9939 Via Pasar • San Dieg o, C A 92126
TEL (619) 621-2700 FAX (619) 621-2722
FEATURES
-
MH z• Frequency Range:
• Tuning Voltage:
•
MINI-16
- Style Package
730 920
1-15 Vdc
APPLICA TIONS
•
VSA T Modems
•
Basestation
Digital Radios
•
PERFORMANCE SPECIFICATIONS
Oscillation Frequency Range
Phase Noise @ 10 kHz offset (1 Hz BW, typ.)
Harmonic Suppression (2nd, typ.)
Tuning Voltage
Tuning Sensitivity (avg.)
CLV0798A
VOLTAGE CONTROLLED OSCILLATOR
PHASE NOISE (1 Hz BW, typica l)
VALU E UNITS
-
730 920
-112
-12
1-15
28
MHz
dBc/Hz
dBc
Vdc
MHz/V
A1Rev
Power Output
Load Impedance
Input Capacitance (max.)
Pushing
Pulli ng (14 dB R etur n Loss, Any Pha se)
Operating Temperature Range
Package Style
POWER SUPPLY R EQUIREMENTS
Supply Voltage (Vcc, nom.)
Supply Current (Icc, typ.)
All specific ations are ty pical unles s otherw ise noted and subject to change w ithout notice.
APPLICATION NOTES
AN-100/1 : Mounting and Grounding of VCOs
•
AN-102 : Proper Output Loading of VCOs
•
AN-107 : How t o Solde r Z -COMM VCOs
•
NOTES:
1.25±3.25
50
100
<2
<2
-40 to 75
MINI-16
5
19
dBm
Ω
pF
MHz/V
MHz
°C
Vdc
mA
© Z-Communications, Inc.
Page 1
All ri ghts reserved
LOW COST - HIG H PERFORMA NCE
VOLTAGE CONTROLLED OSCILLATOR
1120
1070
1020
970
920
870
820
770
720
670
620
0123456789101112131415
TUNING CURVE, typ.
POWER CURVE, typ.
CLV0798A
PAGE 2
75
°c
°c
25
-40
°c
10
8
6
4
2
0
-2
-4
-6
-8
-1 0
640 684 718 747 775 802 830 857 885 914 945 977 1010 1044 1076 1104
PHYSICAL DIMENSIONS
25
°c
© Z-Communications, Inc.
Page 2
±
P r int ed in th e U. S.A.
