Zebra 200719 Product Data Sheet

PRODUCT SPEC SHEET

ZEBRA RUGGED TABLETS:
XS L ATE R 12

Zebra XSLATE R12 Rugged Tablet

The tablet that transforms to match your work style. Rugged redefined.

Think you need a desktop, laptop, and rugged tablet to excel at the tasks you complete in the office, in-vehicle, and in the field? You
don’t...anymore. You just need the highly mobile, extremely flexible and always resilient XSLATE® R12 tablet PC. The transformational
tablet device gives you all the high performance features and complete computing functions you need in a single platform.

Appeal to the workforce

This transformational rugged tablet PC will go with the flow –
and manage a task list as diverse as yours:

• Quality Assurance

• Inspections

• Inventory Management

• Safety Audits and Compliance Reporting

• Asset Monitoring and Control

Always the right form. More than enough flexibility

The XSLATE R12 is a next-generation tablet designed to be the
only computer you’ll need. It is one of the fastest rugged tablets on
the market today and features powerful 2-in-1 capabilities with a
magnetically-attached Companion Keyboard that’s always on standby
and never in the way. You’ll also have the clarity of the industry’s
brightest 12.5” display, and easy-to-use touch, pen, voice, and camera
inputs.

With all of these options, you can’t go wrong

The XSLATE R12 oers more high performance feature options than
any tablet PC in its class. You can pair powerful 7th generation Intel®
processors with your preferred Windows® Professional OS. Attach an
RJ45 + RS232 True Serial port dongle. Or add the SlateMate™ module
to automatically gain a barcode reader and HF RFID reader for easy
point of service data acquisition. If you’re a multi-tasker who needs
consistency – and options – you’ll get everything you need in one
rugged tablet.

Rugged redefined. Mobility without compromise.

This rugged tablet is built to keep your TCO low and ROI high,
especially as mobility demands grow. It’s ready for the field and
front oce, patrol car and factory, present and future. Expandable
SSD, storage, and memory components keep pace with rising data
demands. This level of connectivity ensures you never lose touch
with workers, legacy equipment, and evolving business systems.
You’ll have complete situational awareness in real-time and customer
service advantages at all times.

• Maintenance and Repair Scheduling and Completion

• Claims Processing

• Engineering/Construction Project Management

• Incident Reporting

• Dispatch and Routing (GPS)

• Mapping/GIS Asset Location

• Investigations

• Situational Awareness

• Evidence Documentation

• Ticketing & eCitations

• Electronic Patient Care Reporting (ePCR)/Electronic Health

Records (EHR)

• Emergency Response Planning and Management

The tablet that does it all

Do you need a single mobile computer platform that matches any
one of your workers’ tech styles, and every one of your workflow
requirements? No problem. The XSLATE R12 is prepared to multi­task in demanding work environments. With its highly responsive
pen and touch input capabilities, magnetically-attached Companion
Keyboard, adaptable form factor, and customised mounting options,
this powerful rugged tablet gives all of your workers the flexibility to
quickly and comfortably complete any task at hand – even when it
looks like a notebook or desktop.

PRODUCT SPEC SHEET

ZEBRA RUGGED TABLETS:
XS L ATE R 12

FROM THE FIELD TO THE VEHICLE TO THE OFFICE

Choose Accessories to Maximise Your Mobility Investment

Companion Keyboard Docking Station Secure Mobile Dock

(for vehicle or desktop)

SlateMate Data Acquistion

Mobile (Barcode Reader and

High Frequency RFID)

Work Anywhere Kit

(case, shoulder strap, carry

handle, screen cover)

Additional Digitizer Pen Battery Charger

Additional Battery

  2

PRODUCT SPEC SHEET

ZEBRA RUGGED TABLETS:
XS L ATE R 12

XSLATE R12 Tablet Specifications Chart

DURABILITY

Dr op Te s t MI L-ST D- 810 G

- 4’ drop tested on to plywood over concrete

Hazardous

Class 1 Division 2 for hazardous locations

Environment

Ingress IP54

Internal Magnesium-alloy internal frame

External Rubberised enclosure

SYSTEM FEATURES

Operating System • Windows® 10 Pro 64- bit

• Windows® 8.1 Pro 6 4-bit* †

• Windows® 7 Professional 64-bit*†
*available thru Windows 10 downgrade
† available on i5 -6200U onl y

