Zanker ZDC67550W User Manual

user manual

ZDC 67550W

Tumble Dryer

125987350.qxp 2007-01-09 15:02 Page 1

125987350.qxp 2007-01-09 15:02 Page 2

electrolux 3

Welcome to the world of Electrolux

Thank you for choosing a first class product from Electrolux, which
hopefully will provide you with lots of pleasure in the future. The
Electrolux ambition is to offer a wide variety of quality products that
make your life more comfortable. You find some examples on the
cover in this manual. Please take a few minutes to study this manual
so that you can take advantage of the benefits of your new
machine. We promise that it will provide a superior User Experience
delivering Ease-of-Mind. Good luck!

GB

125987350.qxp 2007-01-09 15:02 Page 3

4 electrolux contents electrolux

Contents

Safety information..............................5

Product description ...........................7

Control panel.....................................7

Use....................................................8

Drying hints ................................12-13

Drying programmes....................14-15

Programme information ...................16

Care and cleaning ...........................17

Something not working ..............20-22

Technical data .................................23

Consumption values ........................24

Installation ..................................25-26

Environment concerns .....................27

Guarantee conditions ......................28

Customer service centres ................29

The following symbols are used in this manual:

Important information concerning your personal safety and information on how
to avoid damaging the appliance.

General information and tips

Environmental information

125987350.qxp 2007-01-09 15:02 Page 4

safety information electrolux 5

Safety Information

In the interest of your safety and to

ensure the correct use, before installing
and first using the appliance, read this
user manual carefully, including its hints
and warnings. To avoid unnecessary
mistakes and accidents, it is important
to ensure that all people using the
appliance are thoroughly familiar with its
operation and safety features. Save
these instructions and make sure that
they remain with the appliance if it is
moved or sold, so that everyone using it
through its life will be properly informed
on appliance use and safety.

General safety

• It is dangerous to alter the

specifications or attempt to modify
this product in any way.

• This appliance is not intended for use by

persons (including children) with reduced
physical, sensory or lack of experience
and knowledge, unless they have
been given supervision or instruction
concerning use of the appliance by a
person responsible for their safety.

• Make sure that small pets do not climb

into the drum. To avoid this, please
check into the drum before using.

• Any objects such as coins, safety

pins, nails, screws, stones or any
other hard, sharp material can cause
extensive damage and must not be
placed into the machine.

• In order to avoid danger of fires

caused by excessive drying, do not
use appliance to dry the following
items: Cushions, quilts and the like
(these items accumulate heat).

• Items such as foam rubber (latex foam),

shower caps, waterproof textiles, rubber
backed articles and clothes or pillows
fitted with foam rubber pads should
not be dried in the tumble dryer.

• Always unplug the appliance after

use, clean and maintenance.

• Under no circumstances should you

attempt to repair the machine
yourself. Repairs carried out by
inexperienced persons may cause
injury or serious malfunctioning.
Contact your local Service Centre.

GB

Control panel

Fluff filters

Rating Plate

Condenser unit

Water reservoir

Adjustable feet

6

5

4

3

2

1

125987350.qxp 2007-01-09 15:02 Page 5

6 electrolux safety information

Always insist on genuine spare parts.

• Items that have been soiled with

substances such as cooking oil
acetone, petrol, kerosene, spot
removers, turpentine, waxes and
wax removers should be washed in
hot water with an extra amount of
detergent before being dried in the
tumble dryer.

•

Danger of explosion:

Never tumble dry
items that have been in contact with
inflammable solvents (petrol, methylated
spirits, dry cleaning fluid and the
like). As these substance are volatile,
they could cause an explosion. Only
tumble dry items washed with water.

•

Risk of fire

: items that have been
spotted or soaked with vegetable or
cooking oil constitute a fire hazard
and should not be placed in the
tumble dryer.

• If you have washed your laundry

with stain remover you must
execute an extra rinse cycle before
loading your tumble dryer.

• Please make sure that no gas lighters

or matches have accidentally been left
in pockets of garments to be loaded
into appliance

Installation

• This appliance is heavy. Care should

be taken when moving it.

• When unpacking the appliance, check

that it is not damaged. If in doubt, do not
use it and contact the Service Centre.

• All packing and transit bolts must be

removed before use. Serious damage
can occur to the product and to
property if this is not adhered to. See
relevant section in the user manual.

• The final part of a tumble dryer cycle

occurs without heat ( cool down
cycle ) to ensure that the items are

left at a temperature that ensures
that items will not be damaged.

• Any electrical work required to

install this appliance should be
carried out by a qualified electrician
or competent person.

• Care must be taken to ensure that

the appliance does not stand on the
electrical supply cable.

• If the machine is situated on a

carpeted floor, please adjust the feet
in order to allow air to circulate freely

• After having installed the appliance,

check that it is not pressing or
standing on its electrical supply
cable, inlet hose and drain hose.

• If the tumble dryer is placed on top of a

washing machine, it is compulsory to
use the stacking kit (optional accessory).

Use

• This appliance is designed for domestic

use. It must not be used for purposes
other than those for which it was
designed.

