Zanussi ZERB8441 User Manual

A/ZE/14-1. (05.)200370292

GB

FRIDGE - FREEZER

ZERB 8441

ZZAANNUUSSSSII

INSTRUCTION BOOK

This instruction book contains safety precautions, information on use and helpful hints and tips.

To ensure you use this appliance effectively and safely, please read this instruction book carefully
before installing or using this appliance and retain for future reference.

The symbols below help you to find things more easily:

Safety precautions

Warnings and Safety information

Hints, useful information

Environmental information

The symbol on the product or on its packaging indicates that this product may not be treated
as household waste. Instead it shall be handed over to the applicable collection point for the
recycling of electrical and electronic equipment. By ensuring this product is disposed of
correctly, you will help prevent potential negative consequences for the environment and
human health, which could otherwise be caused by inappropriate waste handling of this
product. For more detailed information about recycling of this product, please contact your
local city office, your household waste disposal service or the shop where you purchased the
product.

2

3

Do not use electrical appliances inside the food
storage compartments of the appliance.

During Use

This appliance is designed for domestic use
only, specifically for the storage of edible
foodstuffs. It is not intended for commercial or
industrial use.
Containers with flammable gases or liquids can
leak at low temperatures. Do not store any
containers with flammable materials, such as
spray cans, fire extinguisher refill cartridges etc.
in the appliance.
Frozen food should not be refrozen once it has
thawed out.
Do not place carbonated or fizzy drinks in the
freezer compartment.
Ice lollies can cause 'frost/freezer burns' if
consumed straight from the freezer.
Do not remove items from the freezer
compartment if your hands are damp/wet, as
this could cause skin abrasions or frost/freezer
burns.
Bottles and cans must not be placed in the
freezer compartment they can burst when the
contents freeze.
Manufacturers' recommended storage times
should be adhered to. Refer to relevant
instructions.

Maintenance and Cleaning

Before cleaning, always switch off the appliance
and disconnect from the electrical supply.
When unplugging always pull the plug from the
mains socket, do not pull on the cable.

Servicing

This product should be serviced by an
authorised engineer and only genuine spare
parts should be used.
Under no circumstances should you attempt to
repair the appliance yourself. Repairs carried out
by inexperienced persons may cause injury or
serious malfunctioning. Contact your local
Service Force Centre.

At the end of the Appliance Life

When disposing of your appliance use an
authorised disposal site.
Remove the plug and ensure that any locks or
catches are removed, to prevent young children
being trapped inside.

The Appliance and the Environment

This appliance does not contain gases which could
damage the ozone layer.
Avoid damaging the cooling unit.
The packaging used on this appliance marked with
the symbol is recyclable.

Keep this instruction book for future reference
and ensure it is passed on to any new owner.

IMPOR

IMPORTT

ANT S

ANT S

AFET

AFET

Y INS

Y INS

TR

TR

UCTIONS

UCTIONS

These warnings are provided in the interests of your safety. Ensure that you understand them all
before installing or using this appliance. Your safety is of paramount importance. If you are unsure
about any of the meanings or these warnings contact the Customer Care Department.

Prior to installation

Check the appliance for transport damage. Under
no circumstances should a damaged appliance be
installed. In the event of damage please contact
your retailer.

Installation

This appliance is heavy. Care should be taken when
moving it.
It is dangerous to alter the specifications or attempt
to modify this product in any way.
Ensure that the appliance does not stand on the
electrical supply cable. If the supply cable is
damaged, it must be replaced by a cable available
from your local Service Force Centre.

Make sure that the power plug has not been
squashed or damaged during transit.

- A damaged power plug may overheat and cause a fire.

As you unpack the appliance, check carefully
for any signs of transit damage.
Do not place heavy articles or the
fridge/freezer itself on the power cord.

- There is a risk of a short circuit and fire.

Do not remove the power cord by pulling on its
lead, particularly when the fridge/freezer is
being pulled out of its niche.

- Damage to the cord may cause a short-circuit, fire
and/or electric shock.

- If the power cord is damaged, it must be replaced
by a certified service agent or qualified service
personnel.

If the power plug socket is loose, do not insert
the power plug.

- There is a risk of electric shock or fire.

