Page 1

72.

ZCM641/ZCM640

60cm wide dual fuel cooker with single oven

Hob Features

• 1 x rapid burner

• 2 x semi-rapid burners

• 1 x simmer burner

• Enamel pan supports

Grill Features

• Static grill

Main Oven Functions

• Thermaflow

oven • Defrost

Cooker Features

• Rotary minute minder lets you know when your cooking time is up

• Easy clean enamel oven interior

• Interior light

• Air cooled doors reduce outer door temperatures for added safety and comfort

• Storage drawer handy for storing your kitchen utensils

Colour

Stainless steel ZCM641X White ZCM640W

Energy

Energy Rating (Top Oven)

SPECIFICATION TABLES

73.

Page 2

74. 75.

TECHNOLOGY

Wash load

kg777766663

Spin speed 1600rpm 1600rpm 1400rpm 1200rpm 1600rpm 1400rpm 1200rpm 1000rpm 1300rpm

LCD/LED display LCD Display 3 Digit LED Indicator LED Indicator LED Indicator LED Indicator LED Indicator LED Indicator LED Indicator

LCD display

Wash technology Jetsystem+ Aquacycle Aquacycle Aquacycle Aquacycle Aquacycle Aquacycle Aquacycle Aquacycle

Water fill Cold Cold Cold Cold Cold Cold Cold Cold Cold

Programme end countdown

Height cm 85 85 85 85 85 85 85 85 67

Width cm 60 60 60 60 60 60 60 60 49.5

Depth cm 60 60 60 60 59 55.2 55.2 55.2 51.5

Electronic push buttons 7 5 5 5 5 5 5 5 5

Electronic rotary controls 1 1 1 1 1 1 1 1 2

Inverter motor (quiet) II

PROGRAMMES

Cottons Jetsystem

Cottons Eco Jetsystem

Synthetics Jetsystem

Cottons IIIIIIIII

Cottons + prewash I

Cottons - super quick I

Cottons ECO IIIIIII

Synthetics IIIIIIIII

Synthetics + prewash I

Synthetics - super quick I

Delicates IIIIIIIII

Miniprogramme IIIIIIII

Duvet I

Silk IIIIIIII

Hand wash IIIIIIIII

Wool IIIIIIIII

Sport shoes IIIIIIII

Sports IIIIIIII

Easy iron IIIIIII

Others Spin, Spin, Spin, Spin, Spin, Spin, Spin, Spin, Spin,

Drain, Rinse Drain, Rinse Drain, Rinse Drain, Rinse Drain, Rinse Drain, Rinse Drain, Rinse Drain, Rinse Drain, Rinse

OPTIONS

Auto half load II

Auto half load with manual over ride II IIII

Soil level I

Quick IIIIIIII

Intensive III IIII

Prewash III IIIII

Delay start up to 20h up to 20h 3/6/9h 3/6/9h 3/6/9h 3/6/9h 3/6/9h 3/6/9h 2/4/8h

Night cycle IIIIIIIII

Extra rinse I I

Easy iron I

FEATURES

Variable spin IIIIIIIII

Variable temperature IIIIIIII

Large porthole IIIIIIII

PERFORMANCE

Energy class

A+ A+ A+ A+ A+ A A A A

Energy consumption

kWh 1.19 1.19 1.19 1.19 1.02 1.02 1.02 1.02 0.57

Annual energy consumption kWh 238 238 238 238 204 204 204 204 114

Wash performance

AAA AAA AAB

Spin dry performance

AAB BABB CB

Water after spin

%444453534452536059

Water consumption

litres 45 57 59 59 54 54 54 54 39

Annual water consumption

litres 10400 11400 11800 11800 10800 10800 10800 10800 7800

Programme time

mins 119 155 155 155 155 155 155 155 131

COLOUR

White IIIIIIIII

WASHING MACHINES

LAUNDRY

ZWF16581W

ZWF16281W

ZWF14080W

ZWF12080W

ZWF16070W1

ZWF14070W1

ZWF12070W1

ZWF10070W1

ZWC1300W

MODEL

TECHNOLOGY

Wash load kg 7 6 6 6

Spin speed 1400rpm 1600rpm 1400rpm 1200rpm

LCD/LED display LCD display 3 digit LCD display 3 digit LCD display 3 digit LCD display

