QUICK START GUIDE V1.0

Introduction and Overview

01

02

03

04

01 Damping Plate

02 LED Status Indicator

03 RGB Camera Lens

04 Infrared Camera Lens

05

06

07

05 The Gimbal

06 GHzAntenna

07 Card Upgrading Port

Specifications

General

Name:E10T
Dimensions:123*81*140
Weight: 371g

Environmental

Operating Temperature Range: -10℃-40℃

Camera

Infrared Lens：

Thermal Imaging System:
Uncooled Vanadium (VOx) Microbolometer
Sensitivity (NEdT) : <50 mK @f/1.0
FPA/Digital Video Display Formats: 320 × 256

Pixel Size: 12 μm
Spectral Band: 8 - 14 μm

Exportable Frame Rates: <9Hz(U.S. export restrictions)
Full Frame Rate: 30Hz
Image Formats: JPEG, TIFF
Video Format: MP4
Scene Range(high gain): -25°C to 100°C
Scene Range(low gain): -40°C to 550°C
Point Temperature Measurement: 3*3
NTSC/PAL field switchable：yes
Image Optimization: Support
Digital Image Enhancement: Support
Polarity Control（black hot/White hot¬）：yes
Color ＆Monochrome Palettes (LUT)：yes
Digital Zoom Range: 1x , 2x , 4x , 8x
Lense: 4.4mm F/1.0 50°FOV 6.5mm F/1.0 34°FOV

9.1mm F/1.0 24°FOV 13.8mm F/1.0 16°FOV

Gimbal

Angular Vibration Range: 0.03°
Mount: Detachable
Controllable Range: Tilt：+15°to -90°Pan：±360°
Mechanical Range: Tilt: +50°to -140°Pan：±360°，Roll:±50°

RGB Lens:

Sensor: CMOS 1/2.8''
Effective Pixels: 2.13MP
Lens: F2.8 equivalent focal length: 23mm
FOV:90°
Video Resolutions: FHD: 1920x1080 30FPS
Photo Formats: JPEG
Video Formats: MP4
Operation Mode: Capture, Record
Exposure Mode: Program AE Mode, Manual Exposure
Mode
Exposure Compensation:±2
Metering Mode: Spot Metering, Center-weighted
Metering, Average Metering
Shutter Speed:1/30 – 1/8000 s
White Balance: Daylight, Cloudy, Auto, Fluorescent,
Incandescent, Sunrise/Sunset
ISO Range: 100-3200
Digital Downlink Distance: 2km

Gimbal Installing

Assembling

Step 1.

Find the arrow printed on the top of the damping plate,
which indicates the correct direction for installation.

Step 2.

Slide the E10T in the indicated direction all the way
into the mounting slot, until the E10T is secured by the
locking clip.

Step 3.

Remove the lens protector.

Step 4.

Insert the Micro SD card.

Disassembling

Step 1.

Find the locking clip which is located in front of the
mounting slot.

Step 2.

Press and hold the locking clip and push the E10T
forward (the direction shown by the arrow).

Binding the E10T

Step 1.

Switch on the ST16S and the H520 aircraft.

Step 2.

Tap the [ ] on the top right corner on the main
interface of ST16S.

GPS

Fly

Not Connected

Takeoff

RTL

Pause

Action

N/A

75%

NO CAMERA

Step 3.

Tap the serial number of the E10T when the following
window pops up. (If multiple Yuneec UAS are used,
check the ID number on the side of each camera to
assure correct camera selection/binding).v

Step 4.

Using the password “1234567890”, authorize the
camera and tap “OK” to confirm.

NOTICE

If the connection process is delayed, close the pop
up window and then repeat the above steps.

GPS

Fly

Takeoff

RTL

Pause

Action

Fly

Takeoff

RTL

Pause

Action

Not Connected

Select Vehicle to Connect

E10T 31009B

Reset All Links

Not Connected

Please enter password for

ok

E10T 31009B

Reset All Links

Close

E10T 31009B

Cancel

Close

N/A

75%

NO CAMERA

GPS

N/A

75%

NO CAMERA

Customer Service

Manufacturer:

Yuneec International (China) Co., Ltd.

