© Copyright 2007, LG Electronics USA, Inc.
Installation and Operating Guide | Warranty
Model Numbers | 19LS4D, 22LS4D | LCD TV
1
WARNING / CAUTION
WARNING / CAUTION
FCC NOTICE
Class B digital device
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
CAUTION
Do not attempt to modify this product in any way without written authorization from LG Electronics. Unauthorized modification could void the user’s authority to operate this product
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the litera­ture accompanying the appliance.
TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK). NO
USER SERVICEABLE PARTS INSIDE. REFER TO
QUALIFIED SERVICE PERSONNEL.
WARNING/CAUTION
TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
NOTE TO CABLE/TV INSTALLER
This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the National Electric Code (U.S.A.). The code provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of the cable entry as practical.
2
IMPORTANT SAFETY INSTRUCTIONS
SAFETY INSTRUCTIONS
Important safety instructions shall be provided with each apparatus. This information shall be given in a separate booklet or sheet, or be located before any operating instructions in an instruction for installation for use and supplied with the apparatus.
This information shall be given in a language acceptable to the country where the apparatus is intended to be used. The important safety instructions shall be entitled “Important Safety Instructions”. The following safety
instructions shall be included where applicable, and, when used, shall be verbatim as follows. Additional safety information may be included by adding statements after the end of the following safety instruction list. At the manufacturer’s option, a picture or drawing that illustrates the intent of a specific safety instruction may be placed immediately adjacent to that safety instruction:
Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers)that produce heat.
Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong, The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.
Only use attachments/accessories specified by the manufacturer.
Unplug this apparatus when unused for long periods of time.
Owner Manual
Owner Manual
Owner Manual
Owner Manual
Owner Manual
Owner Manual
Owner Manual
Owner Manual
Owner Manual
Owner ManualOwner Manual
1
2
3
4
5
6
7
8
Owner Manual
3
Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
Never touch this apparatus or antenna during a thunder or lighting storm.
Do not allow a impact shock or any objects to fall into the product, and do not drop onto the screen with something.
Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has exposed to rain or moisture, does not operate normally, or has been dropped.
CAUTION concerning the Power Cord : Most appliances recommend they be placed upon a dedicated circuit; that is, a single outlet circuit which powers only that appliance and has no additional outlets or branch circuits. Check the specification page of this owner's manual to be certain.
Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension cords, frayed power cords, or damaged or cracked wire insulation are dangerous. Any of these conditions could result in electric shock or fire. Periodically examine the cord of your appliance, and if its appearance indicates dam­age or deterioration, unplug it, discontinue use
of the appliance, and have the cord replaced with an exact replacement part by an authorized servicer. Protect the power cord from physical or mechanical abuse, such as being twisted, kinked, pinched, closed in a door, or walked upon. Pay particular attention to plugs, wall outlets, and the point where the cord exits the appliance.
Outdoor use marking : WARNING - To reduce the risk of fire or elec-
tric shock, do not expose this appliance to rain or moisture.
Wet Location Marking : Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on or over apparatus.
GGRROOUU NNDD IINNGG
Ensure that you connect the earth ground wire to prevent possible electric shock. If grounding methods are not possible, have a qualified electrician install a separate circuit breaker.
Do not try to ground the unit by connecting it to telephone wires, lightening rods, or gas pipes.
DDII SSCC OONNNNEECC TTIINN GG DDEEVV IICC EE FFRROO MM MMAA IINNSS
Mains plug is the disconnecting device. The plug must remain readily operable.
Owner Manual
Owner Manual
Owner Manual
Owner Manual
Owner Manual
Owner Manual
9
12
10
11
13
14
15
16
17
Power Supply
Short-circuit
Breaker
4
CONTENTS
WARNING / CAUTION
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
SAFETY INSTRUCTIONS
. . . . . . . . . . . . . . . . . . . . . . . . . . 2
INTRODUCTION
Feature of this TV
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
PREPARATION
Accessories
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7
Front Panel Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Back Panel Information
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Stand Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Detaching Stand
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Back Cover for Wire Arrangement
. . . . . . . . . . . . . . . . . . . . . 12
Positioning your display
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
VESA Wall Mounting
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
14
Desktop Pedestal Installation
. . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Kensington Security System
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Attaching the TV to a Desk
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Antenna or Cable Connection
. . . . . . . . . . . . . . . . . . . . . . . . . .
16
EXTERNAL EQUIPMENT SETUP
HD Receiver Setup
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
DVD Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
VCR Setup
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
22
Headphone Setup
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
24
PC Setup
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
WATCHING TV / CHANNEL CONTROL
Remote Control Key Functions
. . . . . . . . . . . . . . . . . . . . . . . . .
28
Turning On TV
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
29
Channel Selection
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
29
Volume Adjustment
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
29
On-Screen Menus Selection
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
30
Channel Search
- Auto Scan (Auto Tuning)
. . . . . . . . . . . . . . . . . . . . . . . . . . . 32
- Add / Delete Channel (Manual Tuning)
. . . . . .
33
- Channel Editing
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
34
Key Lock
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
PICTURE CONTROL
Picture Size (Aspect Ratio) Control . . . . . . . . . . . . . . . . . .36
Preset Picture Settings
- Picture Mode - Preset
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
- Color Tone - Preset
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
39
Manual Picture Adjustment
- Picture Mode - User Mode
. . . . . . . . . . . . . . . . . . . . . . . . 40
- Color Tone - User Mode
. . . . . . . . . . . . . . . . . . . . . . . . . . .
41
DB - Digital Booster
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
42
Advanced - Black (Darkness) Level
. . . . . . . . . . . . . . . . . . . 43
Picture Reset
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
SOUND & LANGUAGE CONTROL
Preset Sound Setting (Sound Mode)
. . . . . . . . . . . . . . . .
45
Sound Setting Adjustment - User Mode
. . . . . . . . . . .
46
Balance
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
Stereo/SAP Broadcasts Setup
. . . . . . . . . . . . . . . . . . . . . . . . . . 48
Audio Language
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
On-Screen Menus Language Selection
. . . . . . . . . . . . .
50
Caption Mode
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
51
- Analog Broadcasting System Captions
. . . . . . .
52
- Digital Broadcasting System Captions
. . . . . . . . 53
- Caption Option
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
54
5
TIME SETTING
Clock Setting
- Auto Clock Setup
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
- Manual Clock Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
56
Auto On/Off Timer Setting
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
Sleep Timer Setting
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
58
Auto Shut-off Setting
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
PARENTAL CONTROL / RATINGS
Set Password & Lock System
- Setting up Your Password
. . . . . . . . . . . . . . . . . . . . . . . . .
60
- Set Password
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
- Lock System
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Movie & TV Rating
- Movie Rating (MPAA)
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
62
- TV Rating Children & General . . . . . . . . . . . . . . . . . . . 63
APPENDIX
Troubleshooting
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
64
Maintenance
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
66
Product Specifications
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
67
6
FEATURE OF THIS TV
INTRODUCTION
If the TV feels cold to the touch, there may be a small “flicker” when it is turned on. This is normal, there is noth­ing wrong with TV.
Some minute dot defects may be visible on the screen, appearing as tiny red, green, or blue spots. However, they have no adverse effect on the monitor's performance.
Avoid touching the LCD screen or holding your finger(s) against it for long periods of time. Doing so may produce some temporary distortion effects on the screen.
On Disposal
a. The fluorescent lamp used in this product contains a small amount of mercury. b. Do not dispose of this product with general household waste. c. Disposal of this product must be carried out in accordance to the regulations of your local authority.
LG's own special digital image generator, consisting of a full digital image processor, six different main picture quality factors.
High-definition television. High-resolution digital television broadcast and playback system composed of roughly a million or more pixels, 16:9 aspect-ratio screens, and AC3 digital audio. A subset of digital television, HDTV formats include 1080i and 720p resolutions.
Manufactured under license from Dolby Laboratories. “
Dolby
“and the double-D symbol are trademarks of
Dolby Laboratories.
HDMITM, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing."
PREPARATION
7
PREPARATION
ACCESSORIES
Ensure that the following accessories are included with your product. If an accessory is missing, please contact the dealer where you purchased the product.
User must use shielded signal interface cables (D-sub 15 pin cable) with ferrite cores to maintain standard compliance for the product.
OOppttiioonn EExxttrraass
D-sub 15 pin Cable
Owner's Manual
1.5V 1.5V
Owner’s Manual CD Manual
123
456
78
0-
9
V
O
L
C
H
B
A
C K
M
U
T E
A
D J U
S T
E
X
IT
C
C
F A
V
S O
U N
D
T I
M
E R
N
P
U T
123
456
78
0-
9
V
O
L
C
H
E
N
T
E
R
P
O
W
E R
B
A
C
K
M
U
T E
M
E
N
U
A
D J
U S
T
E
X
I T
C
C
S A
P
F A
V
P I C
T U
R E
S
O U
N
D
T I
M
E R
T
V
I N
P
U
T
Remote Control,
Batteries
Power Cord
LCD TV
Owner's Manual
http://www.zenith.com
P/NO.SAC30708007 (0706-REV00)
Copyright© 2007 LG Electronics USA, Inc.,
All Rights Reserved.
Cable Management
* Slightly wipe stained spot on the exterior only with the polishing
cloth for the product exterior if there is stain or fingerprint on surface of the exterior.
* Do not wipe roughly when removing stain. Please be cautions of
that excessive pressure may cause scratch or discoloration.
Polishing Cloth
PREPARATION
8
FRONT PANEL INFORMATION
PREPARATION
■
Here shown may be somewhat different from your TV.
Remote Control Sensor
Power/Standby Indicator
Illuminates red in standby mode. When the TV is turned on, the indicator blinks green and then illuminates green before the picture is displayed.
INPUT
MENU
VOL CH
/I
ENTER
CHANNEL (
EE,DD
)Buttons
VOLUME (
FF,GG
)Buttons
MENU Button
ENTER Button
INPUT Button
POWER Button
GG
If your product has a protection tape attached, remove the tape. And then wipe the product with a cloth (If a polishing cloth is included with your product, use it).
NOTE
!
PREPARATION
9
BACK PANEL INFORMATION
SERVICE ONLY
HDMI/DVI IN
Connect a HDMI signal to this jack. Or DVI (Video) signal to this jack with a HDMI to
DVI cable.
AV IN (Audio/Video)
Connect audio/video output from an external device to these jacks.
S-VIDEO
Connect S-Video out from an S-VIDEO device.
ANTENNA/CABLE IN
Connect over-the air signals to this jack. Connect cable signals to this jack.
RGB (PC) IN
Connect the output from a PC.
AUDIO IN (RGB/DVI)
Connect the audio from a PC or DTV.
COMPONENT IN
Connect a component video/audio device to these jacks.