Processor • Intel® Core™ i7 vP ro - 7600U

- 2.8 GHz with tur bo frequency to 3.9 GHz,
4 MB Smar tCache, 2 core s (4 threads)

• Intel® Core™ i7-7500U

- 2.7 GHz with turbo frequency to 3.5 GHz,
4 MB Smar tCache, 2 core s (4 threads)

• Intel® Core™ i5- 6200U

- 2.3 GHz with turbo frequenc y to 2.8 GHz,w
3 MB Smar tCache, 2 core s (4 threads)

• Intel® Celeron® 3865U

- 1.8 GHz, 2 MB Smar tCache, 2 core s (4 threads)

Memory • 4GB (Celeron® 3865U only)

• 8GB

Storage Options • 6 4 GB SSD**

• 128 GB SSD

• 256 GB SSD

• 512 GB SSD

• 1 TB SSD* **

(M.2 SATA only)
(M.2 SATA or PCIe)
(M.2 SATA or PCIe)
(M.2 SATA or PCIe)
(M.2 PCIe only)

** 64 GB M.2 SATA SSD o nly available with 3 865U
processor configuration
*** P CIe drives only available w ith 7500U & 760 0U
processor configurations

Display • 12.5” Wide View ing Angle Display

• Full- HD Resolution (1920 x 1080)

- 1000 Nit Display Brightne ss

- Anti-Smudge & Anti-Reflective
View Anywhere® Display

• Corning® Gorilla® Glass 3

• Capacitive 10-Point Touch

• Wacom Digital Pen Input

• Standard user replaceable anti-glare screen

Integrated
Communications

• Intel® Dual Band Wireless-AC 8260 Wi -Fi plus
Bluetooth® 4.2

• Optional Internal Wireless (1 expansion slot)

- Sierra Wireless EM7455 (NA and EU)

1

4G LTE with GNSS (GPS + GLONASS + Beidou)
or

- Sierra Wireless EM7430 (APAC )
4G LTE with GNSS (GPS + GLONASS + Beidou)
or

- Navis ys Technology (u-blox)
GPS with SBA S (WAAS, EGNOS and MSA S)

• Pass-Through antenna for WWAN , WLAN and GP S

Ports • Docking connector

• USB 3.0 por t

• HDMI port

• 3.5 mm audi o output (stereo out , mono in)

• Micro-SIM Card Slot (3 FF)

• Micro-SDHC port

Integrated Options • Optional 1D/2D Barcode Reader via SlateMate®

• Optional 13.56 MHz HF RFID with read/write
capability via SlateMate®

• Optional RS232 True Serial Port v ia Dongle

• Optional RJ45 Gigabi t Ethernet Por t via Dongle

• Optional Integrated CAC/Smar t Card Reader

Battery Life &
Power

• Battery operation
– Standard battery : up to 9 hours

1

• Batter y charge time
– Standard battery : 2.75 hours wit h system o

2

• Standard bridge battery (1 minute swap time)

– Hot swap battery feature comes standard

• Input Voltage: 19V with AC Adapter

Dimensions /
Weight

• 12.93” x 8.17 ” x .75”
w(328.5 mm x 207.5 mm x 19 mm)

• 2.95 lbs (1.34 kg)

3

Security • Integrated Fingerprint Reader

• Trus ted Platform Modul e (TPM) 2.0

• Optional CAC / SmartCard reader

Audio • Intel® High Definition Audio

• Realtek® HD Codec

• RealTek noise cancellation

• Multi-directional array microphone

- 3 microp hones (2 front f acing array mic’s and 1
rear facing mic)

• 2 Integrated speakers

Status Indicators • Power/Battery Status

• Camera Active

• SSD Activity

Graphics • Intel HD Graphics 620 for i7-7500 U, i7-7600U

• Intel HD Graphics 610 for Celeron

®

3865U

• Intel HD Graphics 520 for i5-6200U

Camera • 8 MP rear camera

• 2 MP front camera

** 64 GB M.2 SATA SSD only available with 3865U processor configuration
*** PCIe drives only available with 7500U & 7600U processor configurations

