Zanussi FL 811 User Manual
Specifications and Main Features
- FL 811
- Physical Measurements:
- Height: 850 mm (33.5'')
- Width: 600 mm (23.6’)
- Depth: 550 mm (22.7’)
- Weight: 176 lb (80 kg)
- Load Capacity: 10 lb (4.5 kg)
- Maximum Revolutions: 400/800
- Input Power: 2730 W
- Rating of Heater: 2300 W
- Rating of Motors:
- Washing: 430 W
- Spinning: 450/650 W
- Electric Supply: 220/240 V
- Supply Frequency: 50 Hz
- Wash Water Requirements:
- Does Regular Load: 2.9 gallons (13 litres)
- Does Heavy Load: 4.4 gallons (20 litres)
- Water Supply Requirements:
- Maximum Pressure: 110 psi
- Minimum Pressure (Hot): 4 psi
- Minimum Pressure (Cold): 7 psi
Frequently Asked Questions
- Q: What is the stipulated weight that is regarded to be maximum load in the washing machine?
Answer. The highest permissible load is regarded to be 10 lb (4.5 kg).
- Q: The other questioned version relates to the RPM setting of the machine used during washing and hence centrifuge operations?
Answer. The spinning speeds’ setting which is revolutions per minute’ is 400 and 800.
- Q: Enquiring about the water heater’s specification on washing machine?
Answer. 2300 W is the heater rating for the product.
- Q: What amount of power is needed in running the machine while in use?
Answer. 2730 W is the amount of Power that is used.
- Q: How can you check and ensure that the water pressure supplied to the appliance is at the correct level?
A: The lower limit of the recommended water pressure readings should be 7 psi when the water is cold, while 4 psi should be set for hot water. The maximum water pressure reading should not go beyond 110 psi.
- Q: Are there any prerequisites and particulars for installing the washing machine in the house?
A: Certainly, the device must be fitted with the plumbing of the water supply and drainage system of the house permanently or existing suitable taps may be used.
- Q: What can be done if the washing machine appears to be dead and unresponsive once the power button is pressed?
A: Make certain that the door is completely closed, that the machine is plugged into the wall, and that the switch located next to the socket is turned on.
- Q: How to conduct maintenance on the drain filter?
A: One should unscrew the filter and push it outward while ensuring that any accumulated water is gathered in a pitcher underneath, after which it can be thoroughly cleaned and replaced.
- Q: Is it safe to use any other powder aside from the one recommended?
A: It is advisable to use a non-foaming powder which is designed for top-load washers.
- Q: How should I react if I experience issues with filling or draining?
A: Please ensure that water supply hoses are not bending and that water tabs are on, as well as examining the drain filter for any clotting issues.