Any electrical work required to install this appliance
should be carried out by a qualified electrician or
competent person.
Parts which heat up should not be exposed.
Whenever possible, the back of the appliance
should be close to a wall, but leaving the required
distance for ventilation, as stated in the installation
instructions.
The appliance should be left for 2 hours after
installation before it is turned on, in order to allow
the refrigerant to settle.

Child Safety

Do not allow children to tamper with the controls or
play with the product.
Keep packaging materials away from children, to
prevent the risk of suffocation!

Safety precautions for isobutane
Warning

The refrigerant isobutane (R 600a) is contained
within the refrigerant circuit of the appliance, a
natural gas with a high level of environmental
compatibility, which is nevertheless flammable.
Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of
obstruction.
Do not use mechanical devices or other means to
accelerate the defrosting process, other than those
recommended by the manufacturer.
Do not damage the refrigerant circuit.

CCONTENT

ONTENTSS

Instructions for the User

Important Safety Instructions 3

General Information 5
Description of the appliance, main parts 5
Thermostat control knob 6

Handling the appliance 6

Putting in into use 6
Controlling the temperature, setting 6
The Refrigerator 7

Storage Shelves 7

Storage Times 7

The Freezer 8

Freezing fresh food 8
Frozen Food Storage 8
Thawing 8

To Make Ice Cubes 8

Hints and ideas 9

How to save energy 9
The appliance and environment 9

Defrosting 9
Refrigerator 9

Maintenance and Cleaning 10

Freezer 10
To Change the Light Bulb 10

If something does not work 11

Service and Spare Parts 12

Customer Care Department 12

Guarantee Conditions 13

Instructions for the Installer

Technical Data 14

Installing the Appliance 14

Transportation, Unpacking 14
Cleaning 14
Placement 14
Change of door opening direction 16

Electrical Connections 17

Storage time chart 18

4

5

INS

INS

TR

TR

UCTIONS F

UCTIONS F

OR THE USER

OR THE USER

General information

This appliance is designed for the storage of
refrigerated and frozen food in a domestic
environment.

To ensure correct operation, the appliance should
be located where the ambient temperature is
between 10-32 °C.

Description of the appliance, main parts

14. Adjustable feet

15. Butter compartment lid

16. Egg tray

17. Door shelf

18. Door gasket

19. Bottle shelf

20. Handles

21. Ice tray

22. Condenser

23. Defrost water outlet tube

24. Spacer

25. Evaporator tray

26. Compressor

27. Rollers

A - Refrigerator
B - Freezer

1. Top with thermostat control knob

2. Light

3. Glass shelves

4. Bottle rack

5. Cooling surface

6. Defrost water drain

7. Glass shelf

8. Vegetable boxes

9. Data label

10. Freezing compartment

11. Storing compartment(s)

12. Defrost water outlet

13. Bottom plinth

6

Handling the appliance

Thermostat control knob

The thermostat control knob can be found under a
cover in the top frame:

A. Thermostat control knob of the appliance

It is for setting the temperature in the appliance.

Putting it into use

Place the accessories into the appliance then plug in
to the mains socket.

The thermostat knob is under a cover in the top
frame.You can switch the appliance on and set the
temperature with it by turning the knob clockwise.

The next paragraph will give instructions for setting.

Controlling the temperature, setting

The thermostat interrupts the operation of the
appliance automatically for more or less time
depending on the setting then restarts it assuring the
required temperature.

The closer it is set to „Max.” position the more
intensive the refrigerating will be. When the thermostat
knob is set to „Medium” position (between „Min.” and
„Max.”), in the freezing compartment -18 °C, in the
fresh food compartment +5 °C can be reached.
Setting it to „Medium” position is adequate for
everyday use.

The temperature coming about in the refrigerator is
effected by not only the position of the thermostat but
the ambient temperature, frequency of door openings
and the quantity of etc.

In the maximum „Max.” position - in case of

increased demand e.g. during heatwaves - the
compressor may operate continually. This does not
cause damages to the appliance.