• Only wash fabrics which are designed

to be machine dried. Follow the
instructions on each garment label.

• Do not dry unwashed items in the

tumble dryer.

• Fabric softeners, or similar products,

should be used as specified by the
fabric softener instructions.

• Do not overload the appliance. See

the relevant section in the user
manual.

• Clothes which are dripping wet

should not be placed in the dryer.

• Garments which have been in

contact with volatile petroleum
products should not be machine
dried. If volatile cleaning fluids are
used, care should be taken to

125987350.qxp 2007-01-09 15:02 Page 6

product description/Control panel electrolux 7

Product description

GB

Control panel

Programme selector dial

Delicate button

Dryness button

Buzzer button

Indicator lights

5

4

3

2

1

Start/Pause button

Delay Start button

7

6

Control panel

Fluff filters

Rating Plate

Condenser unit

Water reservoir

Adjustable feet

6

5

4

3

2

1

125987350.qxp 2007-01-09 15:02 Page 7

8 electrolux use

Use

First Use

l Ensure that the electrical connections

comply with the installation
instructions.

l Remove the polystryrene block and

any material from the drum.

l Before using your tumble dryer for

the first time, were commend that
you to place a few damp cloths
inside the appliance and dry for 30
minutes.

There may be dust inside a brand
new tumble dryer.

Daily Use

Load the laundry

Connect the appliance.
Open the door (see picture).

Place the laundry in the drum, one item
at a time, shaking them out as much as
possible. Close the door.

Please check the laundry does not get
caught between the door and filter.

Select the required programme

Turn the programme selector dial to the
required programme.
The light Start/Pause starts to flash.

The selector dial is divided into following
sections:

• Cottons

• Synthetics

• Time

• Special

Allows you to select electronically
controlled or time controlled drying.

Turn the dial to the required programme
or time.

Electronically controlled drying (automatic)
The appliance runs these programmes

with the help of probes which detect the
degree of dampness of the laundry.
Simply select the programme according
to the type of laundry and degree of
drying required.

The selector dial can be turned either
clockwise or anticlockwise. The lights Drying,

60’

30’

Easy Iron

Mixed

Jeans

Cooling

Time

Special

Cottons

Extra

Strong

Cupboard

Damp

Iron

Extra

CupboardIron

Off

Syntheti cs

125987350.qxp 2007-01-09 15:02 Page 8

use electrolux 9

Cooling and End/Anticrease come on.

At the end of the programme the
selector dial must be turned to position
Off, to switch the machine off.

Attention!

If you turn the programme selector dial
to another programme when the
machine is working, the lights of the
programme progress display start to
flash. The machine will not perform the
new selected programme.

Programme Option buttons

Depending on the programme, different
functions can be combined. These must
be selected after choosing the desired
programme and before depressing the
Start/Pause button.
When these buttons are pressed, the
corresponding pilot lights come on.
When they are pressed again, the pilot
lights go out.

Select Delicate

Pressing this button allows drying to be
performed at a lower temperature, for
delicate items.

The corresponding pilot light comes
on. This option can also be used for
time controlled drying.
DELICATE is only suitable for use with
loads of up to 3kg!

When the programme has finished the
pilot lights End is on.

Select the Dryness

Press the Dryness button repeatedly, to
select the desired option. The relevant
light will light up. Laundry becomes
dryer from MIN to MAX.

Press the Dryness button as many
times as necessary until the small light
at the level of residual dampness
required is illuminated.

When the programme has finished the
pilot lights End is on.

Select the Buzzer

When the drying cycle has finished, an
intermittent audible signal will sound.

By depressing button Buzzer the acou­stic signal is switched off in the following
cases:

• when selecting the programme

• when depressing the buttons

• when the programme selector dial is
turned to another position during the
programme or when you depress an
option button during the cycle

• at the end of the programme.

The corresponding light comes on

Select the Start/Pause

Start/Pause

Dryness

GB

125987350.qxp 2007-01-09 15:02 Page 9

10 electrolux use

Press this button to start the dryer after
having selected the programme and
the options.
The relevant light will stop flashing.
If the programme selector dial is turned
to another position, when the machine is
running, the buzzer will sound and the
programme phase indicator lights will flash.

The drum turns alternately in both direc­tions during drying.

All drying programmes end with a 10 minute
cooling phase (light Cooling is on).
You may remove the laundry after this
phase.

The lights End/Anticrease, Filtre and
Empty Tank illuminate and the buzzer
sounds

If the door of the appliance or the small
door at the bottom is opened while the
programme is running, this button must
be pressed again after closing the door
in order to restart the programme from
the point at which it was interrupted.
This button must be depressed also
after a power failure and after having re-
inserted the water reservoir, if it has
been emptied in the middle of a pro-
gramme after lighting up of light Empty
Tank

.

In both cases the light of the Start/Pause
button flashes to remind you that the
start button needs to be pressed again.

Select the Delay Start

This button allows you to delay the starting of

the programme by 3, 6 or 9 hours.
Press the button until the light relevant

to the desired delay lights up. This
option must be selected

after

having

selected the programme and

before

pressing START/PAUSE to start the
programme.

