For optimum
performance the
dimmer
into programming
mode
must be put
to calibrate
the load
ZGRIDLED150
Next generation 0-150W dimming
WIRING INSTRUCTIONS
Dimmer Switch and dimmer
DIMMER
L2 L1 C
LIVE FEED
LAMP/LOAD
INSTALLATION
NB: Installation must be carried out by a qualified electrician
Turn off the mains at distribution board
•
Wire device using a suitable rated cable as in wiring diagrams
•
Terminals should be tightened to a maximum of 0.33Nm
•
Check polarity is correct throughout
•
Fit appropriate adaptor as in assembly diagrams
•
Fit device into wall box ensuring cables are not obstructed
•
Secure front plate
•
Product should be recycled at end of life where facilities exist
•
2-WAY
SWITCH
L2 L1 C L2 L1 C
DIMMER
LAMP/LOAD
LIVE FEED
ZGRIDLED+
Intelligent 5-250W LED dimming
/
SMART SETTINGS INSTALLATION GUIDE
Please read through before you begin…
1. Turn on the lights and turn control clockwise to full brightness
2. Press to turn off
3. While off, turn the controller fully anti-clockwise
4. Press again to turn on. The lights will flash to indicate that you
are now in programming mode
5. Select the minimum light level required
6. Wait 5 seconds. The lights will flash again to indicate the minimum
level has been stored
7. You are now going to set the start level – turn controller clockwise
to a brighter level
8. Wait 5 seconds. The lights will flash again to indicate the start level
has been stored
9. The lights will now come on at maximum brightness
a. If flicker is seen, adjust the controller down until the flicker
stops and again, wait 5 seconds for the settings to be stored
b. If you are unable to see any flicker wait 5 seconds and the
lights will flash confirming all smart settings have been saved
10. Your dimmer is now set and ready to use. All settings will be saved
even if the power is switched off
1. Remove knob 2. Choose the adaptor to fit your grid 3. Use the tool to secure
adaptor with the ring
3. Clip into grid,
replace knob
SPECIFICATIONS
PART NO. ZGRIDLED150 ZGRIDLED+
MODULE SIZE SINGLE GRID SINGLE GRID
LAMP TYPE LED/CFL LED/CFL
MAX WATT 150W / VA 250W / VA
MIN WATT 0W / VA 5W / VA
MIN BOX DEPTH 35 MM 35 MM
2-WAY SWITCHING YES YES
NEED TO DE-RATE TO 160W / VA N/A YES, IF FITTING 2 OR MORE PER PLATE
MAXIMUM PLATE LOAD RECOMMENDATIONS
COVER PLATE SIZE CFL LED
SINGLE PLATE 500W 500W
DOUBLE PLATE 640W 640W
6-8 GANG 1280W 1280W
WHAT’S IN THE BOX?
1 single space grid module
•
1 standard size rotary control knob
•
1 locking ring
•
1 locking ring tool
•
9 grid adaptors (to fit Hager, Euro Module, Schneider Lisse,
•
MK Logic, Hamilton, Crabtree, BG, Deta, Wandsworth)
We are award-winning manufacturers of LED dimming solutions
and pride ourselves on providing fast, friendly, expert advice.
For our full range of products, technical advice & instructional
films or to find your nearest stockists please see our website.
GUARANTEE
For lamp test results and our full terms and conditions please
see our website: www.zanocontrols.co.uk.
PRODUCT OVERVIEW
The ZGRIDLED range of dimmers has been specifically designed to
dim LED lamps. The advanced technology used to control the load
results in flicker-free dimming of lamps and drivers. This technology also
eliminates the need to differentiate between leading and trailing edge
lamps. It works with either! All our LED dimmers have built-in thermal
and over-load protection, as well as smart settings. It is essential before
making connections to check the load against the table to ensure it
meets the specification of the dimmer switch.
CONTACT OUR FRIENDLY TEAM
Call: 0345 519 5858
Fax: 0845 519 5757
Email: sales@zanocontrols.co.uk
www.zanocontrols.co.uk
Zano Controls, Unit 1 Chantry Court, Wrythe Lane,
Carshalton, Surrey, SM5 2DG
Great British Design
For terms & conditions see www.zanocontrols.co.uk
For safety & certification info see www.zpatent.co.uk