7

The Refrigerator

Below is the recommended storage positions for
various food types:

1. Ready-cooked foods, fresh meat, cold cuts.

2. Milk, dairy products.

3. Fruits, vegetables, salads.

4. Cheese, butter.

5. Eggs.

6. Yoghurt, sour cream.

7. Small bottles, drinks.

8. Large bottles, drinks.

Storage Shelves

The shelves in the refrigerator compartment are
adjustable to allow for the storage of large items.

To re-arrange the shelves, open the door to 90°.

Storage Times

The storage chart at the end of the instruction book
gives information on storage times in the refrigerator
compartment. The storage times quoted are intended
as a guide only.

Do not cover the shelves with paper or trays etc. as
this will affect the air circulation within the
refrigerator compartment.

Do not put hot foods in the refrigerator, allow hot
foods to reach room temperature naturally before
placing in the refrigerator.

Cover foods, or place in closed dishes before
placing them in the refrigerator, this prevents any
transference of food smells.

8

The Freezer

Freezing fresh food

When freezing fresh food always place the food in the
freezing compartment which is the top drawer in the
freezer section.

1. Turn the thermostat control knob to the maximum

setting.

2. Place the food to be frozen in the top drawer.

3. After 24 hours return the thermostat control knob

to the medium setting and place the frozen food
into the storage compartments.

Frozen Food Storage

When first starting the freezer or if the freezer has
been out of use for some time, we advise you to run
your appliance for at least 2 hours before storing
frozen food.

Do not exceed the storage period indicated by the
manufacturer.

Do not open the door frequently or leave it open
longer than is necessary.

Important

Do not put carbonated liquids in the freezer.

Ice lollies, if consumed immediately after removal
from the freezer can cause a low temperature skin
burn.

In the event of a power cut the food in the freezer
will not be affected if the power cut is short and the
freezer is full. Do not open the door. Should the
food begin to thaw it must be consumed quickly
and must not be re-frozen. (See Hints and Tips)

Do not remove items from the freezer if your hands
are damp/wet, as this could cause skin abrasions or
frost/freezer burns.

Thawing

Deep frozen or frozen food, prior to being used,
can be thawed in the fridge or at room temperature,
depending on the time available. Small food items
may even be cooked from frozen, in this case
cooking will take longer.

Any frozen food which is allowed to thaw
accidentally should either be eaten as soon as
possible, or thrown away. Alternatively, if the food is
uncooked and has not been completely defrosted
it can be cooked and then refrozen.

Defrosted cooked food must never be
refrozen.

)

To Make Ice Cubes

1. Fill the ice cube tray ¾full with cold water, place

in the freezing compartment and leave to freeze.

2. To remove the cubes twist the tray or hold it
under running water for a few seconds.

Never try to free an ice tray that is frozen to
the freezer compartment by using pointed

or sharp edged objects.

9

Defrosting

Refrigerator

The refrigerator defrosts every time the compressor
stops. The water is discharged, via the pipe, into a tray
located at the back of the appliance above the
compressor, where it evaporates.

Important

To avoid defrost water overflowing into the fridge,
periodically clean the water discharge hole in the centre
of the V shaped drip collector at the back of the
refrigerator compartment, behind the salad drawers.

Use a piece of flexible curtain wire for this purpose.

The appliance and environment

This appliance does not contain gases which could
damage the ozone layer, in either its refrigerant circuit
or insulation materials. The appliance shall not be
discarded together with the urban refuse and rubbish.
Avoid damaging the cooling unit, especially at the rear
near the heat exchanger. Information on your local
disposal sites may be obtained from your municipal
authorities.

The materials used on this appliance marked with the
sympol are recyclable.

Hints and ideas

In this chapter practical hints and ideas are given
about how to use the appliance to reach maximum
energy saving and there is environmental information
about the appliance as well.

How to save energy

Avoid putting the appliance in a sunny place and
near anything that gives off heat.

Be sure that the condenser and the compressor
are well ventilated. Do not cover the sections where
ventilation is.

Wrap products in tightly closing dishes or cling film
to avoid building up unnecessary frost.

Do not leave the door open longer than necessary
and avoid unnecessary openings.

Put warm foods into the appliance only when they
are at room temperature.

Keep the condenser clean.