HEADPHONE INPUT
Plug the headphone into the headphone socket.
RS-232C IN (CONTROL & SERVICE) PORT
For external control devices.
Power Cord Socket
For operation with AC power. Caution: Never attempt to operate the TV on DC
power.
1
6
5
7
8
9
2
3
4
VIDEO
AUDIO
(MONO)
S-VIDEO
ANTENNA/CABLE IN
RS-232C IN
(SERVICE ONLY)
RGB (PC) IN
AUDIO IN (RGB/DVI)
SERVICE
ONLY
AV I N
H/P
HDMI/DVI IN
VIDEO
AUDIO
COMPONENT IN
8 7 6
1
2
3
5
4
9
■
Here shown may be somewhat different from your TV.
PREPARATION
10
STAND INSTALLATION
PREPARATION
■
Here shown may be somewhat different from your TV.
Insert the
SSTTAA NN DD BB OODDYY
into the product until clicking sound.
Carefully place the product screen side down on a cushioned surface that will protect product and screen from damage.
Assemble the parts of the
SSTTAA NN DD BB OODDYY
with
CCOOVV EERR BBAASS EE
of the product.
SSTTAA NN DD BB OODDYY
3
1
4
Hold the
HHII NN GG EE BB OODDYY
and bend it upward.
2
HHII NN GG EE BB OODDYY
CCOOVV EERR BBAASS EE
PREPARATION
11
DETACHING STAND
Carefully place the product screen side down on a cushioned surface that will protect product and screen from damage.
Pull cover base backward while pressing button on stand body.
Shake the base while pulling, it will separate from stand body.
Pull stand body to separate from set while press­ing the 2 latches.
■
Here shown may be somewhat different from your TV.
1 2
4
3
5
Hold the
HHII NN GG EE BB OODDYY
and bend it upward.
HHII NN GG EE BB OODDYY
PREPARATION
12
BACK COVER FOR WIRE ARRANGEMENT
PREPARATION
Connect the cables as necessary. To connect an additional equipment, see the
EEXXTTEERRNNAALL EEQQUUIIPPMMEENNTT SSEETTUUPP
section.
Install the
CCAABBLL EE MMAANNAA GGEEMMEENNTT
as shown.
First, press the cable management. Hold the
CCAABBLL EE MMAANNAA GGEEMMEENNTT
with both hands and pull it upward.
NOTE
!
GG
Do not hold the
CCAABBLL EE MMAANNAAGGEEMMEE NN TT
when moving the product.
- If the product is dropped, you may be injured or the product may be broken.
How to remove the CABLE MANAGEMENT
■
Here shown may be somewhat different from your TV.
1
2
PREPARATION
13
POSITIONING YOUR DISPLAY
■
Here shown may be somewhat different from your TV.
■
Adjust the position of the panel in various ways for maximum comfort.
• Tilt range
1
2~
1
0
3
0
PREPARATION
14
VESA WALL MOUNTING
PREPARATION
For proper ventilation, allow a clearance of 4inches on all four sides from the wall.
GG
Ensure adequate ventilation by following the clearance recommendations.
CAUTION
DESKTOP PEDESTAL INSTALLATION
This product accepts a VESA-compliant mounting interface pad. (optional) There 4 threaded holes are available for attaching the bracket.
GG
Screw length needed depends on the wall mount used. For further information, refer to the VESA Wall Mounting Instruction Guide.
NOTE
!
100 mm
100 mm
4 inches
4 inches
4 inches
4 inches
PREPARATION
15
KENSINGTON SECURITY SYSTEM
ATTACHING THE TV TO A DESK (Only 23 inches)
- The TV is equipped with a Kensington Security System connector on the back panel. Connect the Kensington Security System cable as shown below.
- For the detailed installation and use of the Kensington Security System, refer to the user’s guide provided with the Kensington Security System.
For further information, contact
hhttttpp::// // wwwwww..kkeenn ssiinnggttoo nn ..ccoomm
, the internet homepage of the Kensington company. Kensington sells security systems for expensive electronic equipment such as note­book PCs and LCD projectors.
NOTE
- The Kensington Security System is an optional accessory.
The TV must be attached to a desk so it cannot be pulled in a forward/backward direction, potentially causing injury or damaging the product.
GG
This apparatus must be securely attached to the floor/wall per installation instructions. Tipping, shak­ing, or rocking the machine may cause injury/death.
WARNING
Desk
Stand
2-Screws (M3x25)
(not provided as parts
of the product)
PREPARATION
16
ANTENNA OR CABLE CONNECTION
PREPARATION
1. Antenna (Analog or Digital)
Wall Antenna Socket or Outdoor Antenna without a Cable Box Connections.
For optimum picture quality, adjust antenna direction if needed.
2. Cable
Wa ll Antenna Socket
Outdoor Antenna (VHF, UHF)
Cable TV Wall Jack
Multi-family Dwellings/Apartments (Connect to wall antenna socket)
RF Coaxial Wire (75 ohm)
RF Coaxial Wire (75 ohm)
Single-family Dwellings /Houses (Connect to wall jack for outdoor antenna)
Be careful not to bend the bronze wire when connecting the antenna.
Copper Wire
ANTENNA/CABLE IN
ANTENNA/CABLE IN
ANTENNA/CABLE IN
ANTENNA/CABLE IN
GG
The TV will let you know when the analog, cable, and digital channel scans are complete.
NOTE
!
■
To improve the picture quality in a poor signal area, please purchase a signal amplifier and install properly.
■
If the antenna needs to be split for two TV’s, install a 2-Way Signal Splitter.
■
If the antenna is not installed properly, contact your dealer for assistance.
Antenna
UHF
Signal Amplifier
VHF
3. Using both cable and antenna
Cable TV Wall Jack
Antenna
RF Coaxial Wire (75 ohm)
RF Coaxial Wire (75 ohm)
Diplexer
(Signal
Combiner)
EXTERNAL EQUIPMENT SETUP
17
HD RECEIVER SETUP
EXTERNAL EQUIPMENT SETUP
This TV can receive Digital Over-the-air/Cable signals without an external digital set-top box. However, if you do receive digital signals from a digital set-top box or other digital external device, refer to the figure as shown below.
■
To prevent the equipment damage, never plug in any power cords until you have finished connecting all equipment.
AUDIO
(MONO)
S-VIDEO
RGB (PC) IN
AUDIO IN
(RGB/DVI)
AV I N
H/P
ANTENNA/CABLE IN
VIDEO
AUDIO
COMPONENT IN
Y L RPB PR
When connecting Component cable
1
2
1. How to connect
Connect the video outputs (Y, P
B, PR
)
of the digital set
top box to the
CC OOMMPPOONN EENNTT II NN VVII DDEE OO
jacks on
the set. Match the jack colors (Y = green, P
B = blue, and P
R = red).
Connect the audio output of the digital set-top box to the
CC OOMMPPOONN EENNTT IINN AAUU DDIIOO
jacks on the set.
2
1
2. How to use
■
Turn on the digital set-top box. (
Refer to the owner’s manual for the digital set-top box. operation
)
■
Select
CC oommpp oonneenn tt
input source by using the
IINN PP UUTT
button on the remote control.
EXTERNAL EQUIPMENT SETUP
18
EXTERNAL EQUIPMENT SETUP
When connecting HDMI cable
Connect the digital set-top box to
HHDDMMII//DDVVII IINN
jack on the set.
No separated audio connection is necessary. HDMI supports both audio and video.
1. How to connect
2. How to use
■
Turn on the digital set-top box. (
Refer to the owner’s manual for the digital set-top box.
)
■
Select
HHDD MM II// DDVVII
input source by using the
II NN PP UUTT
button on the remote control.
2
1
VIDEO
AUDIO
(MONO)
S-VIDEO
RS-232C IN
(SERVICE ONLY)
SERVICE
ONLY
HDMI/DVI IN
AV I N
H/P
ANTENN
VIDEO
CO
HDMI-DTV OUTPUT
1
GG
When connected, the TV will tell a connected device what resolution it supports and the resolution it prefers. If the device supports this Auto HDMI function, the player output resolution will be automatically set to 720p.
GG
If the device does not support Auto HDMI, you need to set the output resolution appropriately.
NOTE
!
EXTERNAL EQUIPMENT SETUP
19
When connecting HDMI to DVI cable
VIDEO
AUDIO
(MONO)
S-VIDEO
RS-232C IN
(SERVICE ONLY)
RGB (PC) IN
AUDIO IN (RGB/DVI)
SERVICE
ONLY
HDMI/DVI IN
AV I N
H/P
ANTENNA/CABLE IN
VIDEO
AUDIO
COMPONENT IN
L R
DVI-DTV OUTPUT
Connect the DVI output of the digital set-top box to the
HHDDMMII//DD VVII IINN
jack on the set.
Connect the audio output of the digital set-top box to the
AAUU DDIIOO IINN
((
RR GG BB// DDVV II
))
jack on the set.
1. How to connect
■
Turn on the digital set-top box. (Refer to the owner’s manual for the digital set-top box.
)
■
Select
HHDD MM II//DD VVII
input source by using the
IINN PP UUTT
button on the remote control.
2. How to use
2
1
1
2
EXTERNAL EQUIPMENT SETUP
20
DVD SETUP
EXTERNAL EQUIPMENT SETUP
When connecting Component cable
AUDIO
(MONO)
S-VIDEO
RGB (PC) IN
AUDIO IN
(RGB/DVI)
AV I N
H/P
ANTENNA/CABLE IN
VIDEO
AUDIO
COMPONENT IN
Y L RPB PR
Component Input ports
To get better picture quality, connect a DVD player to the component input ports as shown below.
Component ports on the TV
YPBP
R
Video output ports
on DVD player
Y
Y
Y
Y
P
B
B-Y
Cb
Pb
P
R
R-Y
Cr
Pr
Connect the video outputs (Y, P
B, P
R
)
of the DVD to the
CC OOMMPPOONN EENNTT IINN VVIIDD EEOO
jacks on the set.
Match the jack colors (
Y = green, P
B = blue, and P
R = red
)
.
Connect the audio outputs of the DVD to the CC OOMMPPOONN EENNTT IINN AAUU DDIIOO
jacks on the set.
1. How to connect
2. How to use
■
Turn on the DVD player, insert a DVD.
■
Select
CC oommpp oonneenn tt
input source by using the
IINN PP UUTT
button on the remote control.
■
Refer to the DVD player's manual for operating instructions.
2
1
1
2
EXTERNAL EQUIPMENT SETUP
21
When connecting with an S-Video cable
VIDEO
AUDIO
(MONO)
S-VIDEO
RGB (PC) IN
AU (RG
AV I N
H/P
ANTENNA/CABLE IN
VIDEO
AUDIO
COMPONENT IN
L R
S-VIDEO
AUDIO
1
2
Connect the S-VIDEO output of the DVD to the SS --VVIIDDEEOO
input on the set.