Wash technology Jetsystem+ Aquacycle Aquacycle Aquacycle

Water fill Cold Cold Cold Cold

Programme end countdown

Height cm 85 85 85 85

Width cm 60 60 60 60

Depth cm 60 60 60 60

Electronic push buttons 7 5 5 5

Electronic rotary controls 1 1 1 1

Inverter motor (quiet) I

PROGRAMMES

Cottons Jetsystem

Cottons Eco Jetsystem

Synthetics Jetsystem

Cottons IIII

Cottons + prewash I

Cottons - super quick I

Cottons ECO III

Synthetics III I

Synthetics + prewash I

Synthetics - super quick I

Delicates III I

Miniprogramme IIII

Duvet I

Silk IIII

Hand wash III

Wool II

Wool & hand wash I

Cottons drying IIII

Synthetics drying IIII

Easy iron III I

Others Spin, Drain, Rinse Spin, Drain, Rinse Spin, Drain, Rinse Spin, Drain, Rinse

OPTIONS

Auto half load III I

Dryness I

Drying time IIII

Quick III

Intensive III

Prewash III

Delay start up to 20h

Night cycle IIII

Extra rinse I

Easy iron I

FEATURES

Variable spin IIII

Variable temperature III I

Large porthole III I

PERFORMANCE

Wash & dry load 5 4 4 4

Energy class

CBCC

Energy consumption

kWh 1.19 1.02 1.02 1.02

Energy consumption2kWh wash & dry 5.9 4.85 5.3 5.55

Annual energy consumption kWh wash 238 204 204 204

Annual energy consumption kWh wash & dry 1180 970 1060 1110

Wash performance

AAAA

Spin dry performance

BABB

Water after spin

%52 44 52 53

Water consumption

litres wash 52 54 54 54

Water consumption6litres wash & dry 108 95 98 102

Annual water consumption8litres wash 10400 10800 10800 10800

Annual water consumption7litres wash & dry 21600 19000 19600 20400

Programme time mins wash & dry 305 315 325 335

COLOUR

White IIII

WASHER DRYERS

LAUNDRY

ZWD14581W1

ZWD16270W1

ZWD14270W1

ZWD12270W1

MODEL

1) On a scale from A (most efficient) to G (least efficient).

2) kWh per cycle based on a standard test results for a standard 60ºC cotton cycle. Actual energy consumption will depend on how the appliance is used and where it is located.

3) On a scale from A (cleanest) to G (dirtiest).

4) On a scale from A (driest) to G (wettest). NB. If you use a tumble dryer, choosing a washing machine with A-rated spin instead of one with G-rated spin will half your tumble drying costs. Tumble drying clothes usually uses more energy than washing them.

5) As proportion of the dry weight of wash.

6) Performance within this table are based upon standard tests for the capacities stated above on a 60ºC wash cycle.

7) Based upon an average 200 annual wash cycles for a standard 60ºC cotton wash cycle.

1) On a scale from A (most efficient) to G (least efficient).

2) kWh per cycle based on a standard test results for a standard 60ºC cotton cycle. Actual energy consumption will depend on how the appliance is used and where it is located.

3) On a scale from A (cleanest) to G (dirtiest).

4) On a scale from A (driest) to G (wettest).

NB. If you use a tumble dryer, choosing a washing machine

with A-rated spin instead of one with G-rated spin will half your tumble drying costs. Tumble drying clothes usually uses more energy than washing them.

5) As proportion of the dry weight of wash.

6) Performance within this table are based upon standard tests for the capacities stated above on a 60ºC wash cycle.

7) Based upon an average 200 annual wash cycles for a standard 60ºC cotton wash cycle always using the dryer.

8) Based upon an average 200 annual wash cycles per year without using the dryer.

Page 3

76. 77.

