ZANUSSI
P R O F E S S I O N A L
GLASSWASHERS
LB-040
727042
SQ. BASKET 400X400MM INCL.BOTTOM H=120MM 1
RECT.CUTLERY HOLDER(55X130X100H)-2 COMP. 1
INCLUDED ACCESSORIES
Supply voltage 230 V, 1N, 50
Net weight - kg. 42
Noise level - dBA 58
total power 2.6
Power - kW
Boiler elements - kW 2.4
Boiler capacity - lt. 3.25
water consumption - lt./cycle 2
temperature during rinse - °C 80-90
duration - sec. 15
Hot rinse cycle
electrical elements - kW 2
power pump - kW 0.55
tank capacity - lt. 12
temperature -°C 55-65
Washing cycle
height 270
Cell dimensions - mm
height 745
depth 512
width 510
External dimensions - mm
Basket capacity/h 30
Duration cycles - sec. 120
N° of cycles 1
Detergent dispenser l
hardness - °f 7-14
temperature - °C 10
Water supply
LB40QD
727042
CHARACTERISTICS MODELS
TECHNICAL DATA
RANGE
COMPOSITION
The range consists of 1 model with square
basket, offering the possibility to wash
glasses and small plates with a capacity of
1.400 glasses per hour.
FUNCTIONAL AND
CONSTRUCTION
FEATURES
� 120 seconds fixed cycle
� Glasses, cups and crockery up to a height
of 270 mm can be washed due to the ample
loading height
� Washing temperature 55° to 65°C and
rinse temperature 80° to 90°
� Double-walled washing chamber and tank
� Separate washing and rinsing circuits: the
washing and rinsing arms rotate.
� This model incorporates a rinse aid
dispenser and a detergent dispenser to
connect to an external container.
� Load bearing frame, and front panels,
tank and filter in 304 AISI stainless steel.
Wash arms and jets in polypropylene
� Basket(s) for glasses with the insert rack
for and cutlery, electric cable and the hose
for water connection supplied as standard
� Model complies with the standards of the
main international approval bodies and are
H marked.
*Declared actual cycle duration times can extend
when water supply temperature is lower than
indicated.
Page 2
GLASSWASHERS
LB-040
EAAA2 2009-07-24 The Company reserves the right to alter technical specifications without prior notice.
www.zanussiprofessional.com
ZANUSSI
P R O F E S S I O N A L
SQUARE BASKET 400X400 MM-INCLINED BOTTOM 860150
SQUARE BASKET 400X400 MM (H. 180 MM) 860149
SQUARE BASKET 400X400 MM (H. 120 MM) 860139
S/S STAND FOR GW WITH BASKET 400X400MM 860154
LB40QD
727042
ACCESSORIES MODELS
OPTIONAL ACCESSORIES
Page 3
GLASSWASHERS
LB-040
EAAA2 2009-07-24 The Company reserves the right to alter technical specifications without prior notice.
www.zanussiprofessional.com
ZANUSSI
P R O F E S S I O N A L
EI - Electrical connection 230 V, 1N, 50
D - Water drain 25mm
CWI - Cold water inlet G 3/4"
LB40QD
727042
LEGEND
727042
