EMY SUSPENSION
D81663-
base number
1.To build a product code in our configurator select the specify button on the base model #
product page
2. To build a manual product code on this datasheet choose from the options listed below
in blue font and add the suffix to the base model #
GENERAL
Division: Design
Series: Girls
Subseries: Emy
Mounting Type: Suspension
Mounting Location: Ceiling
Subcategory: Pendant
Brand: Panzeri
PHYSICAL
Shape: Round
Diameter (mm): 160
Diameter (in): 6 5⁄
Height (mm): 122
Height (in): 4 13⁄
Max. Overall Height (mm): 3122
Max. Overall Height (in): 122 15⁄
Light Distribution: Direct
Weight (kg): 0.67
Weight (lbs): 1.47
Diffuser: Glass - See Finish Options
Fixture Finish: CRY / STE / AMB / BRZ / TOB / GRN
Fixture Material: Glass / Aluminum
Cable Details: 3000mm / 118 1/8" Cable
ELECTRICAL
Number of Lamps: 1
Lamp Type: LED Retrofit
Lamp Shape: T4
Bulb Included: Bulb Not Included
Max. Wattage Per Lamp (W): 4
Lamp Base: G9
Input Voltage (V): 120
RATINGS AND CERTIFICATIONS
Certified By: Certified for North American Standards
IP rating: IP40
GL_D8 Ely_Emy_Evy
16
16
16
PROJECT
TYPE
SPECIFIER
QUANTITY
DATE
Zaneen Group Inc. © 2022, T 1800-388-3382, F 416-247-9319, www.zaneen.com
Available for International specifications by adding ‘INT’ at the end of the existing Model #. For assistance on ‘custom’ specifications, contact zteam@zaneen.com.
In a constant effort to supply the best product, we reserve the right to change specifications or materials without notice. The most recent specification sheets are found at zaneen.com
Page 1/4
May 2, 2022, 3:36 am
EMY SUSPENSION
D81663-
PROJECT
TYPE
SPECIFIER
QUANTITY
DATE
Zaneen Group Inc. © 2022, T 1800-388-3382, F 416-247-9319, www.zaneen.com
Available for International specifications by adding ‘INT’ at the end of the existing Model #. For assistance on ‘custom’ specifications, contact zteam@zaneen.com.
In a constant effort to supply the best product, we reserve the right to change specifications or materials without notice. The most recent specification sheets are found at zaneen.com
Page 2/4
May 2, 2022, 3:36 am
PROJECT
TYPE
SPECIFIER
EMY SUSPENSION
COLOR FINISH CHART
Crystal - CRY Steel - STE Bronze - BRZ Tobacco - TOB Green - GRN
QUANTITY
DATE
Digital: Not all screens are calibrated the same, and therefore, colors will appear differently between screens.
Physical: When texture is involved, there will be variations in color, character and tone within a product series and between product families.