Connect the audio outputs of the DVD to the
AAUUDDIIOO
input jacks on the set.
1. How to connect
2. How to use
■
Turn on the DVD player, insert a DVD.
■
Select
AA VV
input source by using the
IINN PP UUTT
button on the
remote control.
■
Refer to the DVD player's manual for operating instructions.
2
1
VIDEO
AUDIO
(MONO)
S-VIDEO
RS-232C IN
(SERVICE ONLY)
SERVICE
ONLY
HDMI/DVI IN
AV I N
H/P
ANTE
VIDE
C
HDMI-DVD OUTPUT
1
When connecting HDMI cable
Connect the HDMI output of the DVD to the HHDDMMII//DD VVII IINN
jack on the set.
No separated audio connection is necessary. HDMI supports both audio and video.
1. How to connect
2. How to use
■
Select
HHDD MM II//DD VVII
input source by using the
IINN PPUU TT
button on the remote control.
■
Refer to the DVD player's manual for operating instructions.
2
1
GG
When connected, the TV will tell a connected device what resolution it supports and the resolution it prefers. If the device supports this Auto HDMI function, the player out­put resolution will be automatically set to 720p.
GG
If the device does not support Auto HDMI, you need to set the output resolution appropriately.
To get the best picture quality, adjust the output resolution of the DVD to 720p.
NOTE
!
EXTERNAL EQUIPMENT SETUP
22
VCR SETUP
EXTERNAL EQUIPMENT SETUP
When connecting with an antenna
■
To avoid picture noise (interference), leave an adequate distance between the VCR and TV.
■
If the 4:3 picture format is used; the fixed images on the sides of the screen may remain visible on the screen. This phenomenon is common to all manufactures and in consequence the manufactures warranty does not cover the product bearing this phenomenon.
VIDEO
AUDIO
(MONO)
S-VIDEO
RS-232C IN
(SERVICE ONLY)
RGB (PC) IN
AUDIO IN
(RGB/DVI)
SERVICE
ONLY
HDMI/DVI IN
AV I N
H/P
ANTENNA/CABLE IN
VIDEO
AUDIO
COMPONENT IN
L R
S-VIDEOVIDEO
OUTPUT
SWITCH
ANT IN
ANT OUT
Wall Jack
Antenna
1
2
Connect the RF antenna out socket of the VCR to the
AANNTTEENNNNAA //CC AABB LLEE II NN
socket on the set.
Connect the antenna cable to the RF antenna in socket of the VCR.
1. How to connect
■
Set VCR output switch to 3 or 4 and then tune TV to the same channel number.
■
Insert a video tape into the VCR and press PLAY on the VCR. (Refer to the VCR owner’s manual.
)
2. How to use
2
1
EXTERNAL EQUIPMENT SETUP
23
When connecting with a RCA cable
GG
Do not connect to both Video and S-Video at the same time. In the event that you connect both Video and the S-Video cables, only the S-Video will work.
CAUTION
GG
The picture quality is improved: compared to normal composite (RCA cable) input.
NOTE
!
VIDEO
AUDIO
(MONO)
S-VIDEO
RS-232C IN
(SERVICE ONLY)
R
SERVICE
ONLY
HDMI/DVI IN
AV I N
H/P
ANTENN
VIDEO
COM
L R
S-VIDEO VIDEO
OUTPUT
SWITCH
ANT IN
ANT OUT
VIDEO
AUDIO
(MONO)
S-VIDEO
RGB (PC) IN
A
(
AV I N
H/P
ANTENNA/CABLE IN
VIDEO
AUDIO
COMPONENT IN
L R
S-VIDEO
AUDIO
Connect the
AAUUDDIIOO/VV IIDDEEOO
jacks between TV and VCR. Match the jack colors (Video = yellow, Audio Left = white, and Audio Right = red)
1. How to connect
2. How to use
■
Insert a video tape into the VCR and press PLAY on the VCR. (Refer to the VCR owner’s manual.
)
■
Select
AA VV
input source by using the
IINN PP UUTT
button on the
remote control.
When connecting with an S-Video cable
Connect the S-VIDEO output of the VCR to the SS --VVIIDDEEOO
input on the set.
Connect the audio outputs of the VCR to the
AAUUDDIIOO
input jacks on the set.
1. How to connect
2. How to use
■
Insert a video tape into the VCR and press PLAY on the VCR. (
Refer to the VCR owner’s manual.
)
■
Select
AA VV
input source by using the
IINN PP UUTT
button on the
remote control.
1
2
1
GG
If you have a mono VCR, connect the audio cable from
the VCR to the
AAUU DDIIOO LL // MM OONNOO
jack of the set.
NOTE
!
1
1
2
EXTERNAL EQUIPMENT SETUP
24
HEADPHONE SETUP
EXTERNAL EQUIPMENT SETUP
You can listen to the sound through the headphone.
Plug the headphone into the headphone socket.
To adjust the headphone volume, press the
VVOOLL
+ or
- button. If you press the
MM UUTTEE
button, the sound
from the headphone is switched off.
1. How to connect
2
1
VIDEO
A
(MON
RS-232C IN
(SERVICE ONLY)
SERVICE
ONLY
HDMI/DVI IN
H/P
EXTERNAL EQUIPMENT SETUP
25
PC SETUP
This TV provides Plug and Play capability, meaning that the PC adjusts automatically to the TV's settings.
When connecting D-sub 15pin cable
AUDIO
(MONO)
S-VIDEO
RGB (PC) IN
AUDIO IN (RGB/DVI)
AV I N
VIDEO
AUDIO
COMPONENT IN
AUDIO
RGB OUTPUT
Connect the RGB output of the PC to the
RR GGBB
((
PP CC
))
II NN
jack on the set.
Connect the PC audio output to the
AAUU DDIIOO IINN
((
RR GG BB// DDVV II
))
jack on the set.
1. How to connect
2. How to use
■
Turn on the PC and the TV.
■
Select
RR GG BB -- PPCC
input source by using the
IINN PP UUTT
button
on the remote control.
2
1
1
2
When connecting HDMI to DVI cable
Connect the DVI output of the PC to the
HHDDMMII// DDVVII
II NN
jack on the set.
Connect the PC audio output to the
AAUU DDIIOO II NN
((
RR GG BB// DDVV II
))
jack on the set.
1. How to connect
2. How to use
■
Turn on the PC and the TV.
■
Select
HHDD MM II//DD VVII
input source by using the
IINN PP UUTT
but-
ton on the remote control.
2
1
VIDEO
AUDIO
(MONO)
RS-232C IN
(SERVICE ONLY)
SERVICE
ONLY
HDMI/DVI IN
AV I N
H/P
DVI-PC OUTPUT
AUDIO
AUDIO IN
(RGB/DVI)
1
2
EXTERNAL EQUIPMENT SETUP
26
EXTERNAL EQUIPMENT SETUP
GG
To get the the best picture quality, adjust the PC graphics card to 1024x768, 60Hz.
GG
Depending on the graphics card, DOS mode may not work if a HDMI to DVI Cable is in use.
GG
If the video doesn’t fit the screen, try pressing the ADJUST button to adjust the screen position of TV.
GG
Check the image on your TV. There may be noise associated with the resolution, vertical pattern, contrast or brightness in PC mode. If noise is present, change the PC output to another resolu­tion, change the refresh rate to another rate or
adjust the brightness and contrast on the VIDEO menu until the picture is clear. If the refresh rate of the PC graphic card can not be changed, change the PC graphic card or consult the manufacturer of the PC graphic card.
GG
Avoid keeping a fixed image on the screen for a long period of time. The fixed image may become permanently imprinted on the screen.
GG
The synchronization input form for Horizontal and Vertical frequencies is separate.
NOTES
!
Supported Display Specifications
* RGB-PC mode only
Horizontal Vertical
Frequency(KHz)Frequency(Hz
)
31.469 70.08
31.469 70.08
31.469 59.94
37.879 60.31
48.363 60.00
47.776 59.87
47.712 60.01
60.023 60.00
31.469 59.94
31.500 60.00
44.96 59.94
45.000 60.00
33.72 59.94
33.75 60.00
Resolution
720x400
1360x768
640x350
640x480
800x600
1024x768
1280x768
1366x768
720x480
1280x720
1920x1080
* HDMI mode only
EXTERNAL EQUIPMENT SETUP
27
Screen Setup for PC mode
Overview
When the RGB input of the set is connected to a PC output, select the RGB-PC as the main input mode.
When HDMI connect to PC output and select HDMI/DVI input, this function is used.
After connecting RGB-PC or HDMI/DVI to PC output and checking the screen quality.
When you change the resolution, select the proper resolution in pre­sent input to see the best picture appearance.
Adjustment for screen Resolution, Position, Size, and Phase
Press the
AADD JJUUSSTT
button and then use
DD
or EEbutton to
select
RR ee ssoolluuttiioo nn, PPoo ssiittiioonn, SSiizzee
, or
PPhhaassee
.
Press the
EENNTTEERR
button and then use
DD EE FF GG
button to
make appropriate adjustments.
■
The
PPhhaassee
adjustment range is
00 ~++6644
.
In HDMI/DVI-PC mode,
PPhhaassee
is not available.
■
The
SSiizzee
adjustment range is
--3300 ~++3300
.
In HDMI/DVI-PC mode,
SSiizzee
is not available.
Press the
EENNTTEERR
button.
Auto Configuration and Initializing (Reset to original factory values)
Press the
AADD JJUUSSTT
button and then use
DD
or EEbutton to
select
AAuutt oo
or
RR eesseett
.
Press the
EENNTTEERR
button and then use
FF
or
GG
button to
select
YY ee ss
.
Press the
EENNTTEERR
button.
ENTER
BACK
CC
MENU EXIT
1
2
3
1
2
3
1 2 3
1 2 3
Resolution
Position
Size
Phase
Auto
Reset
Select
Prev
Ok
DD
EE
ADJUST
1024 x 768
1280 x 768
1360 x 768
RReessoolluuttiioonn
This function allows you select resolution of XGA/WXGA.
PPoossiittiioonn
This function is to adjust picture to left/right and up/down as you prefer.
SSiizzee
This function is to minimize any ver­tical bars or stripes visible on the screen background. And the hori­zontal screen size will also change.
PPhhaassee
This function allows you to remove any horizontal noise and clear or sharpen the image of char­acters.
AAuuttoo
This function is to adjust picture position and minimizes image shaking automatically.
RReesseett
This function is to initialize the adjusted value.
