Zebra
Incredibly robust. Totally reliable.
Extremely fast.
Designed to deliver the perfect blend of performance and functionality, the robust
and reliable Xi series printers are optimised for high-volume operations.
Zebra Xi series printers are legendary for their durability, outstanding print quality,
fast throughput, long life and unparalleled reliability in demanding applications.
These qualities translate into low total cost of ownership – making them an ideal
smart investment for businesses with high-volume, mission-critical and speciality
labelling applications.
Xi4™ printers build on this legacy to boost operational productivity beyond previous
Xi generations with faster print speeds on selected models, dependable print quality
and enhanced early-warning systems.
Versatile connectivity options plus remote printer deployment/management via
ZebraLink™ Solutions ensure that integration is now even easier.
Xi™
series
®
Ideal for:
Manufacturing
Work-in-progress labelling•
Asset management•
Inventory management•
Product-identification labelling•
Compliance labelling•
Enhanced Xi4 printers feature:
Dependable print quality – on-board diagnostics to ensure optimum print quality•
Faster print speeds – up to 356mm per second (110Xi4™ and 140Xi4™) for •
increased batch and print/apply productivity
Large easy-to-read front panel with LCD content and navigation customisable •
to meet user needs
Fast 10/100 Ethernet connectivity as standard•
Improved ribbon- and media-low LCD/network alerts•
RFID-upgrade-ready (110Xi4)•
Transport and logistics
Receiving and shipping labels•
Asset-tracking labels•
Government and public sector
Military logistics•
Get the most out of your Zebra: put genuine Zebra supplies in!
Zebra offers a wide range of supplies for Xi printers, all made to a high standard
and suitable for a variety of applications.
Manufactured exclusively for Zebra printers•
Laboratory-tested for optimum performance•
Proven to minimise wear and tear on printheads•
For more information, visit www.zebra.com
Xi
series printers and accessories
Meet the Xi4 family!
Xi4 printers offer superior ZebraLink
Solutions, including:
Software
ZebraDesigner™ Pro – An intuitive, easy-to-use •
software program that makes creating complex
label designs and changing label format simple
ZebraDesigner – Offers basic design features •
focused on delivering an easy-to-use label
design application
ZebraNet™ Bridge Enterprise – Centrally manage •
Zebra printers from a single PC screen anywhere on
your global network
ZebraNet Utilities v 7.0 – Provides enhanced printing, •
conversion and administration capabilities, message
management and more
Zebra Universal Driver – The most powerful driver •
available from Zebra
ZBI-Developer™ – Intuitive programming utility used •
to create, test and distribute ZBI™ applications
Networking
Firmware
®
ZebraNet•
– Delivers wireless security and new wireless
capabilities
ZebraNet 10/100 Print Server – Available in an •
internal or external version that provides a complete
wired solution for 10Base-T, 100Base-TX and Fast
Ethernet 10/100 auto-switching networks
APL™ – In many cases, Zebra’s Alternate •
Programming Language allows integration of the
Xi series printers into mixed printer environments
without format re-programming (available on 203dpi
printers only)
ZPL II•
simplifies label formatting and enables format
compatibility with other Zebra printers
XML-enabled printing – Direct-connect integration •
for bar-code-label printing that eliminates licence
fees and printer server hardware, and lowers
customisation and programming costs
Web View – Enables you to connect and control your •
bar code printer’s Web interface using a common
Web browser
Alert – Printers equipped with ZebraNet print servers •
will notify you via any e-mail-enabled wired or
wireless device to minimise downtime
ZBI – Optional, powerful programming enhancement •
that lets printers run stand-alone applications,
connect to peripherals, and much more
Internal Wireless Plus Print Server
®
– Universal language for Zebra printers
110Xi4 – 203/300dpi 110Xi4 – 600dpi
The 110Xi4, with 203- or 300dpi printhead, prints
up to four inches wide, making it ideal for shipping,
warehousing and manufacturing. For crisp, high-quality
printing on small product labels, order the 110Xi4 with
300dpi printhead.
Technical specifications*
Maximum print area
Width: 102mm (4")
Length: 991mm (39")
Resolution
8 dots/mm (203dpi)
12 dots/mm (300dpi)
Maximum print speed
203dpi: 356mm (14") per second
300dpi: 305mm (12") per second
Physical characteristics
Width: 261.9mm (10.31")
Depth: 517.5mm (20.38")
Height: 393.7mm (15.5")
Weight: 22.7kg (50lb)
Media specifications
Label and liner width: 20mm (0.79") to 114mm (4.5")
Ribbon width: 20mm (0.79") to 110mm (4.33")
RFID upgrade-ready
The 110Xi4 printer has an RFID-ready option that
allows you to upgrade to RFID technology in the future.
Upgrade kit for UHF EPC Gen 2, Class 1-compliant.
RFID enablement coming soon.
