USER’S GUIDE
2WSHR LED
FCC ID : O44JMR540
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions :
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
Caution :
or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate this device.
#
YoungShin Elc.
www.magicar.com
USER’S GUIDE
2WSHR LED
IC : 3767B-MR540
Statement : The term "IC:" before the radio certification number only signifies that
Industry Canada technical specifications were met.
Caution : The User that modifications to the unit may void the user's authority
to operate the unit.
#
2
1
Thank you.
Thank you for your purchase of a MAGICAR alarm and/or remote-start system.
MAGICAR alarms and remote-start systems are the most advanced systems on the
market with amazing features, incomparable ease of use, and breakthrough technologies
never before used in the automotive environment. Please take time to read and
understand this owner's manual so that you can fully use and enjoy you new Conpustar
system.
1.
Safety Information
2. Remote-Pager 2WSHR LED
3. LED
6. Remote-Page LED Functions
7. Remote -Page Learn Routine
8. Alarm Mode
9. Dual Stage Shock Sensor
10.Trunk Release
11.Query Function
12. Panic Mode
13. Valet Mode
14. Safety Shutdown Features
15. R.P.S(Remote Paging System)
16. Optional Programmable Features
Ignition Lock
Passive Arming
17. Optional Installation Features
Optional Auxiliary 1 & Auxiliary 2
19. Limited Lifetime Consumer Warranty
TABLE OF CONTENTS
3
4
4
5
6
6
7
8
8
8
9
9
9
10
10
10
11
11
13
Remote-Pager : 2WSHR/LED
LED
4
The model name, 2WSHR LED, stands for
2Way Super Heterodyne
Remote.
This transmitter that allows you to activate multiple functions by
pressing a combination of the 4 the buttons on the unit in order to transmit
signals.
The remote-pager comes with a unique LED display that visually tells the you
the security status of your car at all times. There are differing icons that will
appear on your LED indicating what your vehicle is currently doing.
0.5 Sec
2 Sec
I
Lock
Panic
II
III
+
IV
I +II
Siren Chips- On/Off
Programming Menu 1
+
II+III
Valet Mode - On/Off
Shock Sensor- On/Off
AUX2
x
Unlock
x
BUTTON
PressFor FUCTION
LED ICON
Safety Information
3
Please take these safety precautions under the following conditions:
1. Servicing the vehicle
When servicing (i.e. changing the oil, washing your car) your automobile, the
MAGICAR
system should be in Valet Mode. There is a safety shutdown switch
under the hood that deactivates the remote starter function if the hood is open.
However, if the switch has been damaged or the switch has been installed
improperly, the vehicle may start when the button is pressed for 2 seconds
even if the hood is open.
2. Loaning your vehicle to others
Whenever you loan your vehicle to an individual who is not familiar with
MAGICAR
, please put the vehicle in Valet mode. This will prevent the vehicle
loaner from accidentally activating the
MAGICAR
auto-security system.
3. For manual transmission vehicles
If the
MAGICAR
2WSHR LED is installed in a manual transmission vehicle, extra
precautions are required because the system does not monitor the gear shift.
Important!
Under normal circumstances, Reservation Mode is cancelled when a door or
hatchback opens. Please verify if the opening of any door or hatchback cancels
Reservation Mode. If any of the doors or hatchback are not monitored by
MAGICAR
because of improper installation or a faulty dome light switch, do not
use the
MAGICAR
and take your vehicle to the dealer immediately for repair.
Do not set Reservation Mode when the window(s) are open or if there is anyone
inside of the vehicle including animals.
AUX1
Trunk Open
+
I +III
+
I+IV
x
Programming Menu 2
Passive Locking-On/Off
x
+
III+IV
x
Query
0.5 Sec
2 Sec
0.5 Sec
2 Sec
0.5 Sec
2 Sec
0.5 Sec
2 Sec
0.5 Sec
2 Sec
0.5 Sec
2 Sec
0.5 Sec
2 Sec
0.5 Sec
2 Sec
