Page 1
User Manual
Page 2
Page | 2
Table of Contents
A MESSAGE FROM COOLPAD .......................................................................... 8
TRADEMARKS AND COPYRIGHTS .................................................................. 9
YOUR PHONE ......................................................................................................... 10
FUNCTIONS OF KEYS .............................................................................................. 11
CONVENTIONS USED IN THIS GUIDE ....................................................................... 12
1. GETTING YOU STARTED ...................................................................................... 13
Charging the battery ............................................................................................... 13
Power phone on & off ............................................................................................. 13
Touch screen & typing directions ....................................................................... 14
Other touch tips ....................................................................................................... 14
2. MORE BASICS ..................................................................................................... 16
Page 3
Page | 3
How your phone looks ........................................................................................... 16
Screen-lock security options ................................................................................ 17
Changing sound settings ...................................................................................... 18
Changing other settings ........................................................................................ 18
Taking screenshots ................................................................................................ 18
3. PHONE APPS MADE SIMPLE ............................................................................... 19
Making a call ............................................................................................................. 19
Answering & redirecting calls .............................................................................. 20
Exploring the call log .............................................................................................. 21
4. TEXTING & KEYBOARD USE ................................................................................ 22
Entering & editing text ........................................................................................... 22
Next-word suggestions .......................................................................................... 22
5. CUSTOMIZING & USING YOUR AVAIL PHONE APPS ............................................ 23
Page 4
Page | 4
Customizing your Home screen .......................................................................... 23
People ......................................................................................................................... 24
Setting up & using Gmail ....................................................................................... 25
Getting familiar with your Email app .................................................................. 25
Controlling your calendar...................................................................................... 26
Operating the alarm ................................................................................................ 27
Managing your downloads .................................................................................... 28
6. PHONE SET-UP AND PHONE MANAGEMENT ...................................................... 29
Privacy settings & accounts ................................................................................. 29
Managing location settings ................................................................................... 30
Managing sound settings ...................................................................................... 30
Managing screen settings ..................................................................................... 31
Managing sleep settings ........................................................................................ 31
Notifications .............................................................................................................. 31
Page 5
Page | 5
Airplane mode .......................................................................................................... 32
7. WIRELESS NETWORK SETTINGS .......................................................................... 33
Turning on Wi-Fi ...................................................................................................... 33
Changing network settings ................................................................................... 34
Adding a Wi-Fi network .......................................................................................... 34
Setting advanced Wi-Fi options ........................................................................... 35
8. BLUETOOTH SETTINGS ....................................................................................... 36
Turning Bluetooth on/off ....................................................................................... 36
Changing your phone’s Bluetooth name ........................................................... 36
Pairing your phone with a Bluetooth device .................................................... 37
Connecting to a Bluetooth device ....................................................................... 38
Unpairing or aligning a Bluetooth device .......................................................... 38
9. CREATING & SHARING VIDEOS AND PICTURES ................................................... 40
Page 6
Page | 6
Creating a video ....................................................................................................... 40
Taking a photo ......................................................................................................... 40
Sharing a video or photo ....................................................................................... 41
10. DATA USAGE SETTINGS .................................................................................... 42
Manage your data usage settings ....................................................................... 42
Setting a data usage limit warning ...................................................................... 43
Setting your data usage limits ............................................................................. 43
11. GOOGLE PLAY STORE ........................................................................................ 44
Accessing Play Store ............................................................................................. 44
Google Play settings .............................................................................................. 45
12. USB FILE TRANSFERS ........................................................................................ 46
Windows transfer .................................................................................................... 46
Mac OS transfer ....................................................................................................... 47
Page 7
Page | 7
13. OPTIMIZING YOUR PHONE’S BATTERY LIFE ....................................................... 48
Battery settings ........................................................................................................ 48
14. STAY CONNECTED & GET UPDATES ................................................................... 50
15. AVAIL SPECS & HARDWARE .............................................................................. 51
List of In-Box Contents .......................................................................................... 53
Declaration of Hazardous Substances ............................................................... 54
Page 8
A Message From Coolpad
Page | 8
Thank you for purchasing your Avail mobile phone! Please follow these simple - but important instructions for optimal use of your new phone:
Before using your phone for the first time, please carefully read this User Guide, especially the
security information.
