SERVICE MANUAL
Manual-Service-AP4K-00-1v0 • Sept 30, 2014

AP4K

WORLD HEADQUARTERS
CANADA
Yorkville Sound
550 Granite Court Pickering, Ontario
L1W-3Y8 CANADA
Voice: (905) 837-8481
Fax: (905) 837-8746
TYPE: YS1112
U.S.A.
Yorkville Sound Inc.
4625 Witmer Industrial Estate
Niagara Falls, New York
14305 USA
Voice: (716) 297-2920
Fax: (716) 297-3689
Quality and Innovation Since 1963
Printed in Canada
IMPORTANT SAFETY INSTRUCTIONS
This lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”
magnitude to constitute a risk of electric shock to persons. Ce symbole d’éclair avec tête de flèche dans un triangle
équilatéral est prévu pour alerter l’utilisateur de la présence d’un « voltage dangereux » non-isolé à proximité de l’enceinte du produit qui pourrait être d’ampleur suffisante pour présenter un risque de choque électrique.
within the product’s enclosure that may be of sufficient
Caution: hot surface Attention: surface chaude
IEC 60417-5041
FOLLOW ALL INSTRUCTIONS SUIVEZ TOUTES LES INSTRUCTIONS
Instructions pertaining to a risk of fire,
electric shock, or injury to a person
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
THIS DEVICE IS FOR INDOOR USE ONLY!
Read Instructions: The Owner’s Manual should be read and understood before operation
of your unit. Please, save these instructions for future reference and heed all warnings. Clean only with dry cloth. Packaging: Keep the box and packaging materials, in case the unit needs to be
returned for service. Warning: To reduce the risk or fire or electric shock, do not expose this apparatus to rain or
moisture. Do not use this apparatus near water! Warning: When using electric products, basic precautions should always be followed,
including the following:
Power Sources
Your unit should be connected to a power source only of the voltage specified in the owners manual or as marked on the unit. This unit has a polarized plug. Do not use with an extension cord or receptacle unless the plug can be fully inserted. Precau­tions should be taken so that the grounding scheme on the unit is not defeated. An apparatus with CLASS I construction shall be connected to a Mains socket outlet with
a protective earthing ground. Where the MAINS plug or an appliance coupler is used
as the disconnect device, the disconnect device shall remain readily operable.
Hazards
Do not place this product on an unstable cart, stand, tripod, bracket or table. The product may fall, causing serious personal injury and serious damage to the product. Use only with cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with the product. Follow the manufacturer’s instructions when installing the product and use mounting accessories recommended by the manufacturer. Only use
attachments/accessories specified by the manufacturer
Note: Prolonged use of headphones at a high volume may cause
health damage on your ears.
The apparatus should not be exposed to dripping or splashing water; no objects
filled with liquids should be placed on the apparatus.
Terminals marked with the “lightning bolt” are hazardous live; the external wiring connected to these terminals require installation by an instructed person or the use of ready made leads or cords.
Ensure that proper ventilation is provided around the appliance. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
No naked flame sources, such as lighted candles, should be placed on the apparatus.
Power Cord
Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. The AC supply cord should be routed so that it is unlikely that it will be damaged. Protect the power cord from being walked on or pinched particularly at plugs. If
the AC supply cord is damaged DO NOT OPERATE THE UNIT. To completely disconnect
this apparatus from the AC Mains, disconnect the power supply cord plug from the AC receptacle. The mains plug of the power supply cord shall remain readily operable.
Unplug this apparatus during lightning storms or when unused for long periods of time.
Service
The unit should be serviced only by qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
safety-5v0 • November 11/2013
The exclamation point within an equilatereal triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
Le point d’exclamation à l’intérieur d’un triangle
équilatéral est prévu pour alerter l’utilisateur de la
présence d’instructions importantes dans la littérature accompagnant l’appareil en ce qui
concerne l’opération et la maintenance de cet
S2125A
appareil.
Instructions relatives au risque de feu,
choc électrique, ou blessures aux personnes
AVIS: AFIN DE REDUIRE LES RISQUE DE CHOC ELECTRIQUE,
N’ENLEVEZ PAS LE COUVERT (OU LE PANNEAU ARRIERE)
NE CONTIENT AUCUNE PIECE REPARABLE PAR L’UTILISATEUR.