110Xi4 with 600dpi printhead is unmatched at printing
precise bar codes, text and graphics in limited label
space. This printer is ideal when you require extremely
high resolution and density – for labelling electronic
components, telecommunication assemblies, medical
devices, pharmaceutical vials, and more.
Technical specifications*
Maximum print area
Width: 102mm (4")
Length: 991mm (39")
Resolution
23.5 dots/mm (600dpi)
Maximum print speed
152mm (6") per second
Physical characteristics
Width: 261.9mm (10.31")
Depth: 517.5mm (20.38")
Height: 393.7mm (15.5")
Weight: 22.7kg (50lb)
Media specifications
Label and liner width: 20mm (0.79") to 114mm (4.5")
Ribbon width: 20mm (0.79") to 110mm (4.33")
* Specifications subject to change without notice.
140Xi4 170Xi4™ 220Xi4™
The 140Xi4 is one of the fastest printers in
Zebra’s Xi series, printing at up to 355mm (14") per
second. With such powerful performance and steel
construction, it is the ideal choice for high-volume,
mission-critical applications with 24-hour duty cycles.
The 140Xi4 is also well suited for applications in
which labels are required quickly, either on demand
or in batches.
Technical specifications*
Maximum print area
Width: 128mm (5.04")
Length: 991mm (39")
Resolution
8 dots/mm (203dpi)
Maximum print speed
356mm (14") per second
Physical characteristics
Width: 287.3mm (11.31")
Depth: 517.5mm (20.38")
Height: 393.7mm (15.5")
Weight: 25kg (55lb)
Media specifications
Label and liner width: 40mm (1.57") to 140mm (5.51")
Ribbon width: 40mm (1.57") to 130mm (5.1")
The 170Xi4 is ideal for AIAG, ODETTE, UCC/EAN-128
and other compliance labels on demand or in batches.
With 203- and 300dpi print resolution, it can print labels
up to 168mm (6.6") wide at speeds of up to 305mm
(12") per second. Like all Xi4 printers, its rugged steel
construction enables it to operate dependably in the
harshest environments.
Technical specifications*
Maximum print area
Width: 168mm (6.6")
Length: 991mm (39")
Resolution
8 dots/mm (203dpi)
12 dots/mm (300dpi)
Maximum print speed
203dpi: 305mm (12") per second
300dpi: 203mm (8") per second
Physical characteristics
Width: 338.1mm (13.31")
Depth: 517.5mm (20.38")
Height: 393.7mm (15.5")
Weight: 30.5kg (67lb)
Media specifications
Label and liner width: 51mm (2") to 180mm (7.1")
Ribbon width: 51mm (2") to 170mm (6.7")
The 220Xi4 quickly prints labels up to 216mm (8.5")
wide at 254mm (10") per second. It is ideal for
wide-label applications such as chemical drum
labels, primary metal standard labels, automotive
industry labels, banner-sized labels and pallet
and container shipping labels. Choose the 300dpi
version where high-density graphics or small fonts
are required.
Technical specifications*
Maximum print area
Width: 216mm (8.5")
Length: 991mm (39")
Resolution
8 dots/mm (203dpi)
12 dots/mm (300dpi)
Maximum print speed
203dpi: 254mm (10") per second
300dpi: 152mm (6") per second
Physical characteristics
Width: 397.5mm (15.65")
Depth: 495mm (19.5")
Height: 393.7mm (15.5")
Weight: 32.7kg (72lb)
Media specifications
Label and liner width: 108mm (4.25") to 224mm (8.8")
Ribbon width: 108mm (4.25") to 220mm (8.6")
Specifications at a glance*
Standard features
Dependable print quality – on-board diagnostics •
ensure optimum print quality
Print methods: Thermal-transfer or direct-thermal•
Construction: 12-gauge steel frame•
ZebraLink•
ZebraNet 10/100 Print Server•
USB 2.0 port for faster connectivity and throughput •
(plug and play)
Serial and parallel ports•
Large easy-to-read front panel with multilingual •
back-lit LCD display
Transmissive and reflective media sensors•
Bi-fold media door with clear panel•
Advanced counters•
16MB SDRAM; standard 8MB non-volatile •
flash memory, optional 64MB
Improved ribbon- and media-low •
LCD/network alerts
300 discrete darkness settings for print quality•
Real-time clock•
Multi-level Element Energy Equalizer™ (E•
for superior print quality
ZPL II – Universal language for Zebra printers•
RFID-upgrade-ready (110Xi4 only) •
3
™)
Media characteristics
Labels
Max. roll size
203mm (8") O.D. on a 76mm (3") I.D. core•
Thickness (label & liner)
0.076mm (0.003") to 0.305mm (0.012")•
Media type
Continuous fanfold, die-cut or black mark•
For optimum print quality and printer performance,
use genuine Zebra Supplies.
Ribbons
Ribbon is recommended to be at least
as wide as media.
