ZANEEN design ZN10111 Specifications

DAU SINGLE SURFACE
D92126R9-
base number
1.To build a product code in our configurator select the specify button on the base model # product page
2. To build a manual product code on this datasheet choose from the options listed below in blue font and add the suffix to the base model #
GENERAL
Division: Design Series: Dau Subseries: Dau Single Mounting Type: Surface Mounting Location: Ceiling Subcategory: Downlight Brand: Milan
PHYSICAL
Shape: Cube Length (mm): 80 Length (in): 3 1⁄ Width (mm): 80 Width (in): 3 1⁄ Height (mm): 91 Height (in): 3 9⁄ Light Distribution: Direct
Fixture Finish: BAL / MWL / BSL
Fixture Material: Extruded Aluminum
ELECTRICAL
Lamp Type: LED Input Wattage (W): 10 Total Output Wattage (W): 9.3 Dimming: Tri-Mode (Non-Dimming and Phase Dimming (120Vac only) and 0-10V
Dimming) Driver Included: No Driver Location: Remote Driver Type: Constant Current Input Voltage (V): 120 / 277 Constant Current (MA): 350
LED
Number of LEDs: 1 Color Temperature (°K): 3000 Max. Delivered Lumen (lm): 956 CRI: >90 CRI Lamp Life (hrs): 50000
RATINGS AND CERTIFICATIONS
Certified By: Certified for North American Standards IP rating: IP20
8
8
16
PROJECT
TYPE
SPECIFIER
QUANTITY
DATE
Zaneen Group Inc. © 2022, T 1800-388-3382, F 416-247-9319, www.zaneen.com
Available for International specifications by adding ‘INT’ at the end of the existing Model #. For assistance on ‘custom’ specifications, contact zteam@zaneen.com. In a constant effort to supply the best product, we reserve the right to change specifications or materials without notice. The most recent specification sheets are found at zaneen.com
Page 1/4
May 2, 2022, 2:59 am
DAU SINGLE SURFACE
D92126R9-
PROJECT
TYPE
SPECIFIER
QUANTITY
DATE
Zaneen Group Inc. © 2022, T 1800-388-3382, F 416-247-9319, www.zaneen.com
Available for International specifications by adding ‘INT’ at the end of the existing Model #. For assistance on ‘custom’ specifications, contact zteam@zaneen.com. In a constant effort to supply the best product, we reserve the right to change specifications or materials without notice. The most recent specification sheets are found at zaneen.com
Page 2/4
May 2, 2022, 2:59 am
PROJECT
TYPE
SPECIFIER
DAU SINGLE SURFACE
COLOR FINISH CHART
Brushed Aluminum - BAL Matte White Lacquer - MWL Black Satin Aluminum - BSL
QUANTITY
DATE
Digital: Not all screens are calibrated the same, and therefore, colors will appear differently between screens. Physical: When texture is involved, there will be variations in color, character and tone within a product series and between product families.
Zaneen Group Inc. © 2022, T 1800-388-3382, F 416-247-9319, www.zaneen.com
Available for International specifications by adding ‘INT’ at the end of the existing Model #. For assistance on ‘custom’ specifications, contact zteam@zaneen.com. In a constant effort to supply the best product, we reserve the right to change specifications or materials without notice. The most recent specification sheets are found at zaneen.com
Page 3/4
May 2, 2022, 2:59 am
DAU SINGLE SURFACE
PROJECT
TYPE
SPECIFIER
QUANTITY
DATE
Zaneen Group Inc. © 2022, T 1800-388-3382, F 416-247-9319, www.zaneen.com Page 4/4
Available for International specifications by adding ‘INT’ at the end of the existing Model #. For assistance on ‘custom’ specifications, contact zteam@zaneen.com.
In a constant effort to supply the best product, we reserve the right to change specifications or materials without notice. The most recent specification sheets are found at zaneen.com May 2, 2022, 2:59 am
