Zanussi 131462, 131463, LG1225, LG1426, LG1826DX Specifications
...
ZANUSSI
P R O F E S S I O N A L
HD PLUS DOUBLE BOWL SINKS ON LEGS
1200/1800 mm
133571
Drainer position Right Left Right Left
Net weight - kg. 42 46 51 51 80 80
Bowl dimensions (wxdxh) - mm 500x500xH300 600x500xH300 500x500xH300 500x500xH300 500x500xH300 500x500xH300
Bowls - n. 2 2 2 2 2 2
radius R=10 R=10 R=10 R=10 R=10 R=10
depth 13 13 13 13 13 13
height 100 100 100 100 100 100
Upstand dimensions - mm
Worktop thickness - mm 50 50 50 50 50 50
height 900 900 900 900 900 900
depth 700 700 700 700 700 700
width 1200 1400 1800 1800 1800 1800
External dimensions - mm
LG1225E
133564
LG1426E
133567
LG1826DXE
133570
LG1826SXE
133571
LR2DSXPE
133576
LR2SSPE
133575
CHARACTERISTICS MODELS
TECHNICAL DATA
RANGE
COMPOSITION
The range consists of 6 sinks, with
all-round apron panelling, 1200,
1400, 1800 mm in length, and with
two bowls.
FUNCTIONAL AND
CONSTRUCTION
FEATURES
� Worktop in 12/10, 304 AISI
stainless steel, 50 mm in thickness
and with overflow rim along the top;
the woktop has welded corners and
anti-drip edges.
� Sink bowl in 304 AISI stainless
steel.
� The bows are seam welded and
polished, the base is inclined
towards the drain outlets. All bowls
are supplied as standard with an
overflow pipe and a drain hole.
� Rear splashback with 10 mm
rounded corner, 100 mm in height
and 13 mm deep.
� Round section legs and 50 mm
Dia. height-adjustable (-60 +10 mm)
feet in 304 AISI stainless steel to
guarantee perfect alignment with
other food preparation equipment.
For an easy installation legs are
mounted (in case of external pipes
or other connections) at 80 mm from
the edge of table top; all-round apron
panelling in 304 AISI stainless steel.
� Quick and easy installation as the
Taps are easily installed from the
rear.
� A 50 mm thick lower shelf, in 304
AISI stainless steel can be easily
slotted into position, 200 mm from
the floor.
� All models comply with the more
strict international standards as far
as hygiene and cleanability are
concerned.
HD PLUS DOUBLE BOWL SINKS ON LEGS
1200/1800 mm
ABED1 2010-05-29 The Company reserves the right to alter technical specifications without prior notice.
www.zanussiprofessional.com
ZANUSSI
P R O F E S S I O N A L
WALL MIXER TAP WITH SWIVEL SPOUT 3/4" 855310 855310 855310 855310 855310 855310
WALL
MIX.TAP+SPRAY+SPOUT+SH.LEVER+THERM
855307 855307 855307 855307 855307 855307
SINGLE PLASTIC SYPHON 2" 895313 895313 895313 895313 895313 895313
SINGLE BRASS SYPHON 2" 895314 895314 895314 895314 895314 895314
PRE-WASH SPRAY UNIT,SINGLE HOLE 855315 855315 855315 855315 855315 855315
OVERFLOW FILTER FOR 600X500 MM BOWL 895135 895135 895135
OVERFLOW FILTER FOR 500X500 MM BOWL 895136 895136 895136
MIXER TAP+SPRAY ARM+SPOUT-3/4"
SING.HOLE
855329 855329 855329 855329 855329 855329
MIXER TAP(PREMIUM)+SPRAY ARM-3/4"
HOLE
855326 855326 855326 855326 855326 855326
MIXER TAP(INFRARED)+SPOUT
3/4"SING.HOLE
855325 855325 855325 855325 855325 855325
MIXER TAP WITH SPOUT 3/4" SINGLE HOLE 855319 855319 855319 855319 855319 855319
MIXER TAP W/FOOT PEDAL FOR SINKS ON
LEGS
855317 855317 855317 855317 855317 855317
MAXIREEL-RETRACTABLE HOSE SPRAY
UNIT 6M
855327 855327 855327 855327 855327 855327
MAXIREEL-RETRACTABLE HOSE SPRAY
UNIT 15M
855321 855321 855321 855321 855321 855321
MAXIREEL-RETRACTABLE HOSE SPRAY
UNIT 10M
855320 855320 855320 855320 855320 855320
LOWER SHELF FOR 1800 MM UNITS 855027 855027
LOWER SHELF FOR 1400 MM UNITS 855023
LOWER SHELF FOR 1200 MM UNITS 855021
FOOT OP.MIXER
TAP(HOT+COLD)+SPOUT-3/4"
855328 855328 855328 855328 855328 855328
FALSE BOTTOM FOR R/H 600X500 MM BOWL 895100 895100 895100
FALSE BOTTOM FOR R/H 500X500 MM BOWL 895200 895200 895200
FALSE BOTTOM FOR L/H 600X500 MM BOWL 895110 895110 895110
FALSE BOTTOM FOR L/H 500X500 MM BOWL 895210 895210 895210
ELBOW OP.TAP+SPRAY ARM+SPOUT-3/4"
HOLE
855324 855324 855324 855324 855324 855324
ELBOW OP.MIXER TAP+SPOUT-3/4"SINGLE
HOLE
855322 855322 855322 855322 855322 855322
DOUBLE PLASTIC DRAIN SYPHON 2" 850022 850022 850022 850022 850022 850022
LG1225E
133564
LG1426E
133567
LG1826DXE
133570
LG1826SXE
133571
LR2DSXPE
133576
LR2SSPE
133575
ACCESSORIES MODELS
OPTIONAL ACCESSORIES
HD PLUS DOUBLE BOWL SINKS ON LEGS
1200/1800 mm
ABED1 2010-05-29 The Company reserves the right to alter technical specifications without prior notice.
www.zanussiprofessional.com
ZANUSSI
P R O F E S S I O N A L
HWI - Hot water inlet 3/4"
D - Water drain 2"
CWI - Cold water inlet 3/4"
LG1225E
133564
LEGEND
