
the proper usage written in the manual.

4. Symbols on
the machine

For safe operation and maintenance, symbols are carved
in relief on the machine. According to these indications,
please be careful not to make a mistake.
The port to refuel the “MIX GASOLINE”

Position: FUEL TANK CAP

The direction to close the choke
Position: ENGINE COVER

The direction to open the choke
Position: ENGINE COVER

GB-4

5. For safe operation

SRTZ2601F

1. Read this manual carefully until
you completely understand and
follow all safety and operating
instructions.

2. Keep this manual handy so that
you may refer to it later when­ever any questions arise. Also
note, if you have any questions
which cannot be answered
herein, contact the dealer from
whom you purchased the prod­uct.

3. Always be sure to include this
manual when selling, lending, or
otherwise transferring the own­ership of this product.

4. Never allow children or anyone
unable to fully understand the
directions given in the manual
to use the machine.

WORKING CONDITION

1. When using the product, you
should wear proper clothing and
protective equipment.

(1) Helmet
(2) Ear protectors
(3) Protection goggles or face

protector
(4) Thick work gloves
(5) Non-slip-sole work boots

2. And you should carry with you.
(1) Attached tools
(2) Properly reserved fuel
(3) Spare blade
(4) Things to notify your working

area (rope, warning signs)

(5) Whistle (for collaboration or

emergency)

(6) Hatchet or saw (for removal of

obstacles)

3. Do not wear loose clothing, jew­elry, short trousers, sandals, or go
barefoot. Do not wear anything
which might be caught by a mov­ing part of the unit. Secure hair
so it is above shoulder length.

WORKING CIRCUMSTANCE

1. Never start the engine inside a
closed room or building. Exhaust
gases contain dangerous carbon
monoxide.

2. Never use the product,
a. when the ground is slippery

or when you can’t maintain a
steady posture.

b. At night, at times of heavy fog,

or at any other times when
your field of vision might be
limited and it would be diffi­cult to gain a clear view of the
working area.

c. During rain storms, during

lightning storms, at times of
strong or gale-force winds, or
at any other times when
weather conditions might
make it unsafe to use the
product.

WORKING PLAN

1. You should never use the prod­uct when under the influence of
alcohol, when suffering from ex­haustion or lack of sleep, when
suffering from drowsiness as a re­sult of having taken cold medicine
or at any other time when a pos­sibility exists that your judgment
might be impaired or that you
might not be able to operate the
product properly and in a safe
manner.

2. When planning your work sched­ule, allow plenty of time to rest.
Limit the amount of time over
which the product is to be used
continuously to somewhere
around 30 ~ 40 minutes per ses­sion, and take 10 ~ 20 minutes of
rest between work sessions. Also
try to keep the total amount of
work performed in a single day
under 2 hours or less.

WARNING

1. If you don’t observe the working
time, or working manner (See
“USING THE PRODUCT”), Re­petitive Stress Injury (RSI) could
occur.
If you feel discomfort, redness and
swelling of your fingers or any
other part of your body, see a doc­tor before getting worse.

2. To avoid noise complaints, in gen­eral, operate product between
8 a.m. and 5 p.m. on weekdays
and 9 a.m. to 5 p.m. on weekends.

NOTE

Check and follow the local regula­tions as to sound level and hours of
operations for the product.

GB-5