10

Maintenance

and Cleaning

Freezer

The freezer compartment will become progressively
covered with frost. This should be removed with the
special plastic scraper provided, whenever the

thickness of the frost reaches 6 mm (¾”).

During this operation it is not necessary to switch of
the power supply or to remove the foodstuffs.

However, when the ice becomes very thick on the
inner liner, complete defrosting should be carried out
and it is advisable to perform this operation when the
appliance is empty.

For complete defrosting (once or twice a year)
proceed as follows:

1. Disconnect the appliance from the mains.

2. Remove any food from inside the freezer, wrap it in
several sheets of newspaper and store in a cool,
dry place. Ensure that the fridge door is not
opened to protect the food in the refrigerator while
defrosting the freezer.

3. When defrosting is complete, dry the interior
thoroughly.

4. Reconnect the appliance to the mains, set the
thermostat control knob to the maximum setting.
Leave the appliance to run for at least two hours.

5. Replace the previously removed food.

6. Return the thermostat control knob to a medium
setting.

Important

A temperature rise of the frozen food packs during
defrosting may shorten their safe storage life.

Never use sharp metal tools to scrape off frost from
the evaporator as this could damage the appliance
beyond repair.

)

To Change the Light Bulb

1. Disconnect the appliance from the electrical
supply.

2. Remove the lamp cover securing screw.

3. Take the lamp cover off in the direction of the arrow
and change the bulb. (Type of bulb: 230 V, 15 W,
E 14 thread)

4. Replace the lamp cover and fixing screw.

Spare bulbs are available from your local Service
Force Centre.

11

Possible cause

Thermostatic control can be set
incornectly.

If products are not cold enough or
placed wrongly.

The door does not close tightly or it is not

shut properly.
Thermostatic control can be set

incornectly.

The door does not close tightly or it is not

shut properly.
Products in big quantity to be frozen

were put in.
Products to be frozen are placed too

closely to each other.
It is normal. During automatic defrosting

frost melts on the back plate.
The outlet of the chamber can be

clogged up.
Products placed in can prevent water

from flowing into the collector.
The melting water outlet flows not into

the evaporative tray above the
compressor.

Products are not wrapped properly.
Doors are not shut properly or do not

close tightly.

The thermostatic control can be set
wrongly.

The thermostatic control is set wrongly.

Doors are not shut properly or do not
close tightly.

Products in big quantity to be frozen
were put in.

Too warm food was put in.
The appliance is in too warm place.

Plug is not connected to the mains
socket properly.

The fuse burnt out.
The thermostatic control is not on.

There is no voltage in the mains socket.
(Try to connect another appliance into it.)

The appliance is not supported properly.

Solution

Set the thermostat knob to higher
position.

Place the products to the appropriate
place.

Check if the door closes well and the
gasket remains clean and
undamaded.

Set the thermostat knob to higher
position.

Check if the door closes well and the
gasket remains clean and
undamaded.

Wait some hours and then check the
temperature again.

Place the products in a way so that
cold air could circulate among them.

Clean the outlet.

Replace the products so that they do
not touch the back plate directly.

Put the melting water outlet to the
evaporative tray.

Wrap the products better.
Check if the doors close well and the

gaskets remain clean and
undamaded.

Set the thermostat knob to a position
that gives higher temperature.

Set the thermostat knob to a position
that gives higher temperature.

Check if the doors close well and the
gaskets remain clean and
undamaded.

Wait some hours and then check the
temperature again.

Put food at max. room temperature.
Try to reduce the temperature in the

room where the appliance stands.
Connect the mains plug properly.

Change the fuse.
Start the appliance according to

instructions in chapter 'Putting it into
use'.

Check if the appliance stands stable
(all the four feet should be on the
floor).

Symptom

It is too warm in the
refrigerator.

It is too warm in the
freezer.

Water flows at the back
plate of the refrigerator.

Water flows into the
chamber.

Water flows onto the
floor.

There are too much frost
and ice.

The compressor
operates continually.

The appliance does not
work at all. Neither
cooling, nor lighting
works.

The appliance is noisy.

If something does not work

If the appliance is not working correctly, please carry out the following checks before
contacting your local Service Force Centre.