Note: Products or services of the vendor or carrier are subject to change within this User Guide
without prior notice.
Application features and functions may vary among countries, regions or hardware specifications,
and any third-party application malfunctions are the responsibility of those manufacturers.
Exercise caution when editing User Registration Settings as this may cause functional or
compatability problems for which Coolpad will not be responsible.
Most of all, we want you to thoroughly enjoy your new Avail phone and get the most out of all of its
remarkable features!
Page 9
Trademarks and copyrights
Page | 9
Copyright © 2015 Coolpad Technologies, Inc. All Rights Reserved. All materials in this document
including, without limitation, the design, the text, and any and all marks (unless otherwise indicated)
are the property of Coolpad Technologies, Inc. Coolpad and the Coolpad logo are registered
trademarks of of Yulong Computer Telecommunication Scientific (Shenzhen) Co., Ltd. Google,
Android, Gmail, Hangouts, Google Play, YouTube. Additional related marks are trademarks of
Google Inc. Swype is trademarks or registered trademarks of Nuance Communications, Inc.
Attention: Pictures shown are for illustration only and do not represent actual devices.
Page 10
Your Phone
Page | 10
Page 11
Functions of Keys
Keys
Functions
Menu key
Enable the menu pop-up.
Home key
Return to the Home screen from an app screen.
Back key
Return to the previous screen.
Volume keys
Adjust the volume of calls, ringtone, music and videos.
Power key
Press to turn off the backlight or re-activate the phone.
Press and hold to turn on or off the power.
Note: Menu, Home and Back keys are touch keys.
Page | 11
Page 12
Conventions used in this guide
Note: This is a note or notification giving you additional information on phone operations.
This indicates some important tips of using the phones, such as what to do and what
to avoid to keep good condition of the phone.
This explores different functionalities of an app or a setting.
Page | 12
Page 13
1. Getting you started
Get off to a running start with your new Avail ™.
Charging the battery
1. Connect one end of the data cable to the USB/Power Port. This is located at the
bottom of your phone.
2. Connect the other end to the travel adapter.
3. Connect the travel adapter to an electrical outlet to fully charge your phone.
Use the travel adapter that accompanies your phone; using other adapters may
Charging your phone through a USB cable that is attached to a laptop takes more
Power phone on & off
The Power key is located on the upper, right-hand side of your phone. Press and
Page | 13
damage your phone.
time than charging it with the travel adapter.
hold the Power key for a few seconds to turn on your phone.
Page 14
To turn off your phone, press and hold the Power key for the menu to pops up, and
Touch screen & typing directions
1. Tap selected icon or other items in order to select or activate them.
2. To type a message, tap at the bottom of the Home screen and use the keypad
that appears.
3. You can entering messages in either of the following ways:
Type letters one by one and choose the correct one as suggested.
Swipe between letters on the screen without pausing. Lift your finger when a new
Other touch tips
Touch and hold an object on your phone screen without lifting your finger, you can
To drag something, touch and hold an object without lifting your finger, then move
Page | 14
then select Power off.
word or name is spelled.
then reorganize your apps layout or drag apps to the Home screen.
Page 15
Page | 15
your finger on the screen until you reach the desired spot.
To zoom in/enlarge, double-tap on a screen object (such as Google Maps).
Double-tap again to zoom out.
Some apps allow you to zoom in or out with two fingers on the screen. That is,
pinch your fingers to zoom out, or spread them apart to zoom in.
Page 16
2. More basics
How your phone looks
1. Menu key: Show setting menus.
2. Home key: Return to the Home screen.
3. Back key: Return to the previous screen.
4. Close or open recent apps: Holding the Menu key opens a list of your recent apps.
Tap an app to open it or remove an app from the list by swiping left or right.
5. Start Google search: Touch and hold the Home key to start Google search directly.
Page | 16
Page 17
Screen-lock security options
1. To lock your phone, press the Power key (on the phone’s right side) briefly, and let go.
2. To unlock, press Power key to turn on the screen, let go and slide the Padlock icon to
any direction.
Page | 17
Page 18
Changing sound settings
On the Home screen, tap > > DEVICE > Sound to change sound settings on your
phone.
You can adjust the volume by pressing volume keys on the left side of your phone.
