DISHWASHER
DE 6865
Instruction Book
152968 54/0
UK
2
Setting the water softener 5 Filling with salt 6 Rinse aid 6
Different kinds of detergent 11 Washing programmes 12 Starting a washing programme 13 Maintenance and cleaning 14
Cleaning the filters 14 Prolonged periods of non-operation 14 Frost precautions 14 Moving the machine 14
What to do, when... 15 Service and Spare Parts 17 Customer Care Department 17 Guarantee Conditions 18
Installation instructions 19
Fitting under a counter 19 Levelling 19 Water supply connections 19 Water outlet hose connection 20 Electrical connection 20
Hints for test centres 21
Contents
Dimensions Width 60 cm
Height with worktop 85 cm Height without worktop 82 cm Max depth 63.5 cm Max depth with open door 118.5 cm
Electrical connection: Information on the electrical connection is given on the rating plate on the Voltage inner edge of the dishwasher’s door. Overall power Fuse
Water supply pressure Minimum 50 kPa (0.5 bar)
Maximum 800 kPa (8 bar)
Capacity 12 place settings
Technical specifications
This appliance complies with the following E.E.C. Directives:
- 73/23 or 19.2.73 (Low Voltage Directive) and subsequent modifications;
- 89/336 or 3.5.89 (Electromagnetic Compatibility Directive) and subsequent modifications.
3
Installation
● Check your dishwasher for any transport damage. Never
connect a damaged machine. If your dishwasher is damaged, you should contact your supplier.
● For safety reasons it is dangerous to alter the specifications
or attempt to modify this product in any way.
● Any electrical and plumbing work required to install this
appliance should be carried out by a qualified and competent person.
● Care must be taken to ensure that the appliance does not
stand on the electrical supply cable.
● The sides of the dishwasher must never be drilled to
prevent damage to hydraulic components.
Child safety
● This appliance is designed to be operated by adults.
● Children should not be allowed to tamper with the controls
or play with the product.
● Packaging parts may be dangerous for children, who could
even be suffocated! You should therefore keep all packaging well away from children.
● The water in your dishwasher is not for drinking. Detergent
residues may still be present in your machine. Keep children well away from your dishwasher when the door is open.
● Keep all detergents in a safe place out of children's reach.
Your dishwasher in day-to-day use
● Items that are contaminated by petrol, paint, steel or iron
debris, corrosive, acidic or alkaline chemicals must not be washed in this dishwasher.
● Under no circumstances should you open the door whilst
the appliance is in operation, especially during the washing phase, hot water may escape. However, if the door is opened, a safety device ensures that the machine stops.
● Only use products (detergent, salt and rinse aid) specifically
designed for use in dishwashers.
● Long bladed knives stored in an upright position are a
potential hazard.
● Long and/or sharp items of cutlery such as carving knives
must be positioned horizontally in the upper basket.
● When finishing loading or unloading close the door, as an
open door can be a hazard.
● Do not sit or stand on the open door.
● Isolate the appliance from the power supply and turn off the
water supply after use.
● This product should be serviced by an authorised service
engineer, and only genuine spare parts should be used.
● Under no circumstances should you attempt to repair the
machine yourself. Repairs carried out by inexperienced persons may cause injury or serious malfunctioning. Contact your local Service Force Centre. Always insist on genuine spare parts.
Disposal
Dispose of the dishwasher packaging material correctly. All packaging materials can be recycled.
Plastic parts are marked with standard international abbreviations:
>PE< for polyethylene, e.g. sheet wrapping material. >PS< for polystyrene, e.g. padding material (always CFC-
free).
>POM< for polyoxymethylene, e.g. plastic clips. Cardboard packaging is manufactured from recycled paper
and should be deposited in the waste paper collection for recycling.
As and when you cease to use your dishwasher and withdraw it from service, your should render it unserviceable before having it disposed of.
Warning! Children at play could lock themselves in your dishwasher or otherwise endanger their lives. Therefore cut off the power supply cable and make the door closing device unusable to prevent children from being trapped inside.
For the disposing of the appliance please take it to a recycling centre or to your dealer who will, for a small contribution to the costs, dispose it for you.
Economical and ecological dishwashing
● Ensure that the water softener is correctly adjusted.
● Do not pre-wash under running water.
● Select the wash programme to suit the nature and degree of
the soiling on the dishes.
● Do not use more detergent, special salt and rinse aid than is
recommended in these operating instructions and by the manufacturer of the respective product.
It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is left with the appliance in order that the new owner can get to know the functioning of the appliance and the relevant safety information.
This information has been provided in the interest of your safety. You MUST read it carefully before installing or using the appliance.
Safety instructions
The control panel
4
1. Upper basket stop
2. Water hardness switch
3. Salt container
4. Detergent dispenser
5. Control panel
6. Rating plate
7. Rinse aid dispenser
8. Filters
9. Lower spray arm
10. Upper spray arm
11. Upper basket
12. Worktop
Description of the appliance
IN144
Function push buttons: in addition to the dishwashing
programme selected, the following functions can also be set with the help of these buttons: water softener setting, deactivation/activation of the inflow of rinse aid and the cancelling of a programme in progress.
