machine numbers VCP353
thanks for
choosing zenith
-2-
POWER CORD POLARIZATION
CAUTION
To prevent electric shock, match wide blade of plug to wide slot, fully insert.
ATTENTION
Pour éviter les chocs électriques, introduire la lame la plus large de la fiche dans la borne correspondante
de la prise et pousser jusqu’au fond.
SAFETY WARNINGS
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING
WARNING:
TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
WARNING:
TO PREVENT FIRE OF SHOCK HAZARDS, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
Note to Cable TV System Installer
This reminder is provided to call the cable TV installer’s attention to Article 820-40 of the National Electrical Code
(U.S.A.). The code provides guidelines for proper grounding and, in particular, specifies that the cable ground
shall be connected to the grounding system of the building, as close to the point of the cable entry as practical.
REGULATORY INFORMATION
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION:
Do not attempt to modify this product in any way without written authorization from Zenith Electronics Corporation.
Unauthorized modification could void the user’s authority to operate this product.
-3-
1. Read Instructions
All the safety and operating instructions should
be read before the product is operated.
2. Follow Instructions
All operating and use instructions should be
followed.
3. Retain Instructions
The safety and operating instructions should be
retained for future reference.
4. Heed Warnings
All warnings on the product and in the operating
instructions should be adhered to.
5. Cleaning
Unplug this product from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.
6. Water and Moisture
Do not use this product near water — for example, near a bath tub, washbowl, kitchen sink, or
laundry tub, in a wet basement, or near a swimming pool.
7. Accessories
Do not place this product on an unstable cart,
stand, tripod, bracket, or table. The product may
fall, causing serious injury to a child or adult,
and serious damage to the product. Use only with
a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with the
product. Any mounting of the product should follow the manufacturer’s instructions, and should
use a mounting accessory recommended by the
manufacturer.
8. Transporting Product
A product and cart combination
should be moved with care.
Quick stops, excessive force,
and uneven surfaces may cause
the product and cart combination to overturn.
9. Attachments
Do not use attachments not recommended by the
product manufacturer as they may cause hazards.
10. Ventilation
Slots and openings in the cabinet are provided
for ventilation and to ensure reliable operation of
the product and to protect it from overheating,
and these openings must not be blocked or covered. The openings should never be blocked by
placing the product on a bed, sofa, rug, or other
similar surface. This product should not be
placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided
or the manufacturer’s instructions have been
adhered to.
11. Power Sources
This product should be operated only from the
type of power source indicated on the marking
label. If you are not sure of the type of power
supply to your home, consult your product dealer
or local power company. For products intended
to operate from battery power, or other sources,
refer to the operating instructions.
12. Line-Cord Polarization
This product is equipped with a polarized alternating-current line plug (a plug having one blade
wider than the other). This plug will fit into the
power outlet only one way. This is a safety feature. If you are unable to insert the plug fully
into the outlet, try reversing the plug. If the plug
should still fail to fit, contact your electrician to
replace your obsolete outlet. Do not defeat the
safety purpose of the polarized plug.
13. Power-Cord Protection
Power-supply cords should be routed so that they
are not likely to be walked on or pinched by
items placed upon or against them, paying particular attention to cords at plugs, convenience
receptacles, and the point where they exit from
the product.
14. Outdoor Antenna Grounding
If an outside antenna or cable system is connected to the product, be sure the antenna or cable
system is grounded so as to provide some protection against voltage surges and built-up static
charges. Article 810 of the National Electrical
Code (U.S.A), ANSI/NFPA70 provides information with regard to proper grounding of the mast
and supporting structure, grounding of the leadin wire to an antenna discharge unit, size of
grounding conductors, location of antenna-discharge unit, connection to grounding electrodes,
and requirements for the grounding electrode.
See figure on next page.
15. Lightning
For added protection for this product (receiver)
during a lightning storm, or when it is left unattended and unused for long periods of time,
unplug it from the wall outlet and disconnect the
antenna or cable system. This will prevent damage to the product due to lightning and powerline surges.
IMPORTANT SAFETY INSTRUCTIONS
Your product has been manufactured and tested with your safety in mind. However, improper use can result in
potential electrical shock or fire hazards. T o avoid defeating the safeguards that have been built into your new product, please read and observe the following safety points when installing and using your new product, and save them
for future reference.
Observing the simple precautions discussed in this section can help you get many years of enjoyment and safe operation from your new product.
