Available Sizes and / or Lamping
Linea - C eiling - [D9-2036] -- 30cm / 11 3/4" x 30cm / 11 3/4" - 1x100W - T3Q/3 (79mm) Halogen - Brushed (Satin) Aluminum
Linea - C eiling - [D9-2037] -- 37cm / 14 1/2" x 37cm / 14 1/2" - 1x100W - T3Q/3 (79mm) Halogen - Brushed (Satin) Aluminum
Certified by CSA certified, listed to UL & CSA
Standards
Available for Internat ional specifications by addin g 'INT' at th e end of the existing Model
# Int ern ational spec sheets are available upon requ est
Exact Measurements: Metric
Model: D9-2053
Installation: Surface - Ceiling
Fixture Finish: Black Satin Aluminum
Diffuser: White Glass
Lamp Base: RSC (double ended)
Lamp Type: T3Q/3 (79mm) Halogen
Number Of
Lamps:
1
Max Wattage
Per Lamp:
100W
Input Voltage: 120Vac
IP Rating: IP20
Width: 30cm / 11 3/4"
Length: 30cm / 11 3/4"
Height: 7.6cm / 3"
Extension: 7.6cm / 3"
ADA Co mpliant: Yes
Overstock: Yes
Additional Details
<p style="color:#F 00">Overstock Item: C ontact
customerservice@zaneen.com for stock level and pricing</p>
Linea - Ceiling
Model No: D9-2053
Date:
Project:
Fixture Type:
Specifier/Rep:
30 Tycos Dr. Toronto, ON Canada M6B 1V9 PH: 800.388.3382 / 416.247.9221 FAX: 416.247.9319 www.zaneen.com, tech@zaneen.com Page 1 of 2
Linea - C eiling - [D9-2038] -- 42cm / 16 1/2" x 42cm / 16 1/2" - 1x150W - T3Q (119mm) Halogen - Brushed (Satin) Aluminum
Linea - C eiling - [D9-2053] -- 30cm / 11 3/4" x 30cm / 11 3/4" - 1x100W - T3Q/3 (79mm) Halogen - Black Satin Aluminum
Linea - C eiling - [D9-2067] -- 50cm / 19 3/4" x 50cm / 19 3/4" - 1x40W + 22W - 2GX13 - T5 Circline - Brushed (Satin) Aluminum
Linea - C eiling - [D9-2068] -- 50cm / 19 3/4" x 50cm / 19 3/4" - 1x40W + 22W - 2GX13 - T5 Circline - White
Linea - C eiling - [D9-2072] -- 61cm / 24" x 20cm / 7 4/5" - 2x24W - G5 - T5 Fluorescent - Brushed (Satin) Aluminum
Linea - C eiling - [D9-2073] -- 91. 1cm / 35 7/8" x 20cm / 7 4/5" - 2x39W - G5 - T5 Fluorescent - Brushed (Satin) Aluminum
Linea - C eiling - [D9-2141] -- 37cm / 14 9/16" - 1x22w - 2GX13 - T5 Circline - Brushed (Satin) Aluminum
Linea - Ceiling
Model No: D9-2053
Date:
Project:
Fixture Type:
Specifier/Rep:
30 Tycos Dr. Toronto, ON Canada M6B 1V9 PH: 800.388.3382 / 416.247.9221 FAX: 416.247.9319 www.zaneen.com, tech@zaneen.com Page 2 of 2
