Zanussi FV850N User Manual

WASHING MACHINE

PRALKA AUTOMATYCZA

AUTOMATICKÁ PRACKA
AUTOMATICKÁ PRÁCKA

AUTOMATA MOSÓGÉP

FV 850 N

132987810

INSTRUCTION BOOKLET

INSTRUKCJA OBSLUGI

NÁVOD OBSLUZE

NÁVOD NA OBSLUHU

HASZNÁLATI ÚTMUTATÓ

GB
PL
CZ
SK

H

Dear customer,

Transport damages

Please read these operating instructions carefully
and pay particular attention to the safety notes
indicated in the first pages. We recommend that you
keep this instruction booklet for future reference and
pass it on to any future owners.

Contents

Warnings 3

Disposal 4

Tips for environmental protection 4

Technical specifications 4

Installation 5

Unpacking 5

Positioning and levelling 5

Water inlet 5

Water drainage 6

Electrical connection 6

Your new washing machine 7

Description of the appliance 7

Detergent dispenser drawer 7

When unpacking the appliance, check that it is not
damaged. If in doubt, do not use it and contact the
Service Centre.

Temperatures 9

Before loading the laundry 9

Maximum loads 9

Laundry weights 9

Removing stains 9-10

Detergents and additives 10

Operating sequence 11-12

International wash code symbols 12

Washing programmes 13-14

Maintenance 15-16

Bodywork 15

Door seal 15

Detergent dispenser drawer 15

Drain pump 15

Water inlet filter 16

Emergency emptying out 16

Frost precautions 16

Use 8

Something not working? 17-18

Control panel 8

Controls 8

Washing hints 9

Sorting the laundry 9

The symbols you will see on some paragraphs of this booklet have the following meaning:

The warning triangle and/or the key words (Warning!, Caution!) emphasize information that is particularly
important for your safety or correct functioning of the appliance.

The information marked with this symbol provides additional instructions and practical tips on the use of
the appliance.

Tips and information about economical and ecological use of the machine are marked with this symbol.

Our contribution to the protection of the environment: we use recycled paper.

2

Warnings

The following warnings are provided in the interests of overall safety. You must read them carefully before
installing or using the appliance.

Installation

• All internal packing must be removed before using
the appliance. Serious damage may be caused to
the machine or adjacent furniture if the protective
transit devices are not removed or are not
completely removed. Refer to the relevant
paragraph in the instruction book.

• Any electrical work required to install this appliance
must be carried out by a qualified electrician.

• Any plumbing work required to install this
appliance must be carried out by a qualified
plumber.

• After having installed the machine, check that it is
not standing on its electrical supply cable.

• If the appliance is placed on a carpeted floor,
ensure that air can circulate freely between the
feet and the floor.

Use

• This appliance is designed for domestic use. It
must not be used for purposes other than those for
which it was designed.

• Only wash fabrics which are designed to be
machine washed. Follow the instructions on each
garment label.

• Do not overload the appliance. Follow the
instructions in the instruction book.

• Make sure that all pockets are empty. Objects such
as coins, safety pins, pins and screws can cause
extensive damage.

• Do not machine wash garments saturated with
petroleum, methylated spirits, trichlorethylene, etc.
If such fluids have been used to remove stains
prior to washing, wait until they have completely
evaporated from the fabric before placing
garments in the appliance.

• Place small items such as socks, belts, etc. in a
cloth bag or pillowcase to prevent them getting
trapped between the drum and the tub.

• Use only the recommended quantities of fabric
softener. An excessive amount could damage the
laundry.

• Leave the porthole door slightly ajar when the
appliance is not in use. This preserves the door
seal and prevents the formation of musty smells.

• Always check that water has emptied out before
opening the door. If not, drain the water following
the instructions in the instruction book.

• Always unplug the appliance and shut the water
tap after use.

General safety

• Repairs to the machine must be carried out only by
qualified personnel. Repairs carried out by
inexperienced persons could cause serious
danger. Contact your local Service Centre.

• Never pull the power supply cable to remove the
plug from the socket; always take hold of the plug
itself.

• During high temperature wash programmes the
door glass may get hot. Do not touch it!

