ZAGG ZKPIB User Manual

Rugged Book

Keyboard Instructions

See the important Health and Safety information on page 6 before using this product.

*WARRANTY REGISTRATION

Your ZAGG® Rugged Book comes with a one-year manufacturer’s warranty. In order to activate the warranty,
you must register your Rugged Book as well as keep your purchase receipt. If you purchased your ZAGG
Rugged Book from ZAGG.com, ZAGG® has already registered it and has a copy of your proof of purchase.

NEED MORE HELP? PLEASE SEE OUR FAQ SECTION AT: www.ZAGG.com/faq

INSERTING/REMOVING YOUR DEVICE

To insert your tablet into the Rugged Book, open the case
at a 90˚ angle to the keyboard. First, separate the keyboard
and case by doing the following. With one hand, grasp the
keyboard at the top right or top left corner. With your other
hand, grasp the corresponding top right or top left corner of
the case and pull directly upwards. This will disengage the
magnets and separate the case and keyboard. Note: Do not
try to pull from the center of the case or the keyboard. This may
put stress on the hinge.

Next, align the camera and the charging port with the
corresponding holes in the case. Set the bottom half of the
device into the cover and apply light pressure. Then snap
the top half of your device into the cover. Check all corners
to make sure they have seated properly.

To connect the case and keyboard, place the case into the
magnetic cradle hinge.

To easily remove your device from the case, separate the
case from the keyboard, and then gently roll the rubber
overmold away from the edges while pressing on the device
from behind. Grasp your device’s exposed side and lift/pull
it away from the Rugged Case.

POWERING ON AND OFF

To turn your Rugged Book on, press the Power button. A
green LED on the battery key will illuminate briefly while the
keyboard powers up. To turn your Rugged Book off, press and
hold the Power button for three seconds. A red LED will flash,
indicating your Rugged Book has turned off.

1

PAIRING YOUR ZAGG RUGGED BOOK

Pairing your Rugged Book with your device is easy. It should
only need to be paired once, using the following directions.
If the connection between your device and Rugged Book is
ever lost, repeat these steps.

1. Access the Bluetooth™ settings on your device.

2. Press and hold the Bluetooth button for three seconds.
A blue LED under the Power key will flash until your
Rugged Book and device are paired.

3. Your device will display “ZAGG Rugged Book” as an
available device. Select this option to complete pairing.

CHARGING

Your Rugged Book features a powerful lithium polymer battery that lasts for up
to two years of normal use between charges*. It comes with a charging cable
you can use to charge your keyboard quickly and conveniently. To charge your
Rugged Book, follow these steps:

1. Plug the micro USB connector into the charging port.

2. Plug the regular USB connector into any USB outlet.

3. A red LED under the Power button will illuminate to indicate your Rugged
Book is charging. Wait until this light turns off, indicating a full charge. It
usually takes 2-4 hours to completely charge your Rugged Book.

4. Remove the micro USB connector and enjoy your Rugged Book for up to
two years before you need to charge it again.

* Normal use is approximately one hour of use per day without the backlit feature. Using the backlit feature will impact

battery life and will require more frequent charging.

CHARGING PORT

2

BATTERY LIFE

As mentioned, the Rugged Book features a powerful, rechargeable battery that
lasts up to two years between charges. To check your Rugged Book’s remaining
battery power press the battery key. The LED indicator will flash one of three ways.

1. Three green flashes indicate 50% or more battery life remaining.

2. Three yellow flashes indicate between 25%-49% battery life remaining.

3. Three red flashes indicate less than 25% battery life remaining. When your
Rugged Book reaches critical battery level, the red LED will flash once
every five minutes.

To help preserve battery life, your Rugged Book will enter sleep mode if left on
and not used for several minutes. To awaken your Rugged Book, press any key. The
Rugged Book’s battery has no memory and may be charged whenever you wish.

SPECIAL FUNCTION KEYS

Your Rugged Book keyboard has been designed with the following special
function keys to give you more control over your device:

HOME – Displays your device’s home screen.

