Zebra 10015350 Product Data Sheet

Download
Manufacturing, Transportation and Logistics Supplies Catalog
Many of the world’s manufacturing, warehousing and distribution operations trust Zebra to enable the tracking of assets, work-in-process, parts inventory management, streamline receiving, put-away, delivery, route accounting and picking operations.
Effective January 2015
Manufacturing, Transportation & Logistics Price List
1

Catalog Updates

Manufacturing, Transportation & Logistics Price List
2

Asset Tracking

Size
(inches)
ID OD PartNumber
Quantity Per
Roll
Rolls Per
Carton
Carton Weight Stock MTO Ribbon
2.75" x 1.25" 3" 8" 10014717 3,210 4 28 lbs. Stock 06100BK08045
3" x 2" 3" 8" 10011689 2,230 4 20 lbs. Stock 06100BK08045
Size
(inches)
ID OD PartNumber
Quantity Per
Roll
Rolls Per
Carton
Carton Weight Stock MTO Ribbon
2" x 1" 3" 8" 10008512* 5,570 4 12 lbs. Stock 06200BK06045
PolyPro 4000T
Z-Ultimate 2000T White
3
Asset Tracking
Size
(inches)
ID OD PartNumber
Quantity Per
Roll
Rolls Per
Carton
Carton Weight Stock MTO Ribbon
3" x 2" 3" 8" 10008520* 2,280 4 20 lbs. Stock 06200BK08345
Z-Ultimate 4000T High Tack White
4

Product Labeling

Size
(inches)
ID OD PartNumber
Quantity Per
Roll
Rolls Per
Carton
Carton Weight Stock MTO Ribbon
4" x 6" 3" 8" 10008530* 720 4 32 lbs. Stock 06100BK11045
5" x 8" 3" 8" 10014715* 560 4 24 lbs. Stock 06100BK13145
Size
(inches)
ID OD PartNumber Quantity Per Roll Rolls Per Carton Carton Weight Stock MTO Ribbon
4" x 6" 3" 8" 10002628* 960 4 32 lbs. Stock 05100BK11045
Chemical - GHS - Not Transported via an International Waterway
PolyPro 4000T
Z-Ultimate 4000T White
5
Product Labeling
Size
(inches)
ID OD PartNumber Quantity Per Roll Rolls Per Carton Carton Weight Stock MTO Ribbon
4" x 6" 3" 8" 10008519* 790 4 32 lbs. Stock 06200BK11045
Chemical - GHS - Not Transported via an International Waterway
Z-Ultimate 4000T High Tack White
6
Product Labeling
Size
(inches)
ID OD PartNumber Quantity Per Roll Rolls Per Carton Carton Weight Stock MTO Ribbon
1.5" x 0.5" 3" 8" 10008511* 9,220 4 9 lbs. Stock 06200BK06045
3" x 2" 3" 8" 10008514* 2,950 4 20 lbs. Stock 06200BK08345
Z-Ultimate 2000T White
Computers, Electronics & Telecommunication
7
Product Labeling
Size
(inches)
ID OD PartNumber
Quantity Per
Roll
Rolls Per Carton
Carton Weight
Labels Across Stock MTO Ribbon
0.5" x 1" 3" 8" 10015768*^ 5,000 1 4 lbs. 4 Stock 05555BK08345
1" x 1.437" 3" 8" 10015769*^ 7,500 1 4 lbs. 3 Stock 05555BK08945
1" x 2.25" 3" 8" 10015770*^ 3,000 1 4 lbs. 2 Stock 05555BK06045
Computers, Electronics & Telecommunication
8000T Vinyl Clear - Self-Laminating Wire Wrap Label
8
Product Labeling
Size
(inches)
ID OD PartNumber
Quantity Per
Roll
Rolls Per Carton
Carton Weight
Labels Across Stock MTO Ribbon
0.25" x 0.25" 3" 8" 10015787* 10,003 1 2 lbs. 7 Stock 05100BK08345
0.75" x 0.25" 3" 8" 10015764* 10,000 1 2 lbs. 1 Stock 05100BK04045
1" x 0.25" 3" 8" 10015765* 10,000 1 2 lbs. 1 Stock 05100BK04045
1.5" x 0.25" 3" 8" 10015766* 10,000 1 2 lbs. 1 Stock 05100BK04045
Computers, Electronics & Telecommunication
Z-Supreme 2000T White
9
Product Labeling
Size
(inches)
ID OD PartNumber Quantity Per Roll Rolls Per Carton Carton Weight Stock MTO Ribbon
1.5" x 1" 3" 8" 72280 5,180 14 30 lbs. Stock 06000BK06045
Size
(inches)
ID OD PartNumber Quantity Per Roll Rolls Per Carton Carton Weight Stock MTO Ribbon
3.5" x 1" 3" 8" 72373 5,180 6 30 lbs. Stock 06000BK10245
Z-Select 4000T
Z-Select 4000T All-Temp