Changing other settings
On the Home screen, tap > > DEVICE > Display to change the brightness or font
size settings and customize the wallpaper on your phone.
Taking screenshots
1. Focus on the image so it displays on your phone screen.
2. Press the Power key and Volume Down key at the same time.
3. The image will be auto-saved in Gallery.
Page | 18
Page 19
3. Phone apps made simple
Making a call
On the Home screen, tap > to enter Phone screen.
Dial a number in the keypad to make a call. You can touch to hide the
Tap to display your recent calls and touch a call in the Call log to return the
Tap to display your contacts and tap one to call it.
During a call, you can tap at the bottom of the screen to hang up.
Calls can also be made from other widgets or apps that contain your contact
Page | 19
keypad.
call.
information, by simply tapping the phone number.
Page 20
Answering & redirecting calls
Note: To modify these standard text responses, tap > Settings > Quick responses.
1. The Incoming Call screen pops up when a call comes in, along with the caller ID and
other information you’ve entered in your Contact Book.
2. Any missed calls are logged in the Call log, along with a notification.
3. Press the Volume Down key on the left side of your phone to mute the ringer.
4. There are various options for when a call comes in. To answer a call, slide over
to the answering key on the right.
You may:
Start talking to the caller.
Send to voicemail.
Send a message by opening quick text responses and select one of them.
Page | 20
Page 21
Exploring the call log
The Call log contains your history of calls received, missed or made.
Tapping the beside the numbe will reveal more information about the call.
Tapping the number returns the call.
In the call details screen, tap to send a text message.
Tap for contact information.
Tap to add a new contact.
To clear call logs, tap > Clear call log.
Page | 21
Page 22
4. Texting & keyboard use
Entering & editing text
Enter text by using the screen’s keyboard. To open your phone’s
keyboard, simply tap where you want to type.
Otherwise, some apps will open the keyboard for you.
To close the keyboard, tap below the keyboard.
Next-word suggestions
1. Tap where you want to type text.
2. Begin typing a word. Choose one of the words displayed
above the keyboard.
3. If you do not want to use those words, type the next word
without using the space bar.
4. Your phone will continue to present word choices while you
type.
Page | 22
Page 23
5. Customizing & using your Avail phone apps
Customizing your Home screen
1. Go to the Home screen where you want to position an app.
2. Tap .
3. Swipe right to locate an app or widget icon, and hold it until the Home screen comes
up.
4. After sliding the icon into place, lift your finger.
To reposition an app or widget icon on the Home screen, touch and hold the icon,
To move an app or widget icon to another screen, hold and swipe it toward the
Page | 23
and then move it to a new position.
edge of the current screen. After the icon reaches the other screen, move it to a
new spot and lift your finger.
Page 24
People
The People app easily saves all of your important contact
It also supports lots of other communication operations.
To search for your contacts, tap at the lower left corner of the
To add a new contact, tap at the lower right corner of the People screen.
Enter the contact information and tap DONE to save it.
Page | 24
information including contact names, numbers and email addresses.
People screen, enter keywords in the search box. The phone system will
automatically display the matched results.
Page 25
Setting up & using Gmail
1. The Gmail app allows you to read and compose emails.
2. On the Home screen, tap > to enter the Gmail screen. Here
Gmail has various uses. For instance, utilize your Gmail account for
signing in to all Google apps & services that include but are not limited to:
Google Play Music
Google Play Store
Google Drive
Getting familiar with your Email app
1. On the Home screen, tap > to enter the Email screen. When using it for the
first time, you need to enter your email address and password to configure an
account.
2. After your email account is configured, you can archive, delete, label, or perform other
mail operations.
Page | 25
Page 26
3. Tap the icon on the left of a mail thread to select it.
4. After opening a mail, swipe left or right to read earlier or later mail conversations.
5. Tap at the top of your phone screen to manage your mails.
6. On the Email screen, you can tap > Settings to add a
new email account.
7. On the Email settings screen, tap an email account and
customize your Email settings.
Controlling your calendar
On the Home screen, tap > to enter Calendar screen.
If you have synced your Gmail account, the first time you
Page | 26
open the Calendar app on your phone, it will show your
current calendar events.
Page 27
To modify the Calendar view, choose Day, Week, Month or Agenda by tapping on
View event details by tapping an Event.