Child safety

• Children are often not aware of how dangerous
electrical appliances can be. When the machine is
working, children should be carefully supervised
and not be allowed to play with the appliance.

• The packaging components (e.g. plastic film,
polystyrene) can be dangerous to children - danger
of suffocation! Keep them out of children’s reach.

• Keep all detergents in a safe place out of children’s
reach.

• Make sure that children or pets do not climb into
the drum.

• When the appliance is to be scrapped, cut off the
electrical supply cable and destroy the plug with
the remaining cable. Disable the door catch in
order to prevent children from becoming trapped
inside while playing.

ENGLISH

3

Disposal

Packaging materials

The materials marked with the symbol are
recyclable.

>PE<=polyethylene

>PS<=polystyrene

>PP<=polypropylene

This means that they can be recycled by disposing of
them properly in appropriate collection containers.

Tips for environmental protection

To save water, energy and to help protect the
environment, we recommend that you follow these
tips:

• Normally soiled laundry may be washed without
prewashing in order to save detergent, water and
time (the environment is protected too!).

• The machine works more economically if it is fully
loaded. Do not overload!

Machine

Use authorised disposal sites for your old appliance.
Help to keep your country tidy!

• With adequate pre-treatment, stains and limited
soiling can be removed; the laundry can then be
washed at a lower temperature.

• Measure out detergent according to the water
hardness, the degree of soiling and the quantity of
laundry being washed.

Technical specifications

DIMENSIONS Height 85 cm

Width 60 cm
Depth 44 cm

MAXIMUM LOAD Cotton 4,5 kg

Synthetics 1,5 kg
Delicates 1,5 kg
Woollens/

SPIN SPEED 850 rpm max.

POWER SUPPLY VOLTAGE/FREQUENCY 220-230 V/50 Hz
TOTAL POWER ABSORBED 2200 W
MINIMUM FUSE PROTECTION 10 A

WATER PRESSURE Minimum 0,05 MPa

Maximum 0,8 MPa

This appliance complies with the following EEC Directives:
73/23/EEC of 19/02/73 relating to low voltage
89/336/EEC of 03/05/89 relating to electromagnetic compatibility.

Handwash

1 kg

4

P1127

P1126

P1124

2

3

1

P0001

P1129

P1088

P1051

P0002

P1128

Installation

Unpacking

All transit bolts and packing must be removed
before using the appliance.

You are advised to keep all transit devices so that
they can be refitted if the machine ever has to be
transported again.

1. Using a spanner, unscrew and remove the two
rear bottom screws. Slide out the two plastic pins.

2. Lay the machine on its back, taking care not to
squash the hoses. This can be avoided by
placing one of the corner packing pieces between
the machine and the floor.

3. Remove the polystyrene block from the bottom of
the machine and release the two plastic bags.

6. Set the machine upright and remove the
remaining rear screw. Slide out the relevant pin.

7. Plug all the holes with the plugs which you will
find in the envelope containing the instruction
booklet.

Positioning and levelling

Install the machine on a flat hard floor.
Make sure that air circulation around the machine is
not impeded by carpets, rugs etc. Check that the
machine does not touch the wall or other kitchen
units.
Carefully level by screwing the adjustable feet in or
out. Never place cardboard, wood or similar
materials under the machine to compensate for any
unevenness in the floor.

ENGLISH

4. Very carefully slide out the left polythene bag,
removing it towards the right and then
downwards.

5. Very carefully slide out the right polythene bag,
removing it towards the left and then upwards.

Water inlet

Connect the water inlet hose to a tap with a 3/4"
thread.

5

The other end of the inlet hose which connects to the

P0022

P0021

P1118

machine can be turned in any direction. Simply
loosen the fitting, rotate the hose and retighten the
fitting, making sure there are no water leaks.

The inlet hose must not be lengthened. If it is too
short and you do not wish to move the tap, you will
have to purchase a new, longer hose specially
designed for this type of use.

Water drainage

The end of the drain hose can be positioned in three
ways:

Hooked over the edge of a sink using the plastic
hose guide supplied with the machine. In this

case, make sure the end cannot come unhooked
when the machine is emptying.
This could be done by tying it to the tap with a piece
of string or attaching it to the wall.