CONSULTEZ UN TECHNICIEN QUALIFIE POUR L’ENTRETIENT
CE PRODUIT EST POUR L’USAGE À L’INTÉREUR SEULEMENT
Veuillez Lire le Manuel: Il contient des informations qui devraient êtres comprises avant
l’opération de votre appareil. Conservez. Gardez S.V.P. ces instructions pour consultations ultérieures et observez tous les avertissements.
Nettoyez seulement avec le tissu sec.
Emballage: Conservez la boite au cas ou l’appareil devait être retourner pour réparation. Avertissement: Pour réduire le risque de feu ou la décharge électrique, n'exposez pas
cet appareil à la pluie ou à l'humidité. N’utilisez pas cet appareil près de l’eau! Attention: Lors de l’utilisation de produits électrique, assurez-vous d’adhérer à des
précautions de bases incluant celle qui suivent:
Alimentation
L’appareil ne doit être branché qu’à une source d’alimentation correspondant au voltage spécifié dans le manuel ou tel qu’indiqué sur l’appareil. Cet appareil est équipé
d’une prise d’alimentation polarisée. Ne pas utiliser cet appareil avec un cordon de
raccordement à moins qu’il soit possible d’insérer complètement les trois lames. Des précautions doivent êtres prises afin d’eviter que le système de mise à la terre de l’appareil ne soit désengagé. Un appareil construit selon les normes de CLASS I devrait être raccordé à une prise murale d’alimentation avec connexion intacte de mise à la masse. Lorsqu’une prise de branchement ou un coupleur d'appareils est utilisée comme dispositif de débranchement, ce dispositif de débranchement devra demeurer pleinement fonctionnel avec raccordement à la masse.
Risque
Ne pas placer cet appareil sur un chariot, un support, un trépied ou une table instables.
L’appareil pourrait tomber et blesser quelqu’un ou subir des dommages importants. Utiliser seulement un chariot, un support, un trépied ou une table recommandés par le fabricant ou vendus avec le produit. Suivre les instructions du fabricant pour installer l’appareil et utiliser les accessoires recommandés par le fabricant. Utilisez seulement
les attachements/accessoires indiqués par le fabricant
Note: L'utilisation prolongée des écouteurs à un volume élevé peut
avoir des conséquences néfastes sur la santé sur vos oreilles. .
Il convient de ne pas placer sur l’appareil de sources de flammes nues, telles que
des bougies allumées.
L’appeil ne doit pas être exposé à des égouttements d’eau ou des éclaboussures
et qu’aucun objet rempli de liquide tel que des vases ne doit être placé sur l’appareil.
Assurez que lappareil est fourni de la propre ventilation. Ne procédez pas à
l’installation près de source de chaleur tels que radiateurs, registre de chaleur, fours ou autres appareils (incluant les amplificateurs) qui produisent de la chaleur.
Les dispositifs marqués d’une symbole “d’éclair” sont des parties dangereuses au toucher et que les câblages extérieurs connectés à ces dispositifs de connection extérieure doivent être effectivés par un opérateur formé ou en utilisant des cordons déjà préparés.
Cordon d’Alimentation
Ne pas enlever le dispositif de sécurité sur la prise polarisée ou la prise avec tige de
mise à la masse du cordon d’alimentation. Une prise polarisée dispose de deux lames dont une plus large que l’autre. Une prise avec tige de mise à la masse dispose de deux lames en plus d’une troisième tige qui connecte à la masse. La lame plus large ou la tige de mise à la masse est prévu pour votre sécurité. La prise murale est désuète si elle n’est pas conçue pour accepter ce type de prise avec dispositif de sécurité. Dans ce cas, contactez un électricien pour faire remplacer la prise murale. Évitez d’endommager le cordon d’alimentation. Protégez le cordon d’alimentation. Assurez­vous qu’on ne marche pas dessus et qu’on ne le pince pas en particulier aux prises.
N’UTILISEZ PAS L’APPAREIL si le cordon d’alimentation est endommagé. Pour
débrancher complètement cet appareil de l’alimentation CA principale, déconnectez le cordon d’alimentation de la prise d’alimentation murale. Le cordon d’alimentation du bloc d’alimentation de l’appareil doit demeurer pleinement fonctionnel.
Débranchez cet appareil durant les orages ou si inutilisé pendant de longues périodes.