TECHNOLOGY

Capacity

kg 7 7 7 3.4 7 6

LCD/LED display LED Indicators LED Indicators LED Indicators LED Indicators LED Indicators LED Indicators

Drying technology condense electronic condense electronic condense electronic compact condense vented electronic vented

Programme end countdown I

Height cm 85 85 85 68.6 85 85

Width cm 60 60 60 59.5 60 60

Depth cm 58 58 58 42 58 58

Electronic push buttons 6 3 3 4 2

Electronic rotary controls 1 1 1 1 1 1

PROGRAMMES

Extra cottons III I

Intensive cottons I I

Cupboard cottons III I

Damp cottons I I

Iron cottons I I

Machine cottons I

Extra synthetics II I

Cupboard synthetics II I

Iron synthetics I I

Easy iron II I

Wool II

Jeans I

Mixed I

Time IIII II

Gentle I

OPTIONS

Dryness I

Delicate III II

Buzzer I I

Time I

Textile II

Quick I

Delay start I

FEATURES

Reverse tumble IIII II

Auto cool-down & cool tumble III II

Large porthole III

Large opening angle III

Condensed water capacity litres 3.6 3.6 3.6 2.5

Water container full indicator IIII

Water tank position high low low bottom left

PERFORMANCE

Energy class

BCCCC C

Energy consumption

kWh/cycle 3.92 3.7 3.7 2.47 3.9 3.3

Annual energy consumption4kWh 278.5 300 300 380 263.1 258.8

Drying times mins 130 115 115 100 105

COLOUR

White IIII II

TUMBLE DRYERS

LAUNDRY

ZDC67550W

ZDC47100W

ZDC37100W

TC180W

ZDE57140W

ZDE26000W

MODEL

PRODUCT DIMENSIONS

Product width mm 600 600 600 600 450 545 545

Product height mm 850 850 850 850 850 447 447

Product depth mm 600 610 610 610 610 480 480

Net weight Kg 45.0 40.5 40.5 40.5 36.0 20.7 20.7

Height adjustable feet mm Adj 0 to 1cm Adj 0 to 1cm Adj 0 to 1cm Adj 0 to 1cm Adj 0 to 3cm

Packaged width Kg 650 635 635 635 500 605 605

Packaged height mm 910 902 902 902 910 505 505

Packaged depth mm 680 680 680 680 680 595 595

Gross weight Kg 46.5 42.0 42.0 42.0 37.5 22.3 22.3

PROGRAMMES

No. of programmes 5 5 5 4 5 5 5

No. of temperatures 3 3 3 2 4 4 4

Bio/Eco IIIIIII

Normal III I I

Intensive/Superwash III III

Quick wash (eat-load-run) IIIIIII

Rinse & hold III III

Automatic wash II

FEATURES

Type of controls Electronic Electronic Electronic Electronic Electronic Electronic Electronic

Push Button Push Button Rotary Control Rotary Control Rotary Control Rotary Control Push Button

Heating element Visible/Hidden Hidden Hidden Hidden Hidden Hidden Hidden Hidden

Flood protection III III

Salt refill indicator IIIIIII

Rinse aid indicator IIIII I

Delay timer IIIIIII

3 digit display II

Folding supports for lower basket II Fixed plate racks

Quick lift II

Drying type Active Drying Active Drying Active Drying Active Drying Active Drying Residual Drying Residual Drying

Adjustable water softener II IIII I

DECLARATION DETAILS

Specific to programme Bio 50 Bio 50 Bio 50 Bio 50 Bio 50 Eco 55 Eco 55

with pre-rinse with pre-rinse with pre-rinse with pre-rinse with pre-rinse

IEC place settings 12 12 12 12 12 9 6 6

Water consumption litres 15 15 18 18 13 7 9

Energy consumption* kW/h 1.05 1.05 1.05 1.05 0.80 0.63 0.63

Programme time*** minutes 150 150 140 140 130 150 159

Noise level decibel rating dBA 44 44 51 51 51 53 48

Water fill Cold fill only Cold or Hot Cold or Hot Cold fill only Cold fill only Cold or Hot Cold fill only

Energy rating** A A A A A A A

Wash performance** A A A A A A A

Drying performance** A A A A A B B

COLOUR

White IIIIII

Silver III I I

Black I

DISHWASHERS

DISHWASHING

ZDF601

ZDF511

ZDF231

ZDF131

ZDS231

ZSF2420

ZSF2440

MODEL

Timeline Progress Essential Essential Progress Progress Progress

60cm width 60cm width 60cm width 60cm width 45cm width Compact Compact

dishwasher dishwasher dishwasher dishwasher dishwasher dishwasher dishwasher

* Energy consumption is stated in kW/h per standard test cycle, using cold water fill. Actual consumption will depend on how the appliance is used. ** Models with an 'A' rated classification offer a higher performance than those with a 'G' rating. *** Time taken for a standard test cycle, using cold water fill.