PORTABLE CART WARNING
IMPORTANT SAFETY INSTRUCTIONS (Continued)
-4-
16. Power Lines
An outside antenna system should not be located
in the vicinity of overhead power lines or other
electric light or power circuits, or where it can
fall into such power lines or circuits. When
installing an outside antenna system, extreme
care should be taken to keep from touching such
power lines or circuits as contact with them
might be fatal.
17. Overloading
Do not overload wall outlets and extension cords
as this can result in a risk of fire or electric
shock.
18. Object and Liquid Entry
Never push objects of any kind into this product
through openings as they may touch dangerous
voltage points or short-out parts that could result
in a fire or electric shock. Never spill liquid of
any kind on the product.
19. Servicing
Do not attempt to service this product yourself as
opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
20. Damage Requiring Service
Unplug this product from the wall outlet and
refer servicing to qualified service personnel
under the following conditions:
a. If the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fall-
en into the product.
c. If the product has been exposed to rain or
water.
d. If the product does not operate normally by
following the operating instructions. Adjust
only those controls that are covered by the
operating instructions as an improper adjustment of other controls may result in damage
and will often require extensive work by a
qualified technician to restore the product to
its normal operation.
e. If the product has been dropped or the cabinet
has been damaged.
f. If the product exhibits a distinct change in per-
formance.
21. Replacement Parts
When replacement parts are required, be sure the
service technician has used replacement parts
specified by the manufacturer or have the same
characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock, or
other hazards.
22. Safety Check
Upon completion of any service or repairs to this
product, ask the service technician to perform
safety checks to determine that the product is in
proper operating condition.
23. Wall or Ceiling Mounting
The product should be mounted to a wall or ceiling only as recommended by the manufacturer.
24. Heat
The product should be situated away from heat
sources such as radiators, heat registers, stoves,
or other products (including amplifiers) that produce heat.
EXAMPLE OF ANTENNA GROUNDING PER
NATIONAL ELECTRICAL CODE, ANSI/NFPA 70
Antenna Lead in Wire
Ground
Clamp
Antenna Discharge Unit
(NEC Section 810-20)
Grounding Conductors
Electric Service
Equipment
NEC - NATIONAL ELECTRICAL CODE
Power Service Grounding
Electrode System
(NEC Art 250, Part H)
(NEC Section 810-21)
Ground Clamps
-5-
Safety Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Hook-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Troubleshooting & Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Inside Back Cover
CONTENTS
Note: This video cassette player is for
video playback only. Recording is not
possible with this unit.
-6-
Channel 3/4 Switch
Output video channel switch.
Ant In Jack
Input from external antenna or cableTV Line.
Video Out Jack
Video output must be used in conjunction with audio out connection.
Audio Out Jack
Audio output must be used in conjunction with video out connection.
DC Input Jack
Input from optional DC power source.
RF Out Jack
Output to television.
6
5
4
3
2
1
HOOK-UP
Refer to the following steps to hook up your Video Cassette Player easily and quickly.
Step 1: Identify the Connectors and Switches
Locate the following connectors and switch on the back of your VCP;
Your VCP has been designed to transmit a
signal to channel 3 or 4 of your TV, TO get
the proper TV signal, set the Channel 3/4
switch on the back of the VCP to the channel that provides the best picture.
When playing a tape, the TV
must be tuned to the same channel (3 or 4) as the Channel 3/4
switch on the VCP.
Note: This only applies when the RF OUT
connection is used. If the VCP is connected
to your TV via the Audio/Video output jacks
also, choose appropriate input source at the
TV, (TV Channel 3/4 or Audio/Video In.)
Note: Use of the Audio/Video Output jacks is
optional. Depending on the capability of your
TV, you may get improved picture quality when
using these connections.
Step 2: Select the Output Video Channel
CHANNEL
3
4
1 2 3
CHANNEL
3
4
ANT.IN
RF.OUT
VHF/UHF
DC I N 12V
VIDEO
OUT
AUDIO
456
-7-
1. Disconnect the antenna or cable-TV
line from the TV.
2. Connect the antenna or cable-TV line
to the ANT IN terminal on the VCP.
HOOK-UP (continued)
Step 3: Connect VCP to Antenna or Cable-TV Line
Your antenna/cable-TV connection will be similar to one of the illustrations below.
Match yours to the one like it and make the connections shown.
