Zanussi ZSA 35 User Manual
Specifications and Main Features
- Model: ZSA 35W - ZSA 35B
- For indoor use, the measurements include:
- Height: 580 mm
- Width: 560-570 mm
- Depth: 550 mm
- The size of the oven: cubic 1.9 ft
- Oven features ‘inside’ include:
- Height: 320 mm
- Width: 420 mm
- Depth: 390 mm
- Oven Specifications:
- Power Consumption Oven Element: 2.5 kW
- Power Consumption Grill Element: 2.0 kW
- Power Consumption Double Grill Element: 3.0 kW
- Power Consumption Convection Fan: 30 W
- Power Consumption Oven Light: 15 W
- Power Consumption Cooling Fan: 25 W
- Power Consumption: 3.070 kW
- Electrical Connection:
- Cable size: 2.5 mm²
- Cable type: Ho5 RR-F
- Minimum fuse required: 13 amp
Frequently Asked Questions
Q: How many cubic feet does the ZANUSSI ZSA 35 oven have?
You can bake up to 1.9 cubic ft.
Q: What are the measurements required for embedding the oven?
In order to embed the oven into existing structures, a height requirement measuring at 580 mm, width measuring at 560-570 mm and a depth measuring at 550 mm needs to be met.
Q: What is the amount of energy that the oven element consumes?
It uses 2.5 Kilowatts to run the oven element.
Q: Is there any way to cool the oven after use?
There is in fact a cooling fan which is rated 25 W and can be used to cool the oven.
Q: What kind of cable is needed for the installation?
A: The cable that is specified for this installation is the Ho5 RR-F of cross section 2.5 mm squared.