Initialize Settings
Yes
No
Select
Prev
Ok
FF GG
ADJUST
Resolution
Position
Size
Phase
Auto
Reset
Start Auto configuration
Yes
No
Select
Prev
Ok
FF GG
ADJUST
Resolution
Position
Size
Phase
Auto
Reset
WATCHING TV / CHANNEL CONTROL
28
REMOTE CONTROL FUNCTIONS
WATCHING TV / CHANNEL CONTROL
When using the remote control, aim it at the remote control sensor on the TV.
123
456
780-9
VOL CH
ENTER
POWER
BACK
MUTE
MENU
ADJUST
EXIT
CC
SAP
FAV
PICTURE SOUND
TIMER
TV
INPUT
SAP
SOUND
TIMER
VOLUME UP
/DOWN
ADJUST
MUTE
CC
CHANNEL
UP/DOWN
MENU
BACK
EXIT
THUMBSTICK
(Up/Down/Left
Right/ENTER)
Analog mode: Selects MTS sound (Mono, Stereo, or a SAP)
GG
pp..4488
DTV mode: Changes the audio language.
Selects the factory preset picture depend on the viewing environment.
GG
pp..3388
Selects the factory preset sound for type of program.
GG
pp..4455
Select the amount of time before your TV turns off auto­matically.
GG
pp..5588
Increase/decrease the sound level.
Adjust the screen resolution, position, size and phase.
GG
pp..2277
Switch the sound on or off.
GG
pp..3300
Select a closed caption.
GG
pp..5511
Select available channels.
Displays the main menu.
Tune to the last channel viewed.
Clear all on-screen displays and return to TV viewing from any menu.
Navigate the on-screen menus and adjust the system set­tings to your preference.
WATCHING TV / CHANNEL CONTROL
29
■
Open the battery compartment cover on the back side and install the batteries matching correct polarity (+ with +, - with -).
■
Install two 1.5V AAA batteries. Don’t mix old or used batteries with new ones.
■
Close cover.
■
Use a remote control up to 7 meters distance and 30 degree (left/right) within the receiving unit scope.
■
Dispose of used batteries in a recycle bin to preserve environment.
123
456
780-9
POWER
SAP
FAV
PICTURE SOUND
TIMER
TV
INPUT
Installing Batteries
Remote control effective range
NUMBER button
Turns your TV or any other programmed equipment on or off, depending on the mode.
In AV, Component, RGB-PC, and HDMI/DVI input sources, screen returns to the last TV channel.
External input modes rotate in regular sequence: TV, AV, Component, RGB-PC, and HDMI/DVI. (AV, Component, RGB-PC, and HDMI/DVI input sources are linked automatically, only if a
device is connected.)
Used to enter a program number for multiple program channels such as 2-1, 2-2, etc.
Scroll through the programmed Favorite channels.
GG
pp..3344
POWER
TV
INPUT
— (DASH)
FAV
WATCHING TV / CHANNEL CONTROL
30
TURNING ON TV
WATCHING TV / CHANNEL CONTROL
NOTE
!
GG
If you intend to be away on vacation, disconnect the power plug from the wall power outlet.
First, connect power cord correctly. At this moment, the TV switches to standby mode.
■
In standby mode to turn TV on, press the ,
IINNPPUUTT,CCHH ((
DD
or
EE
))
button on the TV or press the
PPOOWWEERR, IINNPPUUTT, TTVV, CCHH ((
+ or -)),
NNuummbbeerr ((00~99))
button on the remote control.
Select the viewing source by using the
IINNPPUUTT
button on the remote con-
trol.
■
This TV is programmed to remember which power state it was last set to, even if the power cord is out.
When finished using the TV, press the
PPOOWWEERR
button on the remote
control. The TV reverts to standby mode.
123
456
780-9
VOL
CH
POWER
BACK
MUTE
ADJUST
CC
SAP
FAV
MENU EXIT
PICTURE SOUND
TIMER
TV INPUT
1
2
3
123
456
780-9
VOL
CH
MUTE
ADJUST
CC
FAV
Press the
CCHH ((
+ or -))or
NNUUMMBBEERR
buttons to select a channel number.
1
VOLUME ADJUSTMENT
CHANNEL SELECTION
Press the
VVOOLL ((
+ or -))button to adjust the volume.
If you want to switch the sound off, press the
MMUUTTEE
button.
You can cancel the Mute function by pressing the
MMUUTTEE
or
VVOOLL ((
+ or -
))
button.
0-
VOL
CH
BACK
MUTE
ADJUST
CC
FAV
MENU EXIT
Adjust the volume to suit your personal preference.
1
2
3
WATCHING TV / CHANNEL CONTROL
31
ON-SCREEN MENUS SELECTION
Press the
MMEENNUU
button and then use
DD
or
EE
button to select the each menu.
Press the
GG
button and then use
DD EE FF GG
button to display the available menus.
Your TV's OSD (On Screen Display)may differ slightly from what is shown in this manual.
2
1
SETUP
TIME
AUDIO
Sound Mode : Standard
Balance : 0
Clock :
Oct 19, 2007, 03:44 AM
Off Time : Off
On Time : Off
Sleep Time : Off
Auto Sleep : Off
Language : English
Key Lock : Off
Caption : Off
Lock System : Off
Set Password
Movie Rating
TV Rating-Children
TV Rating-General
OPTION
LOCK
Auto Tuning
Manual Tuning
Channel Edit
Picture Mode : User
Color Temperature : Cool
DB
Advanced
Aspect Ratio : 16:9
Picture Reset
WATCHING TV / CHANNEL CONTROL
32
CHANNEL SEARCH
WATCHING TV / CHANNEL CONTROL
Press the
MM EE NN UU
button and then use
DD
or
EE
button
to select the
SSEETT UUPP
menu.
Press the
GG
button and then use
DD
or
EE
button to
select
AAuuttoo TTuunn iinngg
.
Press the
EE NN TTEERR
button to begin the channel search.
Allow
AAuuttoo TTuunn iinngg
to complete the channel search
cycle for
AANNTTEENNNNAA
and
CC AABB LLEE
.
Automatically finds all channels available through antenna or cable inputs, and stores them in memory on the channel list.
Run Auto Tuning again after any Antenna/Cable connection changes.
A password is required to gain access to Auto Tuning menu if the Lock System is turned on.
2
3
1
1
2
3
ENTER
BACK
CC
MENU EXIT
Auto Scan (Auto Tuning)
Auto Tuning
Manual Tuning
Channel Edit
Auto Tuning
G
Manual Tuning
Channel Edit
Selection ( Gor ) leads you to the Auto Tuning screen.
Auto Tuning
G
Manual Tuning
Channel Edit
Selection ( Gor ) leads you to the Auto Tuning screen.
Processing Auto Tuning...
TV CH 23
Found Channel(s): 16
Press to stop the current scan and start TV channel scan.
MENU Prev
Next
WATCHING TV / CHANNEL CONTROL
33
A password is required to gain access to Manual Tuning menu if the Lock System is turned on.
If selecting DTV or CADTV input signal, you can view the on-screen signal strength monitor to see the quality of the signal being received.
Press the
MM EE NN UU
button and then use
DD
or
EE
button
to select the
SSEETT UUPP
menu.
Press the
GG
button and then use
DD
or
EE
button to
select
MM aa nnuuaall TTuunnii nngg
.
Press the
GG
button and then use
DD
or
EE
button to
select
TT VV, DDTTVV, CC AATT VV
, and
CC AADDTTVV
.
Press the
GG
button and then use
DD
or
EE
button to
select channel you want to add or delete.
Press the
EE NN TTEE RR
button to add or delete the channel.
Press the
EE XXIITT
button to return to TV viewing or
press
MM EENN UU
button to return to the previous menu.
ENTER
BACK
CC
MENU EXIT
2
1
4
3
6
5
1
2
3 4 5
Add/Delete Channel (Manual Tuning)
Auto Tuning
Manual Tuning
G
Channel Edit
Select channel type and RF-channel number.
DTV 2
Auto Tuning
Manual Tuning
Channel Edit
Select channel type and RF-channel number.
DTV
GG
12
delete the channel.
DTV 12-0
DD EE
Bad Normal Good
Auto Tuning
Manual Tuning
Channel Edit
WATCHING TV / CHANNEL CONTROL
34
WATCHING TV / CHANNEL CONTROL
There are two different ways in order to add or delete scanned channels. One is "Custom List" and the other is "Favorite List" in the channel list. Both of them are available after Auto Tuning on the SETUP menu.
A Custom List can be created by toggling each channel on or off with ENTER button. The channels in the Custom List are displayed in black, and the channels deleted from the Custom List are displayed in gray. Once a channel is high­lighted you can add or delete the channel by referring to the small window at the top-left corner of the screen.
You can create your own Favorite List. Use the
FFAAVV
button on the remote control when a channel is highlighted and then add or delete the channel to/from your Favorite List.
Press the
MMEENNUU
button and then use
DD
or
EE
button
to select the
SSEETTUUPP
menu.
Press the
GG
button and then use
DD
or
EE
button to
select
CC hhaannnn ee ll EEdd iitt
.
Press the
GG
button and then use
DD
or
EE
button to
select channel and then use the
EENNTTEERR
button to add
or delete it. Press
FFAAVV
button to add the channel to the Favorite List.
The surfing icon will appear in back of that channel number.
Press
EE XX IITT
button to return to TV viewing or press
MM EE NN UU
button to return to the previous menu.
0-
VOL
CH
ENTER
BACK
MUTE
ADJUST
CC
FAV
MENU EXIT
2
1
3
4
1
2
3 4
Channel Editing
Auto Tuning
Manual Tuning
Channel Edit
Auto Tuning
Manual Tuning
Channel Edit
G
TV
DD
EE
2-0
4-0
6-0
9-0
11-0
13-0
14-0
Add/Delete
Favorite
FAV
Auto Tuning
Manual Tuning
Channel Edit
G
DD EE
G
DD
EE
TV
Add/Delete
Favorite
2-0
4-0
6-0
9-0
11-0
13-0
14-0
FAV
WATCHING TV / CHANNEL CONTROL
35
KEY LOCK
ENTER
BACK
CC
MENU EXIT
The TV can be set up so that it can only be used with the remote control.
This feature can be used to prevent unauthorized viewing by locking out the front panel controls.
This TV is programmed to remember which option it was last set to even if you turn the TV off.
Press the
MM EE NN UU
button and then use
DD
or
EE
button
to select the
OOPPTT IIOONN
menu.
Press the
GG
button and then use
DD
or
EE
button to
select
KKeeyy ll oo cc kk
.
Press the
GG
button and then use
DD
or
EE
button to
select
OO nn
or
OO ff ff
.
Press
EE XX IITT
button to return to TV viewing or press
MM EE NN UU
button to return to the previous menu.
