FOLIO SUSPENSION
D61018-
base number
1.To build a product code in our configurator select the specify button on the base model #
product page
2. To build a manual product code on this datasheet choose from the options listed below
in blue font and add the suffix to the base model #
GENERAL
Division: Design
Series: Folio
Mounting Type: Suspension
Mounting Location: Ceiling
Subcategory: Ambient
Brand: Linea Zero
PHYSICAL
Shape: Cylinder
Diameter (mm): 400
Diameter (in): 15 3⁄
Height (mm): 320
Height (in): 12 5⁄
Max. Overall Height (mm): 1820
Max. Overall Height (in): 71 5⁄
Light Distribution: Direct / Indirect
Diffuser: Polilux™ Shade - See Finish Options
Fixture Finish: WHI / BLK / SIL / NGD / COP / PKM
Fixture Material: Polilux™/ Metal holder
Cable Details: Cable length 59" - Transparent
ELECTRICAL
Number of Lamps: 1
Lamp Type: LED Retrofit
Bulb Included: Bulb Not Included
Max. Wattage Per Lamp (W): 7
Lamp Base: E26
Input Voltage (V): 120
Upon Request: 277Vac / GU24
RATINGS AND CERTIFICATIONS
Certified By: Certified for North American Standards
IP rating: IP20
Finish
Options
4
8
8
PROJECT
TYPE
SPECIFIER
QUANTITY
DATE
Zaneen Group Inc. © 2022, T 1800-388-3382, F 416-247-9319, www.zaneen.com
Available for International specifications by adding ‘INT’ at the end of the existing Model #. For assistance on ‘custom’ specifications, contact zteam@zaneen.com.
In a constant effort to supply the best product, we reserve the right to change specifications or materials without notice. The most recent specification sheets are found at zaneen.com
Page 1/4
May 2, 2022, 5:32 am
FOLIO SUSPENSION
D61018-
PROJECT
TYPE
SPECIFIER
QUANTITY
DATE
Zaneen Group Inc. © 2022, T 1800-388-3382, F 416-247-9319, www.zaneen.com
Available for International specifications by adding ‘INT’ at the end of the existing Model #. For assistance on ‘custom’ specifications, contact zteam@zaneen.com.
In a constant effort to supply the best product, we reserve the right to change specifications or materials without notice. The most recent specification sheets are found at zaneen.com
Page 2/4
May 2, 2022, 5:32 am
PROJECT
TYPE
SPECIFIER
FOLIO SUSPENSION
COLOR FINISH CHART
White - WHI Silver - SIL New Gold - NGD Copper - COP Pink Metal - PKM
QUANTITY
DATE
Digital: Not all screens are calibrated the same, and therefore, colors will appear differently between screens.
Physical: When texture is involved, there will be variations in color, character and tone within a product series and between product families.
Zaneen Group Inc. © 2022, T 1800-388-3382, F 416-247-9319, www.zaneen.com
Available for International specifications by adding ‘INT’ at the end of the existing Model #. For assistance on ‘custom’ specifications, contact zteam@zaneen.com.
In a constant effort to supply the best product, we reserve the right to change specifications or materials without notice. The most recent specification sheets are found at zaneen.com
Page 3/4
May 2, 2022, 5:32 am
FOLIO SUSPENSION
PROJECT
TYPE
SPECIFIER
QUANTITY
DATE
Zaneen Group Inc. © 2022, T 1800-388-3382, F 416-247-9319, www.zaneen.com Page 4/4
Available for International specifications by adding ‘INT’ at the end of the existing Model #. For assistance on ‘custom’ specifications, contact zteam@zaneen.com.
In a constant effort to supply the best product, we reserve the right to change specifications or materials without notice. The most recent specification sheets are found at zaneen.com May 2, 2022, 5:32 am