Indicator lights: have the following meanings:
The salt and rinse aid indicator lights are never illuminated while a washing programme is running even if filling with salt and rinse aid is necessary.
Phase indicator lights: have the following meanings:
As soon as you select a washing programme, the phase indicator lights for that programme will start flashing.
As the programme starts, the phase indicator lights turn off except for the indicator light of the phase in progress which will remain lit with a static light.
salt refilling indicator light, illuminates when the salt has run out
rinse aid refilling indicator light, illuminates when the rinse aid has run out
WASH illuminates when the washing phase is running DRY illuminates when the drying phase is running END illuminates when the washing programme has
ended. It also has added functions of visual signalling as:
- the setting of the water softener
- deactivation/activation of the inflow of rinse aid
- intervention of an alarm due to malfunction of the machine.
5
Before using your dishwasher for the first time:
1. Ensure that the electrical and water connections comply with the installation instructions.
2. Remove all packaging from inside the appliance.
3. Set the water softener.
4. Pour 1 litre of water inside the salt container and then fill
with salt.
5. Fill the rinse aid dispenser.
Setting the water softener
The dishwasher is equipped with a water softener designed to remove minerals and salts from the water supply, which would have a detrimental or adverse effect on the operation of the appliance.
The higher the content of these salts, the harder your water is. Water hardness is measured in equivalent scales, Clarke
degrees, French degrees and PPM (parts per Million). The softener should be adjusted according to the hardness of
the water in your area. Your local Water Authority can advise you on the hardness of the water in your area.
The water softener must be set in both ways: manually, using the water hardness switch and electronically, using the function push buttons on the control panel.
If your water is level 1 it is already soft and therefore there is no need to use salt.
a) Setting manually
1. Open the dishwasher door.
2. Remove the lower basket from the dishwasher.
3. Turn the water hardness switch to position 1 or 2 (see
table).
4. Replace the lower basket.
The dishwasher is factory set at position 2.
b)Setting electronically
(The dishwasher must be switched off)
The dishwasher is factory set at level 5.
1. Press the On/Off push button.
2. Press simultaneously function push buttons 2 and 3, until
the indicator lights of the function push buttons 1, 2 and 3 start flashing.
3. Press the function push button 1, the indicator lights of function push buttons 2 and 3 turn off while the indicator light of the push button 1 goes on flashing, at the same time the indicator light END starts to flash.
The current level is indicated by the number of flashes of the indicator light END.
Example: 5 flashes = level 5
4. To change the level, press push button 1. Each time the
push button is pressed the level changes. (For the selection of the new level see the chart).
Examples:
if the current level is 5, by pressing push button 1 once, level 6 is selected. if the current level is 10, by pressing push button 1 once, level 1 is selected.
5. To memorise the operation, switch off the dishwasher by pressing the On/Off push button or wait about 60 seconds after which the dishwasher will automatically return to setting mode.
Prior to using for the first time
AA07
Clarke
degrees
°TH
(french degrees)
PPM
(parts per million)
manually electronically
64 - 88 53 - 63 46 - 52 36 - 45 28 - 35 23 - 27 18 - 22 13 - 17
5 - 12
< 5
901 - 1250
751- 900 641 - 750 501 - 640 391 - 500 321 - 390 251 - 320 181 - 250
70 - 180
< 70
91 - 125
76 - 90 65 - 75 51 - 64 40 - 50 33 - 39 26 - 32 19 - 25
7 - 18
< 7
2 2 2 2 2 2 1 1 1 1
level 10
level 9 level 8 level 7 level 6 level 5 level 4 level 3 level 2 level 1
yes yes yes yes yes yes yes yes yes
no
10
9 8 7 6 5 4 3 2 1
Water hardness
Adjusting the water hardness
setting
Number of
flashes
Use
of salt
6
Filling with salt
Only use salt specifically designed for use in dishwashers. All other types of salt not specifically designed for use in a dishwasher, especially table salt, will damage the water softener. Only fill with salt just before starting one of the complete washing programmes. This will prevent any grains of salt or salty water, which may have been spilt, remaining on the bottom of the machine for any period of time, which may cause corrosion.
To fill:
1. Open the door, remove the lower basket and unscrew the
cap of the salt container by turning it anticlockwise.
2. Pour 1 litre of water inside the container (this is necessary only before filling with salt for the first time).
3. Using the funnel provided,
pour in the salt until the container is full.
4. Replace the cap making sure that there is no trace of salt on the screw thread or on the gasket.
5. Screw on the cap tightly turning it clockwise until it stops with a click.
The salt container will require topping up periodically. You are reminded of this by the salt indicator light on the control panel which comes on when the salt has finished.
The salt indicator light on the control panel can remain illuminated for 2-6 hours after the salt has been replenished, assuming the dishwasher remains switched on. If you are using salts that take longer to dissolve then this can take longer. The function of the machine is not affected.
Do not worry if water over flows from the unit when filling with salt, this is quite normal.