2
3
4
1
1
2 3
Language : English
Key Lock : Off
Caption : Off
Language
Key Lock
G
Caption
Off On
PICTURE CONTROL
36
PICTURE SIZE (ASPECT RATIO) CONTROL
PICTURE CONTROL
ENTER
BACK
CC
MENU EXIT
This feature allows an analog picture with a 4:3 aspect ratio is displayed on your TV. When you receive an analog picture with a 4:3 aspect ratio on your 16:9 TV, you need to specify how the picture is to be displayed.
■
RGB-PC input source use 4:3 or 16:9 aspect ratio.
NOTE
!
GG
If a fixed image is displayed on the screen for a long time, the image may become imprinted on the screen and remain visible. This phenomenon is common to all manufactures and in consequence the manufactures warranty does not cover the product bearing this phenomenon.
Press the
MM EE NN UU
button and then use
DD
or
EE
button
to select the
PPIICCTTUU RREE
menu.
Press the
GG
button and then use
DD
or
EE
button to
select
AAssppeecc tt RRaa ttiioo
.
Press the
GG
button and then use
DD
or
EE
button to
select the desired picture option
((
SSeett BB yy PPrr ooggrraa mm
,
44::33,1166::99,FFuullll,HHoorrii zz oonn
, or
ZZoooo mm
))
.
Press
EE XX IITT
button to return to TV viewing or press
MM EE NN UU
button to return to the previous menu.
2
3
4
1
1
32
Picture Mode
Color Temperature
DB
Advanced
Aspect Ratio
G
Picture Reset
Set By Program
4:3
16:9
Full
Horizon
Zoom
Picture Mode : User
Color Temperature : Cool
DB
Advanced
Aspect Ratio : 16:9
Picture Reset
PICTURE CONTROL
37
Set by program
Selects the proper picture proportion to match the source’s image.
4:3
Choose 4:3 when you want to view a picture with an original 4:3 aspect ratio.
16:9
Adjust the picture horizontally, in a linear pro­portion to fill the entire screen.
Horizon
The screen size is, more enlarged at both sides, to create a spectacular view.
Zoom
Choose Zoom when you want to view the pic­ture without any alteration. However, the top and bottom portions of the picture will be cropped.
Zoom
Set By Program
Set By Program
(4:3 4:3)
(16:9 16:9)
4:3
16 : 9
Horizon
PICTURE CONTROL
38
PRESET PICTURE SETTINGS
PICTURE CONTROL
123
456
780-9
VOL
CH
POWER
MUTE
ADJUST
SAP
FAV
PICTURE SOUND
TIMER
TV INPUT
Picture Mode - Preset
Press the
PPIICCTTUU RREE
button repeatedly to select the picture
appearance setup option as below : DDyynn aa mmiicc, SSttaa nnddaa rrdd, MM ii lldd
, and
UUsseerr
(your own settings).
Press the
EE XX IITT
button to save and return to TV viewing.
Picture Mode adjusts the TV for the best picture appearance. Select the preset value in the Picture Mode menu based on the program category.
DDyynnaammiicc,SSttaannddaarrdd,MMiilldd
Settings are preset for the optimum
picture quality at the factory and are not adjustable. In the
UUsseerr
mode only, user can directly adjust the contrast,
brightness, color, sharpness, tint.
■
You can also use the
PPIICCTTUURREE
menu to adjust
PPiicctt uurr ee MMoodd ee
.
2
1
Picture Mode : User
Color Temperature : Cool
DB
Advanced
Aspect Ratio : 16:9
Picture Reset
Picture Mode
Color Temperature
G
DB
Advanced
Aspect Ratio
Picture Reset
Dynamic
Standard
Mild
User
PICTURE CONTROL
39
VOL
CH
ENTER
BACK
MUTE
CC
MENU EXIT
Color Tone - Preset
Choose one of three automatic color adjustments. Set to warm to enhance hotter colors such as red, or set to cool to see less intense colors with more blue.
When selecting Picture Mode options (Dynamic, Standard and Mild),
CC oo lloo rr TTeemmppeerr aa tt uurree
is automatically change.
When selecting Picture Mode options (User), you can choose the
CC oo lloo rr TTeemmppeerr aa tt uurree
.
Press the
MM EE NN UU
button and then use
DD
or
EE
button
to select the
PPIICCTTUU RREE
menu.
Press the
GG
button and then use
DD
or
EE
button to
select
CCoo lloorr TTeemmpp eerraattuurree
.
Press the
GG
button and then use
DD
or
EE
button to
select either
CC oo oo ll,MM ee dd iiuumm, WWaarrmm
or
UUsseerr
.
Press
EE XX IITT
button to return to TV viewing or press
MM EE NN UU
button to return to the previous menu.
2
3
4
1
1
2 3
Picture Mode
Color Temperature
G
DB
Advanced
Aspect Ratio
Picture Reset
Cool
Medium
Warm
User
Picture Mode : User
Color Temperature : Cool
DB
Advanced
Aspect Ratio : 16:9
Picture Reset
PICTURE CONTROL
40
MANUAL PICTURE ADJUSTMENT
PICTURE CONTROL
VOL
CH
ENTER
BACK
MUTE
CC
MENU EXIT
Picture Mode - User Mode
Adjust the picture appearance to suit your preference and viewing situations.
Press the
MM EE NN UU
button and then use
DD
or
EE
button
to select the
PPIICCTTUU RREE
menu.
Press the
GG
button and then use
DD
or
EE
button to
select
PPiicctt uurr ee MMoodd ee
.
Press the
GG
button and then use
DD
or
EE
button to
select
UUsseerr
.
Press the
GG
button and then use
DD
or
EE
button to
select the desired picture option
((
BB aacc kk ll ii gghhtt
,
CCoo nnttrr aa sstt,BBrriigghhttnn eessss,CCoo lloorr,SShhaa rrpp nneess ss
, or
TTiinntt
))
.
■
BB aa cckklliigg hhtt
To control the brightness of screen, adjust the brightness of LCD panel.
Press the
GG
button and then useFFor GGbutton to
make appropriate adjustments.
Press
EE XX IITT
button to return to TV viewing or press
MM EE NN UU
button to return to the previous menu.
2
3
4
5
6
1
Backlight 100
EE
Picture Mode : User
Color Temperature : Cool
DB
Advanced
Aspect Ratio : 16:9
Picture Reset
EE
User
Backlight 100
G
Contrast 85
Brightness 50
Color 50
Sharpness 50
Tint 0
R G
Press to confirm.
MENU
Picture Mode
Color Temperature
DB
Advanced
Aspect Ratio
Picture Reset
Dynamic
Standard
Mild
User
G
Selection ( Gor ) leads you to the detailed setting screen.
2 3
1
4
5
PICTURE CONTROL
41
VOL
CH
ENTER
BACK
MUTE
CC
MENU EXIT
You can also adjust the detailed settings (Red, Green, Blue) by selecting the
CCoolloo rr TT eemm ppeerraattuu rree--UU sseerr
menu.
This feature operate only if the picture mode set
UUsseerr
.
Color Tone - User Mode
Press the
MM EE NN UU
button and then use
DD
or
EE
button
to select the
PPIICCTTUU RREE
menu.
Press the
GG
button and then use
DD
or
EE
button to
select
CCoo lloorr TTeemmpp eerraattuurree
.
Press the
GG
button and then use
DD
or
EE
button to
select
UUsseerr
.
Press the
GG
button and then use
DD
or
EE
button to
select
RR ee dd, GGrr ee ee nn
, or
BB lluuee
.
Press the
GG
button and then use
FF
or
GG
button to
make appropriate adjustments.
■
The adjustment range of
RR ee dd, GGrr ee ee nn
, or
BB ll uuee
is -
20
~ +20.
Press
EE XX IITT
button to return to TV viewing or press
MM EE NN UU
button to return to the previous menu.
2
3
4
5
6
1
2 3
1
4
5
Picture Mode
Color Temperature
DB
Advanced
Aspect Ratio
Picture Reset
Screen
Press to confirm.
MENU
Cool
Medium
Warm
User
G
User
Red 0
G
Green 0
Blue 0
Picture Mode : User
Color Temperature : Cool
DB
Advanced
Aspect Ratio : 16:9
Picture Reset
Red 0
FF
G
EE
Selection ( Gor ) leads you to the detailed setting screen.
EE
PICTURE CONTROL
42
DB - DIGITAL BOOSTER
PICTURE CONTROL
VOL
CH
ENTER
BACK
MUTE
CC
MENU EXIT
Press the
MM EE NN UU
button and then use
DD
or
EE
button
to select the
PPIICCTTUU RREE
menu.
Press the
GG
button and then use
DD
or
EE
button to
select
DD BB
.
Press the
GG
button and then use
FF
or
GG
button to
select
AAuuttoo orMM aann uuaa ll
.
Press
EE XX IITT
button to return to TV viewing or press
MM EE NN UU
button to return to the previous menu.
DB is LG Electronic’s unique picture improving technology to display a real HD source through an advanced dig-ital signal processing algorithm.
When selecting Picture Mode options (Dynamic, Standard, and Mild), DB is automatically changed to Auto.
When selecting Picture Mode option (User), you can choose the Auto / Manual.
When selecting the Manual, you can adjust the DB Contrast, DB color and DB Noise.
2
3
4
1
2 3
1
Picture Mode : User
Color Temperature : Cool
DB
Advanced
Aspect Ratio : 16:9
Picture Reset
Picture Mode
Color Temperature
DB
G
Advanced
Aspect Ratio
Picture Reset
Manual
DB Contrast On
DB Color On
DB Noise On
SSeelleeccttiinn gg tthh ee MMaann uuaall
1. Press the
EE
button and then use
DD
or
EE
but-
ton to select
DDBB CCoo nnttrr aa sstt, DDBB CCoo lloo rr
or
DDBB NNooiiss ee
.
■
DDBB CCoo nnttrr aa sstt::
Optimizing the contrast automatically according to the brightness of the reflection.
■
DDBB CCoo lloo rr::
Adjusting the colors of the reflection automatically to reproduce as closely as possible to the natural colors.
■
DDBB NNooiissee ::
Removing the noise up to the point where it does not damage the original picture.
2. Use the
DD
or
EE
button to select
OO nn
or
OO ff ff
.
PICTURE CONTROL
43
ADVANCED - BLACK (DARKNESS) LEVEL
VOL
CH
ENTER
BACK
MUTE
CC
MENU EXIT
Press the
MM EE NN UU
button and then use
DD
or
EE
button
to select the
PPIICCTTUU RREE
menu.
Press the
GG
button and then use
DD
or
EE
button to
select
AAdd vvaann cceedd
.
Press the
GG
button and then use
DD
or
EE
button to
select
BBllaacc kk lleevveell LLooww
or
HHiigghh
.