The drain hose must not be kinked.

For a correct functioning of the machine the
drain hose must remain hooked on the proper
support piece situated on the top part of the back
side of the appliance.

Electrical connection

This machine is designed to operate on a 220-230 V,
single-phase, 50 Hz supply.

Check that your domestic electrical installation can
take the maximum load required (1.75 kW), also
taking into account any other appliances in use.

Connect the machine to an earthed socket.

The manufacturer declines any responsibility
for damage or injury through failure to comply
with the above safety precaution.
Should the appliance power supply cable
need to be replaced, this must be carried out
by our Service Centre.

In a sink drain pipe branch. This branch must be
above the trap so that the bend is at least 60 cm
above the ground.

Directly into a drain pipe at a height of not less
than 60 cm and not more than 90 cm.
The end of the drain hose must always be
ventilated, i.e. the inside diameter of the drain pipe
must be larger than the outside diameter of the drain
hose.

Please ensure that when the appliance is
installed the power supply cable is easily
accessible.

6

Your new washing machine

This new machine meets all modern requirements for effective treatment of laundry with low water, energy and
detergent consumption.

• The temperature selector dial will allow you to choose the most suitable temperature for your laundry.

• The automatic cooling of the washing water to 60°C before draining with the 95°C programme. This

reduces thermal shock to fabrics, helping to prevent creasing.

• The ECO valve allows total use of detergent and reduces water consumption so saving energy.

Description of the appliance

ENGLISH

1 Detergent dispenser drawer

2 Programme chart

3 Control panel

4 Door handle

5 Drain pump

6 Adjustable feet

13

F

V

8

5

0

B

J

3

6

0

0

°

°

-

-

6

9

0

5

°

°

B

K

3

0

°

-

6

0

°

-

4

0

°

B

L

-

4

0

°

4

0

°

-

6

0

°

E

H

A

3

0

°

-

6

0

°

6

0

°

-

9

5

°

C

M

6

0

°

D

N

4

0

°

F

P

G

850

A

A

N

2

4

5

6

Detergent dispenser drawer

Prewash

Main wash

Fabric softener, starch

C0069

7

Use

Control panel

B

B
B

60°- 95°

30°- 60°

40°- 60°E
A
C

D

F
G

60°- 95°

60°

40°

J
K

L
H
M

N

P

30°- 60°

30°- 60°

- 40°

- 40°

AA

FV 850 N

850

1

234567 8 9

1 Detergent dispenser drawer

2 ON/OFF button

By depressing this button the machine is switched
on. By depressing it again the machine is switched
off.

3 Mains on light

This light is on whilst the machine is operating and
goes out at the end of the programme.

4 Spin suppression button

Depress this button when you have to wash
particularly delicate items in order to exclude all the
spinning phases.

5 Spin speed reduction button

By depressing this button the final spin speed is
reduced as follows:

- from 850 to 400 rpm in programmes for cotton
and linen

- from 550 to 400 rpm in programmes for synthetics,
delicates and wool.

6 Super rinse button

Can be used only for cotton programmes A-B-C-D­F. The machine will perform the rinses with more

water. This option is recommended for people who
are allergic to detergents and in areas where the
water is very soft.

7 Rinse hold button

By depressing this button the water of the last rinse
is not emptied out to avoid any creasing in the
laundry.
To drain water and spin, depress button again.
To drain only, select programme P.

8 Temperature selector dial

Turn this dial to select the washing temperature.
Position = cold wash.

9 Programme selector dial

To select the required programme, turn this dial
clockwise until the programme letter is exactly
opposite the pointer.
Before selecting a programme or changing a
programme in progress the machine must be
switched off by depressing ON/OFF button.

8

Washing hints

Laundry weights

Sorting the laundry

Follow the wash code symbols on each garment
label and the manufacturer’s washing instructions.
Sort the laundry as follows:
whites, coloureds, synthetics, delicates, woollens.

Temperatures

95°

for normally soiled white cottons and linen
(e.g. tea cloths, towels, tablecloths,
sheets...)