1) On a scale from A (most efficient) to G (least efficient).

2) kWh per cycle performances based on corresponding capacities within this table.

3) Performances in this table are based upon the standard tests for the capacities stated above.

4) Based on 220 cycles per annum.

Page 4

78. 79.

FRIDGE FEATURES

Door hinging Right & Reversible Right & Reversible Right & Reversible Right & Reversible Right & Reversible Right & Reversible Right & Reversible

Height mm 2010 1850 1750 1860 1720 1650 1650

Width mm 595 595 595 550 550 550 550

Depth mm 632 632 632 625 625 625 625

Gross capacity fridge litres/cu.ft 291/10.28 249/8.8 226/7.98 166/5.87 135/4.77 170/6.00 170/6.00

Net capacity fridge litres/cu.ft 285/10.07 245/8.7 223/7.88 165/5.83 134/4.73 165/5.83 165/5.83

Gross capacity freezer litres/cu.ft 91/3.21 91/3.21 91/3.21 121/4.28 121/4.28 90/3.18 90/3.18

Net capacity freezer litres/cu.ft 78/2.75 78/2.75 78/2.75 90/3.18 90/3.18 67/2.37 67/2.37

Energy label* A A A A A A A

Energy consumption per day kWh 1.03 0.98 0.95 0.96 0.92 0.88 0.88

Yearly energy consumption** kWh 374 357 347 350 334 321 321

Climate class*** SN-N-ST SN-N-ST SN-N-ST SN-N-ST SN-N-ST SN-N-ST SN-N-ST

Frost free IIIIIII

Fridge defrost function Automatic Automatic Automatic Automatic Automatic Automatic Automatic

Freezer defrost function Automatic Automatic Automatic Automatic Automatic Automatic Automatic

Power indicator Green lamp Green lamp Green lamp Green lamp

Fan cooling system III I

INTERIOR FRIDGE FEATURES

Glass shelves 4 4 3 3 2 3 3

Wine rack III

Adjustable shelves IIIIII I

2 half width drawers IIIIIII

Interior lights Bulb Bulb Bulb Bulb Bulb Bulb Bulb

FRIDGE DOOR FEATURES

Full width dairy compartment 1 1 1 1 1 1 1

Number of door shelves 2 1 2 1 1 1 1

Full width bottle shelf IIIIIII

Number and type of egg trays 1 for 6 eggs 1 for 6 eggs 1 for 6 eggs 1 for 6 eggs 1 for 6 eggs 1 for 6 eggs 1 for 6 eggs

Butter dish III

FREEZER FEATURES

Freezer drawers 3 3 3 4 4 3 3

Ice cube tray 1 1 1 1 1 1 1

COLOUR

White IIIII I

Silver III I I

Stainless steel

COOLING

MODEL

ZNB383W

ZNB343W/S

ZNB323W/S

ZRB2925W/S

ZRB2725W

ZRB2625S

ZRB2630W

COOLING

FRIDGE FEATURES

Door hinging Right & Reversible Right & Reversible Right & Reversible Right & Reversible

Height mm 1630 1660 1404 1209 850

Width mm 550 500 545 496 895

Depth mm 625 600 604 604 600

Gross capacity fridge litres/cu.ft 167/5.90 149/5.27 190/6.71 138/4.88 130/4.59

Net capacity fridge litres/cu.ft 165/5.83 145/5.12 186/6.57 136/4.81 128/4.52

Gross capacity freezer litres/cu.ft 110/3.88 104/3.67 44/1.55 42/1.48 83/2.93

Net capacity freezer litres/cu.ft 90/3.18 85/3.00 44/1.55 42/1.48 52/1.84

Energy label* A A A A B

Energy consumption per day kWh 0.87 0.84 0.78 0.72 0.98

Yearly energy consumption** kWh 319 306 285 263 358

Climate class*** SN SN SN-N-ST SN-N-ST SN-N-ST

Fridge defrost function Automatic Automatic Automatic Automatic Automatic

Freezer defrost function Manual Manual Manual Manual Manual

INTERIOR FRIDGE FEATURES

Glass shelves 3 3 4 3 4

Adjustable shelves IIIII

2 half width drawers II

Full width drawer III

Interior lights Bulb Bulb Bulb Bulb Bulb

FRIDGE DOOR FEATURES

Full width dairy compartment 1 1 1 1 1

Number of door shelves 1 1 1 1 1

Full width bottle shelf 1 1 1 1 1

Number and type of egg trays 1 for 6 eggs 1 for 6 eggs 1 for 6 eggs 1 for 6 eggs 1 for 6 eggs