■
LL oo ww
The screen gets darker.
■
HHiigghh
The screen gets brighter.
Press
EE XX IITT
button to return to TV viewing or press
MM EE NN UU
button to return to the previous menu.
Adjusting the contrast and the brightness of the screen using the black level of the screen.
This feature operates only in AV1, AV2, HDMI1/DVI, or HDMI2 mode.
2
3
4
1
2 3
1
Picture Mode
Color Temperature
DB
Advanced
G
Aspect Ratio
Picture Reset
Black Level Low
Picture Mode : User
Color Temperature
DB
Advanced : High
Aspect Ratio : 16:9
Picture Reset
VOL
CH
ENTER
BACK
MUTE
CC
MENU EXIT
PICTURE CONTROL
44
PICTURE RESET
PICTURE CONTROL
Press the
MM EE NN UU
button and then use
DD
or
EE
button
to select the
PPIICCTTUU RREE
menu.
Press the
GG
button and then use
DD
or
EE
button to
select
PPiiccttuurree RReesseett
.
Press the
GG
button to reset the Picture menu options
to original values.
Use to quickly reset all the Picture menu options to their original factory preset values.
2
3
1
2 3
1
Picture Mode
Color Temperature
DB
Advanced
Aspect Ratio
Picture Reset
G
Picture Mode : User
Color Temperature : Cool
DB
Advanced
Aspect Ratio : 16:9
Picture Reset
Selection ( Gor ) resets to the factory settings (default).
SOUND & LANGUAGE CONTROL
45
123
456
780-9
VOL
CH
POWER
MUTE
ADJUST
SAP
FAV
PICTURE SOUND
TIMER
TV INPUT
PRESET SOUND SETTINGS (SOUND MODE)
SOUND & LANGUAGE CONTROL
Sound Mode lets you enjoy the best sound without any special adjustment because the TV sets the appropriate sound options based on the program content.
Standard, Music, News, Movie, and Sports are preset for good sound quality at the factory and are not adjustable.
Press the
SSOOUUNNDD
button repeatedly to select the appropri-
ate sound setup as below : SSttaa nnddaa rrdd
,
MM uussiicc, MM oo vviiee, SSpp oo rrttss
, and
UUsseerr
(
your own
settings
).
Press
EE XX IITT
button to return to TV viewing.
■
You can also adjust
SSoouunndd MMoo dd ee
in the
AAUUDDIIOO
menu.
2
1
Sound Mode
G
Balance
Standard
Music
Movie
Sports
User
Sound Mode : Standard
Balance : 0
SOUND & LANGUAGE CONTROL
46
SOUND &LANGUAGE CONTROL
VOL
CH
ENTER
BACK
MUTE
CC
MENU EXIT
SOUND SETTING ADJUSTMENT - USER MODE
Press the
MM EE NN UU
button and then use
DD
or
EE
button
to select the
AAUU DDII OO
menu.
Press the
GG
button and then use
DD
or
EE
button to
select
SSoouunndd MMoo dd ee
.
Press the
GG
button and then use
DD
or
EE
button to
select
UUsseerr
.
Press the
GG
button and then use
DD
or
EE
button to
select the desired sound option (
TTrreebbllee
or
BB aa ss ss
).
Press the
GG
button and then use
FF
or
GG
button to
make appropriate adjustments.
Press
EE XX IITT
button to return to TV viewing or press
MM EE NN UU
button to return to the previous menu.
Adjust the sound to suit your taste and room situations.
2
3
4
5
6
1
Sound Mode
Balance
Standard
Music
Movie
Sports
User
G
User
Treble 50
G
Bass 50
Press to confirm.
MENU
2 3
4
5
1
Sound Mode : Standard
Balance : 0
Treble 85
FF
G
EE
Selection (
G
or ) leads you to the detailed setting screen.
EE
SOUND & LANGUAGE CONTROL
47
BALANCE
VOL
CH
ENTER
BACK
MUTE
CC
MENU EXIT
Press the
MM EE NN UU
button and then use
DD
or
EE
button
to select the
AAUU DDII OO
menu.
Press the
GG
button and then use
DD
or
EE
button to
select
BB aa llaanncc ee
.
Press the
GG
button and then use
FF
or
GG
button to
make appropriate adjustments.
Press
EE XX IITT
button to return to TV viewing or press
MM EE NN UU
button to return to the previous menu.
Adjust the left/right sound of speaker to suit your taste and room situations.
L R
Balance 0
2
3
4
1
1
2
3
Sound Mode
Balance 0
L R
Sound Mode : Standard
Balance : 0
SOUND & LANGUAGE CONTROL
48
STEREO/SAP BROADCASTS SETUP
SOUND &LANGUAGE CONTROL
123
456
780-9
VOL
CH
POWER
MUTE
ADJUST
SAP
FAV
PICTURE SOUND
TIMER
TV INPUT
This TV can receive MTS stereo programs and any SAP (
Secondary Audio Program)that accompanies the stereo program if the station transmits an additional sound signal as well as the original one and when you select Stereo or SAP on the remote control.
Mono sound is automatically received if the broadcast is only in Mono; even though Stereo or SAP has been selected.
Select Mono if you want to listen to the mono sound in remote areas during stereo/SAP broadcasting.
Stereo or SAP can be received in Analog channel.
Use the
SS AAPP
button to select your desired MTS mode in
analog signal. Each time you press the
SS AAPP
button,
MM oo nnoo
,
SStt eerreeoo
, or
SS AAPP
appear in turn.
■
If other languages available on the digital signal, select them with the
SS AAPP
button.
Press
EE XX IITT
button to save and return to TV viewing.
2
1
SOUND & LANGUAGE CONTROL
49
AUDIO LANGUAGE
VOL
CH
ENTER
BACK
MUTE
CC
MENU EXIT
Other languages may be available if a digital signal is provided by the broadcasting station.
This feature operates only in DTV/CADTV mode.
Press the
MM EE NN UU
button and then use
DD
or
EE
button
to select the
OOPPTT IIOONN
menu.
Press the
GG
button and then use
DD
or
EE
button to
select
LLaanngguu aa ggee
.
Press the
GG
button and then use
DD
or
EE
button to
select
AAuudd iioo
.
Press the
GG
button and then use
FF
or
GG
button to
select
EE nngg lliisshh, SSpp aa nniiss hh
, or
FFrr eenncc hh
.
Press
EE XX IITT
button to return to TV viewing or press
MM EE NN UU
button to return to the previous menu.
2
3
4
5
1
2 3
1
4
Language :
English
Key Lock : Off
Caption : Off
Language
G
Key Lock
Caption
Language
Key Lock
Caption
Menu English
Audio
FF
English
GG
Menu English
Audio English
SOUND & LANGUAGE CONTROL
50
ON-SCREEN MENUS LANGUAGE SELECTION
SOUND &LANGUAGE CONTROL
VOL
CH
ENTER
BACK
MUTE
CC
MENU EXIT
The menus can be shown on the screen in the selected language. First select your language.
Press the
MM EENN UU
button and then use
DD
or
EE
button
to select the
OOPPTTIIOONN
menu.
Press the
GG
button and then use
DD
or EEbutton to
select
LLaanngguu aa ggee..
Press the
GG
button and then use
DD
or EEbutton to
select
MM ee nnuu..
Press the
GG
button and then use
FF
or
GG
button to
select your desired language. From this point on, the on-screen menus will be shown
in the selected language.
Press the
EE XX IITT
button to return to TV viewing or
press
MM EENN UU
to return to the previous menu.
1
2
3
4
5
2 3
1
4
Language : English
Key Lock : Off
Caption : Off
Language
G
Key Lock
Caption
Language
Key Lock
Caption
Menu FFEnglish
GG
Audio English
Menu English
Audio English
SOUND & LANGUAGE CONTROL
51
CAPTION MODE
VOL
CH
ENTER
BACK
MUTE
CC
MENU EXIT
Caption must be provided to help people with hearing loss watch TV.
Language :
English
Key Lock : Off
Caption : Off
Language
Key Lock
Caption
Mode FFOn
GG
Analog Text1
Digital Service3
Digital Option
Use the
CC CC
button to select Caption
OO nn
or
OO ff ff
.
■
When selecting
OO ff ff
,
Sub-menus for Analog, DTV, and
Digital Option become disabled.
Press
EE XX IITT
to save and return to TV viewing.
2
1
■
You can also adjust
CC aa pp ttiioonn
in the
OOPPTTIIOONN
menu.
SOUND & LANGUAGE CONTROL
52
SOUND &LANGUAGE CONTROL
VOL
CH
ENTER
BACK
MUTE
CC
MENU EXIT
Analog Broadcasting System Captions
Select a caption mode for displaying captioning information if provided on a program. Analog caption displays information at any position on the screen and is usually the program's dialog.
Caption/Text, if provided by the broadcaster, would be available for both digital and analog channels on the Antenna/Cable.
This TV is programmed to memoririze the caption/text mode which was last set when you turn the power off.
This function is only available when
CCaapp tt iioonn
Mode is set
OO nn
.
Press the
MM EENN UU
button and then use
DD
or
EE
button
to select the
OOPPTTIIOONN
menu.
Press the
GG
button and then use
DD
or EEbutton to
select
CC aa pp ttiioonn..
Press the
GG
button and then use
DD
or EEbutton to
select
AAnnaalloogg..
Press the
GG
button and then use
FF
or
GG
button to
select
CC CC 11, CC CC 22, CC CC 33, CC CC 44, TTeexxtt11, TTeexxtt22
,
TTeexxtt33
or
TTeexxtt44
■
CC AAPPTTIIOONN
The term for the words that scroll across the bottom of the TV screen; usually the audio portion of the program provided for the hearing impaired.
■
TTEEXX TT
The term for the words that appear in a large black frame and almost cover the entire screen; usually mes­sages provided by the broadcaster.
Press the
EE XX IITT
button to return to TV viewing or
press
MM EENN UU
to return to the previous menu.
1
2
3
4
5
1
3 42
Language :
English
Key Lock : Off
Caption : Off
Language
Key Lock
Caption
Mode On
Analog
FF
Text1
GG
Digital Service3
Digital Option
SOUND & LANGUAGE CONTROL
53
VOL
CH
ENTER
BACK
MUTE
CC
MENU EXIT
Press the
MM EE NN UU
button and then use
DD
or
EE
button
to select the
OOPPTT IIOONN
menu.
Press the
GG
button and then use
DD
or
EE
button to
select
CC aa pp ttiioonn
.
Press the
GG
button and then use
DD
or
EE
button to
select
DDiigg iitt aa ll
.
Press the
GG
button and then use
FF
or
GG
button to
select
SSeerr vviiccee11~SSeerr vviiccee66
.