The machine begins the countdown,
which is shown by the pilot lights. For
example, if you have chosen a 9-hour
delay (pilot light 9h lit), after 3 hours, 9h
goes out and 6h lights up; after 3 more
hours, 6h goes out and 3h lights up.
When the 9 hours are over (pilot light 3h
off), the drying cycle begins.During the
delayed start period, it is not possible to
change the programme or the selected
delay. If you wish to do so, you must first
cancel everything by rotating the pro­gramme selector dial to position “

Off

”.
Select the new programme, the options
and the delayed start, then press
START/PAUSE. If you wish to change
only the options, this can be done on
condition that the new option(s) is(are)
compatible with the programme. Set the
machine to PAUSE by depressing the rel­evant button, select the new option(s) and
depress START/PAUSE button again.

If you wish to add some laundry while the
machine is performing the countdown, after
having done so and having closed the door,
press START/PAUSE again, in order to allow
the machine to complete the remaining
countdown time.

Indicator lights

TThese lights indicate the following
functions:

“

Drying”light

This light indicates that the appliance is
in the drying phase

.

“Cooling” light

This light indicates that the appliance is in the
cooling phase. At the end of drying, there is
a 10 minute cooling phase to cool the

125987350.qxp 2007-01-09 15:02 Page 10

use electrolux 11

laundry.

“

Empty Tank””light

This light indicates that the appliance is in the
drying phase

.

This light comes on at the end of the
programme to remind you that the water
reservoir must be emptied out. If this light
illuminates during a programme this means
that the water reservoir is full. The buzzer
sounds, the programme stops, the light of
the Start/Pause button flashes. This light
comes on also when the water reservoir is
not inserted correctly.

“Filter” light

This light illuminates at the end of the
programme to remind you that the
filters must be cleaned.

“Condenser” light

It comes on every 80 cycles to remind you
that the condenser must be cleaned.

Cancelling a programme

Turn the selector dial to

“Off”

to cancel
a programme which is running. Now
you can select a new programme.

At the end of the programme

If the laundry is not removed at the end
of the cycle, the dryer performs an

anti-

creasing

phase (duration: 30 minutes

maximum).

If you do not remove the laundry, the
dryer will stop automatically at the
end of the anti-creasing phase.
Lights End/Anticrease, Filter and

Condenser

remain lit and the buzzer

sounds for 2 minutes.

Turn the programme selector dial to

“Off”

to switch the machine off. Remove the
laundry from the drum and carefully
check that the drum is empty.

If you do not intend to carry out another

wash, close the water tap. Leave the
door open to prevent the formation of
mildew and unpleasant smells.

Turn the programme selector dial to
“

Off

”; all the lights go out. The appli-

ance is switched off.
Remove the laundry.

If you open and then close the door
before turning the selector dial to
“Off” all the lights corresponding to
the phases making up the performed
programme come on.

After each use

• Clean the filters.

• Empty the water reservoir.

Important!

If the drying programme has to be
stopped before it reaches the end, we
recommend that you turn the pro­gramme selector dial to position Cooling
and wait until the end of this cooling
phase before removing the laundry. This
will avoid a build-up of heat inside the
appliance.To do this first turn the dial to
“

Off

” and then to Cooling and depress

Start button.

Modifying the programme

To change a programme which is run­ning, first cancel it by turning the pro­gramme selector dial to “

Off

”. Select the
new programme and press the Start
button .

GB

125987350.qxp 2007-01-09 15:02 Page 11

12 electrolux drying hints

Drying hints

Before loading the laundry

Never tumble dry the following:
Particularly delicate items such as
net curtains, woollen, silk, fabrics
with metal trim, nylon tights, bulky
materials such as anoraks, blankets,
eiderdowns, sleeping bags, feather
quilts and any items containing rub­ber foam or materials similar to rub­ber foam.

• Always follow the instructions on gar­ment labels:

may be tumble dried

normal drying (high tempera-

ture)

delicate drying (low tempera-

ture)

do not tumble dry

• Close pillowcases and covers with
fasteners to prevent small laundry
items getting tangled inside them.
Close press studs, zips and hooks
and tie belts and apron strings.

• Sort laundry according to type and
degree of drying required.

• Do not over-dry laundry, this avoids
creasing and saves energy.

• Avoid drying dark clothes with light
coloured fluffy items such as towels
as they could attract the fluff.

• The laundry must be thoroughly spun
before tumble drying.

•

Easy-care items

, too, e.g. shirts,

should be briefly pre-spun before

drying (depending on crease resist­ance approx. 30 seconds or using
the special brief spin programme of
your washing machine).

• Knitted textiles (knitted underwear)
may shrink a little during drying.
Please do not overdry items of this
type. It is advisable to allow for
shrinkage when choosing the size of
new purchases.

• You can also put starched items into
your dryer. However, to achieve the
desired starched effect, choose the
programme “iron dry”. To remove any
starch residues, wipe out the internal
drum after drying with a moist cloth
and then rub it dry.