60° for normally soiled, colour fast garments

(e.g. shirts, night dresses, pyjamas....) in

linen, cotton or synthetic fibres and for
lightly soiled white cotton (e.g. underwear).

(cold)for delicate items (e.g. net curtains), mixed

30°-40° laundry including synthetic fibres

and woollens bearing the label «pure new
wool, machine washable, non-shrink».

Before loading the laundry

Never wash whites and coloureds together. Whites
may lose their “whiteness” in the wash.

New coloured items may run in the first wash; they
should therefore be washed separately the first time.

Make sure that no metal objects are left in the
laundry (e.g. hair clips, safety pins, pins).

Button up pillowcases, close zip fasteners, hooks
and poppers. Tie any belts or long tapes.

Remove persistent stains before washing. Rub
particularly soiled areas with a special detergent or
detergent paste.

Treat curtains with special care. Remove hooks or tie
them up in a bag or net.

Maximum loads

Recommended loads are indicated in the
programme charts.

General rules:

Cotton, linen: drum full but not too tightly packed;

Synthetics: drum no more than half full;

Delicate fabrics and woollens: drum no more than

one third full.

Washing a maximum load makes the most efficient
use of water and energy.

For heavily soiled laundry, reduce the load size.

The following weights are indicative:

bathrobe 1200 g

napkin 100 g

quilt cover 700 g

sheet 500 g

pillow case 200 g

tablecloth 250 g

towelling towel 200 g

tea cloth 100 g

night dress 200 g

ladies’ briefs 100 g

man’s work shirt 600 g

man’s shirt 200 g

man’s pyjamas 500 g

blouse 100 g

men’s underpants 100 g

Removing stains

Stubborn stains may not be removed by just water
and detergent. It is therefore advisable to treat them
prior to washing.

Blood: treat fresh stains with cold water. For dried
stains, soak overnight in water with a special
detergent then rub in the soap and water.

Oil based paint: moisten with benzine stain
remover, lay the garment on a soft cloth and dab the
stain; treat several times.

Dried grease stains: moisten with turpentine, lay
the garment on a soft surface and dab the stain with
the fingertips and a cotton cloth.

Rust: oxalic acid dissolved in hot water or a rust
removing product used cold. Be careful with rust
stains which are not recent since the cellulose
structure will already have been damaged and the
fabric tends to hole.

Mould stains: treat with bleach, rinse well (whites
and fast coloureds only).

Grass: soap lightly and treat with bleach (whites and
fast coloureds only).

Ball point pen and glue: moisten with acetone (*),
lay the garment on a soft cloth and dab the stain.

Lipstick: moisten with acetone as above, then treat
stains with methylated spirits. Remove any residual
marks from white fabrics with bleach.

ENGLISH

9

Red wine: soak in water and detergent, rinse and
treat with acetic or citric acid, then rinse. Treat any
residual marks with bleach.

Ink: depending on the type of ink, moisten the fabric
first with acetone (*), then with acetic acid; treat any
residual marks on white fabrics with bleach and then
rinse thoroughly.

Tar stains: first treat with stain remover, methylated
spirits or benzine, then rub with detergent paste.

(*) do not use acetone on artificial silk.

Detergents and additives

Good washing results also depend on the choice of
detergent and use of the correct quantities to avoid
waste and protect the environment. Although
biodegradable, detergents contain substances
which, in large quantities, can upset the delicate
balance of nature.

The choice of detergent will depend on the type of
fabric (delicates, woollens, cottons, etc.), the colour,
washing temperature and degree of soiling.

All commonly available washing machine detergents
may be used in this appliance:

– powder detergents for all types of fabric,

– powder detergents for delicate fabrics (60°C max)

and woollens,

– liquid detergents, preferably for low temperature

wash programmes (60°C max) for all types of
fabric, or special for woollens only.

The detergent and any additives must be placed in
the appropriate compartments of the dispenser
drawer before starting the wash programme.

If using concentrated powder or liquid detergents, a
programme without prewash must be selected.

The washing machine incorporates a recirculation
system which allows an optimal use of the
concentrated detergent.