Press
EE XX IITT
button to return to TV viewing or press
MM EE NN UU
button to return to the previous menu.
Choose the language you want the DTV/CADTV Captions to appear in.
Other Languages can be chosen for digital sources only if they are included on the program.
This function in only available when Caption Mode is set On.
2
3
4
5
1
Digital Broadcasting System Captions
1
3 42
Language :
English
Key Lock : Off
Caption : Off
Language
Key Lock
Caption
Mode On
Analog Text1
Digital
FF
Service3
GG
Digital Option
VOL
CH
ENTER
BACK
MUTE
CC
MENU EXIT
SOUND & LANGUAGE CONTROL
54
SOUND &LANGUAGE CONTROL
Caption Option
Customize the DTV/CADTV captions that appear on your screen.
This function in only available when Caption Mode is set On.
Press the
MM EE NN UU
button and then use
DD
or
EE
button
to select the
OOPPTT IIOONN
menu.
Press the
GG
button and then use
DD
or
EE
button to
select
CC aa pp ttiioonn
.
Press the
GG
button and then use
DD
or
EE
button to
select
DDiiggiittaall OOppttiioonn
.
Press the
GG
button and then use
FF
or
GG
button to
select
CC uussttoomm
.
Use
DD
or
EE
button to customize the
SStt yyllee, FFoo nntt
,
etc., to your preference. A preview icon is provided at the bottom of the
screen, use it to see the caption language.
■
SSiizzee
: Set the word size.
■
FFoonntt
: Select a typeface for the text.
■
TTeexxtt CCoolloorr
: Choose a color for the text.
■
TTeexxtt OOppaacciittyy
: Specify the opacity for the text color.
■
BBgg ((BBaacckkggrroouunndd))CCoolloorr
: Select a background color.
■
BBgg ((BBaacckkggrroouunndd))OOppaacciittyy
: Select the opacity for the
background color.
■
EEddggee TTyyppee
: Select an edge type.
■
ddggee CCoolloorr
: Select a color for the edges.
Press
EE XX IITT
button to return to TV viewing or press
MM EE NN UU
button to return to the previous menu.
2
3
4
5
6
1
1
2 3
4 5
Language :
English
Key Lock : Off
Caption : Off
Language
Key Lock
Caption
Mode On
Analog Text1
Digital Service3
Digital Option
G
Selection ( Gor ) leads you
to the Caption Option Screen.
Language
Key Lock
Caption
Mode On
Analog Text1
Digital Service3
Digital Option
G
Selection ( Gor ) leads you
to the Caption Option Screen.
Style Custom
Size A Standard Font Font 0 Text Color White Text Opacity
Solid Bg Color Black Bg Opacity Solid Edge Type None Edge Color Black
TIME SETTING
55
CLOCK SETTING
TIME SETTING
VOL
CH
ENTER
BACK
MUTE
CC
MENU EXIT
Auto Clock Setup
The time is set automatically from a digital channel signal. The digital channel signal includes information for the
current time provided by the broadcasting station. Set the clock manually if the current time is set incorrectly
by the auto clock function.
Press the
MM EE NN UU
button and then use
DD
or
EE
button
to select the
TTIIMMEE
menu.
Press the
GG
button and then use
DD
or
EE
button to
select
CC lloo cckk
.
Press the
GG
button and then use
DD
or
EE
button to
select
AAuutt oo
.
Press the
GG
button and then use
DD
or
EE
button to
select your viewing area time zone:
EE aa ssttee rrnn, CC ee nn ttrraa ll
,
MM oo uunn ttaaiinn, PPaa cc ii ff iicc, AAllaasskk aa
or
HHaaww aa iiii
.
Press the
GG
button and then use
DD
or
EE
button to
select
AAuutt oo, OO ff ff, OO nn
, depending on whether or not
your viewing area observes Daylight Saving time.
Press
EE XX IITT
button to return to TV viewing or press
MM EE NN UU
button to return to the previous menu.
2
3
4
5
6
1
1
32
54
Clock
G
Off Time
On Time
Sleep Time
Auto Sleep
Time Zone Eastern
Auto
Daylight Saving
Clock : Oct 19, 2006, 03:44 AM
Off Time : Off
On Time : Off
Sleep Time : Off
Auto Sleep : Off
Year - - - ­Date - - / - ­Time - - : - - - -
Auto
Clock
G
Off Time
On Time
Sleep Time
Auto Sleep
Auto
Year - - - ­Date - - / - ­Time - - : - - - -
Auto
Time Zone Eastern
Daylight Saving
DD EE
G
DD EE
G
TIME SETTING
56
TIME SETTING
VOL
CH
ENTER
BACK
MUTE
CC
MENU EXIT
Manual Clock Setup
Press the
MM EE NN UU
button and then use
DD
or
EE
button
to select the
TTIIMMEE
menu.
Press the
GG
button and then use
DD
or
EE
button to
select
CC lloo cckk
.
Press the
GG
button and then use
DD
or
EE
button to
select
MM aann uuaa ll
.
Press the
GG
button and then use
FF
or
GG
button to select either the year, date, or time option. Once selected, use the
DD
or
EE
button to set the year, date,
and time options.
Press
EE XX IITT
button to return to TV viewing or press
MM EE NN UU
button to return to the previous menu.
If the current time setting is wrong, reset the clock manually.
2
3
4
5
1
1
32
Clock
G
Off Time
On Time
Sleep Time
Auto Sleep
Clock : Oct 19, 2007, 03:44 AM
Off Time : Off
On Time : Off
Sleep Time : Off
Auto Sleep : Off
Year - - - ­Date - - / - ­Time - - : - - - -
Manual
DD EE
G
TIME SETTING
57
AUTO ON/OFF TIMER SETTING
VOL
CH
ENTER
BACK
MUTE
CC
MENU EXIT
Press the
MM EE NN UU
button and then use
DD
or
EE
button
to select the
TTIIMMEE
menu.
Press the
GG
button and then use
DD
or
EE
button to
select
OOffff TT iimmee
or
OOnn TTiimmee
.
Press the
GG
button and then use
DD
or
EE
button to
select
OO nn
.
■
To cancel the
OOnn//OOff ff ttiimmee
function, select
OO ff ff
.
Press the
GG
button and then use
DD
or
EE
button to set
the hour.
Press the
GG
button and then use
DD
or
EE
button to set
the minutes.
OOnnll yy OOnn ttiimmeerr
Press the
GG
button and then use
DD
or
EE
button to
select the channel at turn-on.
Press the
GG
button and then use
DD
or
EE
button to set
the sound level at turn-on.
Press
EE XX IITT
button to return to TV viewing or press
MM EE NN UU
button to return to the previous menu.
2
3
4
5
6
7
1
The timer function operates only if the current time has been set.
The Off-Timer function overrides the On-Timer function if they are both set to the same time.
The TV must be in standby mode for the On-Timer to work. If you do not press any button within 2 hours after the TV
turns on with the On Timer function, the TV will automati­cally revert to standby mode.
1
32 54 6
Clock
Off Time
On Time
G
Sleep Time
Auto Sleep
Off On
Time 6 : 30 AM Ch. TV 2-0 Vol 17
Clock : Oct 19, 2007, 03:44 AM
Off Time : Off
On Time : Off
Sleep Time : Off
Auto Sleep : Off
TIME SETTING
58
TIME SETTING
SLEEP TIMER SETTING
123
456
780-9
VOL
CH
POWER
MUTE
ADJUST
SAP
FAV
PICTURE SOUND
TIMER
TV INPUT
Press the
TTIIMMEE RR
button repeatedly to select the number of
minutes. First the
OO ff ff
option appears on the screen, followed by the following sleep timer options : 10, 20, 30, 60, 90, 120, 180, and 240 minutes.
When the number of minutes you want is displayed on the screen, press the
EE NN TTEERR
button. The timer begins to count
down from the number of minutes selected.
To check the remaining minutes before the TV turns off, press the
TTIIMMEE RR
button once.
To cancel the Sleep Timer, press the
TTIIMMEE RR
button repeat-
edly to select
OO ff ff
.
The Sleep Timer turns the TV off at the preset time. Note that this setting is cleared when the TV is turned off.
■
You can also set up the
SSlleeeepp TT iimmeerr
in the
TT IIMMEE
menu.
2
3
4
1
Clock
Off Time
On Time
Sleep Time
G
Auto Sleep
Off
10 min
20 min
30 min
60 min
90 min
120 min
180 min
240 min
Clock : Oct 19, 2006, 03:44 AM
Off Time : Off
On Time : Off
Sleep Time : Off
Auto Sleep : Off
TIME SETTING
59
AUTO SHUT-OFF SETTING
VOL
CH
ENTER
BACK
MUTE
CC
MENU EXIT
If set to on and there is no input signal, the TV turns off automatically after 10 minutes.
Press the
MM EE NN UU
button and then use
DD
or
EE
button
to select the
TTIIMMEE
menu.
Press the
GG
button and then use
DD
or
EE
button to
select
AAuuttoo SSlleeeepp
.
Press the
GG
button and then use
DD
or
EE
button to
select
OO nn
or
OO ff ff
.
Press
EE XX IITT
button to return to TV viewing or press
MM EE NN UU
button to return to the previous menu.
2
3
4
1
1
32
Clock
Off Time
On Time
Sleep Time
Auto Sleep
G
Off On
TV will be automatically turned off, in case of No Signal for 10 minutes.
Clock : Oct 19, 2007, 03:44 AM
Off Time : Off
On Time : Off
Sleep Time : Off
Auto Sleep : Off
PARENTAL CONTROL / RATING
60
PARENTAL CONTROL / RATINGS
Parental Control can be used to block specific channels, ratings and other viewing sources.
The Parental Control Function (V-Chip) is used to block program viewing based on the ratings sent by the broadcasting station. The default setting is to allow all programs to be viewed. Viewing can be blocked by choosing the type of the program and the categories. It is also possi­ble to block all program viewing for a time period. To use this function, the following must be done :
1. Set ratings and categories to be blocked.
2. Specify a password
3. Enable the lock
V-Chip rating and categories
Rating guidelines are provided by broadcasting stations. Most television programs and television movies can be blocked by TV Rating and/or Individual Categories. Movies that have been shown at the theaters or direct-to-video movies use the Movie Rating System (MPAA)only.
Ratings for Television programs including made-for-TV movies :
■
TV-G(General audience
)
■
TV-PG(Parental guidance suggested
)
■
TV-14(Parents strongly cautioned
)
■
TV-MA (Mature audience only
)
■
TV-Y(All children
)
■
TV-Y7(Children 7 years older
)
SET PASSWORD & LOCK SYSTEM
Set up blocking schemes to block specific channels, ratings, and external viewing sources.
A password is required to gain access to this menu.