Butter dish I

FREEZER FEATURES

Freezer drawers 4 4 1 wire shelf 1 wire shelf 3

Ice cube tray 1 2 1 1 1

Ice scraper IIII

Defrosting spout IIII

COLOUR

White IIIII

Silver I

Stainless steel I

MODEL

ZRB2825W

ZRB2531W/S

ZRD233W

ZRD183W

ZRT210W/X

FRIDGE FREEZERS FRIDGE FREEZERS

* Energy efficiency class based on a scale of A+ (most efficient) to G (least efficient). ** Based on standard test results for 24 hours in accordance with EN153. Actual consumption will depend on how the appliance is used and where it is located. *** Climate class - the product is suitable for use in ambient temperatures of SN:10-32ºC, N:16-32ºC, ST:18-38ºC, T:18-43ºC

Page 5

80. 81.

FRIDGE FEATURES

Door hinging Right & Reversible Right & Reversible Right & Reversible Right & Reversible Right & Reversible

Height mm 1450 850 850 850 520

Width mm 600 595 595 550 525

Depth mm 600 635 635 612 587

Frost Free I

Fast Freeze IIII

High temperature indicator IIII

Power indicator Green lamp Green lamp Green lamp Green lamp

Energy consumption per day kWh 0.73 0.58 0.58 0.56 0.48

Yearly energy consumption** kWh 266 211 210 204 175

Energy label* A A A A A

Climate class*** SN SN-N-ST SN-N-ST-T SN-N-ST-T SN-N-ST

Gross capacity freezer litres/cu.ft 243/8.59 115/4.06 100/3.53 115/4.06 50/1.77

Net capacity freezer litres/cu.ft 205/7.24 98/3.46 80/2.82 100/3.53 50/1.77

FREEZER FEATURES

Freezer drawers/compartments 6 4 4 4 1 wire shelf

Ice tray 1 1 1 1

Ice scraper III

COLOUR

White IIIII

Silver I

Stainless steel

COOLING

MODEL

ZFU325W

ZUT125W

ZUF105W

ZUT113W/S

ZUC053W

FREEZERS REFRIGERATORS

COOLING

Door hinging Right & Reversible Right & Reversible Right & Reversible Right & Reversible Right & Reversible Right & Reversible Right & Reversible

Height mm 1450 1250 850 850 850 850 520

Width mm 600 550 595 595 550 550 525

Depth mm 600 612 635 635 612 612 587

Power indicator Green lamp

Energy consumption per day kWh 0.46 0.75 0.42 0.64 0.42 0.64 0.29

Yearly energy consumption** kWh 168 274 154 233 154 234 109

Energy label* A A A A A A A+

Climate class*** SN SN-N-ST SN-N-ST SN-N-ST-T SN-N-ST SN-N-ST SN-N-ST

Gross capacity fridge litres/cu.ft 284/10.04 237/8.37 155/5.47 125/4.4 155/5.47 128/4.52 65/2.3

Net capacity fridge litres/cu.ft 275/9/.71 213/7.52 152/5.37 119/4.2 152/5.37 122/4.31 62/2.19

Net capacity star compartment litres/cu.ft 18/0.64 18/0.63 18/0.63 5/0.17

INTERIOR FRIDGE FEATURES

Extra large salad drawer 2 half width 1 1 1 1 1

Adjustable glass shelf with trim 5 3 2 1 2 1 1 wire shelf

Type of star compartment 4* 4* 4* 2*

Butter dish IIIIII

Other refrigerator features Ice cube tray Ice cube tray Ice cube tray

& Ice scraper

Bottle grip IIIIIII

Interior light Bulb Bulb Bulb Bulb Bulb Bulb Bulb

FRIDGE DOOR FEATURES

Full width dairy compartment 1 1 1 1 1 1

Door shelves 3 2 1 1 1 1 2 half width

Number and type of egg trays 1 for 6 eggs 1 for 6 eggs 1 for 6 eggs 1 for 6 eggs 1 for 6 eggs 1 for 6 eggs

Bottle shelves 1 1 1 1 1 1 1

COLOUR

White IIIIII I

Silver I

Stainless steel

MODEL

ZRA328W

ZRC243W

ZRT175W

ZRT155W

ZRT163W/S

ZRT143W

ZRC077W

Page 6

82. 83.