Rinse aid
Rinse aid is automatically added during the last rinse, ensuring thorough rinsing, and spot and streak free drying.
The dispenser, which is positioned inside the door, holds about 110 ml of rinse aid, which is sufficient for 16 - 40 dishwashing programmes, depending upon the dosage setting.
Filling with rinse aid
1. Open the container by pressing the release button (A).
2. Add the rinse aid until the container is completely full. The
maximum level for filling is indicated by "max".
Ensure that the lid is closed after every refill.
Top up the rinse aid when the rinse aid indicator light on the control panel illuminates.
Adjusting the dose
According to the finish and drying results obtained, adjust the dose of rinse aid by means of the 6 position selector (position 1 minimum dosage, position 6 maximum dosage).
Increase the dose if there are drops of water or lime spots on the dishes after washing.
The dose is factory set in position 4.
Reduce it if there are sticky whitish streaks on the dishes.
Clean up any rinse aid spilt during filling with an absorbent cloth to avoid excess foaming during the next wash.
Only use branded rinse aid for dishwashers. Never fill the rinse aid dispenser with any other substances (e.g. dishwasher cleaning agent, liquid detergent). This would damage the appliance.
SALE
ZOUT
SALT
SALZ
SEL
SR14
BR07
BR14
BR09
7
To deactivate the rinse aid indicator light proceed as follows:
(The dishwasher must be switched off)
When the inflow of rinse aid has been deactivated, the rinse aid indicator light on the control panel is automatically deactivated.
1. Press the On/Off push button.
2. Press simultaneously function push buttons 2 and 3, until
the indicator lights of the function push buttons 1, 2 and 3 start flashing.
3. Press the function push button 2, the indicator lights of function push buttons 1 and 3 turn off while the indicator light of the function push button 2 goes on flashing, at the same time the indicator light END illuminates indicating that the inflow of rinse aid is active.
4. To deactivate the inflow of rinse aid, press the function push button 2 again, the indicator light END turns off, indicating that the inflow of rinse aid has been deactivated.
5. To memorise the operation, switch off the dishwasher by pressing the On/Off push button or wait about 60 seconds after which the dishwasher will automatically return to setting mode.
To activate the inflow of rinse aid follow the above instructions until the indicator light END illuminates.
8
In daily use
● Check if it’s necessary to refill with special salt or rinse aid
● Load cutlery and dishes into the dishwasher.
● Fill with dishwasher detergent .
● Select a wash programme suitable for the cutlery and
dishes.
● Start the wash programme.
Loading cutlery and dishes
Sponges, household cloths and any object that can absorb water may not be washed in the dishwasher.
● Before loading the dishes, you should:
- Remove large left-overs.
- Soften remnants of burnt food in pans
● When loading the dishes and cutlery, please note:
- Dishes and cutlery must not impede the rotation of the spray arms .
- Load hollow items such as cups, glasses, pans, etc. with the opening downwards so that water cannot collect in the container or a deep base.
- Dishes and items of cutlery must not lie inside one another, or cover each other.
- To avoid damage to glasses, they must not touch.
- Lay small objects in the cutlery basket.
● Plastic items and pans with teflon have a tendency to
retain water drops; these items will not dry as well as porcelain and steel items.
Open the door and slide out the baskets to load the dishes.
The lower basket
The lower basket is designed to take saucepans, lids, plates, salad bowls, cutlery etc.
Serving dishes and large lids should be arranged around the edge of the basket, ensuring that the spray arms can turn freely.
The cutlery basket
Long bladed knives stored in an upright position are a potential hazard. Long and/or sharp items of cutlery such as carving knives must be positioned horizontally in the upper basket. Take care when loading or unloading sharp items such as knives.
Removable knife basket
Long and/or sharp items of cutlery such as carving knives must be placed horizontally in the removable knife basket, which is positioned at the rear of the upper basket.
For washing in the dishwasher the following cutlery/dishes
are of limited suitability:
- Only wash stoneware in the dishwasher if it is specifically marked as being dishwasher-safe by the manufacturer.
- Glazed patterns may fade if machine washed frequently
- Silver and aluminium parts have a tendency to discolour during washing. Left-overs, e.g. egg white, egg yolk and mustard often cause discolouring and staining on silver. Therefore always clean left-overs from silver immediately, if it is not to be washed straight after use.
- Some types of glass can become dull after a large number of washes
are not suitable:
- Cutlery with wooden, horn, china or mother-of-pearl handles
- Plastic items that are not heat resistant
- Older cutlery with glued parts that is not temperature resistant
- Bonded cutlery items or dishes
- Pewter or copper items
- Lead crystal glass
- Steel items subject to rusting
- Wooden platters
- Items made from synthetic fibres
UI90
UI89
UI53
9
Cutlery should be placed in the removable cutlery basket with the handles facing downwards. If the handles protrude from the bottom of the basket, obstructing the lower spray arm, load the cutlery with the handles facing upwards.
Mix spoons with other cutlery to prevent them from sticking together.
For best results we recommend you to use the cutlery grids provided (if the size and dimensions of the cutlery allow it).
