RANGE
COMPOSITION


The Zanussi Dishwashing
range is produced for
customers with the highest
conceivable demands in
efficient, economic and
ergonomic dishwashing
operations. The product
range is comprised of
glasswashers, undercounter
dishwashers, hood type
dishwashers, rack type
dishwashers and pot and pan
washers. The Corner Dryers
complete the rack type
dishwashing range.

864512 864513

CORNER DRYER FOR RTM

RACK TYPE DISHWASHERS

FUNCTIONAL AND
CONSTRUCTION
FEATURES

� It is designed to be placed

on a 90° or 180° dishwashing
driven curve, immediately
after a modular rack type
dishwasher. The dryer must
always be ordered with a 90°
or 180° dishwashing driven
curve.

� The feeding system from

the dishwasher and the curve
will automatically move the
racks through the dryer.

� The drying zone removes

every trace of water from the

TECHNICAL DATA

CHARACTERISTICS MODELS

Power supply Electric Electric
External dimensions - mm
width 850 850
depth 706 706
height 895 895
Power - kW
installed-electric 8.5 8.5
Net weight - kg. 70 70
Supply voltage 400 V, 3N, 50/60 400 V, 3N, 50/60

crockery, through a high
powered fan that extracts dry
air from outside with
minimum temperature loss
and steam escape.

� Electronically controlled to

optimize the drying results.

� The hygienic design

provides easy cleaning.

� The dryer is constructed in

304 AISI stainless steel.

� Developed and produced in

an ISO 9001 and ISO 14001
certified factory.

� CFC free packaging.
� For further specifications

and accessories, please see

ADTERC90MD

864512

overleaf.

ZANUSSI

P R O F E S S I O N A L

ADTELC90MD

864513

RACK TYPE DISHWASHERS

CORNER DRYER FOR RTM

EBCE20 2009-06-19 The Company reserves the right to alter technical specifications without prior notice.
