rugged book go
Keyboard Instructions
See the important Health and Safety information on page 7 before using this product.
™
*WARRANTY REGISTRATION
Your ZAGG Rugged Book Go comes with a one-year manufacturer’s warranty. In order to activate
the warranty, you must register your Rugged Book Go as well as keep your purchase receipt. If you
purchased your ZAGG Rugged Book Go from ZAGG.com, ZAGG has already registered it and has a
copy of your proof of purchase.
NEED MORE HELP? PLEASE SEE OUR FAQ SECTION AT: www.ZAGG.com/faq
INSERTING/REMOVING YOUR DEVICE
1. Hold your device in landscape mode with the volume control
buttons facing up. Insert the top half of your device at an angle
into the top of the case and apply light pressure to snap it snuggly
into place.
2. At the top of the keyboard, there is a hinged magnetic bar with
two long teeth at either end. At the bottom of the case, you’ll see
two long slots that will fit the teeth on the magnetic hinge bar.
Line the slots up with the teeth and lower the case face down onto
the keyboard. You will feel the powerful magnetic bar engage and
attach the keyboard and case.
3. You can now open the case and adjust the kickstand on the back
to support your tablet at an ideal viewing angle.
4. To easily remove your device from the case, first detach the case
from the keyboard. (See directions below.) Then hold the top of
the case with one hand and press against the back of the case with
the other. Then grasp the exposed side of your device and lift/pull
it away from the cover.
DETACHING THE CASE FROM THE KEYBOARD
Hold one of the top corners of the keyboard in one hand, hold the
corresponding top corner of the case with the other hand, and pull the
case back away from the keyboard. This will disengage the magnets
holding the keyboard and case together.
POWERING ON AND OFF
1. To turn your Rugged Book Go on, press the Power button
located at the top right corner of the keyboard. A green LED will
light briefly.
2. To turn your Rugged Book Go o, press and hold the Power button
for three seconds. A red LED will flash indicating it has turned o.
PAIRING YOUR RUGGED BOOK GO
Your Rugged Book Go can pair with up to two devices at once. Pairing your
Rugged Book Go is easy; just follow these instructions.
1. Ensure your device’s Bluetooth® is on.
2
2. Press your Rugged Book Go’s or keys for three seconds. A
blue LED light on the Power button will begin pulsing, indicating
your Rugged Book Go is in pairing mode.
3. Your device will display “ZAGG Rugged Book Go” as an available
pairing option. Select it and complete any other pairing steps
based on your device.
4. To pair your Rugged Book Go to another device, repeat steps
2 and 3. To toggle between devices, simply press or .
5. Once paired, the LED light under the Power button will stop
pulsing and fade to o. Once begun, if the Rugged Book Go
doesn’t complete pairing after 60 seconds, it will abort the
process. If this happens, repeat steps 2 and 3.
1
2
1
DISCONNECTING YOUR KEYBOARD
Your Rugged Book Go features a case that protects your device even when it’s
not connected to your keyboard. When you’d like to use the case without the
keyboard, there are three ways you can switch to your onscreen keyboard.
1. Press the Keyboard Hide/Show button. This will disengage the
Rugged Book Go keyboard and allow you to use your device’s
on-screen keyboard. Press the Keyboard Hide/Show button again
when you are ready to use your Rugged Book Go keyboard.
2. Turn o the Bluetooth® connection from your device.
3. Turn your Rugged Book Go keyboard o.
CHARGING
Your Rugged Book Go features a powerful lithium polymer battery that
lasts up to two years of normal use between charges.* To charge your
Rugged Book Go, follow these steps.
1 . Using the cable from your iPad, plug the USB-C connector into the
charging port.
2. Plug the USB connector at the other end into any 5V USB outlet. The
Power key LED on your Rugged Book Go will light to indicate your
keyboard is charging. This LED will turn o when your keyboard is
fully charged.
*Normal use is approximately one hour of use per day without the backlit feature. Using the backlit feature will impact
battery life and require more frequent charging.
BATTERY LIFE
To check your Rugged Book Go keyboard’s battery life, press fn + the
battery key. The LED light on the Power key will flash one of the following
three ways:
Three green flashes = 50% or more battery life
Three yellow flashes = 25-49% battery life
Three red flashes = less than 25% battery life
SPECIAL FUNCTION KEYS
Your Rugged Book Go keyboard has been designed with the following
special function keys to give you more control of your device:
1 & 2 MULTI-PAIRING – Activates your device’s pairing mode.