The cutlery basket is in two parts which can be separated to give greater loading flexibility. To separate the two parts, slide them horizontally in opposite directions and pull them apart. To reassemble, reverse the procedure.
The upper basket
The upper basket is designed for plates (dessert plates, saucers, dinner plates of up to 24 cm in diameter), salad bowls, cups and glasses.
Arrange items on and underneath the cup racks so that water can reach all surfaces.
Glasses with long stems can be placed upside down in the cup racks.
Light items (plastic bowls etc.) must be loaded in the upper basket and arranged so they do not move.
In case that plates are loaded in the upper basket:
load them starting from the rear positions of the basket; tilting them slightly forwards and avoiding the front positions near the door.
Before closing the door, ensure that the spray arms can rotate freely.
Adjusting the height of the upper basket
If washing very large plates you can load them in the lower basket after moving the upper basket to the higher position.
To move to the higher position proceed as follows:
1. Move the front runner stops (A) of the upper basket
outwards and slide the basket out.
2. Refit the basket in the higher position and replace the stops (A) in their original position.
When the basket is in the higher position you will not be able to use the cup rack(s).
After loading your machine always close the door, as an open door can be a hazard.
UI63
UI62
With upper basket raised 20 cm 31 cm With upper basket lowered 24 cm 27 cm
Maximum height of the dishes in
upper basket lower basket
US47
US71
RC01
10
Use of detergent
Only use detergents specifically designed for use in dishwashers.
We recommend the use of Finish detergents. Using no more then the correct amount of detergent
contributes to reducing pollution.
Prior to the start of a wash programme (not for the "Rinse and Hold" programme, that does not require the use of detergent). The detergent is released during the washing phase.
Please observe the manufacturer’s dosing and storage recommendations as stated on the detergent packaging.
Fill with detergent
1. If the lid is closed: press release button (1).
The lid springs open.
2. Fill the detergent dispenser with detergent. The marking indicates the dosing levels:
20 = approximately 20 g of detergent 30 = approximately 30 g of detergent
3. Close the lid and press until it locks in place.
4. For all programmes with prewash, an additional detergent
dose (5/10 g) must be placed into the WRD detergent dispenser, located in the centre of the upper basket. This detergent will take effect during the prewash phase
DE19
DE21
DE13
11
Detergent tablets
Detergent tablets of different brands dissolve at different speeds. For this reason some detergent tablets cannot dissolve and develop their full cleaning power during short programmes. Therefore please use long programmes when using detergent tablets, to ensure the complete removal of detergent residuals.
Do not place the tablets in the tub or in the cutlery basket as this will result in poorer wash results. The tablets should be placed in the detergent dispenser.
Concentrated detergent
Based on their chemical composition, dishwasher detergents can be split into two basic types:
- conventional, alkaline detergents with caustic components.
- low alkaline concentrated detergents with natural enzymes. The use of 50°C washing programmes in conjunction with
concentrated detergents reduces pollution and is good for your dishes; these wash programmes are specially matched to the dirt-dissolving properties of the enzymes in the concentrated detergent. For this reason 50°C wash programmes in which concentrated detergents are used can achieve the same results that can otherwise only be achieved using 65°C programmes.
Combi detergents
If you are using dishwasher detergent that includes the rinse aid function, this must be placed in the detergent compartment.
In this case the rinse aid inflow must be deactivated, in order to avoid a double dosage.
Use of "3 in 1" combi detergents
General advice
These products are detergents with integrated and combined detergent/rinse-aid and salt functions.
1. Before using these products you should first check that the water hardness in your supply is compatible with the use of these products as per the detergent manufacturers (on the product packaging).
2. These products should be strictly used according to the detergent manufacturers instructions.
3. If you encounter problems when using 3 in 1 products for the first time then please contact the detergent manufacturers care line (the telephone number is given on the product packaging).
Special advice
When using combination 3 in 1 products select the lowest possible setting for water hardness.
If you decide to turn back to the use of the standard detergent system we advise that you:
● Refill both the salt container and rinse aid dispenser.
● Switch the water hardness setting to the highest possible
position and run a normal washing programme without a load.
● Readjust the water hardness setting again according to the
hardness of the water in your area.
Different kinds of detergent
BRILLIANT
FOR A
SHINE
RINSE
CONCENTRATED DISHWASHER DETERGENT
A
CTIO
N
N
E
W
DOUBLE
LIQUID GEL
POWDER
EASY
POURING
PACK
For best results we recommend the use of Finish detergents, rinse aid and salt.
DE15
12
Washing programmes
Programme Degree of soil
and
type of load
Heavy soil. Crockery, cutlery, pots and pans
Normal soil. Crockery and cutlery
Normal soil. Crockery and cutlery
Fresh soil. Crockery and cutlery
Press the
programme
button
Cycle
description
(3) Consumption values
Hot prewash Main wash up to 70°C 2 warm rinses 1 hot rinse Drying
Main wash up to 60°C 1 hot rinse
Cold prewash Main wash up to 65°C 1 cold rinse 1 hot rinse Drying
Cold prewash Main wash up to 50°C 1 cold rinse 1 hot rinse Drying
(1) Ideal for washing crockery and cutlery of breakfast and dinner (fresh soil).