12

For Customer Service in Ireland please
contact us at the aderess below:

Zanussi - Electrolux
Electrolux Group (Irl) Ltd
Long Mile Road
Dublin 12
Republic of Ireland

Tel: [phone]

Email: [email protected]

Ser

Ser

vice and Spar

vice and Spar

e P

e P

ar

ar

ts

ts

In the event of your appliance requiring service, or if you wish to purchase spare parts, please contact your
local Service Force Centre by telephoning:-

08705 929929

Your telephone call will be automatically routed to the Service Force Centre covering your post code area.

For the address of your local Service Force Centre and further information about Service Force, please visit
the website at www

.serviceforce.co.uk

Before calling out an engineer, please ensure you have read the details under the heading "Something Not
Working."

When you contact the Service Force Centre you will need to give the following details:

1. Your name, address and post code

2. Your telephone number

3. Clear and concise details of the fault

4. The model and serial number of the appliance (found on the rating plate)

5. The purchase date

Please note that a valid purchase receipt or guarantee documentation is required for in-guarantee
service calls.

Cus

Custt

omer Car

omer Car

e Depar

e Depar

tment

tment

For general enquiries concerning your Zanussi - Electrolux appliance or for further information on
Zanussi - Electrolux products, please contact our Customer Care Department by letter or telephone at the
adresses below or visit our website at www.zanussi-electrolux.co.uk

Major Appliances - Customer Care Department
Zanussi-Electrolux
Addington Way
Luton
Bedfordshire
LU4 9QQ
08705 727727 (*)
*calls to this number may be recorded for training purposes.

If after the above checks your appliance still does not
operate correctly, contact your local Service Force
Centre.

Please note that it will be necessary to provide proof
of purchase for any in-guarantee service calls.

In-guarantee customers should ensure that the
above checks have been made, as the
engineer will make a charge if the fault is.

13

Guar

Guar

ant

ant

ee Conditions

ee Conditions

We Zanussi - Electrolux undertake that if within 12
months of the date of the purchase this
ZANUSSI - ELECTROLUX appliance or any part
thereof is proved to be defective by reason only of
faulty workmanship or materials, the company will, at
our option repair or replace the same FREE OF
CHARGE for labour, materials or carriage on condition
that:

The appliance has been correctly installed and
used only on the electrical supply stated on the
rating plate.

The appliance has been used for normal domestic
purposes only, and in accordance with the
manufacturer's instructions.

The appliance has not been serviced, maintained,
repaired, taken apart or tampered with by any
person not authorised by us.

All service work under this guarantee must be
undertaken by a Service Force Centre.

Any appliance or defective part replaced shall
become the Company's property.

Home visits are made between 8.30am and 5.30pm
Monday to Friday. Visits may be available outside
these hours in which case a premium will be charged.

EXCLUSIONS

This Guarantee does not cover:

Damage or calls resulting from transportation,
improper use or neglect, the replacemet of any light
bulbs or removable parts of glass or plastic.

Costs incurred for calls to put right an appliance
improperly installed or calls to appliances outside
the United Kingdom.

Appliances found to be in use within a commercial
environment, plus those which are the subject of
rental agreements.

Products of Zanussi - Electrolux manufacture
which are not marketed by Zanussi - Electrolux.

The guarantee is in addition to your statutory and legal
rights.

EUROPEAN GUARANTEE

If you should move to another country within
Europe then your guarantee moves with you to your
new home subject to the following qualifications:

The guarantee starts from the date you first
purchased your product.

The guarantee is for the same period and to the
same extent for labour and parts as exists in the
new country of use for this brand or range of
products.

This guarantee relates to you and cannot be
transferred to another user.

Your new home is within the European
Community (EC) or European Free Trade Area.

The product is installed and used in accordance
with our instructions and is only used
domestically, i.e. a normal household.

The product is installed taking into account
regulations in your new country.

Before you move please contact your nearest
Customer Care Centre, listed below, to give them
details of your new home. They will then ensure that
the local Service Organisation is aware of your
move and able to look after you and your
appliances.

