GRADIMINI SURFACE
D32021-
base number
1.To build a product code in our configurator select the specify button on the base model #
product page
2. To build a manual product code on this datasheet choose from the options listed below
in blue font and add the suffix to the base model #
GENERAL
Division: Design
Series: Gradimini
Mounting Type: Surface
Mounting Location: Ceiling
Subcategory: Ambient
Brand: Cini & Nils
PHYSICAL
Shape: Abstract
Length (mm): 220
Length (in): 8 11⁄
Height (mm): 260
Height (in): 10 1⁄
Extension (mm): 255
Extension (in): 10 1⁄
Light Distribution: Indirect
Weight (kg): 0.6
Weight (lbs): 1.32
Diffuser: Opal / Transparent & Opal / Transparent / Screen
Fixture Finish: CHR / SNI
Fixture Material: Metal
ELECTRICAL
Lamp Type: LED
Total Output Wattage (W): 12
Dimming: Non-Dimming / Phase Dimming (120vac Only)
Driver Included: No
Driver Location: Remote
Driver Type: Constant Current - Universal
Driver Class: Class 2
Input Voltage (V): 120 / 277
Constant Current (MA): 600
LED
Number of LEDs: 2
Color Temperature (°K): 2800
Nominal Lumen (lm): 1500
CRI: >80 CRI
Lamp Life (hrs): 50000
RATINGS AND CERTIFICATIONS
Certified By: Certified for North American Standards
IP rating: IP20
Finish
Options
16
16
16
PROJECT
TYPE
SPECIFIER
QUANTITY
DATE
Zaneen Group Inc. © 2022, T 1800-388-3382, F 416-247-9319, www.zaneen.com
Available for International specifications by adding ‘INT’ at the end of the existing Model #. For assistance on ‘custom’ specifications, contact zteam@zaneen.com.
In a constant effort to supply the best product, we reserve the right to change specifications or materials without notice. The most recent specification sheets are found at zaneen.com
Page 1/4
May 2, 2022, 5:52 am
GRADIMINI SURFACE
D32021-
PROJECT
TYPE
SPECIFIER
QUANTITY
DATE
Zaneen Group Inc. © 2022, T 1800-388-3382, F 416-247-9319, www.zaneen.com
Available for International specifications by adding ‘INT’ at the end of the existing Model #. For assistance on ‘custom’ specifications, contact zteam@zaneen.com.
In a constant effort to supply the best product, we reserve the right to change specifications or materials without notice. The most recent specification sheets are found at zaneen.com
Page 2/4
May 2, 2022, 5:52 am
GRADIMINI SURFACE
COLOR FINISH CHART
Chrome - CHR Satin Nickel - SNI
PROJECT
TYPE
SPECIFIER
QUANTITY
DATE
Digital: Not all screens are calibrated the same, and therefore, colors will appear differently between screens.
Physical: When texture is involved, there will be variations in color, character and tone within a product series and between product families.
Zaneen Group Inc. © 2022, T 1800-388-3382, F 416-247-9319, www.zaneen.com
Available for International specifications by adding ‘INT’ at the end of the existing Model #. For assistance on ‘custom’ specifications, contact zteam@zaneen.com.
In a constant effort to supply the best product, we reserve the right to change specifications or materials without notice. The most recent specification sheets are found at zaneen.com
Page 3/4
May 2, 2022, 5:52 am
GRADIMINI SURFACE
PROJECT
TYPE
SPECIFIER
QUANTITY
DATE
Zaneen Group Inc. © 2022, T 1800-388-3382, F 416-247-9319, www.zaneen.com Page 4/4
Available for International specifications by adding ‘INT’ at the end of the existing Model #. For assistance on ‘custom’ specifications, contact zteam@zaneen.com.
In a constant effort to supply the best product, we reserve the right to change specifications or materials without notice. The most recent specification sheets are found at zaneen.com May 2, 2022, 5:52 am