Service
Consultez un technicien qualifié pour l’entretien de votre appareil. L'entretien est nécessaire quand l'appareil a été endommagé de quelque façon que se soit. Par exemple si le cordon d’alimentation ou la prise du cordon sont endommagés, si il y a eu du liquide qui a été renversé à l’intérieur ou des objets sont tombés dans l'appareil, si l'appareil a été exposé à la pluie ou à l'humidité, si il ne fonctionne pas normalement, ou a été échappé.
IMPORTANT SAFETY INSTRUCTIONS (UL60065)
The Lightning Flash with arrowhead symbol within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product enclosure that may be of sufficient magnitude to constitute a risk of shock to persons
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prongs are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particu­larly at plugs, convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power­supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
WARNING:
• To reduce the risk of fire or electric shock, do not expose this apparatus
to rain or moisture and objects filled with liquids, such as vases, should not be placed on this apparatus.
• To completely disconnect this apparatus from the ac mains, disconnect
the power supply cord plug from the ac receptacle.
• The mains plug of the power supply cord or appliance coupler shall
remain readily accessible.
CAUTION
TO PREVENT ELECTRIC SHOCK HAZARD,
DO NOT CONNECT TO MAINS POWER SUPPLY
WHILE GRILLE IS REMOVED.
Le symbole représentant un éclair avec une flèche à l’intérieur d’un triangle équilatéral est utilisé pour prévenir l’utilisateur de la présence d’une tension électrique dangereuse non isolée à l’intérieur de l’appareil. Cette tension est d’un niveau suffisam­ment élevé pour représenter un risque d’électrocution
Le symbole représentant un point d’exclamation à l’intérieur d’un triangle équilatéral, signale à l’utilisateur la présence d’instructions importantes relatives au fonctionnement et à l’entretien de l’appareil dans cette notice d’installation
1. Lisez ces instructions.
2. Conservez ces instructions.
3. Respecter tous les avertissements.
4. Suivez toutes les instructions.
5. N'utilisez pas l'appareil près de l'eau.
6. Nettoyer uniquement avec chiffon sec.
7. Ne bloquez pas les ouvertures de ventilation. Installer en suivant les instructions du fabricant.
8. Ne pas installer près des sources de chaleur telles que radiateurs, bouches de chaleur, four ou autres appareils (y compris les amplifica­teurs) produisant de la chaleur.
9. N'annulez pas l'objectif sécuritaire de la fiche polarisée ou de la tige de mise à la terre. Une fiche polarisée possède deux lames avec une plus large que l'autre. Une prise avec mise à la terre possède deux lames et une troisième tige. La lame large ou la troisième tige sont fournis pour votre sécurité. Si la fiche n'entre pas dans votre prise, consultez un électricien pour remplacer la prise obsolète.
10. Protéger le cordon d'alimentation des piétinements ou pince­ments en particulier près des fiches, des prises de courant et au point de sortie de l'appareil.
11. Utilisez uniquement les accessoires spécifiés par le fabricant.
12. Utiliser uniquement avec un charriot, stand, trépied ou une table spécifiée par le fabricant, ou vendus avec l'appareil.
13. Débranchez l'appareil durant un orage ou lorsqu'il reste inutilisé pendant de longues périodes de temps.
14. Confiez toute réparation à un technicien qualifié. Une réparation est nécessaire lorsque l'appareil a été endommagé de quelque façon que ce soit; comme lorsque le cordon d'alimentation ou la fiche est endom­magé, lorsque du liquide a été renversé ou des objets sont tombés à l'intérieur, lorsque l'appareil a été exposé à la pluie ou l'humidité, ne fonctionne pas normalement, ou est tombé.
AVERTISSEMENT:
• Pour réduire les risques d'incendie ou de choc électrique, ne pas
exposer cet appareil à la pluie ou à l'humidité et ne placez pas d’objets contenant des liquides, tels que des vases, sur l’appareil.
• Pour isoler totalement cet appareil de l'alimentation secteur, débran­chez totalement son cordon d'alimentation du réceptacle CA.
• La prise du cordon d’alimentation ou du prolongateur, si vous en utilisez
un comme dispositif de débranchement, doit rester facilement accessible
AVIS
POUR PRÉVENIR LES RISQUES
D'ÉLECTROCUTION,
NE PAS RACCORDER A L’ALIMENTATION ÉLEC­TRIQUE ALORS QUE LA GRILLE EST RETIRÉE.