Pharmaceutical

10
Product Labeling
Size
(inches)
ID OD PartNumber Quantity Per Roll Rolls Per Carton Carton Weight Stock MTO Ribbon
3" x 2" 3" 8" 10011689 2,230 4 20 lbs. Stock 06100BK08045
Size
(inches)
ID OD PartNumber Quantity Per Roll Rolls Per Carton Carton Weight Stock MTO Ribbon
3" x 3" 3" 8" 10011710* 1,880 4 20 lbs. Stock 05100BK08345
PolyPro 4000T
Z-Ultimate 4000T White
UDI
11
Product Labeling
Size
(inches)
ID OD PartNumber Quantity Per Roll Rolls Per Carton Carton Weight Stock MTO Ribbon
1" x 0.5" 3" 8" 10008510* 9,420 4 9 lbs. Stock 06200BK04045
Size
(inches)
ID OD PartNumber Quantity Per Roll Rolls Per Carton Carton Weight Stock MTO Ribbon
0.75" x 0.25" 3" 8" 10015764* 10,000 1 2 lbs. Stock 05100BK04045
Size
(inches)
ID OD PartNumber Quantity Per Roll Rolls Per Carton Carton Weight Stock MTO
2.2" x 0.5" 1" 5" 10010064 3,510 6 12 lbs. Stock
Z-Ultimate 2000T White
Z-Supreme 2000T White

Small Item Marking

8000D Jewelry (Butterfly Label Without Flaps)
12
Product Labeling
Size
(inches)
ID OD PartNumber Quantity Per Roll Rolls Per Carton Carton Weight Stock MTO Ribbon
4" x 3" 3" 8" 10008531* 1,420 4 32 lbs. Stock 06200BK11045
4" x 6" 3" 8" 10008530* 720 4 32 lbs. Stock 06200BK11045
Size
(inches)
ID OD PartNumber Quantity Per Roll Rolls Per Carton Carton Weight Stock MTO Ribbon
1.5" x 0.5" 3" 8" 10011706* 9,420 4 8 lbs. Stock 05100BK06045
3" x 1" 3" 8" 10011709* 5,240 4 20 lbs. Stock 05100BK08345
4" x 6" 3" 8" 10002628* 960 4 32 lbs. Stock 05100BK11045
PolyPro 4000T
UID
Z-Ultimate 4000T White
13

Quality Assurance

Size
(inches)
ID OD PartNumber Color
Quantity Per
Roll
Rolls Per Carton Carton Weight Stock MTO Ribbon
4" x 3" 3" 8" 10006209-1* Yellow 1,840 4 27 lbs. Stock 06000BK11045
4" x 3" 3" 8" 10006209-3* Pink 1,840 4 27 lbs. Stock 06000BK11045
Z-Perform 2000T Floodcoated
14

Work-In-Process

Size
(inches)
ID OD PartNumber Quantity Per Roll Rolls Per Carton Carton Weight Stock MTO Ribbon
3.25" x 5" 3" 8" 65156* 1,030 6 26 lbs. Stock 06000BK10245
Size
(inches)
ID OD PartNumber Quantity Per Roll Rolls Per Carton Carton Weight Stock MTO Ribbon
4" x 6" 3" 8" 10005486* 1,000 4 27 lbs. Stock 06000BK11045
Z-Perform 1000T 7.5 Mil Tag
Work-In-Process
Z-Select 4000T Removable
15

Parts Inventory Management

Size
(inches)
ID OD PartNumber
Quantity Per
Roll
Rolls Per
Carton
Carton Weight Stock MTO Ribbon
3" x 2" 3" 8" 10000286* 2,750 6 27 lbs. Stock 06000BK08345
4" x 3" 3" 8" 10000284* 2,000 4 27 lbs. Stock 06000BK11045
4" x 6" 3" 8" 10000281* 1,000 4 27 lbs. Stock 06000BK11045
Z-Perform 2000T
16