• To avoid a static charge when drying
is completed, use either a fabric sof­tener when you are washing the
laundry or a fabric conditioner specif­ically for tumble dryers.

• Remove the laundry when the dryer
has finished drying.

• If individual items are still damp after
drying, set a brief post-drying time,
but

at least 30 minutes

. This will be
necessary particularly for multilayered
items (e.g. collars, pockets, etc.).

Make sure that no metal objects are
left in the laundry (e.g. hair clips, safety
pins, pins).

Button up pillowcases, close zip
fasteners, hooks and poppers. Tie any
belts or long tapes.

To avoid laundry becoming tangled:
close zips, button up duvet covers and
tie loose ties or ribbons (e.g. of aprons).

Turn items with double-layered fabrics
inside out (e.g. with cottonlined anoraks,
the cotton layer should be outermost).
These fabrics will then dry better.

125987350.qxp 2007-01-09 15:02 Page 12

Maximum loads

Recommended loads are indicated in
the programme charts.

General rules:

Cotton, linen:

drum full but not too

tightly packed;

Synthetics:

drum no more than half full;

Delicate fabrics and woollens:

drum no

more than one third full.

Try to load to the maximum capacity
of the machine as small loads are
uneconomical.

Laundry weights

The following weights are indicative:

drying hints electrolux 13

GB

bathrobe 1200 g
napkin 100 g
quilt cover 700 g
sheet 500 g
pillow case 200 g
tablecloth 250 g
towelling towel 200 g
tea cloth 100 g
night dress 200 g
ladies’ briefs 100 g
man’s work shirt 600 g
man’s shirt 200 g
man’s pyjamas 500 g
blouse 100 g
men’s underpants 100 g

125987350.qxp 2007-01-09 15:02 Page 13

14 electrolux drying programmes

Drying programmes

Programme

Type of
laundry

Options Description of programme

Extra

Cotton and
linen

Dryness
Delicate
Buzzer
Time

Drying thick or multi-layered textiles,
e.g. terry towelling items Max load: 7
kg

Strong

Cotton and
linen

Dryness
Delicate
Buzzer
Time

Drying thick textiles, e.g. terry
towelling items, towels.

Cupboard

Cotton and
linen

Dryness
Delicate
Buzzer
Time

Drying textiles of even thicknesses,
e.g. terry towelling items, knitted
items, towels.

Damp

Cotton and
linen

Dryness
Delicate
Buzzer
Time

For thin textiles which are still to be
ironed, e.g. knitted items, cotton
shirts.

Iron

Cotton and
linen

Dryness
Delicate
Buzzer
Time

For cotton or linen laundry which are
still to be put through a machine, e.g.
bedding, table linen.

Extra

Synthetics

Dryness
Delicate
Buzzer
Time

Drying thick or multi-layered textiles,
e.g. pullovers, bedding, table linen.

Cupboard

Synthetics

Dryness
Delicate
Buzzer
Time

For thin textiles which are not ironed,
e.g. easy care shirts, table linen,
baby’s clothes, socks, underwear.

Iron

Synthetics

Dryness
Delicate
Buzzer
Time

For thin textiles which are still to be
ironed, e.g. knitted items, cotton
shirts.

Time
30 min
60 min

Synthetics
Cotton

Delicate
Buzzer
Time

Drying thick or multi-layered textiles,
e.g. terry towelling items. For drying
individual items of laundry or for small
volumes of less than 1kg.

125987350.qxp 2007-01-09 15:02 Page 14

GB

drying programmes electrolux 15

Drying programmes

Max Cottons load: 7 kg
Max Synthetics load: 3 kg
Max Time load: 1 kg
Max Special Mix load: 3 kg
Max Special Jeans load: 7 kg

Programme

Type of
laundry

Options Description of programme

Special

Mixed

Cotton
Cupboard dry
Synthetics

Dryness
Delicate
Buzzer
Time

Special programme for cotton and
easy care, which can drying together
in the same time.

Special

Easy iron

Synthetics

Delicate
Buzzer
Time

Special programme with anti-crease
mechanism for easy care textiles
such shirts and blouses; for minimum
ironing effort. The result depends on
the type and quality of textiles. (The
loading volume corresponds to
approx. 4 to 5 shirts.)
Recommendation: Place textiles in
the dryer straight after spinning. Once
dried, immediately remove textiles
and place on clothes hanger.

Special

Jeans

Cotton
Cupboard dry

Dryness
Delicate
Buzzer
Time

Special programme for leisure
clothing, such as jeans, sweat-shirts,
etc., of different material thicknesses
(e.g. at the cuffs and seams).

Special

Cooling

Cotton and
linen
Synthetics

Buzzer

Special programme, lasting around
10 minutes, for refreshing or gently
cleaning textiles with commercially
available dry cleaning sets.
(Only use those products which are
declared as suitable for the drier by
the manufacturer; please observe the
manufacturer’s instructions for use.)

