RANGE
COMPOSITION
Zanussi Professional have designed
and produced a complete range of
refrigerated tables, that combines
the dual function of worktop and
refrigerated table. This versatility
allows notable savings in space
whilst offering functional and
modular solutions to kitchen
requirements.
FUNCTIONAL AND
CONSTRUCTION
FEATURES
� Built-in refrigeration unit.
� Height-adjustable feet.
� Constructed from AISI 304
stainless steel throughout to meet
the highest hygiene standards.
� Rounded internal corners for ease
of cleaning.
� Lower refrigerated compartment
designed to accommodate GN 1/1
containers.
� Digital control panel.
� Suitable to operate in ambient
temperatures up to +32°C.
Temperature range: +2+10 °C.
� Forced air circulation for rapid
cooling and an even temperature
distribution.
� Automatic evaporation of defrost
water. Drain outlet.
� Access to all components from the
front.
� In compliance with H
requirements.
� C.F.C. and H.C.F.C. free.
250 LT
SALADETTE
� Environmentally friendly: R134a.
� High-density expanded
polyurethane foam, 50 mm in
thickness, with cyclopenthane
TECHNICAL DATA
CHARACTERISTICS MODELS
Operating temperature - min/max °C 2/10 2/10
Operating mode Ventilated Ventilated
Gross capacity (D.I.N. 8952) - l. 250 250
Cooling unit Built-In Built-In
External dimensions - mm
width 955 950
depth/with open doors 700, 1120 700, 1120
height 845 1126
Internal dimensions - mm
width 870 870
depth 550 550
height 520 520
Worktop type Plastic Marble
Min/Max internal humidity - % 50/70 50/70
N° of drawers None None
N° and type of door 2 2
Door hinges 1 Left+1 Right 1 Left+1 Right
Compressor power - HP 1/4; 1/4;
N° defrost in 24 hrs. 4/25' 4/25'
Refrigerant type R134a R134a
Refrigerant quantity - g. 120 120
Refrigeration power - W 224 224
Power - kW
installed-electric 0.288 0.288
Net weight - kg. 82 162
Power supply - V, phases, Hz 230 V, 1N, 50 230 V, 1N, 50
injection.
� Developed and produced in ISO
9001 and ISO 14001 certified factory.
SAL25L2C9
728627
ZANUSSI
P R O F E S S I O N A L
PTR259
728628
![](/html/b4/b481/b481a1ebcad32dc7f65ed98c18b40dda17b9883968c844487d48f83b50e32521/bg2.png)
728627 728628
LEGEND
EI - Electrical connection 230 V, 1N, 50 230 V, 1N, 50
OPTIONAL ACCESSORIES
ACCESSORIES MODELS
1/1 GN GREY "RILSAN" GRID 881435 881435
HACCP ADV.CONN.10 UNITS-DIG.REF.(ID9XX) 880119 880119
HACCP ADV.CONN.80 UNITS-DIG.REF.(ID9XX) 880132 880132
HACCP ADV.CONN.PER UNIT-DIG.REF.(ID9XX) 880133 880133
KIT 4 WHEELS FOR 250L COUNTER/SALADETTE 880267
KIT HACCP EKIS 922166 922166
PLASTIC CONTAINER GN 1/1 H=100 MM 811451 811451
PLASTIC CONTAINER GN 1/1 H=150 MM 881040 881040
PLASTIC CONTAINER GN 1/1 H=65 MM 881038 881038
DBE03 2009-07-03 The Company reserves the right to alter technical specifications without prior notice.
SAL25L2C9
728627
PTR259
728628
SAL25L2C9
728627
PTR259
728628
ZANUSSI
P R O F E S S I O N A L
www.zanussiprofessional.com