Address:East Zhengwei Road No.388, Jinxi Town, Kunshan City, Jiangsu Province

Distributor:

CN: Youyu (Shanghai) Digital Technology Co.,Ltd.

Address: B 15F, 461 HongCao Road,CaoHeJing Software Building XuHui District, Shanghai, China
Tel.: [phone]
[e-mail]

HK: Yuneec HK

Address: 2/F, Man Shung Industrial Building, 7 Lai Yip Street, Kwun Tong, Kowloon, Hong Kong
Tel.:[phone]
[e-mail]

US: Yuneec USA Inc
Address: 2275 Sampson Ave, Suite 200 Corona, CA 92879, USA
Tel.: [phone]
[e-mail]

EU: Yuneec Europe GmbH

Address: Nikolaus–Otto-Strasse 4, 24568 Kaltenkirchen, Germany
Tel.: [phone]
[e-mail]

UK: YUNEEC UK

Address: 181 Victoria Road, Barnet, Hertfordshire EN4 9PA, UK
Tel.:[phone]
[e-mail]

NOTICE

1 Ensure that the firmware of the gimbal has been updated to the latest version.
2 For the latest product information, please check our official website：www.yuneec.com

WARNING

Do not try to repair the E10T gimbal camera.
Do not expose the lens of E10T gimbal camera to extreme light sources.
Do not operate the E10T gimbal camera in the rain or in environments with high humidity.
Do not touch or move the E10T gimbal camera until the initialization process has been completed.

The following special language terms are used throughout the product literature to indicate various levels
of potential harm when operating this product:

NOTICE

possibility of injury.

CAUTION

possibility of serious injury.

WARNING

damage and/or serious injury or create a high probability of superficial injury.

Procedures, which if not properly followed, create a possibility of property damage and/or little to no

Procedures, which if not properly followed, create the probability of property damage and/or a

Procedures, which if not properly followed, create the probability of property damage, collateral

WARNING

Read the entire instruction manual to become familiar with the features of the product before operating.
Do not use with incompatible components or alter this product in any way outside o the instructions provided by
Yuneec.
Failure to use this product in the intended manner as described in instruction manual can result in damage to the
product, property and/or cause serious injury.

Collection and Processing of Data

Yuneec may collect navigation information such as GPS data to help improve our products.
We may also collect Depth Map information and Infrared Image information from your drone delivered to our
service center for repair and maintenance service or any other service.
We may also collect other information such as device information, server log information, etc. We may also collect
personal information used in registration if you choose to become a registered user and any other information
user provided to Yuneec. We may also collect information which user send to other users, and the recipients and
senders of such information.

We reserve the right to disclose your information if required to do so by law or in the good-faith belief that such
disclosure is needed to comply with applicable laws, for example in response to a court order, judicial subpoena,
warrant or request from government, or otherwise cooperating with government agencies or law enforcement.
We also reserve the right to disclose your information that we believe in good faith is necessary or appropriate to:
(i) protect ourselves or others from fraudulent, unlawful, or abusive activities; (ii) take precautions against potential
liability; (iii) protect the security of the Yuneec Apps embedded into or downloaded onto your drone or any associ­ated equipment and services; (iv) protect the legal rights of ourselves or any others.
Any information we collected maybe disclosed or transferred to an acquirer, successor or assignee as part of any
potential merger, acquisition, debt financing or other activities that involves transfer of business assets.
We may make the aggregated non-personal information of the users available to third parties for various purpos­es, including (i) complying with various report obligations; (ii) marketing efforts; (iii) analyzing product safety; (iv)

understanding and analyzing our users’ interests, habits, usage pattern for certain functionalities, services,

content, etc.