Pour liquid detergent into the dispenser drawer
compartment marked just before starting the
programme.

Any fabric softener or starching additives must be
poured into the compartment marked before
starting the wash programme.

Follow the product manufacturer’s recommendations
on quantities to use and do not exceed the «MAX»

mark in the detergent dispenser drawer.

Quantity of detergent to be used

The type and quantity of detergent will depend on
the type of fabric, load size, degree of soiling and
hardness of the water used.

Water hardness is classified in so-called “degrees” of
hardness. Information on hardness of the water in
your area can be obtained from the relevant water
supply company, or from your local authority.

Follow the product manufacturers’ instructions on
quantities to use.

Use less detergent if:

– you are washing a small load,

– the laundry is lightly soiled,

– large amounts of foam form during washing.

10

P0080

M0046

B

M0045

95

Operating sequence

C0071

C0070

P0004

Before the first wash we recommend that you pour 2
litres of water into the main wash compartment
of the detergent drawer in order to activate the
ECO valve. Then run a cotton cycle at 60°C, with the
machine empty, in order to remove any
manufacturing residue from the drum and tub.
Pour half a measure of detergent into the main wash
compartment and start up the machine.

1. Place the laundry in the drum

Open the door.

Place the laundry in the drum, one item at a time,
shaking them out as much as possible.

Close the door.

4. Select the desired option

Depress the required button.

ENGLISH

5. Select the temperature

Turn the dial to the required setting.

2. Measure out the detergent

Pull out the dispenser drawer until it stops. Measure
out the amount of detergent recommended by the
manufacturer in a graduated cup and pour it into the
main wash compartment .

If you wish to carry out the prewash, pour detergent
into the appropriate compartment marked .

3. Measure out the additive

If required, pour fabric softener into the compartment
marked , without exceeding the «MAX» mark.

6. Select the programme and start the
machine

Turn the programme selector dial clockwise to the
required programme and press ON/OFF button :
the mains on light comes on and the machine starts
to operate.

11

7. At the end of the programme

95

60

60

40

40

40

30

30

The machine stops automatically. The mains on light
goes out.

If you have selected a programme which ends with
the water of the last rinse left in the tub (button
depressed), drain the water before opening the
door.

To drain water and spin, depress button again.
To drain only, select programme P.

Wait approx. two minutes before opening the door to
give the electric locking mechanism time to release
it.

Depress the ON/OFF button again to switch the

machine off.

Remove the laundry.

Turn the drum by hand to make sure it is completely
empty, so as to avoid any forgotten items being
damaged in a subsequent wash (e.g. shrinking) or
their colour running into a load of whites.

Release any buttons which have been pressed.

Turn the water tap off and unplug the machine.

Leave the door ajar to air the machine.

International wash code symbols

These symbols appear on fabric labels, in order to help you choose the best way to treat your laundry.

Energetic wash

Delicate wash

Max. wash

temperature

95°C

Max. wash

temperature

60°C

Max. wash

temperature

40°C

Max. wash

temperature

30°C

Hand wash

Do not

wash

at all

Bleaching Bleach in cold water Do not bleach

Ironing Hot iron

max 200°C

Dry cleaning Dry cleaning

in all solvents

Drying Flat On the line On clothes

Warm iron

max 150°C

Dry cleaning in

perchlorethylene,

petrol, pure alcohol,

R 111 & R 113

hanger

12

Lukewarm iron

max 110°C

Dry cleaning

in petrol,

pure alcohol

and R 113

high
temperature

low
temperature

Tumble dry

Do not iron

Do not

dry clean

Do not

tumble dry

Programme table

Washing programmes for cotton and linen

Max. load: 4,5 kg

ENGLISH

Progr.