Characterised by a duration of about 30 minutes and a washing temperature of 60°C. The time value is approximate and depends on the pressure and the temperature of the water and also by the variations of the power supply. This is the perfect daily programme, made to meet the needs of a family of 4 persons who only wish to load breakfast and dinner crockery and cutlery.
(2) Testing programme for EN 50242 (see "Hints for Test Centres"). This programme, developed for the use of detergents with
enzymes, allows you to achieve, with reduced consumption of energy the same cleaning results that would otherwise be obtained only with the 65°C programmes and conventional detergents. To compensate the lower temperature, the duration of washing and drying have been extended.
(3) The consumption values are intended as a guide and depends on the pressure and the temperature of the water and also by
the variations of the power supply.
70°
INTENSIVE
WRD
65°
NORMAL
60°
QUICK
50°
ECONOMY
Intensive 70°
WRD
(1) Quick 60°
(2)
Economy 50°
Normal 65°
Programme
duration
(in minutes)
Energy
consumption
(in kWh)
Water
consumption
(in litres)
80 - 90 1,65 - 1,85 22 - 24
95 - 105 1,25 - 1,45 19 - 21
30 0,8 9
155 - 165
0,95 - 1,05
13 - 15
Light soil. Delicate china and glassware
Main wash up to 45°C 1 warm rinse 1 hot rinse Drying
45°
DELICATE
Delicate 45°
75 0,90 15
Any. Partial load (to be completed later in the day).
1 cold rinse (to avoid food scraps from sticking together).
RINSE &
HOLD
Rinse and Hold
12
0,1
4
13
1. Check that the baskets have been loaded correctly and that the spray arms can rotate freely
2. Turn on the water tap
3. Close the dishwasher door
4. Press the On/Off push button
The On/Off indicator light will come on.
5. Setting and starting the programme
Press the push button corresponding to the required programme (see "Washing programmes" chart). The indicator light corresponding to the programme and the phase indicator lights foreseen for that programme will illuminate.
After about 3 seconds from the last pressure of a push button the programme starts automatically.
Once the programme has started the phase indicator lights will turn off except for the phase under way.
Note: it is possible to select a washing programme also with the door slightly opened. In this case the start of the programme will occur after about 3 seconds from the closure of the door.
a) Press On/Off push button. b) Select a washing programme. c) Close the door.
The programme will start automatically after about 3 seconds from the closure of the door.
6. To interrupt or cancel a washing programme in progress
Interrupt or cancel a washing programme in progress ONLY if it’s absolutely necessary.
Attention! Hot steam may escape when the door is opened. Open the door carefully.
To interrupt a washing programme in progress
a) Open the dishwasher door; the programme will stop.
Close the door; the programme will start from the point in which it was interrupted.
b) Press the On/Off push button (in this case all the
indicator lights turn off). Press the On/Off push button again; the programme will start from the point in which it was interrupted.
To cancel a washing programme in progress
To cancel a washing programme you have to reset the dishwasher; press simultaneously the function push buttons 2 and 3 until all the indicator lights will turn off (except for the On/Off indicator light and eventually the rinse aid and salt indicator lights) indicating that the running programme has been cancelled.
7. End of the washing programme
The dishwasher will automatically stop and the end of programme phase indicator light (END) will illuminate.
The indicator light of the programme just ended will remain on.
If the door is not immediately opened at the end of the programme, air will circulate inside the dishwasher to prevent residual steam recondensing on the dishes as water droplets. This device operates intermittently for about 20 minutes, as long as the dishwasher is switched on. if the On/Off push button is pressed or the door is opened during these 20 minutes, the device will be automatically cancelled.
Switch off the dishwasher by pressing the On/Off push button, the On/Off indicator light turns off.
Open the door and wait a few minutes before removing the dishes; in this way they will be cooler and the drying will be improved.
Water may appear on the sides and the door of the dishwasher as the stainless steel will eventually become cooler than the dishes.
Unloading the dishwasher
Hot dishes are sensitive to knocks. The dishes should therefore be allowed to cool down before removing from the appliance.
Empty the lower basket first and then the upper one; this will avoid water dripping from the upper basket onto the dishes in the lower one.
When the washing programme has finished, it is recommended that the dishwasher is unplugged and the water tap turned off.
Starting a washing programme
14
Clean the external surfaces of the machine and control panel with a damp soft cloth. If necessary use only neutral detergents. Never use abrasive products, scouring pads or
solvent (acetone, trichloroethylene etc....).
Ensure that the seals around the door, the detergent and rinse aid dispensers are cleaned regularly with a damp cloth.
We recommend the use of Finish Dishwasher Cleaner every 3 months or run a 65°C wash programme without dishes using detergent.
Regular use of Finish Dishwasher Cleaner cleans inaccessible parts, eliminates unpleasant food odours and helps prevent the build-up of limescale.