HOME – Displays your device’s home screen.
LOCK – Activates and deactivates your device’s sleep mode.
APPS RUNNING – Displays all of the apps currently running on your device.
LANGUAGE SYMBOL – Toggles between keyboard languages and emojis (if active on
your device); pressing cmd + spacebar will do the same.
KEYBOARD HIDE/SHOW – Hides or shows your device’s on-screen keyboard.
PREVIOUS TRACK – Skips to the previous track on your selected playlist.
PLAY/PAUSE – Starts or pauses your current playlist.
NEXT TRACK – Skips to the next track on your selected playlist.
MUTE – Mutes your device’s audio.
VOLUME DOWN – Decreases your device’s volume.
VOLUME UP – Increases your device’s volume.
POWER – Turns your Rugged Book Go keyboard on and o.
BATTERY LEVEL – Indicates remaining battery life.
FN + BACKLIGHT SYMBOL – Activates the backlight feature.
FN + COLOR CHANGE SYMBOL – Changes backlight colors. (7 possible)
TROUBLESHOOTING
If your device doesn’t respond to the Rugged Book Go keyboard, there
may be a simple explanation such as a dead battery or unsuccessful
pairing. Please use the following to help troubleshoot your situation. If
none of the following solve your issue, please contact ZAGG Customer
Service and one of our trained professionals will be happy to assist you.
1. Restart your device.
2. Turn your Rugged Book Go keyboard o and back on.
3. Forget and re-pair your Rugged Book Go keyboard.
4. If your Rugged Book Go keyboard does not establish or maintain
a Bluetooth® connection, reset the Bluetooth® module by charging
your keyboard.
5. If, after charging, your keyboard doesn’t operate correctly, please
contact ZAGG Customer Service.
For more help, please see our FAQ section at www.zagg.com/faq.
To reach a trained customer service representative, please use one of
the following:
• Zagg.com/support/contact.php | questions@zagg.com
• 1-800-700-ZAGG [9244] | 00-1-801-839-3906 for
international customers
For more help please visit: www.zagg.com/support
For unparalleled scratch protection for your device, we recommend
ZAGG InvisibleShield®.
©2005 - 2019 ZAGG Inc All Rights Reserved.
Patents: zagg.com/patents | NASDAQ: ZAGG | MADE IN PHILIPPINES
The Bluetooth® word mark and logo are trademarks of Bluetooth SIG, Inc.
and any use of such marks by ZAGG Inc is under license.
ZAGG, InvisibleShield, ZAGG logo, and Rugged Book Go are trademarks
of ZAGG IP Holding Co., Inc.
iPad is a trademark of Apple Inc.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined
by turning the equipment o and on, the user is encouraged to try to correct the
interference by one of the following measures:
• Reorient or relocated the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate this equipment.
This device complies with Part 1S of the FCC Rules. Operation is subject to the
following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that
may cause undesired operation.
Please read the precautions and operation information before using your keyboard
or any accessories that accompany it. Retain this information for future use.
1. Health Warning: Take frequent breaks when using your keyboard. If you
experience any discomfort, pain, tingling, numbness or burning in your neck,
shoulders, arms, wrists, hands or any other part of the body, stop using your
keyboard and consult a physician.
2. Use only USB-C chargers in connection with your keyboard.
3. Do not attempt to service your keyboard.
4. Do not disassemble or attempt to disassemble your keyboard.
5. Do not crush or puncture the keyboard.
6. Do not immerse your keyboard in water.
7. Do not put your keyboard in contact with water or other liquids as they could
cause a short circuit, fire, or electric shock which could result in serious injury,
death or property damage.
8. Do not use liquid or aerosol cleaners or solvents on or near your keyboard.
Clean only with a soft, dry cloth. Disconnect any cords before cleaning
the keyboard.
9. Do not use your keyboard while operating a motorized vehicle, including
automobile, boat or airplane. Doing so could put you and others at risk of
serious injury, death or property damage.
10. Do not use or place your keyboard near any heat sources including, but not
limited to, radiators, heat registers, stoves, other appliances, campfires or
barbeque grills.
11. To reduce the risk of fire or electric shock, wire or connect your keyboard
to products only in the manner instructed in the documentation supplied
herewith.
12. Do not attempt to modify or adjust any ports. Any improper connections or
adjustments may cause damage.
13. When you are ready to discard your keyboard, recycle your keyboard in a
manner consistent with electronic recycling requirements or recommendations
in your geographic area.
7