France Senlis [phone]
Germany Nurenberg [phone]
Italy Pordenone [phone]
Sweden Stockholm [phone]
UK Luton [phone]

Ireland Dublin [phone]

14

Ins

Instrtr

uctions f

uctions f

or the Ins

or the Instt

aller

aller

Technical data

Installing the appliance

Transportation, unpacking

It is recommended to deliver the appliance in
original packaging, in vertical position

considering the protective warning on packaging.

After each transportation the appliance must not be
switched on for approx. 2 hours.

Unpack the appliance and check if there are damages
on it. Report possible damages immediately to the
place you bought it. In that case retain packaging.

Cleaning

Remove every adhesive tape and everything else,
which ensure the accessories not to move in the
appliance.

Wash the inside of the appliance using lukewarm
water and mild detergent. Use soft cloth.

After cleaning wipe out the inside of the appliance.

Placement

The ambient temperature has an effect on the energy
consumption and proper operation of the appliance.
When placing, take into consideration that it is
practical to operate the appliance between ambient
temperature limits according to the climate class that
is given in the chart below and can be found in the
data label.

Model

Gross capacity (l)

Net capacity (l)

Width (mm)

Height (mm)

Depth (mm)

Energy consumption (kWh/24h)

(kWh/year)

Energy class, according to EU standards

Freezing capacity (kg/24h)

Rising time (h)

Rated current (A)

Weight (kg)

Number of compressors

ZERB 8441

Freezer: 226

Refrigerator: 109

Freezer: 223

Refrigerator: 92

595

1790

632

0,93

339

A

4

20

0,9

66

1

Mount the spacers supplied in the plastic bag
of the accessories. Hold the spacer as shown
on the Fig., knock it home, then turn it by 90°.
(Into the oval holes of back side of the
appliance.)

If the ambient temperature goes below the lower
data the temperature of the cooling compartment
can go beyond the prescribed temperature.

If the ambient temperature goes beyond the upper
data this means longer operating time of the
compressor, breakdown in the automatic
defrosting increasing temperature in the cooling
compartment or increasing energy consumption.

Class of climate Ambient temperature

SN +10 ... +32 °C

N +16 ... +32 °C

ST +18 ... +38 °C

15

When placing the appliance ensure that it stands level.
This can be achieved by two adjustable feet at the
bottom in front.

Do not stand the appliance on a sunny place or close
to a radiator or cooker.

If it is unavoidable because of furnishing and the
appliance has to be stood near a cooker take these
minimum distances into consideration:

In case of gas or electric cooker 3 cm must be left,
when it is less put a 0,5-1 cm non-flam insulation
between the two appliances.

In case of oil or coal-fired stove the distance must
be 30 cms since they give off more heat.

The refrigerator is designed to operate when it is
totally pushed to the wall.

When placing the refrigerator keep minimal
distances recommended in figure.

A : placing it under a wall-cupboard
B : placing it freely

16

Change of door opening direction

Disconnect the appliance from the electricity
supply.
Open the doors and dismount the double door
hinge (a,b) by removing the screws (2 pieces) (c).
(fig.2)
Take off the double door hinge (a,b,c) by gradually
removing it from the cabinet, slightly tilting both
doors. Do not forget to remove the plastic spacer
(b) under the hinge. (fig.2)
Take off the refrigerator door by pulling it slightly
downwards.
Take of the freezer door by pulling it slightly
upwards.
Remove the plug on the upper side of the
refrigerator door and put it to the other side.
Remove the plug on the upper side of the freezer
door and put it to the other side.
Unscrew the top door hinge pin (d) of the
refrigerator then screw it back on the other side.
(fig.1)
Remove the insert of the plinth (e) by a screwdriver.
(fig.3)
Unmount the lower hinge pin (f) and its washer (h)
and mount them on the other side. (fig.3)
Replace the insert of the plinth (e) on the other
side.
Remove the blanking pins (3 pieces) (n,k) of the
double door holder on the left side and put them to
the other side. (fig.2)
Fit the pin of the double door hinge (m) into the left
drill of the freezer door. (fig.2)
Fit the freezer door to the lower door hinge pin (f).
(fig.3)
Fit the refrigerator door to the upper door hinge pin
(d) then slightly tilting both doors fit the pin of the
double door hinge (m) into the left drill of the
refrigerator door.
Opening both doors fix the double door hinge onto
the left side using the screws (2 pieces) (c). Do not
forget to replace the plastic spacer (b) under the
hinge. Be careful that the door edges are parallel
with the edge of the top panel.
Put over the handles (r) on the other side and put
the plastic blanking pins (p) supplied in the plastic
bag of this instruction book into the holes set free.
(fig.4)
Put the appliance to its place, set it level, and apply

to voltage it.
In case you do not want to perform the procedures
above, call your local Service Force. Technicians will
accomplish the refitting expertly for charge.

fig. 1.

fig. 2.

fig. 3.

fig. 4.