Cleaning the filters
The filters in the base of the washing compartment are to a large extent self-cleaning. Nevertheless the filters should be checked and cleaned from time to time. Dirty filters will degrade the washing result.
1. Open the door, remove the lower basket.
2. The dishwasher filter system comprises a coarse/fine filter (A/B), a microfilter (C) and a flat filter (D).
Some dishwasher will only have a coarse filter (A), a microfilter (C) and a flat filter (D).
Unlock the filter system using the handle on the microfilter, and remove.
3. Turn the handle about
1
/4a turn anticlockwise and remove.
4. Take hold of the coarse/fine filter (A/B) by the handle with
the hole and remove from the microfilter (C).
5. Clean all filters thoroughly under running water.
6. Remove the flat filter (D) from the base of the washing
compartment and clean both faces thoroughly.
7. Put the flat filter (D) back in the base of the washing
compartment.
8. Place the coarse/fine filter (A/B) in the microfilter C) and
press together.
9. Put the filter combination in place and lock by turning the handle clockwise to the stop. During this process ensure that the flat filter does not protrude above the base of the washing compartment.
Under no circumstances may the dishwasher be used without filters. Incorrect repositioning and fitting of the filters will produce poor washing results.
NEVER try to remove the upper spray arm.
If residues of soil have clogged the holes in the upper spray arm, remove them with a toothpick.
Check that the WRD is not clogged with detergent residue. If necessary rinse it under running water after having removed it from the basket by twisting it anticlockwise and pulling it upwards.
Never use your dishwasher without the WRD dispenser. Since WRD also ensures correct distribution of the water to the upper spray arm, running the dishwasher without it will impair the washing results.
Prolonged periods of non-operation
If you are not using the machine for any period of time you are advised to:
1. Unplug the appliance and then turn off the water.
2. Fill the rinse aid dispenser.
3. Leave the door ajar to prevent the formation of any
unpleasant smells.
4. Leave the inside of the machine clean.
Frost precautions
Avoid placing the machine in a location where the temperature is below 0°C. If this is unavoidable, empty the machine, close the appliance door, disconnect the water inlet pipe and empty it.
Moving the machine
If you have to move the machine (moving house etc....):
1. Unplug it.
2. Turn the water tap off.
3. Remove the water inlet and discharge hoses.
4. Pull the machine out together with the hoses.
Avoid over tilting the machine during transportation.
Maintenance and cleaning
MA11
MA33
MA36
MA31
MA32
MA35
15
What to do, when...
Certain problems are due to the lack of simple maintenance or oversights, which can be solved with the help of the instructions given here, without calling out an engineer.
...a flashing fault code appears
The dishwasher will not start or stops during operation. All push buttons are inoperative except for the On/Off push button and a combination of indicator lights, as indicated in the following chart, are flashing. Press the On/Off push button to switch the dishwasher off and carry out the following suggested corrective actions.
Important: If you call out an engineer to a fault listed below or to repair a fault caused by incorrect use or installation a charge will be made, even if the appliance is in guarantee.
Once the checks have been carried out, press the On/Off push button, the programme will continue from the point in which it was interrupted. If the fault code reappears contact the Service Force Centre.
For other combinations of fault codes not described in the above chart will appear, please contact your Service Force Centre.
- Indicator light of the programme in progress is flashing.
- 1 flash of the indicator light END.
The machine does not fill with water.
- Indicator light of the programme in progress is flashing.
- 2 flashes of the indicator light END.
The dishwasher will not drain.
- Indicator light of the programme in progress is flashing.
- 3 flashes of the indicator light END.
Fault code / malfunction Possible cause Solutions
The water tap is blocked or furred with limescale.
The water tap is turned off. The filter (where present) in the threaded hose
fitting at the water inlet valve is blocked. The water inlet hose has not been correctly laid
or it is bent or squashed.
Clean the water tap.
Turn the water tap on. Clean the filter in the threaded hose
fitting. Check the water inlet hose connection.
The siphon is blocked. Clean out the siphon.
The water drain hose has not been correctly laid or it is bent or squashed.
Check the water drain hose connection.
Protection against flooding is active.
Close the water tap and contact the Service Force Centre.
...there are problems when operating the dishwasher
The programme does not start
There is a whistling noise during washing
Fault Possible cause Solutions
The dishwasher door has not been properly closed.
The main plug is not plugged in. The fuse has blown in the household fuse box.
For dishwasher models with delay start option:
Delay start has been selected.
Close the door.
Insert the mains plug. Replace the fuse.
If dishes are to be washed immediately, cancel the delay start.
Use a different brand of detergent.The whistling is not a cause for concern.
16
...the wash results are not satisfactory
The dishes are not clean
● The wrong washing programme has been selected.
● The dishes were arranged in such a way as to stop water reaching all parts of the surface. The baskets must not be overloaded.
● The spray arms do not rotate freely due to wrong arrangement of the load.
● The filters in the base of the washing compartment are dirty or incorrectly positioned.
● Too little or no detergent has been used.
● Where there are limescales deposits on the dishes; the salt container is empty or the wrong level of the water softener has been
selected.
● The drain hose connection is not correct.