Compliance Labeling

Size
(inches)
ID OD PartNumber Quantity Per Roll Rolls Per Carton Carton Weight Stock MTO Ribbon
4" x 6" 3" 8" 10000281* 1,000 4 27 lbs. Stock 06000BK11045
Size
(inches)
ID OD PartNumber Quantity Per Roll Rolls Per Carton Carton Weight Stock MTO Ribbon
4" x 6" 3" 8" 72294* 950 4 26 lbs. Stock 06000BK11045
Z-Perform 2000T
Z-Select 4000T
17

Inventory Management

Size
(inches)
ID OD PartNumber Quantity Per Roll Rolls Per Carton Carton Weight Stock MTO Ribbon
3" x 3" 3" 8" 10008515* 1,880 4 20 lbs. Stock 06200BK08345
Size
(inches)
ID OD PartNumber Color
Quantity Per
Roll
Rolls Per Carton Carton Weight Stock MTO Ribbon
4" x 6" 3" 8" 10006208* Blue 1,000 4 27 lbs. Stock 06000BK11045
4" x 6" 3" 8" 10006208-1* Yellow 1,000 4 27 lbs. Stock 06000BK11045
4" x 6" 3" 8" 10006208-2* Green 1,000 4 27 lbs. Stock 06000BK11045
4" x 6" 3" 8" 10006208-4* Orange 1,000 4 27 lbs. Stock 06000BK11045
4" x 6" 3" 8" 10006208-5* Red 1,000 4 27 lbs. Stock 06000BK11045
Z-Ultimate 2000T White
Z-Perform 2000T Floodcoated
18

Load Management

Size
(inches)
ID OD PartNumber Color
Quantity Per
Roll
Rolls Per Carton Carton Weight Stock MTO Ribbon
4" x 6" 3" 8" 10000281* White 1,000 4 27 lbs. Stock 06000BK11045
4" x 6" 3" 8" 10006208* Blue 1,000 4 27 lbs. Stock 06000BK11045
4" x 6" 3" 8" 10006208-1* Yellow 1,000 4 27 lbs. Stock 06000BK11045
4" x 6" 3" 8" 10006208-2* Green 1,000 4 27 lbs. Stock 06000BK11045
4" x 6" 3" 8" 10006208-4* Orange 1,000 4 27 lbs. Stock 06000BK11045
4" x 6" 3" 8" 10006208-5* Red 1,000 4 27 lbs. Stock 06000BK11045
Z-Perform 2000T
19

Order Picking & Staging

Size
(inches)
ID OD PartNumber Quantity Per Roll Rolls Per Carton Carton Weight Stock MTO
3" x 1" 3" 8" 10000296* 5,500 6 26 lbs. Stock
Size
(inches)
ID OD PartNumber Quantity Per Roll Rolls Per Carton Carton Weight Stock MTO Ribbon
3" x 1" 3" 8" 10000287* 5,500 6 27 lbs. Stock 06000BK08345
Z-Perform 2000D
Z-Perform 2000T
20
Order Picking & Staging
Size
(inches)
ID OD PartNumber Quantity Per Roll Rolls Per Carton Carton Weight Stock MTO Ribbon
3.25" x 5" 3" 8" 65156* 1,030 6 26 lbs. Stock 06000BK10245
Z-Perform 1000T 7.5 Mil Tag
21
Security
Size
(inches)
ID OD PartNumber Quantity Per Roll Rolls Per Carton Carton Weight Stock MTO
4" x 3" 1" 5" 10010056* 730 4 10 lbs. Stock
Size
(inches)
ID OD PartNumber Quantity Per Roll Rolls Per Carton Carton Weight Stock MTO Ribbon
4" x 3" 3" 8" 10000284* 2,000 4 27 lbs. Stock 06000BK11045
Z-Select 4000D 7.5 Mil Tag
Access & Identification
Z-Perform 2000T
22
Security
Size
(inches)
ID OD PartNumber Quantity Per Roll Rolls Per Carton Carton Weight Stock MTO Ribbon
3.25" x 5" 3" 8" 65156* 1,030 6 26 lbs. Stock 06000BK10245
Z-Perform 1000T 7.5 Mil Tag
Access & Identification
23