Max. roll size
81.3mm (3.2") O.D. on a 25.4mm (1") I.D. core•
Standard lengths
450m (1,476') or 300m (984'); provides 3:1 •
and 2:1 media roll-to-ribbon ratios
Ribbon setup
Ribbon wound ink-side out•
Operating characteristics
Environment
Operating temp. (TT): 5°C (41°F) to 40°C (104°F)•
Operating temp. (DT): 0°C (32°F) to 40°C (104°F)•
Storage/Transport environ. -40°C (40°F) to 60°C •
(140°F)
Operating humidity: 20 to 85% non-condensing•
Storage humidity: 5 to 85% non-condensing•
Electrical
Universal power supply with power-factor •
correction 90–264VAC; 48–62Hz
Communication interface capabilities
USB 2.0 port (480Mbits/second)•
RS-232C/422/485 multi-drop•
Hi-speed, bi-directional, IEEE 1284 parallel •
interface
Agency approvals
Bi-National UL 60950 Third Edition/CSA CAN/•
CSA-C22.2 No. 60950-00 Third Edition; IEC 950/
EN 60950: 1992 w/amendments 1 to 4 (CB
Scheme); EN 55022: 1998 Class B; EN 55024:
1998; EN 61000-3-2, 3 w/amendment A12;
Canadian ICES-003, Class B, FCC Class B;
Argentina 92/98 Phase 3; Australia AS/NZS 3548;
R.O.C. CNS 13438; BSMI; CCC
Options and accessories
Rewind•
Label peel•
Cutter•
Media supply spindle for 75mm cores •
(standard on 110Xi 4 – 600dpi)
Scalable and international fonts•
Applicator interface•
ZebraLink Solutions
Software
ZebraDesigner Pro•
ZebraDesigner•
ZebraNet Bridge Enterprise•
ZebraNet Utilities v 7.0•
ZBI-Developer•
Networking
ZebraNet Internal Wireless Plus Print Server•
ZebraNet 10/100 Print Server•
®
IBM•
twinax/coax interface
Firmware
APL•
ZPL II (standard)•
XML-enabled•
Web View•
Alert•
ZBI•
Fonts and graphics
Fonts and character sets
Standard fonts: 7 bitmapped, 1 smooth-scalable •
(CG Triumvirate™ Bold Condensed)
Contains UFST
Pre-loaded Unicode™-compliant scalable fonts •
for EMEA character sets
Sets: IBM Code Page 850 International •
character set
Graphics features
Supports user-defined fonts and graphics – •
including custom logos
®
from Agfa Monotype Corporation
Bar code symbologies
Linear bar codes: Codabar, Code 11, Code 39, •
Code 93, Code 128 with subsets A/B/C and UCC
Case C Codes, EAN-8, EAN-13, Industrial 2 of 5,
Interleaved 2 of 5, ISBT-128, Logmars, MSI, Planet
Code, Plessey, Postnet, Standard 2 of 5, UPC-A,
UPC-E, UPC and EAN 2 or 5 digital extensions
Two-dimensional: Codablock, Code 49, •
Data Matrix, GS1 DataBar (RSS), MaxiCode,
MicroPDF417, PDF417, QR Code, TLC 39
Thinking about mobilising your workforce?
The use of mobile printers in a warehouse or supply-chain environment improves productivity
and provides a fast return on investment.
To find out how your business could benefit from a Zebra mobile-printing solution,
please visit www.zebra.com, call +44 (0)1628 556000 or e-mail mseurope@zebra.com
*Specifications subject to change without notice.
©2009 ZIH Corp. APL, E3, Element Energy Equalizer, ZBI, ZBI-Developer, ZebraDesigner, ZebraLink, ZebraNet and all product names and numbers are Zebra trademarks, and Zebra, the representation of Zebra Head,
ZebraNet, and ZPL II are registered trademarks of ZIH Corp. All rights reserved. CG Triumvirate is a trademark of Agfa Division, Miles Inc. UFST is a registered trademark of Agfa Monotype Corporation. Unicode is
a trademark of Unicode, Inc. IBM is a registered trademark of International Business Machines Corporation. All other trademarks are the property of their respective owners. For optimal printing quality and proper
printer performance across our product line, Zebra strongly recommends the use of genuine Zebra supplies as part of the total solution. Specifically, the Xi series printers are designed to work only with genuine Zebra
printheads, thus maximising safety and print quality.
Zebra Technologies – EMEA Headquarters & Sales Office
Zebra Technologies Europe Limited, Dukes Meadow, Millboard Road, Bourne End, Buckinghamshire, SL8 5XF, United Kingdom
Telephone: +44 (0)1628 556000 Fax: +44 (0)1628 556001 E-mail: mseurope@zebra.com Web: www.zebra.com
Other EMEA Locations
Europe: France, Germany, Italy, the Netherlands, Poland, Spain, Sweden Middle East & Africa: Dubai, South Africa
12511L Rev.8 (09/09)
Loading...