● The salt container cap is not properly closed.
The dishes are wet and dull
● Rinse aid was not used.
● The rinse aid dispenser is empty.
There are streaks, milky spots or a bluish coating on glasses and dishes
● Decrease rinse aid dosing.
Water drops have dried onto glasses and dishes
● Increase rinse aid dosing.
● The detergent may be the cause. Contact the detergent manufacturer’s consumer care line.
If after all these checks, the problem persists, contact your local Service Force Centre, quoting the model (Mod.), product number (PNC) and serial number (S.N.). This information can be found on the rating plate located on the side of the dishwasher’s door (see picture).
So that you always have these numbers at hand, we recommend you to make a note of them here:
Mod. : . . . . . . . . . . . . . . . . . .
PNC : . . . . . . . . . . . . . . . . . .
S.N. :. . . . . . . . . . . . . . . . . . .
RA08
17
Service and Spare Parts
In the event of your appliance requiring service, or if you wish to purchase spare parts please contact your local Service Force Centre by telephoning:
08705 929929
Your telephone call will be automatically routed to the Service Force Centre covering your post code area.
For the address of your local Service Force Centre and further information about Service Force, please visit the website at
www
.serviceforce.co.uk
Before calling out an engineer, please ensure you read the details under the heading "What to do, when...".
When you contact the Service Force Centre you will need to give the following details:
1. Your name, address and post code
2. Your telephone number
3. Clear and concise details of the fault
4. The model and serial number of the appliance (found on the
rating plate)
5. The purchase date Please note that a valid purchase receipt or guarantee
documentation is required for in-guarantee service calls.
For Customer Service in Ireland please contact us at the address below:
Zanussi Electrolux Electrolux Group (Irl) Ltd Long Mile Road Dublin 12 Republic of Ireland
Tel: + 353 (0)1 4090751 Email: service.eid@electrolux.ie
Customer Care Department
For general enquiries concerning your Zanussi Electrolux appliance or for further information on Zanussi Electrolux products please contact our Customer Care Department by letter or telephone at the address below or visit our website at
www
.zanussi.co.uk
Customer Care Department Zanussi Electrolux 55-77 High Street Slough Berkshire SL1 1DZ Tel: 08705 727727 (
*
)
*
calls to this number may be recorded for training purposes
18
Standard Guarantee Conditions
We, Zanussi Electrolux, undertake that if within 12 months of the date of purchase this ZANUSSI ELECTROLUX appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that:
● The appliance has been correctly installed and used only on
the electricity supply stated on the rating plate.
● The appliance has been used for normal domestic purposes
only, and in accordance with the manufacturer’s instructions.
● The appliance has not been serviced, maintained repaired,
taken apart or tampered with by any person not authorised by us.
● All service work under this guarantee must be undertaken by
a Service Force Centre.
● Any appliance or defective part replaced shall become the
Company’s property.
● This guarantee is in addition to your statutory and other legal
rights.
Home visits are made between 8.30am and 5.30pm Monday to Friday. Visits may be available outside these hours in which case a premium will be charged.
Exclusions
This guarantee does not cover:
● Damage or calls resulting from transportation, improper use
or neglect, the replacement of any light bulbs or removable parts of glass or plastic.
● Costs incurred for calls to put right an appliance which is
improperly installed or calls to appliances outside the United Kingdom.
● Appliances found to be in use within a commercial
environment, plus those which are subject to rental agreements.
● Products of Zanussi Electrolux manufacture which are not
marketed by Zanussi Electrolux.
European Guarantee
If you should move to another country within Europe then your guarantee moves with you to your new home subject to the following qualifications:
● The guarantee starts from the date you first purchased your
product.
● The guarantee is for the same period and to the same extent
for labour and parts as exists in the new country of use for this brand or range of products.
● This guarantee relates to you and cannot be transferred to
another user.
● Your new home is within the European Community (EC) or
European Free Trade Area.
● The product is installed and used in accordance with our
instructions and is only used domestically, i.e. a normal household.
● The product is installed taking into account regulations in
your new country.
Before you move please contact your nearest Customer Care centre, listed below, to give them details of your new home. They will then ensure that the local Service Organisation is aware of your move and able to look after you and your appliance.
France Senlis +33 (0) 344 62 29 29 Germany Nurnberg +49 (0) 800 234 7378 Italy Pordenone +39 (0) 434 39 4700 Sweden Stockholm +46 (0) 8 672 53 90 UK Slough +44 (0)1753 219897 Ireland Dublin +353 (0)1 4090751
Guarantee Conditions
19
Installation instructions
Any electrical and/or plumbing work required to install this appliance should be carried out by a qualified electrician and/or plumber or competent person.
Remove all packaging before positioning the machine. If possible, position the machine next to a water tap and a
drain.
Fitting under a counter
(kitchen worktop or sink) By removing the machine’s worktop, you can install it under a
close fitting sink unit or a pre-existing top, providing the dimensions of the recess correspond to those shown in the picture.
Proceed as follows:
Remove the machine’s worktop by unscrewing the two rear retaining screws, pull from the front and slide out the rear slots, lifting the worktop.