125987350.qxp 2007-01-09 15:02 Page 15

16 electrolux programme information

Programme information

Objective Implementation

Adjusting
the level of
conductivity

Water contains, a variable quantity of limestone and mineral salts of which
quantities vary according to geographical locations thus varying its
conductivity values. Relevant variations of the conductivity of the water
compared to those prefixed by the factory could slightly influence the
residual humidity of the laundry at the end of the cycle. Your dryer allows
you to regulate the sensitivity of the drying sensor based on conductivity
values of the water by using the following procedure.

To access adjustment mode:

1. Turn the programme selector dial to switch on the appliance.

2. In selection mode,press simultaneously the buttons DRYNESS
and START.

Press the buttons down until the pilot lights above each ones begin
to flash and one of the pilot lights indicating the drying phase lights
Empty Tank, Filter and Condenser remains it.

Adjusting the level of conductivity

:

Press the START/PAUSE button sequentially: the level of
conductivity is indicated by the phase pilot lights, which light in
various combinations as follows:

LED lit Conductivity Approximate value µS/cm

Empty Tank

Low < 300

Filter

Medium 300-600

Condenser

High >600

Normally, the appliance is factory-set to the highest level; however,
certain models may be configured differently.

Memorizing the new setting:

Simultaneously press the buttons DRYNESS and START. Press the
buttons down until the pilot lights above each ones stop flashing
and the buzzer sounds.

Off =
Cancelling/
OFF

To reset a programme and to switch off the machine turn the
selector dial to Off. Now can a new programme be selected.

125987350.qxp 2007-01-09 15:02 Page 16

care and cleaning electrolux 17

Care and cleaning

You must DISCONNECT the appliance
from the electricity supply, before you
can carry out any cleaning or
maintenance work.

External cleaning

Use only soap and water and then dry

thoroughly.

Important:

do not use methylated

spi`rit, diluents or similar products..

Cleaning the door

Clean periodically the interior part of
the door to remove any fluff from the
seals around the filter. Accurate clean­ing ensures correct drying.

Cleaning the filters

Your dryer will only function well if the fil­ters are clean.

The filters collect all the fluff which
accumulates during drying and they
must therefore be cleaned

at the end

of each programme

, before removing
the laundry, with a damp cloth.
The light Filter is on to remind you this
operation.

The filter in the inner door must be
removed for cleaning.

Do not be alarmed by the amount of fluff. It
is not due to excessive wear caused by the
dryer.

All fabric loses fluff when drying but it
goes un-noticed in the air. In a tumble
dryer it simply collects in the filter.

After a while, a withish patina due to
detergent residue on laundry forms on
the filters. When this occurs, clean the
filters with warm water using a brush.
Remove the filter in the door opening
as per picture (it can be positioned with
the tooth facing to the left or to the
right).

GB

125987350.qxp 2007-01-09 15:02 Page 17

18 electrolux care and cleaning

Do not use the appliance without filters.

Cleaning the condenser unit

Clean the condenser when light
Condenser comes on.
The condenser is situated at the lower
part of the cabinet behind a small door.
To open the door, push the catch as
per picture.
During the drying cycle or at the end, it
is normal for water to be present on
the surface of the condenser insertion.

To pull out the condenser, first turn the
two red stops downwards and then
remove the condenser unit holding it at
the handle.

Clean it with a brush and rinse it under
the shower if necessary. Also clean the
outside, removing all fluff. Clean the
rubber seal round the condenser cabi­net and in the inner part of the small
door with a damp cloth..

Important!

Do not use pointed
objects or utensils to clean the spaces
between the plates, as this could dam­age the condenser and make it perme­able. Re-fit the condenser, turn the red
stops upwards and close the door.

Do
not use this appliance if the condenser
has not been fitted.

Emptying the water reservoir

Water extracted from the laundry con­denses inside the machine and is col­lected in a reservoir. The reservoir must
be emptied after each drying cycle to
ensure efficient operation when the
machine is next used. The pilot light
Empty Tank reminds you this opera­tion.

125987350.qxp 2007-01-09 15:02 Page 18

care and cleaning electrolux 19

GB

Proceed as follows:

• Open the small door at the lower part
of the cabinet

• Turn the yellow stop upwards

• Pull out the reservoir

• Open the small cover and let water
flow down

• Close the small cover and re-insert
correctly the reservoir

• Push it until it clicks and turn the yel­low stop downwards to lock firmly it

• Close the small door and press the
START/PAUSE button again to allow
the programme to continue.

The reservoir must be re-inserted cor­rectly. If this is not done the pilot light
Empty Tank comes on during next dry­ing and the programme stops, leaving
the laundry damp. The buzzer will
sound for 1 minute.

After emptying and inserting the reser­voir the START-button has to be
depressed again to allow the pro­gramme to continue.

Handy tip:

The condensed water may
be used in a steam iron or to top up a
battery, etc. In this case it must be fil­tered (e.g. through a coffee filter)).

Cleaning the air intake grille
Using a vacuum cleaner remove the

fluff from the air intake grille at the back
of the appliance.

Cleaning the drum

When your laundry does not reach the
desired degree of dryness, in other
words, when it turns out either too dry
or too damp, we advise you to clean
the inside of the drum with a cloth
soaked with vinegar.