UL60065 Safety Instructions Page-2v0
# Part# Description Qty
Labeled Components
1 CH1418 XFMR:AP4K 1
2448 15.00 AMP CIRCUIT BREAKER 1
2
3
3410 RED:LEFT/BLACK:RIGHT BIND POST TPP5 1
4
3415 RED:RIGHT/BLACK:LEFT BIND POST TPP5 1
5
3645 RECEPTACLE:INLET 1 3587 DPST ROKR SW QUIK 250"AC/PWR ON-OF 1
6
4174 FAN 80MM X 80MM 72CFM 24VDC 2
7
8
10021 AP SERIES ALU KNOB W SILVER STRIPE 2
9 3440 4PT MINI VERT ALT SWITCH 1 10 3522 DPDT MINI PC VERT SNP ALT 2 11
12 13 14
8
14
15
6956 SPKON 4C PCB MT HORZ GRY 2 3426 8' 3/16 SJT AC LINE CORD REMOVB-CSA 1 3425 DPDT PUSH SW PCMT 1 2340 20K 15C R/A 12MM DUAL 21DET 2 3498 1/4" JCK PCB MT HORZ 4
16 3922 XLR FEM PCB MT HORZ THIN SNAP 2
2
6
10
1
9
10
12
4
3
5
15 16
13
11
SERVICE-QuickGuide-apk4 SHORT VERSION 1v0.xls ftp.yorkville.com Combo Amplifier
7
AP4K PARTS Parts List 9/30/2014
K
L
T
K
K
C
A
A
T
K
T
R
YS # Description Qty. YS # Description Qty. YS # Description Qty.
6772 BRIDGE 25A 400V WIRE LEAD SIP 3 2328 8 CIR XH-HEADER 0.098IN 1 8832 6-32 X 1/4 PAN PH TAPTITE JS500 18 6425 BAV21 200V 0A25 DIODE T&R 34 3045 PATCH 06 22AWG 10.0 XH FLAT 1 8801 6-32 X 3/8 PAN PH TAPTITE JS500 3 6825 1N4148 75V 0A45 DIODE T&R 37 3060 PATCH 06 22AWG 23.0 XH FLAT-BLACK 1 8829 6-32 X 3/8 FLAT PH TAPTITE BO#C HEA 41 6438 1N4007 1000V 1A0 DIODE T&R 8 3028 PATCH 08 22AWG 18.0 XH 1 8828 6-32 X 3/4 PAN PH TAPTITE JS500 1 6934 MR854 400V 3A0 DIODE FASREC 28 4174 FAN 80MM X 80MM 72CFM 24VDC 2 8763 8-32 X 1/2 PAN PH MS JS500 BLAC 6426 1N5254B 27V0 0W5 ZENER 5% T&R 1 9575AP4K HEATSINK SMAL 6436 1N753ARL 6V2 0W5 ZENER 5% T&R 1 9576AP4K HEATSINK LARGE 2 8772 1/4-20 X 1 TRUSS PH MS JS500 BLACK 1 6440 1N750ARL 4V7 0W5 ZENER 5% T&R 1 3910 XTR SPRING 0.4" V TO220 9 8770 1/4-20 X 1 5/16 TRUSS PH MS JS500 1 6450 1N5242B 12V0 0W5 ZENER 5% T&R 4 4199 XTR SPRING CLIP TO220 4 7813 _47P 50V 5%CAP 0805 SMT NPO 2 6461 1N5240BRL 10V0 0W5 ZENER 5% T&R 2 9177AP4K/AM5CE XSISTOR SPRING 6 7927 100P 50V 10%CAP 0805 SMT NPO 6 6486 1N5244B 14V0 0W5 ZENER 5% T&R 2 3645 RECEPTACLE:INLE 6824 1N5246B 16V0 0W5 ZENER 5% T&R 24 3810 4" NYLON CABLE TIE 6 7871 470P 50V 5%CAP 0603 SMT NPO 2 5124 1N5338B 5V1 5W0 ZENER 5% T&R 4 3827 SQUARE BUMPER BUTTON BLAC 6875 1N5359B 24V0 5W0 ZENER 5% T&R 2 4096 CONN PLUG 4 POS. .084" V-2 FEMALE 1 7613 100N 25V 10%CAP 0805 SMT X7R 4 6871 MC7915CT TO220 N 15V0 REG V2 1 4146 3 PIN POWER PIN HEADER MALE POLZED 1 7875 