Tap a blank square on the Calendar screen and tap that shows up to add a
Operating the alarm
On the Home screen, tap > to enter Clock screen. Then, tap to switch to the
Alarm tab.
Tap and the time displayed to set your alarm.
Once your alarm is set, you may add a label to it.
Select the VIBRATE check box and choose your ringtone from the Ringtones
Page | 27
date at the top left of the Calendar screen.
new event; or tap an existing event to edit it in a new window.
drop-down list.
Page 28
Managing your downloads
On the Home screen, tap > to enter Downloads screen.
You can download files from Gmail or other areas.
On the Downloads screen, tap an item to open it.
Touch and hold an item and tap that appears. In the Share via drop-down list,
Touch and hold an item and tap that appears to delete it.
Tap > By name, By date modified, or By size to sort the downloaded items.
Page | 28
select a sharing method to share it.
Page 29
6. Phone set-up and phone management
Privacy settings & accounts
Perform either of the following operations:
• On the Home screen, tap > to enter Settings screen. Then, choose
ACCOUNTS > Google > Search > Accounts & privacy.
• On the Home screen, tap > System Settings > ACCOUNTS > Google >
Search > Accounts & privacy.
These settings control your phone’s Google Search privacy features and search-related
confidentiality selections for your Google account.
Page | 29
Page 30
Managing location settings
On the Home screen, tap > to enter Settings screen. Then, choose PERSONAL >
Location.
On the Location screen, you can perform the following operations:
Turn on or off the location service.
Set Location mode to High accuracy, Battery saving, or Deivce only.
View recent location requests
Perform Google Location Reporting settings.
Managing sound settings
On the Home screen, tap > to enter Settings screen. Then, choose DEVICE >
Sound.
Tap Volumes. Swipe the slider of volume levels for sources, such as music,
Page | 30
ringtone, or alarms. Alternatively, press the Volume Up or Down keys on the left
side of your phone.
Page 31
Tap Phone ringtone. Choose a desired ringtone for your phone. You can select
Managing screen settings
On the Home screen, tap > to enter Settings screen. Then, choose DEVICE >
Display > Brightness.
Managing sleep settings
On the Home screen, tap > to enter Settings screen. Then, choose DEVICE >
Display > Sleep. You can tap one of the options to select.
Notifications
On top left of your phone, status icons will pop up displaying which apps have sent
Page | 31
Vibrate when ringing to enhance notifying effects.
you notifications.
Page 32
For finding notifications, pull the notification shade down from the top.
Tap to view your settings for Bluetooth, Wi-Fi, etc.
Airplane mode
On the Home screen, tap > to enter Settings screen. Then, choose WIRELESS &
NETWORKS > More… > Airplane mode.
This mode is ideal for in-flight phone status, where no signal or Wi-Fi is connected.
Page | 32
Page 33
7. Wireless network settings
Note: If having been connected to a Wi-Fi network, your phone will be
auto-connected once locating it.
Turning on Wi-Fi
1. On the Home screen, tap > to enter Settings screen.
Then, choose WIRELESS & NETWORKS > Wi-Fi to turn Wi-Fi
on/off.
2. Swipe the Wi-Fi switch to ON for enabling your phone to scan for Avail able Wi-Fi
networks. It will show the networks.
3. Tap the name of a desired network to connect, entering your password if necessary.
Page | 33
Page 34
Changing network settings
Touch and hold the name of a connected network to change the network’s settings.
Adding a Wi-Fi network
1. A Wi-Fi network may be added so that your phone will recognize it along with any of
its security credentials, and then it will auto-connect.
2. Always add a Wi-Fi network if the network name is not transmitted (SSID), or when
you are out of range.
3. Tap at the bottom right of the Wi-Fi settings screen.
4. Enter the SSID network name and select the correct security mode.
5. Tap Save. Your phone will auto-connect to this network whenever you return to its
coverage.
Page | 34
Page 35
Setting advanced Wi-Fi options
On Wi-Fi settings screen, tap > Advanced.
You will receive Wi-Fi notifications for Avail able networks in your status bar by
To save your phone’s data usage, your phone will remain connected to Wi-Fi when
Page | 35
default. To disregard notifications, clear the Network notification check box.
your screen sleeps.