Disclaimer

Yuneec Electric Aviation cannot be held liable for any damage, injury or for use of the product in violation with legal
regulations, especially in the following circumstances: Damage and/or injury as well violation of legal regulations
resulting from a failure to comply with the operating instructions or the instructions at www.yuneec.com, product
information, user manual and other legally binding information.
Damage and/or injury as well violation of legal regulations brought about by the influence of alcohol, drugs,
medication or other narcotics which may impact on the concentration of the user.
The same applies to illnesses effecting the concentration of the user(dizziness, tiredness, nausea etc.) or other
factors compromising mental and physical capabilities.
Intentionally caused damage, injury or violation of legal regulations.
Any request for compensation caused by an accident resulting from use of the product.
Damage and/or injury as well as violation of legal regulations caused by use of the product in a no-fly zone,
e.g.next to an airfield, above a motorway or a natural conservation area.
Malfunction of the product caused by retrofitting or replacement with components which did not come from
Yuneec Electric Aviation.
Damage and/or injury caused by the use of replica parts (non-original parts).
Damage and/or injury as well as violation of legal regulations caused by incorrect operation or misjudgement.
Damage and/or injury caused by damaged spare parts or not using original Yuneec Electric Aviation spare parts.
Damage and/or injury as well as violation of legal regulations caused by ignoring the low voltage battery warning.
Damage and/or injury as well as violation of legal regulations caused by operating the model in a magnetic field
(e.g. high voltage lines, electricity/ transformer stations, radio towers,mobile phone masts etc.), a strong wireless

signal environment, no-fly zones, poor visibility and in the event of vision impairments or other impacts on the pilot
which are left unchecked etc.
Damage and/or injury brought about through a violation of the legal regulations for operating the model, in unsuit­able weather conditions, e.g. rain, wind, snow, hail, storms, hurricanes etc.
Damage and/or injury as well as violation of legal regulations caused by force majeure, e.g. collision, fire,
explosion, flooding, tsunami, landslide, avalanche, earthquake or other forces of nature.
Damage and/or injury as well as violation of legal regulations caused by the illegal or immoral use of the model,
e.g. capturing videos or recording data which infringes upon/harms the privacy of other people.
Damage and/or injury as well as violation of legal regulations caused by incorrect use of the batteries, protection
systems, chargers or aircraft.
Consequential damage caused by the incorrect operation of any kind of system components and accessory parts,
especially memory cards, whereby image or video material from the camera can become defect.
Any non-compliance with legal obligations, personal injury, material damage and environmental damage caused
by use and a failure to comply with the local laws and regulations.
Damage and/or injury as well as violation of legal regulations caused by hazardous use without sufficient practical
experience.
Damage and/or injury as well as violation of legal regulations caused by flying in legally defined no-fly zones.
Further losses which do not fall within the scope of use defined by Yuneec Electric Aviation as improper.
This product is designed for both professional use and personal, private use. The national and international laws
and regulations in force as the time of taking off must be adhered to.

Regulation Information

FCC Statement

This equipment has been tested and found to comply with the limits for Part 15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user is encour­aged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.

RF Exposure Warning

This equipment must be installed and operated in accordance with provided instructions and the antenna(s)
used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons
and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and
installers must be provide with antenna installation instructions and transmitter operating conditions for
satisfying RF exposure compliance.

IC Radiation Exposure Statement for Canada

This device complies with Industry Canada licence-exempt RSS standard(s).Operation is subject to the following
two conditions: (1) this device may not cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the device.Le présent appareil est conforme aux
CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux
deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit
accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le
fonctionnement.
This equipment complies with IC RSS-102 radiation exposure limit set forth for an uncontrolled environment.Cet
équipement respecte les limites d'exposition aux rayonnements IC définies pour un environnement non contrôlé

NCC Warning Statement

Article 12
Without permission, any company, firm or user shall not alter the frequency, increase the power, or change the
characteristics and functions of the original design of the certified lower power frequency electric machinery.
Article 14
The application of low power frequency electric machineries shall not affect the navigation safety nor interfere a
legal communication, if an interference is found, the service will be suspended until improvement is made and
the interference no longer exists.

CE Warning Statement

This device meets the EU requirements on the limitation of the general public to electromagnetic fields by way
of health protection.
EU Operation Frequency (The Maximum Transmitted Power)
5G Wifi: 5560-5580MHz (27dBm), 5680-5700MHz (27dBm)

EU Compliance Statement

Hereby, Yuneec International (China) Co., Ltd. declares that this device is in compliance with the essential
requirements and other relevant provisions of the RED Directive 2014/53/EU. The full text of the EU Declaration
of Conformity is available at the following internet address: http://yune.ec/de-downloads.
Please visit the address above and enter into corresponding product page.