Press the
MM EE NN UU
button and then use the
DD
or
EE
button
to select the
LLOOCC KK
menu. Then, press the
GG
button.
■
Enter the password as requested.
■
The TV is set up with the initial
password “0-0-0-0”.
VOL
CH
ENTER
BACK
MUTE
CC
MENU EXIT
Enter Password
1
Enter Password
** **
Setting up Your Password
PARENTAL CONTROL / RATING
61
After inputting the password, use the
DD
or
EE
button
to choose
SSeett ppaassss wwoo rrdd
.
Press the
GG
button and then choose any 4 digits for
your new password. As soon as the 4 digits are entered, re-enter the same
4 digits on the
CC oo nnffiirr mm
.
Then your changed password has been memorized.
Press
EE XX IITT
to return to TV viewing or press
MM EE NN UU
to return to the previous menu.
Change the password by inputting a new password twice.
Lock System
Set Password
G
Movie Rating
TV Rating-Children
TV Rating-General
New
Confirm
2
3
1
**** ****
1
2
NOTE
!
GG
If you ever forget your password, key in ‘7’, ‘7’, ‘7’, ‘7’ on the remote control.
After inputting the password, use the
DD
or
EE
button
to choose
LLoocckk SSyysstteemm
.
Press the
GG
button and then use the
DD
or
EE
button
to select
OO nn
or
OO ff ff
.
■
When you select
OO nn
, the Lock System is enable.
Press
EE XX IITT
button to return to TV viewing or press
MM EE NN UU
button to return to the previous menu.
Enables or disables the blocking scheme you set up previously.
Lock System
G
Set Password
Movie Rating
TV Rating-Children
TV Rating-General
Off On
2
3
1
1
2
Set Password
Lock System
Lock System : Off
Set Password
Movie Rating
TV Rating-Children
TV Rating-General
Lock System : Off
Set Password
Movie Rating
TV Rating-Children
TV Rating-General
PARENTAL CONTROL / RATING
62
PARENTAL CONTROL /RATINGS
ENTER
BACK
CC
MENU EXIT
MOVIE & TV RATING
Movie Rating (MPAA)
Blocks movies according to the movie ratings limits speci­fied, so children cannot view certain movies. You can set the ratings limit by blocking out all the movies with the ratings above a specified level. Keep in mind that the movie ratings limit only applies to movies shown on TV, not TV programs, such as soap operas.
After inputting the password, use the
DD
or
EE
button
to choose
MM oo vvii ee RR aa ttiinn gg
.
Press the
GG
button and then use the
DD
or
EE
button
to select GG,
PP GG, PPGG --1133, RR, NNCC --1177
or XX.
■
G (General audience)
■
PG (Parental guidance suggested)
■
PG-13 (Parents strongly cautioned)
■
R (Restricted)
■
NC-17 (No one 17 and under admitted)
■
X (Adult only)
■
Blocking Off (Permits all programs)
Press
EE XX IITT
button to return to TV viewing or press
MM EE NN UU
button to return to the previous menu.
GG
If you set PG-13 : G and PG movies will be available,
PG-13, R, NC-17 and X will be blocked.
Lock System
Set Password
Movie Rating
G
TV Rating-Children
TV Rating-General
Blocking off : permits all programs
G PG PG-13 R NC-17
X Blocking Off
2
3
1
1
2
Lock System : Off
Set Password
Movie Rating
TV Rating-Children
TV Rating-General
PARENTAL CONTROL / RATING
63
TV Rating Children
After inputting the password, use the
DD
or
EE
button to
choose
TTVV RRaa tt iinngg --CChh iillddrr eenn
.
Press the
GG
button and then use the
DD
or
EE
button to
select
AA ggee
, or
FFaanntt aa ssyy VViioolleennccee
.
Press the
GG
button and then use the
DD
or
EE
button to
select block options.
■
Age(applies to TV-Y, TV-Y7)
■
Fantasy Violence(applies to TV-Y7)
Press
EE XX IITT
button to return to TV viewing or press
MM EE NN UU
button to return to the previous menu.
Prevents children from watching certain children's TV pro­grams, according to the ratings limit set. The children rating does not apply to other TV programs. Unless you block cer­tain TV programs intended for mature audiences in the TV Rating - sub menu, your children can view those programs.
TV Rating General
After inputting the password, use the
DD
or
EE
button to
choose
TTVV RRaa tt iinngg --GG eenneerraall
.
Press the
GG
button and then use the
DD
or
EE
button to
select
AA ggee, DDiiaalloogg uuee, LLaanngguu aa ggee, SS ee xx
or
VViioolleennccee
.
Press the
GG
button and then use the
DD
or
EE
button to
select block options.
■
Age(applies to TV-G,TV-PG,TV-14,TV-MA)
■
Dialogue-sexual dialogue (applies to TV-PG,TV-14)
■
Language-adult language (applies to TV-PG,TV-14,TV-MA)
■
Sex-sexual situations (applies to TV-PG,TV-14,TV-MA)
■
Violence (applies to TV-PG,TV-14,TV-MA)
Press
EE XX IITT
button to return to TV viewing or press
MM EE NN UU
button to return to the previous menu.
Based on the ratings, blocks certain TV programs that you and your family do not want to view.
Lock System
Set Password
Movie Rating
TV Rating-Children
G
TV Rating-General
Age Fantasy Violence
Lock System
Set Password
Movie Rating
TV Rating-Children
TV Rating-General
G
Age Dialogue Language Sex Violence
2
3
1
2
3
1
1
2
1
2
Lock System : Off
Set Password
Movie Rating
TV Rating-Children
TV Rating-General
Lock System : Off
Set Password
Movie Rating
TV Rating-Children
TV Rating-General
PARENTAL CONTROL / RATING
64
APPENDIX
TROUBLESHOOTING
TThhee ooppeerraattiioonn ddooeess nnoott wwoorrkk nnoorrmmaallllyy..
TThhee vviiddeeoo ffuunnccttiioonn ddooeess nnoott wwoorrkk..
No picture &No sound
No or poor color
or poor picture
Poor reception on
some channels
Lines or streaks
in pictures
Horizontal/vertical bars
or picture shaking
Picture appears slowly
after switching on
The remote control
doesn’t work
Power is suddenly
turned off
■
Check to see if there is any object between the product and the remote control causing obstruction. Ensure you are pointing the remote control directly at the TV.
■
Ensure that the batteries are installed with correct polarity (+ to +, - to -).
■
Ensure that the correct remote operating mode is set: TV, VCR etc.
■
Install new batteries.
■
Is the sleep timer set?
■
Check the power control settings. Power interrupted.
■
No broadcast on station tuned with Auto off activated.
■
Check whether the product is turned on.
■
Try another channel. The problem may be with the broadcast.
■
Is the power cord inserted into wall power outlet?
■
Check your antenna direction and/or location.
■
Test the wall power outlet, plug another product’s power cord into the outlet where the product’s power cord was plugged in.
■
This is normal, the image is muted during the product startup process. Please contact your service center, if the picture has not appeared after five minutes.
■
Adjust Color in menu option.
■
Keep a sufficient distance between the product and the VCR.
■
Try another channel. The problem may be with the broadcast.
■
Are the video cables installed properly?
■
Activate any function to restore the brightness of the picture.
■
Check for local interference such as an electrical appliance or power tool.
■
Station or cable product experiencing problems, tune to another station.
■
Station signal is weak, reorient antenna to receive weaker station.
■
Check for sources of possible interference.
■
Check antenna (Change the direction of the antenna).
APPENDIX
65
TThheerree iiss aa pprroobblleemm iinn PPCC mmooddee.. ((OOnnllyy PPCC mmooddee aapppplliieedd))
■
Adjust resolution, horizontal frequency, or vertical frequency.
■
Check the input source.
■
Work the Auto configure or adjust clock, phase, or H/V position. (Option)
■
Check the signal cable.
■
Reinstall the PC video card.
The signal is out of range
Screen color is unstable
or single color
Vertical bar or stripe on
background &
Horizontal Noise &
Incorrect position
■
Press the VOL or VOLUME button.
■
Sound muted? Press MUTE button.
■
Try another channel. The problem may be with the broadcast.
■
Are the audio cables installed properly?
■
Adjust Balance in menu option.
■
A change in ambient humidity or temperature may result in an unusual noise when the product is turned on or off and does not indicate a fault with the product.
Picture OK & No sound
Unusual sound from
inside
the product
No output from one
of the speakers
TThhee aauuddiioo ffuunnccttiioonn ddooeess nnoott wwoorrkk..
APPENDIX
66
MAINTENANCE
APPENDIX
Early malfunctions can be prevented. Careful and regular cleaning can extend the amount of time you can enjoy your new TV.
Caution: Be sure to turn the power off and unplug the power cord before you begin any cleaning.
Cleaning the Screen
Here’s a great way to keep the dust off your screen for a while. Wet a soft cloth in a mixture of lukewarm water and a little fabric softener or dish washing detergent. Wring the cloth until it’s almost dry, and then use it to wipe the screen.
Make sure the excess water is off the screen, and then let it air-dry before you turn on your TV.
Cleaning the Cabinet
■
To remove dirt or dust, wipe the cabinet with a soft, dry, lint-free cloth.
■
Please be sure not to use a wet cloth.
Extended Absence
GG
If you expect to leave your TV dormant for a long time (such as a vacation), it’s a good idea to unplug the power cord to protect against possible damage from lightning or power surges.
CAUTION
2
1
APPENDIX
67
PRODUCT SPECIFICATIONS
■
The specifications shown above may be changed without prior notice for quality improvement.
19LS4D
(19LS4D-UA)
22LS4D
(22LS4D-UA)
MODELS
18.0 x 15.6 x 6.8 inches
456.8 x 396.6 x 172.0mm
18.0 x 14.5 x 2.8 inches
456.8 x 368.5 x 70.5 mm
11.5 pounds / 5.2 kg
10.1 pounds / 4.6 kg
20.7 x 17.4 x 7.4 inches
525.4 x 441.6 x 187.4 mm
20.7 x 16.3 x 2.7 inches
525.4 x 413.0 x 68.6 mm
12.8 pounds / 5.8 kg
11.5 pounds / 5.2 kg
AC100-240V ~ 50/60Hz
NTSC-M, ATSC, 64 & 256 QAM
VHF 2-13, UHF 14-69, CATV 1-135, DTV 2-69, CADTV 1-135
75 ohm
32 ~ 104°F (0 ~ 40°C)
Less than 80%
-4 ~ 140°F (-20 ~ 60°C)
Less than 85%
Dimensions
(Width x Height x Depth)
Weight
Power requirement
Television System
Program Coverage
External Antenna Impedance
Environment condition
Including stand
Excluding stand
including stand
excluding stand
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