This will eliminate the slight patina that
has formed in the drum (due to
residues of detergent and softeners
used in the washing, and to the lime
contained in the water), which prevents
the probes from detecting the correct
degree of dryness.

125987350.qxp 2007-01-09 15:02 Page 19

20 electrolux something not working

Something not working

Certain problems are due to lack of simple maintenance or oversights, which can be
solved easily without calling out an engineer. Before contacting your local Service
Centre, please carry out the checks listed below.

During machine operation it is possible that the red Start/Pause pilot light flashes to
indicate that the machine is not working.

Once the problem has been eliminated, press the

Start/Pause

button to restart the
programme. If after all checks, the problem persists, contact your local Service
Centre.

Malfunction Possible cause Solution

Dryer does not

work.

● Mains plug is not plugged in

or fuse is not working
correctly.

● Loading door is open.

● Have you pressed the START/

PAUSE button?

● Plug in at mains socket. Check fuse

in fuse box (domestic installation).

● Close loading door.

● Press the START/PAUSE button

again.

Drying results
unsatisfactory.

● Wrong programme selected.

● Lint filter clogged.

● Heat exchanger clogged with lint.

● Incorrect volume of laundry.

● Ventilation slots in base area

covered up.

●Residue on inside surface of

drum or drum ribs.

●Conductance of water at

installation site differs from

● Select a different programme the next

time you dry (see “Overview of
programmes” section).

● Clean lint filter.

● Clean heat exchanger.

● Observe recommended loading

volumes.

● Uncover ventilation slots in

base area.

● Clean inside surface of drum and

drum ribs

● Re-programme standard setting for

degree of drying

Loading door
does not close.

● Fine strainer not in place

and/or large mesh filter not
locked in place.

● Install fine strainer and/or

snap large mesh filter into
place.

125987350.qxp 2007-01-09 15:02 Page 20

GB

something not working electrolux 21

Malfunction Possible cause Solution

When pressing a button,
the corresponding button
flashes several times.

● Washing protection.

After the start of the pro­gramme, the option can no
longer be set.

● Turn the programme knob

to OFF. Set the
programme again

Programme inactive,

Empty Tank

light illumina-

ted.:

● Condensate tank is full.

● Empty condensate tank,

then start programme with
START/PAUSE button.

Drying cycle ends shortly
after programme starts.
END light illuminated.

● Not enough washing

loaded
or washing loaded is too
dry for selected program­me.

● Select time programme or

higher drying level (e.g.
EXTRA DRY instead of
CUPBOARD).

Drying cycle lasts an
unusually long time.
Note:
After around 5 hours the
drying cycle ends automa­tically (see „Drying cycle
complete“)

● Lint filter clogged.

● Heat exchanger clogged

with lint.

● DELICATE button

pressed and load volume

too big.

● Load volume too big.

● Laundry insufficiently

predrained.

● Clean lint filter

● Clean heat exchanger.

● DELICATE is only suitable

for use with loads of up to
3 kg!

● Reduce load volume.

● Laundry must be

adequately pre-drained.

125987350.qxp 2007-01-09 15:02 Page 21

If you are unable to identify or solve the
problem, contact our service centre.
Before telephoning, make a note of the
model, serial number and purchase date
of your machine: the Service Centre will
require this information.

1206

IMPORTANT: if you call out an engineer to a fault listed
below, or to repair a fault caused by incorrect use or
installation, a charge will be made even if the appliance is
under guarantee.

22 electrolux something not working

125987350.qxp 2007-01-09 15:02 Page 22

technical data electrolux 23

Technical data

This appliance conforms with the following EU Directives:
– 73/23/EEC dated 19.02.1973 Low Voltage Directive
– 89/336/EEC dated 03.05.1989 EMC Directive inclusive of
Amending
Directive 92/31/EEC
– 93/68/EEC dated 22.07.1993 CE Marking Directive

GB

Dimensions

Width
Height
Depth

60 cm
85 cm
58 cm

Electrical connection Voltage

- Overall power - Fuse

Information on the electrical connection is
given on the rating plate on the inner edge of
the appliance door

Depth with loading door
open

109 cm

Maximum Load

Cotton

Synthetics

7 kg

3 kg

Use

Domestic

+ 5°C + 35°C

125987350.qxp 2007-01-09 15:02 Page 23

The consumption values have been
established under standard conditions.

They may deviate when the machine is
operated in domestic circumstances.

24 electrolux consumption values

1)

Max Cottons load: 7 kg

2)

Max Synthetics load: 3 kg

Consumption values

Programme

Programme

duration

(in minutes)

Energy

consumption

(in kWh)

Revolutions

per

minute

Cottons Cupboard

1)

125 3,92 1000

Cottons Iron

1)

96 3,05 1000

Cottons Cupboard

1)

110 3,39 1400

Cottons Iron

1)

85 2,5 1400

Synthetics Cupboard

2)

55 1,45 1200

125987350.qxp 2007-01-09 15:02 Page 24

installation electrolux 25

Installation

Unpacking

Slide out the polythene bag with the
polystyrene stuffing before using the

appliance Pull off adhesive strips from
inside machine on top of drum.