Insert the machine after adjusting height and levelling with the adjustable feet. When inserting the machine, ensure that the water inlet and drain hoses are not kinked or squashed.
If the dishwasher is later used as a free-standing appliance, the original worktop must be re-mounted.
The plinth on free-standing appliances is not adjustable.
Levelling
Good levelling is essential for correct closure and sealing of the door.
When the appliance is correctly levelled, the door will not catch on either side of the cabinet.
If the door does not close correctly, loosen or tighten the adjustable feet until the machine is perfectly level.
Water supply connections
This dishwasher must be plumbed into a cold water supply. For making the connection itself, the coupling nut fitted to the
machine’s supply hose is designed to screw onto either a 3/4" inch gas thread spout or to a purpose made quick-coupling tap such as the Press-block.
The water pressure must be within the limits given in the "Technical specifications". Your local Water Authority will advise you on the average mains pressure in your area.
The water inlet hose must not be kinked, crushed, or entangled when it is being connected up.
The dishwasher features fill and drain hoses which can be turned either to the left or the right to suit the installation by means of the locknut. (Attention! NOT all models of
dishwashers have fill and drain hoses provided with locknut. In this case, this kind of facility is not possible).
The locknut must be correctly fitted to avoid water leaks. If the machine is connected to new pipes or pipes which have
not been used for a long time, you should run the water for a few minutes before connecting the inlet hose.
Do not use, for connection, old hoses which have been used in another appliance.
The dishwasher is fitted with safety devices that prevent the wash water returning into the drinking water system and comply with the applicable plumbing regulations.
820
570 - 600
600
IN05
20
Water outlet hose connection
The end of the drain hose can be connected in the following ways:
1. To the sink outlet spigot, securing it to the underside of the work surface. This will prevent waste water from the sink running into the machine.
2. Hooked over the edge of the sink using the special curved plastic guide (if provided with the machine).
3. To a stand pipe provided with vent-hole, minimum internal diameter 4 cm.
The waste connection must be at a height of between 30 cm (minimum) and 100 cm (maximum) from the bottom of the dishwasher.
The drain hose can face either to the right or left of the dishwasher
Ensure the hose is not bent or squashed as this could prevent or slow down the discharge of water.
The sink plug must not be in place when the machine is draining as this could cause the water to siphon back into the machine.
If you use a drain hose extension it must be no longer than 2 metres and its internal diameter must be no smaller than the diameter of the hose provided.
Likewise the internal diameter of the couplings used for connections to the waste outlet must be no smaller than the diameter of the hose provided.
Attention!
Our appliances are supplied with a security device to protect against the return of dirty water back into the machine. If the spigot of your sink has a "no return valve" incorporated this can prevent the correct draining of your dishwasher. We advise you therefore to remove it.
Electrical connection
This appliance must be earthed. The manufacturer declines any responsibility should this safety measure not be observed.
If the plug that is fitted to your appliance is not suitable for the socket, it must be cut off and the appropriate plug fitted.
Important
The wires on the mains lead are coloured in accordance with the following code:
Green and Yellow - Earth Blue - Neutral Brown - Live
If you fit your own plug, the colours of the wires in the mains lead of your appliance may not correspond with the markings identifying the terminals in your plug.
Proceed as follows:
1. Connect the Green and Yellow (earth) wire to the terminal
in the plug which is marked with the letter "E" or the earth symbol or coloured green and yellow.
2. Connect the Blue (neutral) wire to the terminal in the plug which is marked with the letter "N" or coloured black.
3. Connect the Brown (live) wire to the terminal in the plug which is marked with the letter "L" or coloured red.
The plug moulded onto the lead incorporates a 13amp BSI362 fuse. Only ASTA or BSI fuses should be used.
The plug must not be used if the fuse cover/carrier is lost. The cover/carrier is indicated by the coloured insert at the base of the plug.
A replacement cover/carrier must be obtained from your local Service Force Centre.
To isolate the dishwasher from mains, remove the mains plug.
Important! The plug must still be accessible after the appliance has been installed.
The appliance should not be connected to the electrical supply by means of an extension cable.
In case that the electrical cable has to be replaced, please contact your local Service Force Centre.
13A
CE04
E
N
L
CS18
21
Testing in accordance with EN 60704 must be carried out with appliance fully loaded and using the test programme (see "Washing programmes" chart).
Test in accordance with EN 50242 must be carried out when the salt dispenser and rinse aid container have been filled with salt and rinse aid respectively and using the test programme (see "Washing programmes" chart).
Hints for test centres
Load: 12 standard place settings Rinse aid setting: position 4 (Type III) Detergent dosage : 5 g + 25 g (Type B)
Arrangement lower basket
Arrangement upper basket
Arrangement cutlery basket
Arrangement cutlery basket
Subject to change without notice
From the Electrolux Group. The world’s No.1 choice.
The Electrolux Group is the world’s largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, cookers, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx. 14 billion USD in more than 150 countries around the world.
©
Electrolux plc 2003
0 06/03
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