A

B

B

B

C

Temp. Type of laundry Cycle description

60°-95°

60°-95°

30°-60°

40°-

60°E

60°

WHITES WITH PREWASH,
for example work garments,
sheets, household linen,
underwear, towels

WHITES WITHOUT
PREWASH, for example
household linen, sheets,
shirts, underwear

COLOUREDS WITHOUT
PREWASH, for example
shirts, blouses, terry cloths,
underwear, sheets

WHITES, COLOUREDS,
ECONOMY PROGRAMME
Lightly soiled sheets,
tablecloths, towels

WHITES, SHORT CYCLE
Lightly soiled shirts,
underwear, sheets

Prewash
Wash at 60°-95°C
4 rinses
Long spin

Wash at 60°-95°C
4 rinses
Long spin

Wash at 30°-60°C
4 rinses
Long spin

Wash at 40°-60°C
4 rinses
Long spin

Wash at 60°C
4 rinses
Long spin

Possible

options

COLOUREDS, SHORT

D

40°

F

G

Long spin

The temperatures indicated are the optimum temperatures for each programme and depend on the type of
laundry and degree of soiling.

In compliance with EC directive 92/75, the consumption figures indicated on the energy label refer to the wash
programme for cotton (programme “B” at 60°).

CYCLE
Lightly soiled cotton or linen
items

This programme can be
used for rinsing hand
washed garments

Separate spin
for cotton and linen

Wash at 40°C
4 rinses
Long spin

4 rinses with liquid additive, if
required
Long spin

Drain and long spin

13

Programme table

Washing programmes for synthetics, mixed fabrics, delicates and wool

Max. load: 1,5 kg, wool/handwash 1 kg

Progr. Temp. Type of laundry Cycle description

H

J

K

L

M

Rinses

SYNTHETICS WITH

30°- 60°

30°- 60°

- 40°

- 40°

PREWASH, for example
underwear, coloured items,
shirts, blouses

SYNTHETICS WITHOUT
PREWASH, for example
shirts, blouses, mixed fabrics

Delicate fabrics - Silk, for
example curtains

Wool /Handwash
Special programme for
garments bearing the “Pure
new wool, non-shrink,
machine washable” label

This programme can be used
for rinsing hand washed
garments.

Prewash
Wash at 30°-60°C
3 rinses
Short spin

Wash at 30°-60°C
3 rinses
Short spin

Wash - 40°C
3 rinses
Short spin

Wash - 40°C
3 rinses
Short spin

3 rinses with fabric softener
Short spin

Possible

options

Separate spin for synthetics,

N

Short spin

P

Drain

The temperatures indicated are the optimum temperatures for each programme and depend on the type of
laundry and degree of soiling.

mixed fabrics, delicates and
wool.

For emptying out the last
rinse water of the
programmes with the
anticrease option .

Drain and short spin

Draining of water

14

C0073

C0072

P1050

Maintenance

Bodywork

Clean the outside of the machine with soap and
water only. Rinse with clean water and dry with a soft
cloth.

Important: do not use methylated spirits, solvents or
similar products to clean the bodywork.

Door seal

Check from time to time the door seal and eliminate
eventual possible objects that could be trapped in
the fold.

ENGLISH

P0038

Drain pump

The pump should be inspected if

• the machine does not empty and/or spin

• the machine makes an unusual noise during

draining due to objects such as safety pins, coins
etc. blocking the pump.

Proceed as follows:

• Disconnect the appliance.

• If necessary wait until the water has cooled down.

• Open the pump door.

Detergent dispenser drawer

After a while, detergents and fabric softeners leave
deposits in the drawer.

Clean the drawer from time to time by rinsing it under
a running tap. To remove the drawer from the
machine, press the button in the rear left-hand
corner.

To facilitate cleaning, the top part of the additive
compartments can be removed.

Detergent can also accumulate inside the drawer
recess: clean it with an old toothbrush. Refit the
drawer after cleaning.

P1114

• Place a container close to the pump to collect any

spillage.

• Release the emergency emptying hose, place it in

the container and remove its cap.

• When no more water comes out, unscrew the

pump cover and remove it. Always keep a rag
nearby to dry up spillage of water when removing
the pump.

P1115

• Remove any objects from the pump impeller by

rotating it.

15

• Put the cap back on the emergency emptying hose

P1090

and place the latter back in its seat.

P1117

• Screw the pump fully in.

• Close the pump door.

Water inlet filter

If you notice that the machine is taking longer to fill,
check that the filter in the water inlet hose is not
blocked.