Continued on page 4

  3

PRODUCT SPEC SHEET

ZEBRA RUGGED TABLETS:
XS L ATE R 12

XSLATE R12 Tablet Specifications (continued)

SOFTWARE

Software • Know Your Tablet ( Windows 10, 8.1, 7)

• Pen and Touch Enabled BIOS Setup

• xCapture Pro™ Camera App

• Xplore Dashboard (Windows 7)

• Xplore Tablet Center (Windows 10, 8.1)

• RFID Sample Reader (SlateMate™)

• Barcode Reader (SlateMate™)

WARRANTY

Warranty
Information

• 3 year sta ndard coverag e included

• Extended Warranty & xDefend Programs available.

TESTING AND STANDARDS

Standards • ACPI 5.0 compliant

• UEFI BIOS

• Certified for Microsoft Windows 10 Client family
version 1607, x64

• Microsoft Azure Cer tified for IoT

IEC Ingress Testing • IEC (60529) Ingress Tes ted to an IP54 Standard

Environmental • Tested to MIL-STD-810G Standards

• Operating Temperature: -20 °C to 60 °C / -4 °F
to 140 °F

• Storage Temperature: -30 °C to 70 °C / -22 ° F to
158 °F

• Transit Drop - Operating: 4’ ( 1.22 M) Drop Direct to
Plywood over Concrete while Syste m is Operating,
26 Drops

• Vibration: Minimum Integrity Non-operating, US
Highway Truck and C omposite Whe el Operating

• Shock: 20 G Operating, 40G non-operat ing

• Humidity: 23 °C to 60 °C / 7 3 °F to 140 °F, 95%
NonCondensing, 10 Days

• Water Proofness: Fig 506.5, 140L/hr, per sq/m ,
15 Minutes

• Blowing Sand: 20M/S, rate 1.1g/m3 (+/-.3 g) at High
Temperat ure of 60 °C

• Blowing Dust: Velocity 8.9M/s Dust Concent ration

3.9 g/m3 at High Temp erature of 60 °C

• Temperature Shock: -30 °C to 70 ° C / -22 °F to 15 8
°F within 5 Minutes

• Contamination by Fluids: 50/50 Solu tion of Water
and Bleach, 50/50 Solution of Water and Hydro gen
Peroxide, Diesel Fuel, Mineral Base d Oil, Lysol
Disinfectant, Denatured Alcohol, Isopropyl Alcohol

• Altitude: 40,000 Ft (12,192 M) Operating, 50,000 ft
(15,240m) Non Operating

REGULATORY

Product Safety • UL/CSA 6095 0-1, 2nd Ed.

• IEC/EN 60950-1

• A S/NZS 60950-1, 2n d ED.

• LVD Direct ive 2014/35/EU

• NOM 019

• ANSI/ISA 12.12.01-2013 (Hazardous Location)

SAR • FCC OET 65 Supplement C

• C AN/CSA RSS-102 Is sue 5, Safety Code 6

• EN 62311, EN 62209 -2

EMC • FCC Par t 15 B, Class B

• C AN/CSA ICE S-003, Class B

• EN 55032, Class B

• EN 3 01-489 -1

• EN 3 01-489 -17

• EN 30 1-489-24

• EN 61000-3-2

• EN 61000-3-3

Environment • California Proposition 65

• Battery Charging Systems

• RoHS 2 Directive 2011 /65/EU

• WEEE Directive 2012/ 19/EU

• Batter y Waste Direc tive 2013/56/EU

• EN 62623:2013 ( ErP Lot 3 / Lot 26)

• NMX -1-122-NYCE-2006 (Mexico Energy
Consumption)

• Energy Star Compliant

1

Battery performance will vary by system configuration. Battery life and recharge estimates will
vary based on system settings, applications, optional features, environmental conditions, battery
conditioning and user preferences. MobileMark 2014 performance testing on Intel Core i7

2

Approximate c hargi ng time. Valida ted charging f rom 5% to 90 % wit h system on or system off.

3

Weight represents approximate system weight measured with a 45WHr battery. Actual system

weight may vary depending on component and manufacturing variability.

4

GNSS n ot avai lable w hen ex terna l moni tor is in use.