Page 36
8. Bluetooth settings
Bluetooth has the capacity to connect several mobile devices at once, enabling superior
synchronization while reversing challenges and problems that would otherwise occur. Use
Bluetooth to maximize awesome phone capabilities and functions of your Avail ™.
Turning Bluetooth on/off
On the Home screen, tap > to enter Settings screen. Then,
choose WIRELESS & NETWORKS > Bluetooth to turn Bluetooth on/off.
Changing your phone’s Bluetooth name
Your phone contains a random Bluetooth name which will be visible to other Bluetooth devices
during connection attempts. You can change the random name to a more identifiable one.
1. On the Home screen, tap > to enter Settings screen. Then, choose
WIRELESS & NETWORKS > Bluetooth to turn Bluetooth on.
2. Tap Bluetooth.
Page | 36
Page 37
Page | 37
3. On the Bluetooth settings screen, tap > Rename phone.
4. Enter a new name and tap Rename.
Pairing your phone with a Bluetooth device
When initially using a new Bluetooth device, it will be necessary to pair it with your phone,
which is crucial in order to connect.
Now both devices save the connected record and will auto-connect for you next time.
If the device to pair with isn’t contained in the list, ensure that it is turned on and that it is set to
be detectable.
1. On the Home screen, tap > to enter Settings screen. Then, choose
WIRELESS & NETWORKS > Bluetooth to turn Bluetooth on.
2. Tap Bluetooth. Your phone will begin searching for nearby Bluetooth devices.
3. If your phone stops scanning before your Bluetooth device is ready, tap SEARCH
FOR DEVICES.
Page 38
4. Within the list, tap the ID of the Bluetooth device so as to pair with it.
5. Ensure that both devices show the same passkey and touch Pair.
Connecting to a Bluetooth device
Now that your phone is paired with a Bluetooth device, they can be connected manually.
1. On the Home screen, tap > to enter Settings screen. Then, choose
WIRELESS & NETWORKS > Bluetooth to turn Bluetooth on.
2. Within the devices list, tap a paired and unconnected device.
3. The list will indicate that the device and the phone are connected.
Unpairing or aligning a Bluetooth device
Some Bluetooth devices have multiple profiles. Profiles can include the ability to transmit your
conversations, play music in stereo, or transfer files or other data.
You can select which profiles you want to use with your phone. You can also change the name
of the Bluetooth device as it appears on your phone.
Page | 38
Page 39
Page | 39
1. On the Home screen, tap > to enter Settings screen. Then, choose
WIRELESS & NETWORKS > Bluetooth to turn Bluetooth on.
2. On the Bluetooth settings screen, tap next to the connected Bluetooth device
which you are configuring.
3. Check the choices offered, such as to change the name, to unpair it or to select
profiles.
4. When settings are complete, tap to return to the previous screen.
Page 40
9. Creating & sharing videos and pictures
Creating a video
1. On the Home screen, tap > to enter Camera screen.
2. Tap the icon on the lower left of the screen to expand the list and select
3. Tap while using the screen in order to see your video being recorded.
4. Tap to stop recording.
Taking a photo
1. On the Home screen, tap > to enter Camera screen.
2. Tap the icon on the lower left of the screen to expand the list and select .
Page | 40
.
Page 41
3. Focus on your subject by looking through your phone screen.
4. Tap to take a picture.
Sharing a video or photo
1. On the Home screen, tap > to enter Gallery screen.
2. Select a video or photo and tap .
3. From the drop-down list, select your desired sharing method.
It really is that easy! Your new Avail makes it that way.
Page | 41
Page 42
10. Data usage settings
Note: Be sure to check with your carrier for further information.
Manage your data usage settings
Here data usage settings for your new Avail are described, but they are carrier-specific.
The following instructions will assist in tracing data usage, which may help avoid possible
additional charges.
1. On the Home screen, tap > to enter Settings screen. Then, choose
WIRELESS & NETWORKS > Data usage and switch Mobile data to ON.
2. Here you will see a graph. The vertical white lines present a time period within the
data usage phase.
3. Touch and drag the white lines in order to change a data usage time period.
4. Your actual data usage is shown below the graph.
Page | 42
Page 43
Setting a data usage limit warning
Touch the orange line on its right side and drag it to the point where you wish to receive a data
usage warning notification.