Note: The 300/75 ohm adapter is an optional
accessory that is not supplied with the VCP but
should be available from your Zenith video
product retailer.
Figure 2a: Antenna Connection
Turn off power or unplug unit
before making any connections.
Figure 2b: Cable-TV Connection
300/75 ohm
Adapter
Flat Wire
or
Round Wire
CHANNEL
3
4
ANT.IN
VHF/UHF
RF.OUT
DC I N 1 2V
VIDEO
OUT
AUDIO
CABLE-TV
DECODER/
CONVERTER
(Direct Connection)
CH 3/4
Output
or
CHANNEL
3
4
ANT.IN
RF.OUT
VHF/UHF
DC I N 1 2V
VIDEO
OUT
AUDIO
-8-
1. Connect one end of the round coaxial
cable supplied with your VCPto the RF
OUT terminal of the VCP.
2. Connect the other end of the cable to
the RF IN (or ANTIN)terminal on your
TV.
Hook-Up (continued)
Step 4: Connect VCP to the TV
Refer to the following illustration to properly connect the VCP to your TV.
1. Plug the AC adapter power cord into an
operating 120VAC outlet and the other
end into the DC input on the back of
the VCP, or
2. Using the adapter cord, plug one end of
the cord into a 12 volt negative ground
DC source (such as the cigarette lighter
socket of a car) and the other end into
the DC input on the back of the VCP.
Figure 3: Connecting the VCPto Your TV
Note: An alterative to using the RF cable is to
connect the Audio/Video Out jacks on the VCP
to the corresponding jacks on your TV (if
present). However, these cables are optional
accessories that are not supplied with the VCP
but should be available from your Zenith video
product retailer.
Step 5: Supply Power to the VCP
(Back of TV)
VHF/UHF/CATV
AUDIO
CHANNEL
IN
VIDEO
IN
3
4
VIDEO
ANT.IN
RF.OUT
VHF/UHF
DC I N 12V
OUT
AUDIO
-9-
POWER
Turns the VCP on or off. The indicator
lights to indicate that the power is on.
EJECT
Ejects a cassette from the video cassette
compartment. If pressed while the VCP
is turned off, the power will turn on, the
cassette will be ejected, then the power
will turn off automatically.
STOP
Stops playback, fast forward, reverse,
rewind, or speed search. Cancels automatic modes of operation.
TRK (Tracking) Control
Adjusts the tracking until video noise is
lessened or eliminated.
REW (Rewind) Indicator
Indicates the VCP is rewinding.
CST.IN (Cassette In) Indicator
Indicates a cassette is in the VCP.
DEW Indicator
Indicates excessive moisture condensation is in the unit. Keep power on at
room temperature until indicator turns
off. The VCP will not operate if the
DEW indicator is on.
PLAY/A.TRK
(Auto Tracking) Indicator
Indicates tape is playing and tracking
automatically.
FF (Fast Forward) Indicator
Indicates tape is fast forwarding.
A. (Auto) REPEAT Indicator
Indicates automatic repeat is active.
A. (Auto) REPEAT
Enables auto repeat. T ape will automatically rewind when it reaches the end,
then begin to play again. Press a second
time to disable repeat.
STILL
Press during tape playback to pause the
tape and "freeze" the picture. Press
PLAY to resume normal playback. If
left in the Still mode for five minutes,
the VCP will automatically go into
Stop mode to protect the tape and the
VCP from possible damage.
(continued on next page)
8
7
6
5
4
3
2
1
OPERATION
Controls and Indicators
power stop trk
eject
VCP353 ac/dc video cassette player
rew play/a.trk
cst.in a.repeat
dew
still
ff
a.repeat
play
rew
f fwd
1 2 3 4 5 6 7 8 9
10 11 12
-10-
REW (Rewind/Reverse Search)
Button
Press while the VCP is in Stop mode
to rewind the tape (no picture, no
sound). During tape playback, press to
begin Reverse Search; The picture
portion of the tape is played in the
reverse direction at high speed (sound
is muted). Press and hold down REW
to rewind the tape at Jet Search speed,
release for normal playback. Press
STOP to end rewind or search.
PLAY
Begins tape playback. The correct
playback speed is automatically selected.
F FWD (Fast Forward/Forward
Search)
Press while the VCP is in the Stop
mode to fast forward the tape (no picture or sound). During tape playback,
press to begin Forward search; The
picture portion of the tape is played at
high speed (the sound is muted). Press
and hold down F FWD to play the
tape at Jet Search speed, release for
normal playback. Press STOP to end
fast forward or search.
