LED120 SURFACE
D73027-
base number
1.To build a product code in our configurator select the specify button on the base model #
product page
2. To build a manual product code on this datasheet choose from the options listed below
in blue font and add the suffix to the base model #
GENERAL
Division: Design
Series: Woodlin
Subseries: LED120
Mounting Type: Surface
Mounting Location: Wall
Subcategory: Profile
Brand: Tunto
PHYSICAL
Shape: Rectangle
Length (mm): 200
Length (in): 7 7⁄
Width (mm): 40
Width (in): 1 9⁄
Height (mm): 120
Height (in): 4 3⁄
Extension (mm): 40
Extension (in): 1 9⁄
Light Distribution: Direct / Indirect
Diffuser: Opal
Fixture Finish: WAL / ASH / OAK / BLK / WHI
Fixture Material: Wood
ELECTRICAL
Lamp Type: LED
Input Wattage (W): 6
Total Output Wattage (W): 4.5
Dimming: Tri-Mode (Non-Dimming and Phase Dimming (120Vac only) and 0-10V
Dimming)
Driver Included: Yes
Driver Location: Remote
Driver Type: Constant Current - Universal
Driver Class: Class 2
Housing: ENCP3
Input Voltage (V): 120 / 277
Constant Current (MA): 500
LED
Color Temperature (°K): 2700 / 3000 / 4000
Max. Delivered Lumen (lm): 300
CRI: >93 CRI
Lamp Life (hrs): 50000
RATINGS AND CERTIFICATIONS
Certified By: Certified for North American Standards
IP rating: IP20
Color
Temperature
8
16
4
-
Finish
Options
16
PROJECT
TYPE
SPECIFIER
QUANTITY
DATE
Zaneen Group Inc. © 2022, T 1800-388-3382, F 416-247-9319, www.zaneen.com
Available for International specifications by adding ‘INT’ at the end of the existing Model #. For assistance on ‘custom’ specifications, contact zteam@zaneen.com.
In a constant effort to supply the best product, we reserve the right to change specifications or materials without notice. The most recent specification sheets are found at zaneen.com