Setting your data usage limits
1. On the Home screen, tap > to enter Settings screen. Then, choose
WIRELESS & NETWORKS > Data usage and switch Mobile data to ON.
2. Activate the red line at the top of the graph by selecting the Set mobile data limit
check box.
3. Touch the red line on its right side and drag it to the point where you wish to set the
limit. Your data will automatically switch off when your usage limit has been reached.
Page | 43
Page 44
11. Google Play Store
Google Play Store is all-in-one entertainment point with music, movies,
books and apps on the web.
Accessing Play Store
1. On the Home screen, tap > to enter Google Play Store screen.
2. Swipe right from the left edge of the screen for the menu to pop up. This menu
displays your content for that part of Google Play.
3. Your Google Play content can be retrieved this way (from the Play Store app) even if
you access it through another phone.
4. Sign in to play.google.com to access your entertainment from any location.
Page | 44
Page 45
Google Play settings
1. On the Google Play Store screen, tap > Settings to change your Google Play
settings.
2. The Google Play settings screen enables you to:
Control game & app updates’ notifications.
Set auto updates for apps and widgets.
Clear search history.
Manage user controls.
Page | 45
Page 46
12. USB file transfers
With a USB cable, you can transfer pictures, music, and other data files between
For transferring files to Mac OS X, the Android File Transfer application can be
Windows transfer
1. Connect your phone to the computer’s USB port. Its USB storage drive will appear on
the computer screen.
2. Begin copying files between your phone and the computer.
3. When transfer is complete, eject the phone from Windows before unplugging the USB
cable.
Page | 46
your Avail phone and your computer.
utilized. (Refer to instructions below.)
Page 47
Mac OS transfer
1. Install Android File Transfer from http://www.android.com/filetransfer and follow the
directions. Double-click for first-time use. (Auto-connect will occur thereafter.)
2. Connect your phone to the computer using a USB cable.
3. The Android File Transfer will begin, including a window pop-up showing your phone
contents & other pertinent information.
4. Here you can open or close folders, create new folders, and drag files.
5. Disconnect the USB cable upon completion.
Page | 47
Page 48
13. Optimizing your phone’s battery life
Battery settings
Prolong your phone battery life by shutting down apps not in use or not required.
On the Home screen, tap > to enter Settings screen. Then, choose DEVICE >
Battery.
Here you may monitor how apps, other data and your phone system all consume battery
power.
The following are some suggestions for prolonging the battery life of your phone:
Turn off Wi-Fi, Bluetooth, or GPS with the Settings app.
On the Home screen, tap > to enter Settings screen. Then, choose
Turn off Navigation or Maps when not in use.
Dim your phone’s screen brightness: > > DEVICE > Display.
Page | 48
PERSONAL > Location to access GPS settings.
Page 49
Page | 49
Note: If auto-sync is turned off, you must manually sync to check emails, and related
notifications will no longer pop up.
Note: If you stop some apps or services completely, your phone may not operate
properly.The battery status & battery levels are indicated at the top of your phone
screen.
Consider turning off auto-sync for all apps: > > ACCOUNTS > Google.
Assess battery level and usage: > > DEVICE > Battery.
• Battery usage for each app is displayed near the bottom of your phone
screen.
• Get more details by tapping an app. For some apps, you may modify power
usage settings, or halt the app entirely.
Page 50
14. Stay connected & get updates
www.facebook.com/user/CoolpadAmericas
www.youtube.com/CoolpadAmericas
www.twitter.com/CoolpadAmericas
Get updates, user guides and other more information for your Avail at
www.coolpad.com.
Discover what’s going on right now in cell phone news, trends, techniques & other
cool stuff by connecting with us at:
Page | 50
Page 51
Page | 51
Specifications
Dimensions
121.97 mm x 62.84 mm x 12.5 mm
Form Factor
Bar, Touchscreen
Antenna
Built-in
Network Mode
CDMA
Camera
Rear camera: 2.0 MP FF
Earphone Jack
CTIA Standard earphone jack
Screen Parameters
Type
Dimensions
Resolution
FWVGA
4 inches
800x480
Accessories
Battery
Battery Type
Lithium Ion Polymer Rechargeable
15. Avail specs & hardware
Page 52
Page | 52
Battery
Rated Capacity
1600 mAh
Nominal Voltage
3.7 V
Prompt: The battery capacity changes with battery upgrade.