Cassette Loading Compartment
Insert a VHS video cassette into the
video cassette compartment until it is
automatically drawn into the VCP. The
cassette can be inserted even when
power is off. Power turns on automatically and playback begins.
CAUTION; DO NOT attempt to
insert a cassette into the compartment
when the power cord is unplugged.
CAUTION; DO NOT insert fingers
into the cassette compartment.
12
11
10
9
OPERATION (continued)
Playing a Video Cassette
• Turn on the TV.
• If the VCP is connected to the TV via
the RF OUT jack, tune the TV to the
same channel (3 or 4) as the Channel
3/4 switch on the back of the VCP.
• If the connection in mode via the VCP's
Audio/Video Out jacks, your TV must
be set to receive audio and video from
an auxiliary source. (Refer to your TV
operating instructions.)
• To view a VHS cassette tape, insert it
into the cassette compartment. The
VCP will automatically turn on, play
the tape to its end, rewind the tape,
eject the tape, and shut off. If necessary, use the TRK (TRACKING) control to adjust for the best picture.
Normal TV Viewing
T o watch TV, simply turn off the VCP. If the
TV antenna or cable-TV line has been connected to the VCP as shown in this manual,
its signal will pass through the turned-off
VCP unaffected, as if connected directly to
the TV.
-11-
Installing Batteries
Be sure to install the batteries provided
with this remote. Match positive (+) and
negative (–) with markings shown in the
battery compartment.
REMOTE SC353
AAA
AAA
power eject
play
stop
rew
still a.repeat
ff
tracking
-12-
Note: Specifications, features, and appearance of this Video Cassette Player are subject to
change without notice. Weight and dimensions are approximate.
Power Requirements
Operating Voltage . . . . . . . . . . . . . . . .AC 120 V, 60Hz
DC 12 V, Neg Ground
Power consumption . . . . . . . . . . . . . .16W (AC)
16W (DC)
Environmental Conditions
Operation . . . . . . . . . . . . . . . . . . . . . .41 to 95° F (5 to 35° C) Temperature
35 to 80% Relative Humidity
Storage . . . . . . . . . . . . . . . . . . . . . . . .-4 to 140° F (-20 to 60° C) Temperature
5 to 80% Relative Humidity
Physical Characteristics
Dimensions(W x H x D) . . . . . . . . . . .10.6 x 3.6 x 11.7 Inches(270 x 94 x 297 mm)
Weight . . . . . . . . . . . . . . . . . . . . . . . .7.9 lbs (3.6 kg)
Video System
Format . . . . . . . . . . . . . . . . . . . . . . . .VHS 1⁄2 Inch (12.7 mm) Tape
Signal . . . . . . . . . . . . . . . . . . . . . . . . .NTSC color/EIA monochrome
(525 lines/60 fields)
Output . . . . . . . . . . . . . . . . . . . . . . . .1.0 Vp-p
Signal-to-Noise ratio . . . . . . . . . . . . . .≥ 43 dB (SP speed)
Audio Systems
Monaural . . . . . . . . . . . . . . . . . . . . . . . .1 channel standard VHS
Frequency Response . . . . . . . . . . . . . . . .200 to 7,000 Hz (SP speed)
Signal-to-Noise ratio . . . . . . . . . . . . . . . .≥ 38 dB (SP speed)
Output . . . . . . . . . . . . . . . . . . . . . . . . . . .Minus 8 dB into ≤ 1,000 ohms
SPECIFICATIONS
Note: This video cassette player is for
video playback only. Recording is not
possible with this unit.
-13-
Observed Condition
No power to the VCP.
The tape will not rewinds
Operating sound is audible
during playback, rewind, fast
forward. etc.
The playback picture does not
appear while the tape is running.
Noise appears during search and still
pictures.
Noise appears during playback.
Playback picture is blurred or inter-
rupted while normal TV picture is
clear.
Cassette cannot be inserted into
VCP.
Remote control does not work.
DEW Indicator is lit.
Operating Problems
Possible Cause
Power cord is not connected.
Playback Problems
Tape is already fully rewound.
Normal condition.
You are using the RF OUT jack but
the TV is not turned to the correct
video channel.
You are using the VCP audio/video
Out jacks but the TV is not set to
AUX channel or Audio/Video In
source.
Normal condition.