DIMENSIONS

Width cm 60 60 60 55 60 50 50 50

Height cm 90 90 90 90 90 90 90 90

Depth cm 60 60 60 60 60 60 60 60

HOB

Type Ceramic Ceramic Ceramic Ceramic Solid plate Ceramic Ceramic Solid plate

Hot hob Indicator II I

COOKING ZONES

Rear left 140mm 140mm 140mm 140mm 1 x 1.0kW 140mm 140mm 1 x 1.5kW

/1.2kW(RPZ) /1.2kW(RPZ) /1.2kW /1.2kW /1.2kW /1.2kW

Rear right 180mm 180mm 180mm 180mm 1 x 1.5kW 180mm 180mm 1 x 1.5kW

/1.8kW(RPZ) /1.8kW(RPZ) /1.7kW /1.7kW /1.8kW /1.8kW

Front left 180mm 180mm 180mm 180mm 1 x 2.0kW 180mm 180mm 1 x 1.5kW

/1.8kW(RPZ) /1.7/0.7kW /1.7kW /1.7kW /1.8kW /1.8kW

(dual)(RPZ)

Front right 140mm 140mm 140mm 140mm 1 x 1.5kW 140mm 140mm 1 x 2.0kW

/1.2kW(RPZ) /1.2kW(RPZ) /1.2kW /1.2kW /1.2kW /1.2kW

PROGRAMMER

Automatic fully programmable IIII

Electronic clock/minute minder with end cook I

Rotary minute minder I

TOP CAVITY/OVEN

Grill type Intelligent Variable Variable Variable Fixed Variable Variable

Variable (3 positions)

Conventional cooking IIII III

Oven lining Catalytic Catalytic Enamel Enamel Enamel Enamel Enamel

Viewing window IIII III

Useable volume 37 37 37 37 26 26 26

Oven light II

MAIN OVEN

Grill type Fixed

Thermaflow

IIIIIIII

Defrost IIII III I

Heat and hold I

Quick preheating I

Top heat I

Bottom heat I

Oven light IIII III

Oven lining Catalytic Catalytic Enamel Catalytic Enamel Enamel Enamel Enamel

Viewing window IIIIIIII

Useable volume*** litres 58 58 58 58 58/53 53 72 72

STORAGE

Compartment I

Drawer

ENERGY RATING

Top oven* A A A A B

Main oven* B A A A A A A A

COLOUR

White IIIIIIII

Black

Brown

Silver III III

Stainless steel IIII III

ELECTRIC COOKERSCHEST FREEZERS

COOKING

ZKT6050W/X

ZKC6040W/S/X

ZKC6020W/S/X

ZKC5540W/S/X

ZCE640W/ZCE641X

ZKC5030W1/X1/S1

ZKC5020W1/S1/X1

ZKS5010W1/S1

MODEL

Range Chest Chest Chest Chest

Height mm 876 868 868 850

Width mm 1050 935 795 550

Depth mm 665 665 665 593

Suitable for outbuilding III

Freezing capacity kg/24hr 24 16 14 12

Energy consumption per day kWh 0.581 0.879 0.781 0.69

Yearly energy consumption** kWh 212 321 285 250

Control position Thermostat control Thermostat control Thermostat control

knob on side knob on side knob on side

Energy label* A+ B B C

†

Climate class** SN-N-ST SN-N-ST-T SN-N-ST-T SN

Gross capacity freezer litres/cu.ft 221/7.81 263/9.29 213/7.5 105/3.7

Net capacity freezer litres/cu.ft 216/7.63 260/9.18 210/7.4 102/3.6

FREEZER FEATURES

Freezer baskets 1 2 1 1

Interior light III

Vacuum release valve III

Wheels I Fixed Feet Fixed Feet Fixed Feet

COLOUR

White III I

COOLING

MODEL

ZFC622WA

ZFC326WB

ZFC321WB

ZFC35C

†

This model will be upgraded to a ‘B’ rated appliance in July 2008 * Energy efficiency class based on a scale of A+ (most efficient) to G (least efficient). ** Based on standard test results for 24 hours in accordance with EN153. Actual consumption will depend on how the appliance is used and where it is located. *** Climate class - the product is suitable for use in ambient temperatures of SN:10-32ºC, N:16-32ºC, ST:18-38ºC, T:18-43ºC

* Energy efficiency class on a scale of A (more efficient) to G (less efficient). ** Energy consumption in kWh for the heating functions based on standard load determined in accordance with the test procedures of the harmonised standard. ***Useable volume of the oven in litres, determined in accordance with harmonised standard.