17

Electrical Connection

Electrical Connection

Any electrical work required to install this
appliance should be carried out by a
qualified electrician or competent person.

This appliance must be earthed.

The manufacturer declines any liability should
these safety measures not be observed.

Electrical Requirements

Before switching on, make sure the electricity supply
voltage is the same as that indicated on the appliance
rating plate.

The appliance is supplied with a 13 amp plug fitted. In
the event of having to change the fuse in the plug
supplied, a 13 amp ASTA approved (BS 1362) fuse
must be used. Should the plug need to be replaced
for any reason. The wires in the mains lead are
coloured in accordance with the following code:

Green and Yellow: Earth
Blue: Neutral
Brown: Live
The wire coloured green and yellow must be

connected to the terminal marked with the letter „E“ or
by the earth symbol or coloured green and yellow.

The wire coloured blue must be connected to the
terminal „N“ or coloured black.

The wire coloured brown must be connected to the
terminal marked „L“ or coloured red.

Upon completion there must be no cut, or stray
strands of wire present and the cord clamp must
be secure over the outer sheath.

Important!

The plug must still be accessible after the
appliance has been installed.

The appliance should not be connected to the
electrical supply by means of an extension cable.

In case that the electrical cable has to be
replaced, please contact your local Service Force
Centre.

Warning!

A cut off plug inserted into a 13 amp socket is a
serious safety (shock) hazard. Ensure that it is
disposed of safely.

This appliance complies with the following
E.E.C. Directives:

73/23 EEC of 19.02.73 (Low Voltage Directive)

and subsequent modifications,

89/336 EEC of 03.05.89 (Electromagnetic

Compatibility Directive) and subsequent

modifications.

SSttor

or

age time char

age time chartt

Time and method of storage of fresh foods in the refrigerator

Foods Storage time in days Method of packaging

1234567

Raw meat XXx x x cling film, airtight
Cooked meat XXXx x x dish covered
Roasted meat XXXx x dish covered
Raw minced meat X dish covered
Cooked minced meat XXx x dish covered
Cold cuts XXx x cling film, cellophane, grease-

proof paper
Fresh fish X x x cling film, airtight
Cooked fish XXx x dish covered
Tinned fish, open X x x dish covered
Fresh chicken XXXx x x cling film, airtight
Fried chicken XXXx x x dish covered
Fresh duck, goose XXXx x x cling film, airtight
Roasted duck, goose XXXXx x x dish covered
Butter unopened XXXXXXXoriginal packaging
Butter opened XXx x x x x original packaging
Milk XXXx x original packaging
Cream XXx x plastic box
Sour cream XXXXx x x plastic box
Cheese (hard) XXXXXXXaluminium foil
Cheese (soft) XXXX x x x cling film
Egg XXXXXXX
Spinach, sorrel XX x x cling film
Green peas, green beans XXXXx x x cling film
Mushroom XXx x x cling film
Carrot XXXXXXXcling film
Tomato XXXXXXXcling film
Cabbage XXXXXx x cling film
Fruits (Strawberry,
raspberry, etc.) XXXx x cling film
Tinned fruits opened XXXx x dish covered
Cakes filled with cream XXx x dish covered

Notation:

X recommended storage time

x maximum recommended storage time

18

A/ZE/14-1. (05)

19

From the Electrolux Group. The world’s No.1 choice.

The Electrolux Group is the world's largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux
Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of
approx. USD 14 billion in more than 150 countries around the world.

ELECTROLUX HOME PRODUCTS OPERATIONS EUROPE

© Electrolux plc 2005

Printed By Océ Hungária Kft.

2006. 02. 17.