The tracking needs to be adjusted.
Video heads may be dirty.
The cassette is being loaded backwards or upside down or another
cassette is already loaded.
Power cord is not connected.
Batteries are not installed or old.
Excessive condensation.
Probable Solution
Connect it.
No action is necessary.
No action is necessary.
Set the TV to either channel 3 or
channel 4.
Set the TV to AUX channel or
Audio/Video In source.
No action is necessary.
Adjust tracking.
Head cleaning is necessary.
Consult your local Zenith video
retailer.
Load cassette in direction Indicated
by arrow on cassette, or remove the
cassette that is loaded already.
Connect power cord.
Install or replace with new batteries.
Keep power on until indicator turns
off.
TROUBLESHOOTING & MAINTENANCE
Troubleshooting
Before requesting Warranty service, please refer to the chart below. It may help you avoid
a service call.
Maintenance
Video Head Cleaning
Your VCP automatically cleans the heads as it
is used.
After long periods of use, the video heads
may become clogged with accumulated dirt,
causing distortion (snow, streaking in picture
and horizontal pulling of picture). When this
occurs, use do-it-yourself VHS wet head
cleaning cassettes available through your
Zenith video product retailer.
Caution: Do not use dry head cleaning systems. They may seriously damage both the
video cassette player an cassette.
Cabinet Cleaning
Clean the outside surfaces of the VCP with a
soft, lint-free cloth as required.
NOTE
-14-
VIDEO CASSETTE RECORDER OR PLAYER
Welcome into the Zenith family! We believe that you will be pleased with your new Zenith
Entertainment Machine. Please read this warranty carefully, it is a “LIMITED WARRANTY” as defined
under Federal Law. This warranty gives you specific legal rights, and you may also have other rights that
vary from state to state within the U.S.A.
ZENITH’S RESPONSIBILITY
Service Labor During a period of 90 days from effective warranty date, Zenith will provide service labor by a Zenith
authorized service center when needed as determined by Zenith, as a result of manufacturing defects.
Parts New or remanufactured replacements for factory-defective parts will be supplied by a Zenith authorized
service center for one year from effective warranty date . Such replacement parts are warranted for the
remaining portion of the original warranty period.
Not Covered This warranty covers manufacturing defects and does not cover installation, adjustment of customer
controls in the home, installation or repair of home antenna systems, cable converters or cable
company-supplied equipment; it also does not cover damage due to misuse, abuse, negligence, acts of
God or other causes beyond the control of Zenith. Any alteration of the product after manufacture voids
this warranty in its entirety.
OWNER’S RESPONSIBILITY
Effective Warranty Date Warranty begins on the date of original consumer purchase. For your convenience, keep the dealer’s
dated bill of sale or a delivery ticket as evidence of the purchase date.
Operating Guide Read your Operating Guide carefully so that you will understand the operation of your set and how to
adjust the customer controls.
Carry-In Service The video product must be taken to a U.S. or Canadian Zenith authorized service center for warranty
service and must be picked up by the owner.
TV Set Performance It is the owner’s responsibility to maintain the TV receiver with which the video product is used, and
the associated antenna system, in proper operating condition.
Important Product Registration—Please fill out and mail your Product Registration Card. It is imperative that
Zenith know how to reach you promptly if we should discover a safety problem that could affect you.
Warranty Service For warranty service information, contact any Zenith authorized service center. Parts and service labor
that are Zenith’s responsibility (see above) will be provided without charge. Other service is at the
owner’s expense. If you have any problem in obtaining satisfactory warranty service, call or write the
Zenith Response Center. You must provide the model number, serial number and date of purchase or
date of original installation. Before you ask for warranty service, read “Maintenance And
Troubleshooting” in your operating guide. You might avoid a service call.
THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTY, EXPRESS OR IMPLIED, INCLUDING WITHOUT
LIMITATION, ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, AND
ZENITH SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL, INDIRECT, OR INCIDENTAL DAMAGES OF ANY
KIND, INCLUDING LOST REVENUES OR PROFITS IN CONNECTION WITH THE PRODUCT.
Zenith Electronics Corporation
Customer Service Department
1000 Milwaukee Avenue
Glenview, Illinois 60025-2493
Telephone: (847) 391-8752
Mon-Fri, 8:00 a.m. - 4:30 p.m. Central Time
Your Zenith Limited Warranty
Zenith Part No. 206-3431
GS#3835RM0007S
Loading...