Turn off the water tap.

Unscrew the hose from the tap.

Clean the filter with a stiff brush.

Screw the hose back onto the tap.

• clean the pump if necessary as previously

described;

• replace the emergency emptying hose in its seat

after having plugged it;

• screw the pump again and close the door.

Frost precautions

If the machine is installed in a place where the
temperature could drop below 0°C, proceed as
follows:

• Remove the plug from the socket.

• Close the water tap and unscrew the water inlet

hose from the tap.

• Place the end of the emergency emptying hose

and that of the inlet hose in a bowl placed on the
floor and let water drain out.

• Screw the water inlet hose back on and reposition

the emergency emptying hose after having put the
cap on again.

By doing this, any water remaining in the machine is
removed, avoiding the formation of ice and,
consequently, breakage of the affected parts.

When you use the machine again, make sure that
the ambient temperature is above 0°C.

Emergency emptying out

If the water is not discharged, proceed as follows to
empty out the machine:

• pull out the plug from the power socket;

• close the water tap;

• if necessary, wait until the water has cooled down;

• open the the pump door;

• place a bowl on the floor and place the end of the
emergency emptying hose into the bowl. Remove
its cap. The water should drain by gravity into the
bowl. Whe the bowl is full, put the cap back on the
hose. Empty the bowl. Repeat the procedure until
water stops flowing out;

Important!

Every time you drain the water through the
emergency emptying hose you must pour 2 litres of
water into the main wash compartment of the
detergent drawer and then run the drain programme
“P”. This will activate the ECO valve avoiding that
part of the detergent remains unused at next
washing.

16

Something not working?

Problems which you can resolve yourself.

Problem Possible cause

• The machine does not start up:

• The machine does not fill:

• The machine fills then empties

immediately:

• The machine does not empty and/or

does not spin:

ENGLISH

• The door is not firmly closed.

• The machine is not plugged in or there is no power
at the socket.

• The main fuse has blown.

• The programme selector dial is not positioned correctly

• The ON/OFF button has not been depressed.

• The water tap is closed.

• The inlet hose is squashed or kinked.

• The filter in the inlet hose is blocked.

• The door is not properly closed.

• The end of the drain hose is too low. Refer to
relevant paragraph in “water drainage” section.

• The drain hose is squashed or kinked.

• You have selected option or .

• The drain pump is clogged.

• There is water on the floor:

• Unsatisfactory washing results:

• The machine vibrates or is noisy:

• Too much detergent or unsuitable detergent
(creates too much foam) has been used.

• Check whether there are any leaks from one of the
inlet hose fittings. It is not always easy to see this
as the water runs down the hose; check to see if it
is damp.

• The drain hose is damaged.

• The drain pump has not been properly screwed on
after cleaning.

• The cap on the emergency emptying hose has not
been replaced after cleaning the pump.

• Too little detergent or unsuitable detergent has
been used.

• Stubborn stains have not been treated prior to
washing.

• The correct temperature was not selected.

• Excessive laundry load.

• The transit bolts and packing have not been
removed.

• The support feet have not been adjusted.

• The laundry is not evenly distributed in the drum.

• Maybe there is very little laundry in the drum.

17

Mod. ..........

Prod. No. ...........

Ser. No. .........

M
o

d
.
.
..
.
.

...
.
.

P

r
o
d
.
N

o
.
..

..
...
..
.
.

S
e
r

.
N
o
. .

..
.
..
..

.

P0042 BD

Problem Possible cause

• Water is not visible in the machine:

• The door will not open:

If you are unable to identify or solve the problem,
contact our service centre. Before telephoning, make
a note of the model, serial number and purchase
date of your machine: the Service Centre will require
this information.

• The machine, which is the result of modern
technology, runs in a very economical way with low
water consumption. Performance is nevertheless
excellent.

• The programme is still running.

• The door lock has not been released.

• There is water in the drum.

18

From the Electrolux Group. The world’s No.1 choice.

The Electrolux Group is the world’s largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million
Electrolux Group products (such as refrigerators, cookers, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of
approx.14 billion USD in more than 150 countries around the world.
