Zeeva SP0167 User Manual
BASS JAXX
Bluetooth Giant Speaker
Instruction Manual
Contents
1
Introduction
2
Package Contents
3
Connection Diagram
4
How to use
4.1 General function
4.2 Pairing to mobile phone
4.3 Charging your speaker
5
Product Specifications
6
FAQ
7
FCC Statement
1.Introduction 2. Package Contents
1
2
2
3
3
4
5
6
6
7
Congratulations, and thank you for
choosing the Bluetooth Giant Speaker.
This manual will help you operate
the Bluetooth Giant Speaker, but you
should first familiarize yourself with the
Bluetooth functionality of your mobile
phone or other devices before using
the Bluetooth Giant Speaker.
Safety Rules
1 Please follow the rules depicted in this
manual closely to ensure your safety.
Before using this Bluetooth speaker, we
would strongly encourage you to read
through this user manual.
2 Be wary of any edges, uneven
surfaces, metal parts, accessories and
its packaging to prevent any possible
injury or damage.
Do not modify, repair or dismantle this
3
speaker. Doing so may result
in fire, electric shock, complete
breakdown of this Bluetooth speaker,
etc. All of which are not covered under
warranty.
Do not use any diluent or volatile liquid
4
to clean the Bluetooth speaker.
Do not use the Bluetooth speaker in a
5
hazardous location.
1X Bluetooth Giant Speaker
3.Connection Diagram
Front Back
1X Aux-in Cable
1X Micro USB Cable
1X User Manual
4 3 2 1
DC5VAUDIO-IN OFF/ON
1. On/Off Switch
2. Micro USB Charging Port
3. LED Indicator
4. Aux-in Port
Rechargeable
Li-ion Battery
4.How to use
4.1.General Functions
Desired Result Required Action
Turn on &
Enter the
pairing mode
Pairing
Turn off
Charging
Aux-in Mode
Slide the button to the right.
Use a Bluetooth enabled mobile
phone or other Bluetooth enabled
device to perform necessary
pairing action.
Slide the button to the left.
Plug the Micro USB end to the
port for charging device.
Plug the Aux-in cable to the audio
port, then plug the other end to
your music device.
1 2 3
4.2.Pairing to a mobile phone or other device
To use your Bluetooth speaker, you must
first pair your speaker with a phone or a
computer. Once your Bluetooth speaker
is paired to a specific mobile device, they
will remain paired and automatically
recognize each other whenever they are
within range.
Pairing to a Bluetooth Enabled Mobile Phone:
Turn on your phone and ensure the Bluetooth
function is activated.
Turn on the speaker, enter the pairing mode.
Search the Bluetooth devices on your phone
by following the phone’s instructions. Refer
to your phone’s user manual for more
information.
After a few seconds the phone will list the
“SP-0167-Giant Speaker” as a discover device.
Select it and follow your phone’s instructions
to select this pairing.
You can play music, watch TV shows/movies,
and play games with your device, with all of
the sound coming from the speaker.
4.3.Charging your speaker
Use the Micro USB cable provided with
this speaker. Connect the Micro USB
plug to the Micro USB charging port on
the speaker positioned at in speaker
diagram on page 2. Connect the USB
plug to a USB port on a computer or
wall adapter to activate charging.
**Make sure to keep the speaker charging
for a minimum of 6 hours before initial use.
USB Plug Micro USB Plug
Warning:
You must select a qualified charger from
a regular manufacturer.
You must charge the Bluetooth speaker
if it has been not used for more than 12
months.
2
5.Product Specifications 7.FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is
Bluetooth Version
Bluetooth Range
Driver Diameter
Output Power
Impedance
Battery Capacity
Working Hours
Charging Hours
Charge Type
2.1
≤ 32 Feet
76 mm
5 W
Voltage
3.7 V
4 Ohms
900mAh Li-ion Battery
5-6 Hours
3-4 Hours
Micro USB Cable (Included)
6.FAQ
1.Why is there no power even when the
Speaker is turned on?
Ans: Ensure the battery has been charged
up to 6 hours for initial use.
2.There is no sound during playback.
Ans: Check the connection between the
speaker and the phone or computer, if the
connection is not established,please connect
again.Make sure the speaker is paired with
your Bluetooth enabled device.
subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) This
device must accept any interference received,
including interference that may cause undesired operation.
Warning: Changes or modications to this unit not expressly
approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
“FCC RF Radiation Exposure Statement Caution:
To maintain compliance with the FCC’s RF exposure guidelines,
place the product at least 20cm from nearby persons.”
FCC ID: 2ADM5-SP0167
iPod®, iPhone® and iPad® are trademarks
of Apple Inc. registered in the U.S. and other
countries. Android
™ is trademarks of Google, Inc.
Keep All Relevant information for Future Reference