Page 7

84. 85.

DIMENSIONS

Width cm 100 60 60

Height cm 90 90 90

Depth cm 60 60 60

HOB

Type Gas Gas Gas

Pan supports Cast Iron Enamel Enamel

BURNERS

Rear left 1 x 1.75kW (Semi-Rapid) 1 x 1.9kW (Semi-Rapid) 1 x 2.0kW (Semi-Rapid))

Rear right 1 x 3.0kW (Rapid) 1 x 1.9kW (Semi-Rapid) 1 x 2.0kW (Semi-Rapid)

Centre 1 x 3.3kW (Wok)

Front left 1 x 3.0kW (Rapid) 1 x 2.9kW (Rapid) 1 x 3.0kW (Rapid)

Front right 1 x 1.75kW (Semi-Rapid)) 1 x 1.0kW (Simmer) 1 x 1.0kW (Simmer)

PROGRAMMER

Automatic fully programmable II

Rotary minute minder II

TOP CAVITY/OVEN

Grill type Electric variable Variable

Conventional cooking II

Oven lining Enamel Catalytic

Viewing window II

Useable volume** 31 37

Oven light I

MAIN OVEN

Grill type Electric variable Electric fixed

Thermaflow

III

Conventional I

Defrost II I

Top heat I

Bottom heat I

Oven light III

Oven lining Enamel Catalytic Enamel

Viewing window III

Useable volume litres 52 58 53

STORAGE

Compartment I

Drawer I

ENERGY RATING

Top oven* B A

Main oven* B A A

COLOUR

White II

Black

Silver I

Stainless steel III

DUAL FUEL COOKERS

MODEL

ZCM1030X

ZKM6040WN

/SN/XN

ZCM641X

/ZCM640W

COOKING

DIMENSIONS

Width cm 60 60 55 55 50 50

Height cm 90 90 90 90 90 90

Depth cm 60 60 60 60 60 60

HOB

Type Gas Gas Gas Gas Gas Gas

Lid IIIII

Pan supports Enamel Enamel Enamel Enamel Enamel Enamel

BURNERS

Rear left 1 x 1.9kW 1 x 1.9kW 1 x 1.9kW 1 x 1.9kW 1 x 2.0kW 1 x 2.0kW

(Semi-Rapid) (Semi-Rapid)) (Semi-Rapid) (Semi-Rapid) (Semi-Rapid) (Semi-Rapid)

Rear right 1 x 1.9kW 1 x 1.9kW 1 x 1.9kW 1 x 1.9kW 1 x 2.0kW 1 x 2.0kW

(Semi-Rapid) (Semi-Rapid) (Semi-Rapid) (Semi-Rapid) (Semi-Rapid) (Semi-Rapid)

Front left 1 x 2.9kW 1 x 2.9kW 1 x 2.9kW 1 x 2.9kW 1 x 2.8kW 1 x 2.8kW

(Rapid) (Rapid) (Rapid) (Rapid) (Rapid) (Rapid)

Front right 1 x 1.0kW 1 x 1.0kW 1 x 1.0kW 1 x 1.0kW 1 x 1.0kW 1 x 1.0kW

(Simmer) (Simmer) (Simmer) (Simmer) (Simmer) (Simmer)

PROGRAMMER

Electronic clock/minute minder with end cook II I

TOP CAVITY/OVEN

Grill type Variable Variable Variable Variable Variable Variable

Multi zone cooking III II

Oven lining Enamel Enamel Enamel Enamel Enamel Enamel

Viewing window II I II I

Useable volume 27 27 27 27 23 23

MAIN OVEN

Grill type Variable Variable Variable Variable Variable

Multi zone cooking III III

Viewing window II I II I

Oven light II I II

Oven lining Catalytic Enamel Catalytic Catalytic Enamel Enamel

Useable volume litres 49 49 49 49 69 69

COLOUR

White II I II I

Black

Brown

Silver II I II

Stainless steel IIII

GAS COOKERS

MODEL

ZKG6040WN/SN

/XN/WFN*

ZKG6020WN/SN

ZKG5540WN

/SN/XN

ZKG5530WN

/SN/XN/WFN*

ZKG5030WN1

/XN1/SN1

ZKG5020WN1

/WFN*

COOKING

* Models with full safety device. Suitable for apartments and multi-occupancy dwellings

