Zanussi R04FSGGW, 730159 Specifications

ZANUSSI

P R O F E S S I O N A L

400LT WHITE PRE-PAINTED REFRIGER./FREEZ.

AG I SERIES

730191

PAIR OF GRIDS (WHITE) FOR 400LT
REFRIG.

2 2

INCLUDED ACCESSORIES

Power supply - V, phases, Hz 230 V, 1N, 50 230 V, 1N, 50 230 V, 1N, 50 230 V, 1N, 50

Net weight - kg. 75 89 75 89

Noise level - dBA 53.5 55 56 56

Internal light l

installed-electric 0.17 0.19 0.527 0.85

Power - kW

at evaporation temperature - °C -12 -10 -29 -23

Refrigerant power

Refrigeration power - W 306 249 881 628

Refrigerant quantity - g. 240 240 240 240

Refrigerant type R134a R134a R404a R404a

Defrost type Automatic (air) Automatic Manual Manual

Compressor power - HP 1/5 1/5 1 1/2

N° and type of grids (included) 4, 600x400 4, 600x400 ; 600x400 600x400

Door hinges Right Side Right Side Right Side Right Side

Min/Max internal humidity - % 70 60

height 1450 1450 1450 1450

depth 435 435 435 435

width 610 610 610 610

Internal dimensions - mm

height 1645 1645 1645 1645

depth/with open doors 620, 1310 620, 1310 620, 1310 620, 1310

width 703 703 703 703

External dimensions - mm

Gross capacity (D.I.N. 8952) - l. 400 400 400 400

panels Polystyrene Polystyrene Polystyrene Polystyrene

Internal material

door Prepainted Steel Glass Prepainted Steel Glass Heated

panels Prepainted Steel Prepainted Steel Prepainted Steel Prepainted Steel

External material

Operating mode Ventilated Ventilated Static Static

Operating temperature - min/max °C 0/10 0/10 -24/-15 -22/-15

R04PVFW

730191

R04PVGW

730192

R04FSFW

730193

R04FSGGW

730159

CHARACTERISTICS MODELS

TECHNICAL DATA

RANGE

COMPOSITION

A range of 400 litre refrigerators
designed to satisfy the
food-conservation requirements of
professional caterers who want the
high performance and reliability of a
commercial unit but who have limited
space in the kitchen. The AG I
Series refrigerators have separate
storage areas for different types of
food and indeed separate cabinets.
The range consists of white
pre-painted steel models, stainless
steel models, glass door models and
wine models. The models detailed in
this sheet are 4 white pre-painted
models.

FUNCTIONAL AND
CONSTRUCTION
FEATURES

� Internal structure in polystyrene, external

structure in white prepainted steel with the
top and back in galvanised steel.
Height-adjustable plastic feet.

� Digital control panel allowing for an easy

and precise setting and control of the internal
temperature.

� Automatic defrosting and defrost water

evaporation for refrigerators.

� The models use CFC free R134a and

R404a.

� High-density expanded polyurethane

insulating foam, 45 mm in thickness, with
cyclopenthane injection, guarantees
exceptional, long-term insulation and notable
energy savings.

� The rational use of the internal space of

the refrigerator guarantees a large storage
area suitable to contain 600 x 400 mm grids.

� A reversible self-closing door equipped

with a magnetic door seal to guarantee
perfect closure. The recessed door handle
makes opening the cabinet extremely easy.
180° maximum door opening and doors stay
open at 95°. All the doors are fitted as
standard with locks and keys.

400LT WHITE PRE-PAINTED REFRIGER./FREEZ.

AG I SERIES

DAG02 2010-05-29 The Company reserves the right to alter technical specifications without prior notice.

www.zanussiprofessional.com

ZANUSSI

P R O F E S S I O N A L

PVC CONTAINER W/FALSE BOTTOM FOR 400 LT 881072 881072 881072

PRINTER FOR HACCP BASIC VERSION REFRIG. 881457 881457 881457 881457

PAIR OF GRIDS (WHITE) FOR 400LT REFRIG. 880292 880292

R04PVFW

730191

R04PVGW

730192

R04FSFW

730193

R04FSGGW

730159

ACCESSORIES MODELS

OPTIONAL ACCESSORIES

� Designed to operate at ambient

temperature of 43° C for refrigerator, 38 °C
for freezer and 32 °C for glass model.

� High standards of hygiene and ease of

cleaning are guaranteed by the white
thermoformed polystyrene internal cell with
rounded internal corners of the cabinet and
thermoformed runners for an easy and safe
positioning of the grids.

� Equipment supplied as standard: n. 4

600x400 mm plastic-coated grids.

� CFC and HCFC free; complies with

EN55014 and EN55104 electromagnetic
standards.

� All models comply with the standards

required by the main international approval
bodies and are H marked.
