SCUDO SUSPENSION
D41038-
base number
1.To build a product code in our configurator select the specify button on the base model #
product page
2. To build a manual product code on this datasheet choose from the options listed below
in blue font and add the suffix to the base model #
GENERAL
Division: Design
Series: Scudo
Mounting Type: Suspension
Mounting Location: Ceiling
Subcategory: Pendant
Brand: Icone
PHYSICAL
Shape: Oblong
Diameter (mm): 650
Diameter (in): 25 9⁄
Max. Overall Height (mm): 1200
Max. Overall Height (in): 47 1⁄
Light Distribution: Direct
Fixture Finish: WHI / BLK / GRY / GLF / SLF
Fixture Material: Aluminum
ELECTRICAL
Lamp Type: LED
Total Output Wattage (W): 40
Dimming: Electronic Low Voltage Dimming
Input Voltage (V): 120Vac Direct Line
LED
Number of LEDs: 9
Color Temperature (°K): 3000
Nominal Lumen (lm): 3150
CRI: >90 CRI
Lamp Life (hrs): 50000
RATINGS AND CERTIFICATIONS
Certified By: Certified for North American Standards
IP rating: IP20
Finish
Options
16
4
PROJECT
TYPE
SPECIFIER
QUANTITY
DATE
Zaneen Group Inc. © 2022, T 1800-388-3382, F 416-247-9319, www.zaneen.com
Available for International specifications by adding ‘INT’ at the end of the existing Model #. For assistance on ‘custom’ specifications, contact zteam@zaneen.com.
In a constant effort to supply the best product, we reserve the right to change specifications or materials without notice. The most recent specification sheets are found at zaneen.com
Page 1/4
May 2, 2022, 4:14 am
SCUDO SUSPENSION
D41038-
PROJECT
TYPE
SPECIFIER
QUANTITY
DATE
Zaneen Group Inc. © 2022, T 1800-388-3382, F 416-247-9319, www.zaneen.com
Available for International specifications by adding ‘INT’ at the end of the existing Model #. For assistance on ‘custom’ specifications, contact zteam@zaneen.com.
In a constant effort to supply the best product, we reserve the right to change specifications or materials without notice. The most recent specification sheets are found at zaneen.com
Page 2/4
May 2, 2022, 4:14 am
PROJECT
TYPE
SPECIFIER
SCUDO SUSPENSION
COLOR FINISH CHART
White - WHI Black - BLK Gray - GRY Gold Leaf - GLF Silver Leaf - SLF
QUANTITY
DATE
Digital: Not all screens are calibrated the same, and therefore, colors will appear differently between screens.
Physical: When texture is involved, there will be variations in color, character and tone within a product series and between product families.