LOCK – Activates and deactivates your device’s sleep mode.

APPS RUNNING – Displays all of the apps currently running on your device.

FN + SEARCH – Opens your device’s search function.

LANGUAGE SYMBOL – Toggles between keyboard languages and emojis (if active on
your device); pressing cmd + spacebar will do the same.

FN + KEYBOARD HIDE/SHOW – Hides or shows your device’s
on-screen keyboard.

PREVIOUS TRACK – Skips to the previous track on your selected playlist.

PLAY/PAUSE – Starts or pauses your current playlist.

NEXT TRACK – Skips to the next track on your current playlist.

MUTE – Mutes your device’s audio.

VOLUME DOWN – Decreases your device’s volume.

VOLUME UP – Increases your device’s volume.

BLUETOOTH

POWER – Turns your Rugged Book keyboard on and off.

™

– Press and hold for three seconds to pair.

3

FN + BATTERY SYMBOL – Indicates remaining battery life.

FN + BACKLIGHT SYMBOL – Activates the backlight feature.

FN + COLOR CHANGE SYMBOL – Changes backlight colors. (7 possible)

NOTE: The backlights will automatically turn off after a couple seconds if not being used. Begin typing again to activate them.

TROUBLESHOOTING

If your device does not respond to your Rugged Book there may be a simple
explanation such as a dead battery or an unsuccessful pairing. Please use the
following to help troubleshoot your situation. If none of the following solve
your issue, then please contact ZAGG Customer Service and one of our trained
professionals will be happy to assist you.

1. Restart your device.

2. Turn your Rugged Book off and back on. You should see the LED illuminate
briefly, if not, charge your Rugged Book.

3. After charging, turn your Rugged Book on. If the LED does not illuminate,
and your keyboard doesn’t operate correctly, please contact ZAGG
customer service.

4. If your Rugged Book cannot establish or maintain a Bluetooth® connection,
reset the Bluetooth® module by charging your keyboard.

5. Forget and re-pair your Rugged Book.

a. Push the Pair buttons on your Rugged Book and watch for the

LED to flash blue.

b. Your device should display “ZAGG Rugged Book” as an available

device. Select it.

c. If your device gives you an error message, repeat the pairing process.

4

For more help:
ZAGG.com/support

For unparalleled scratch protection for your device, we recommend ZAGG’s InvisibleShield

©2005 - 2019 ZAGG Inc All Rights Reserved.
PATENT: zagg.com/patents | NASDAQ: ZAGG | MADE IN CHINA
iPad mini™ is a trademark of Apple, Inc., registered in the US and other countries.
The Bluetooth® word mark and logos are registered trademarks of Bluetooth SIG, Inc.
ZAGG®, InvisibleShield®, and ZAGG Rugged Book™ are trademarks or registered
trademarks of ZAGG Inc.
This Bluetooth keyboard(ZAGG rugged book, FCC ID: QTG-ZKPIB) is compatible
with the iPad/A2133 (FCC ID: BCGA2133).

Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any Interference received, Including Interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception,

to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

•

the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

.

5

Please read the following precautions and operation information before using your
keyboard or any accessories that accompany it. Retain this information for future use.

1. Health warning: Take frequent breaks when using your keyboard. If you

experience any discomfort, pain, tingling, numbness, or burning in your neck,
shoulders, arms, wrists, hands, or any other part of your body, stop using your
keyboard and consult a physician.

2. Use only micro USB chargers in connection with your keyboard.

3. Do not attempt to disassemble, modify, or service the keyboard.

4. Do not crush or puncture your keyboard.

5. Do not allow this product to come into contact with liquids. Clean only with a soft,
dry cloth. Disconnect any cords before cleaning the keyboard.

6. Do not use your keyboard while operating a motorized vehicle or other
equipment.

7. Store and operate your keyboard between 32˚–113˚ F. Keep away from heat
sources and open flame.

8. When you are ready to discard your keyboard, comply with all applicable rules

and regulations regarding disposal. Wherever possible, please act responsibly
and use an approved electronics recycling program.