Should the appliance be moved, it must
be transported vertically

.

The appliance must not be installed
behind a lockable door, a sliding door a
door with a hinge on the opposite side
to that of the appliance.

Positioning

It is recommended that, for your
convenience, the machine is positioned
close to your washing machine.

The tumble dryer must be installed in a
clean place, where dirt does not build up.

Air must be able to circulate freely all
round the appliance. Do not obstruct the
front ventilation grille or the air intake
grilles at the back of the machine.

To keep vibration and noise to a

minimum when the dryer is in use, it
should be placed on a firm, level surface.

Once in its permanent operating position,
check that the dryer is absolutely level
with the aid of a spirit level. If it is not,
raise or lower the feet until it is.

The feet must never be removed. Do not
restrict the floor clearance through
deeppile carpets, strips of wood or

similar. This might cause heat build-up
which would interfere with the operation
of the appliance.

Important

The hot air emitted by the tumble dryer
can reach temperatures of up to 60°C.
The appliance must therefore not be
installed on floors which are not resistant
to high temperatures.

When operating the tumble dryer, the
room temperature must not be lower than
+5°C and higher than +35°C, as it may
affect the performance of the appliance.

Stacking kit

A special stacking kit is available through
your dealer, to enable the mounting of
the dyer on top of a front loading
washing machine with cover’s depth
between 48 and 60 cm.

Read carefully the instructions supplied
with the kit.

GB

125987350.qxp 2007-01-09 15:02 Page 25

26 electrolux installation

Door reversal

To make it easier to load or unload the
laundry the door can be reversed.

Reversing the door is not possible if after
this operation the appliance result
installed behind a door with a hinge on
the opposite side to that of the
appliance.
This operation must be carried out by
qualified personnel.
Please contact the nearest Service
Centre.

Electrical connection

Any electrical work required to install this
appliance should be carried out by a
qualified electrician or competent
person.

WARNING: THIS APPLIANCE MUST
BE EARTHED.

The manufacturer declines any liability
should this safety measure not be
observed.

Before switching on, make sure the
electricity supply voltage is the same as
that indicated on the appliance’s rating
plate.

The appliance is supplied with a 13amp
plug fitted.

In the event of having to change the fuse
in the plug supplied, a 13amp ASTA
approved (BS1362) fuse must be used.

Should the plug need to be replaced for
any reason, proceed as described
below.

The wires in the mains lead are coloured
in accordance with the following code:

Green and Yellow - Earth
Blue - Neutral
Brown - Live

GREEN & YELLOW

BROWN

CORD CLAMP

BLUE

13A

P1041

E

N

L

125987350.qxp 2007-01-09 15:02 Page 26

environment concerns electrolux 27

Environment concerns

Packaging materials

The materials marked with the symbol

are recyclable.
>PE<=polyethylene
>PS<=polystyrene
>PP<=polypropylene
This means that they can be recycled by

disposing of them properly in
appropriate collection containers.

Old machine

Use authorised disposal sites for your
old appliance. Help to keep your country
tidy!

The symbol on the product or on its
packaging indicates that this product
may not be treated as household waste.
Instead it shall be handed over to the
applicable collection point for the
recycling of electrical and electronic
equipment. By ensuring this product is
disposed of correctly, you will help
prevent potential negative consequences
for the environment and human health,
which could otherwise be caused by
inappropriate waste handling of this
product. For more detailed information
about recycling of this product, please
contact your local city office, your
household waste disposal service or the
shop where you purchased the product.

Ecological hints

To save energy and to help protect the
environment,we recommend that you
follow these hints:

• Try to load the maximum capacity of
the machineas small loads are
uneconomical.

• Always load well spun laundry. The
higher the spinspeed, the lower the
electricity consumption andthe shorter
the drying times.

• Do not over-dry laundry, this avoids
creasing andsaves energy.

Select the drying programme
according to thetype of laundry and
the required degree of dryness.

• To utilize the maximum load, laundry
which is tobe dried ready to put away
(store dry) can be driedtogether with
items to be ironed. To do this,
selectthe programme for iron-dry,
remove the iron-dryitems at the end of
the programme and thenfinish-dry the
rest of the load.

• Clean the filters regularly to avoid
excessive dryingtimes and high
electricity consumption.

• Ventilate the room well. The room
temperatureshould not exceed +35°C
during drying.

GB

125987350.qxp 2007-01-09 15:02 Page 27

28 electrolux guarantee conditions

Belgium

DECLARATION OF GUARANTEE TERMS.

Our appliances are produced with the greatest of
care. However, a defect may still occur. Our
consumer services department will repair this
upon request, either during or after the guarantee
period. The service life of the appliance will not,
however, be reduced as a result.

This declaration of guarantee terms is based on
European Union Directive 99/44/EC and the
provisions of the Civil Code. The statutory rights that
the consumer has under this legislation are not
affected by this declaration of guarantee terms.
This declaration does not affect the vendor's
statutory warranty to the end user. The appliance
is guaranteed within the context of and in
adherence with the following terms:

1. In accordance with provisions laid down in

paragraphs 2 to 15, we will remedy free of charge
any defect that occurs within 24 months from the
date the appliance is delivered to the first end user.
These guarantee terms do not apply in the event of
use for professional or equivalent purposes.