Shipping & Receiving

Size
(inches)
ID OD PartNumber Quantity Per Roll Rolls Per Carton Carton Weight Stock MTO
4" x 6" 3" 8" 10000290* 1,000 4 26 lbs Stock
4" x 2.5" 3" 8" 10000294* 2,280 4 25 lbs Stock
Size
(inches)
ID OD PartNumber Quantity Per Roll Rolls Per Carton Carton Weight Stock MTO
4" x 6" 3" 8" 10018341* 1,000 4 26 lbs Stock
4" x 6" 3" 8" 10021199*^ 2,000 2 26 lbs Stock
Z-Perform 2000D
Z-Perform 2000D with Rubber Adhesive
24
Shipping & Receiving
Size
(inches)
ID OD PartNumber Quantity Per Roll Rolls Per Carton Carton Weight Stock MTO
4" x 6" 0.75" 2.5" LD-R4AW5B* 105 36 24 lbs. Stock
Size
(inches)
ID OD PartNumber Quantity Per Roll Rolls Per Carton Carton Weight Stock MTO
4" x 6" 1" 5" 10010060* 410 4 10 lbs. Stock
Z-Perform 1000D
8000D Near-IR (Parcel Shipping Label)
25
Shipping & Receiving
Size
(inches)
ID OD PartNumber Quantity Per Roll Rolls Per Carton Carton Weight Stock MTO Ribbon
4" x 6" 3" 8" 10000281* 1,000 4 27 lbs Stock 06000BK11045
Size
(inches)
ID OD PartNumber Quantity Per Roll Rolls Per Carton Carton Weight Stock MTO Ribbon
4" x 2" 3" 8" 10018351* 3,000 4 26 lbs Stock 06000BK11045
4" x 3" 3" 8" 10018349* 2,000 4 26 lbs Stock 06000BK11045
4" x 6" 3" 8" 10018340* 1,000 4 26 lbs Stock 06000BK11045
4" x 6" 3" 8" 10021198*^ 2,000 2 26 lbs Stock 06000BK11045
Z-Perform 2000T
Z-Perform 2000T with Rubber Adhesive
26
Shipping & Receiving
Size
(inches)
ID OD PartNumber Quantity Per Roll Rolls Per Carton Carton Weight Stock MTO
4.375" x 6.875" 3" 8" 10006703* 580 4 32 lbs. Stock
6.625" x 6" 3" 8" 10004425* 660 2 20 lbs Stock
Z-Slip
27
Shipping & Receiving
Size
(inches)
ID OD PartNumber Quantity Per Roll Rolls Per Carton Carton Weight
8.375" x 12.8125" 3" 8" 10007333* 1,570 ff 41 lbs
Slip And Ship
28
RFID
Size
(inches)
ID OD PartNumber Quantity Per Roll Rolls Per Carton Carton Weight Stock MTO Ribbon
2.874" x .669" 3" 8" 10015350 5,000 1 5 lbs. Stock 06100BK08045
Size
(inches)
ID OD PartNumber Quantity Per Roll Rolls Per Carton Carton Weight Stock MTO Ribbon
3.819" x 1.063" 3" 8" 10015351 3,000 1 6 lbs. Stock 06100BK11045
Size
(inches)
ID OD PartNumber Quantity Per Roll Rolls Per Carton Carton Weight Stock MTO Ribbon
3.819" x .591" 3" 8" 10015352 5,000 1 6 lbs. Stock 06100BK11045
Belt RFID Label
DogBone RFID Label
For use with R110Xi4, RZ400 and RZ600 printers
ShortDipole RFID Label
29
Listing of Ribbons
Manufacturing, Transportation & Logistics Price List
30
DELIVERED PROFITABILITY.
EMPOWERED WORKFORCE.
Zebra gives a digital voice to drivers, routes and deliveries.
Zebra’s RW 420—the mobile printer designed to keep every route driver moving. Looking to drive profitability in your direct store delivery operation? Then it’s time you looked at Zebra mobile printers and supplies. Our solutions automate invoice and receipt creation, so drivers can cover more territory in every shift and get more profit from every stop.
Improve your bottom line—www.zebra.com/dsd
©2011 ZIH Corp. All rights reerved.
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