Page 53
List of In-Box Contents
No.
Name
Quantity
1
Phone 1 2
Battery
1
3
Travel Charger
1
4
USB Cable
1
5
Warranty Card
1
6
Quick Start Guide
1
Prompt: The accessory items are as per the final transaction. Please contact the dealer for
further details.
Page | 53
Page 54
Declaration of Hazardous Substances
Parts Name
Toxic or hazardous substances or elements
Plumbu
m (Pb)
Mercur
y (Hg)
Cadmiu
m (Cd)
Chromium
VI (Cr(VI))
Polybrominate
d Biphenyls
(PBB)
Polybrominate
d Diphenyl
Ethers (PBDE)
PCB Board and
Accessories
○ ○ ○ ○ ○
○
Plastics
○ ○ ○ ○ ○
○
Metals
○ ○ ○ ○ ○
○
Battery
○ ○ ○ ○ ○
○
Other
○ ○ ○ ○ ○
○
○: indicates that the content of the toxic or hazardous substance in all homogeneous materials is within the
limit of the SJ/T11363-2006 standard.
Page | 54
Page 55
Page | 55
×: indicates that the content of the toxic or hazardous substance in some homogeneous materials exceeds
the limit of the SJ/T11363-2006 standard.
The Environmentally Friendly Use Period of this product is 20 years, as shown by the symbol on
the left. The Environmentally Friendly Use Period of replaceable parts, such as battery, may be
different from that of the product. The Environmentally Friendly Use Period is valid only when the
product is operated under the conditions defined in this User Guide.
Page 56
Page | 56
FCC Regulations:
This mobile phone complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause
undesired operation.
This mobile phone has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiated radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation If this
equipment does cause harmful interference to radio or television reception, which can be
Page 57
determined by turning the equipment off and on, the user is encouraged to try to correct the
FFCCCC NNoottee::
Page | 57
interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
Caution: Changes or modifications not expressly approved by the party responsible for
compliance could void the user‘s authority to operate the equipment.
Page 58
Page | 58
RF Exposure Information
(SAR)
This phone is designed and manufactured not to exceed the emission limits for exposure to
radio frequency (RF) energy set by the Federal Communications Commission of the United
States.
During SAR testing, this device was set to transmit at its highest certified power level in all
tested frequency bands, and placed in positions that simulate RF exposure in usage against
the head with no separation, and near the body with the separation of 10 mm. Although the
SAR is determined at the highest certified power level, the actual SAR level of the device while
Page 59
operating can be well below the maximum value. This is because the phone is designed to
operate at multiple power levels so as to use only the power required to reach the network. In
general, the closer you are to a wireless base station antenna, the lower the power output.
The exposure standard for wireless devices employing a unit of measurement is known as the
Specific Absorption Rate, or SAR.
The SAR limit set by the FCC is 1.6W/kg.
This device is complied with SAR for general population /uncontrolled exposure limits in
ANSI/IEEE C95.1-1992 and had been tested in accordance with the measurement methods
and procedures specified in IEEE1528. This device has been tested and meets the FCC RF
exposure guidelines when tested with the device directly contacted to the body.
The FCC has granted an Equipment Authorization for this model phone with all reported SAR
levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information on
this model phone is on file with the FCC and can be found under the Display Grant section of
www.fcc.gov/oet/ea/fccid after searching on FCC ID: R38YL3300A.
Page | 59
Page 60
For this device, the highest reported SAR value for usage against the head is 0.93 W/kg, for
usage near the body is 1.17 W/kg.
While there may be differences between the SAR levels of various phones and at various
positions, they all meet the government requirements.
SAR compliance for body-worn operation is based on a separation distance of 10 mm
between the unit and the human body. Carry this device at least 10 mm away from your body
to ensure RF exposure level compliant or lower to the reported level. To support body-worn
operation, choose the belt clips or holsters, which do not contain metallic components, to
maintain a separation of 10 mm between this device and your body.
RF exposure compliance with any body-worn accessory, which contains metal, was not tested
and certified, and use such body-worn accessory should be avoided.
Page | 60
Loading...