Page 8

ENERGY EFFICIENCY INFORMATION

This scheme, which covers refrigerators, freezers, washing machines, tumble dryers, dishwashers

and electric ovens is designed to offer consumers a standardised method of choosing the most

energy efficient appliances. For refrigerators and freezers, as well as stating the Energy Efficiency

Class (ʻA+ʼ - most efficient, ʻGʼ - least efficient) the label also gives the annual electricity consumption

(i.e. running cost) and the usable storage capacity. For washing machines the label also states the

wash performance and spin efficiency. Three ratings are given to ensure energy efficiency combined

with effective washing and spinning. For dishwashers the label states energy efficiency, washing and

drying performance. For electric ovens the label also states the energy consumption (in kWh) and the

usable volume of the oven. If the oven is a double oven it will carry this information for both ovens.

appliance with low energy consumption

appliance with medium energy consumption

appliance with high energy consumption

Many products in the Zanussi range are ʻAʼ rated and endorsed by the Energy Savings Trust with an Energy Efficiency Recommendation. The award by this independent body is made only to the most energy efficient appliances on the market.

www.energysavingtrust.org.uk

AFTER SALES SUPPORT

CUSTOMER CARE - TELEPHONE (08705) 727 727

Service Force Network

Telephone (08705) 929 929 www.serviceforce.co.uk

RESPONSIVE CUSTOMER CARE/AFTER SALES SERVICE

Once youʼve bought a Zanussi appliance youʼre safe in the knowledge that in

the unlikely event of a fault occurring you can rely on our commitment to look

after your appliance throughout its working life. Over five hundred manufacturer

trained service engineers are available nationwide and our complete care service

is one of the most extensive and reliable available.

12 MONTHS PARTS AND LABOUR GUARANTEE

In the unlikely event of any repairs being required in the first year, we will carry them out free of charge. In addition, any repairs carried out after the guarantee period are covered by their own 12 month guarantee*.

* Guarantee conditions provided on request.

RAPID SERVICE

If you call us out under the 12 month guarantee, we endeavour to fix the appliance within seven working days of our first call.

LOCAL SERVICE NATIONWIDE

Backed by the extensive range of spare parts held by our central warehouse, the Service Force Network will endeavour to repair your product in your home within 72 hours of receipt of the original call.*

* Excludes Saturdays, Sundays and Bank holidays, and may not be available in rural or outlying areas.

SERVICE BY APPOINTMENT

To allow you to plan your day we can offer an appointment within a 3 hour time period, when the call is booked two days in advance.* We can also provide service outside of office hours and Saturday mornings.**

* Please note. The service pledge does not apply in the Republic of Ireland. ** A small extra charge is payable for this service.

MARKETING POLICY

The policy of Zanussi is one of continued improvement. We therefore reserve the right to alter or amend product ranges, specifications and dimensions without notice. All specifications/dimensions including installation dimensions should be checked with the appropriate instruction manual before use or installation. If in doubt, contact your local Zanussi stockist who regularly receives up to date product information from our marketing department. E and O.E.

86. 87.

THE THOUGHTFUL DESIGN INNOVATOR

Do you remember the last time you opened a gift that made you say ʻOh how did you know? Thatʼs exactly what I wanted!ʼ Thatʼs the kind of feeling that the designers at Electrolux seek to evoke in everyone who chooses or uses one of our products. We devote time, knowledge, and a great deal of thought to anticipating and creating the kind of appliances that our customers really need and want.

This kind of thoughtful care means innovation with insight. Not design for designʼs sake, but design for the userʼs sake.

For us, thoughtful design means making appliances easier to use and tasks more enjoyable to perform, freeing our customers to experience that ultimate 21st century luxury, ease of mind. Our aim is to make this ease of mind more available to more people in more parts of their everyday lives, all over the world. So when we say weʼre thinking of you, you know that we mean just that.

Electrolux - Thinking of you.

Share more of our thinking at www.electrolux.com