2. Performing the guarantee means that the

appliance is returned to the condition it was in
before the defect occurred. Defective parts are
replaced or repaired. Parts replaced free of
charge become our property.

3. So as to avoid more severe damage, the defect

must be brought to our attention immediately.

4. Applying the guarantee is subject to the

consumer providing proof of purchase showing
the purchase and/or delivery date.

5. The guarantee will not apply if damage caused to

delicate parts, such as glass (vitreous ceramic),
synthetic materials and rubber, is the result of
inappropriate use.

6. The guarantee cannot be called on for minor

faults that do not affect the value or the overall
reliability of the appliance.

7. The statutory warranty does not apply when

defects are caused by:
– a chemical or electrochemical reaction

caused by water,
– abnormal environmental conditions in general,
– unsuitable operating conditions,
– contact with harsh substances.

8. The guarantee does not apply to defects due to

transport which have occurred outside of our
responsibility. Nor will the guarantee cover those
caused by inadequate installation or assembly, lack
of maintenance or failure to respect the

European guarantee

This appliance is guaranteed by
Electrolux, in each of the countries
listed in the following page, for the
period specified in the appliance
guarantee or otherwise by law. If you
move from one of these countries to
another of these countries the
appliance guarantee will move with you
subject to the following qualifications:

• The appliance guarantee starts from

the date you first purchased the
appliance which will be evidenced
by production of a valid purchase
document issued by seller of the
appliance.

• The appliance guarantee is for the

same period and to the same
extent for labour and parts as exists
in your country of residence for this
particular model or range of
appliances.

• The appliance guarantee is personal

to the original purchaser of the
appliance and cannot be transferred
to another user.

• The appliance is installed and used

in accordance with instructions
issued by Electrolux and is only
used within the home, i.e. is not
used for commercial purposes.

• The appliance is installed in

accordance with all relevant
regulations in force within your new
country of residence.

The provisions of this European
Guarantee do not affect any of the rights
granted to you by law.

125987350.qxp 2007-01-09 15:02 Page 28

guarantee/customer service electrolux 29

GB

assembly instructions or directions for use.

9. Defects that result from repairs or measures
carried out by people who are not qualified or
expert or defects that result from the addition of
non-original ccessories or spare parts are not
covered by the guarantee.

10.Appliances that are easy to transport may be
delivered or sent to the consumer services
department. Home repairs are only anticipated for
bulky appliances or built-in appliances.

11. If the appliances are built-in, built-under,
fixed or suspended in such a way that removing
and replacing them in the place where they are
fitted takes more than half an hour, the costs
that result therefrom will be charged for. Connected
damage caused by these removal and replacement
operations will be the responsibility of the user.

12. If, during the guarantee period, repairing the
same defect repeatedly is not conclusive, or if the
repair costs are considered disproportionate, in
agreement with the consumer, the defective
appliance may be replaced with another appliance of
the same value. In this event, we reserve the right to
ask for a financial contribution calculated according
to the length of time it has been used.

13. A repair under guarantee does not mean that
the normal guarantee period will be extended nor
that a new guarantee period begins.

14.We give a twelve month guarantee for
repairs, limited to the same defect.

15. Except in the event where liability is legally
imposed, this declaration of guarantee terms excludes
any compensation for damage outside the appliance
for which the consumer wishes to assert his rights.
In the event of legally admitted liability,
compensation will not exceed the purchase
price paid for the appliance. These guarantee
terms are only valid for appliances purchased
and used in Belgium. For exported appliances,
the user must first make sure that they satisfy
the technical conditions (e.g.: voltage,
frequency, installation instructions, type of gas,
etc.) for the country concerned and that they can
withstand the local climatic and environmental
conditions.

For appliances purchased abroad, the user must first
ensure that they meet the qualifications required in
Belgium. Non-essential or requested adjustments
are not covered by the guarantee and are not
possible in all cases. Our consumer services
department is always at your disposal, even after the
guarantee period has expired.

Address for our consumer services
department

:

Belgium

Electrolux Home Consumer 02/ 02/

Products Belgium services 363.04. 363.04.0

44 0

ELECTROLUX 02/
SERVICE 363.04.6

0
Bergensesteenweg 719
1502 Lembeek
E-mail: [e-mail]

Luxembourg

Electrolux Home Consumer 00352 00352

Luxembourg services 42 431- 42 431-

1 360

ELECTROLUX
HOME PRODUCTS
Rue de Bitbourg. 7
L-1273 Luxembourg- Hamm

E-mail: consumer-service.luxembourg@electrolux.

125987350.qxp 2007-01-09 15:02 Page 29

125987350.qxp 2007-01-09 15:02 Page 30

www.electrolux.com

www.electrolux.co.uk

125 987 350 -00- 09012007

125987350.qxp 2007-01-09 15:02 Page 31