100N 100V 10%CAP 1206 SMT X7R 4 6872 MC7815CT TO220 P 15V0 REG V1 1 4151 4 PIN POWER PIN HEADER MALE POLZED 2 7738 _10U0 16V 10%CAP 1206 SMT X7R 2 5101 BC550C TO92 NPN TRAN T&R TB 2 4163 5 PIN POWER PIN HEADER MALE POLZED 1 7750 CDSF4148 75V 0A15 1005 SMT 28 5103 MPSA06 TO92 NPN TRAN T&R TA 5 3576 SOCKET TERMINAL 14-20 AWG TAPE/REEL 4 7829 MM3Z10VT1G 10V0 0W2 5% SMT ZEN 1 5104 MPSA56 TO92 PNP TRAN T&R TA 4 8633 KNOB ROUND PUSHBUTTON 1/4" BLAC 5113 MPSA42 TO92 NPN TRAN T&R TA 1 10021AP SERIES ALU KNOB W SILVER STRIPE 2 7828 LM13700M XCONDUCTANC AMP SMT I 5105 MPSA13 TO92 NPN DARL T&R TA 4 3426 8' 3/16 SJT AC LINE CORD REMOVB-CS 5106 MPSA63 TO92 PNP DARL T&R T 6808 MJE15032 TO220 NPN TRAN TE 2 8854 6-32 X 1/4" 0.D. HEX NUT ZINC CLEAR 1 7669 TL072 DUAL OPAMP SMT SO-8 2 6809 MJE15033 TO220 PNP TRAN TE 2 8841 10-32 KEPS NUT TIN PLATED 8 7706 GRN LED 2V2 20MA 1206 SMT 7 6916 TIP107 TO220 PNP TRAN DARL TE 1 4124 SILPAD 1500ST 1.100 X0.820 BERQUIST 2 8154 RED LED 1V9 20MA 1206 SMT 2 6931 IRFP140N TO247 NCH MFET TM 12 4124 SILPAD 1500ST 1.100 X0.820 BERQUIST 2 8155 YEL LED 2V0 20MA 3216 SMT 2 6932 IRFP9140N TO247 PCH MFET TM 12 4171 SILPAD 1500ST 6.200 X1.100 BERQUIST 6 7821 W125 10R0 1% 0805 SMT RES 1 6988 MJL21194 TO3P NPN TRAN TK 6 4745 5W0 0R1 5% BLK RES 12 7854 W125 47R 5% 0805 SMT RES 1 6991 MJL21193 TO3P PNP TRAN TK 6 2005 1W00 0R47 5%FLAME PROOF T&R RES 4 7624 W100 100R 1% 0805 SMT RES 12 6804 MC33079P IC QUAD OP AMP 4 2006 1W00 1R 5%FLAME PROOF T&R RES 5 7671 W125 249R0 1% 0805 SMT RES 4 6882 TL072CP IC FET DUAL OP AMP 1 2007 W250 1R 5%FLAME PROOF T&R RES 4 7673 W100 475R 1% 0805 SMT RES 3 5190 MBS4992 TO92 8V5 DIAC T&R 2 4748 2W00 3R9 5% T&R RES 2 7689 W250 619R0 1% 1206 SMT RES 1 6517 BTB24-600 TO220AB 25A TRIAC 600V 2 2008 1W00 10R 5%FLAME PROOF T&R RES 4 7621 W100 1K0 1% 0805 SMT RES 4 6880 4N35 OPTO-COUPLER 2 2010 W600 10R0 2%FLAME PROOF T&R RES 10 7858 W125 1K5 5% 0805 SMT RES 1 6619 _10K 5% THERMISTOR VISH NTC 2 2039 W250 22R0 FUSIBLE T&R RES 4 7676 W100 2K0 1% 0805 SMT RES 7 5197 220P 100V 2%CAP T&R RAD CER.2NPO 4 2013 W600 22R1 1%FLAME PROOF T&R RES 6 7859 W125 2K2 5% 0805 SMT RES 2 5412 220P 100V 10%CAP T&R BEAD NPO 6 2019 W125 100R0 1%FLAME PROOF T&R RES 24 7860 W125 4K7 5% 0805 SMT RES 3 5417 330P 50V 10%CAP T&R BEAD NPO 2 2044 W250 100R0 FUSIBLE T&R RES 15 7822 W100 7K50 1% 0805 SMT RES 1 5816 680P 100V 5%CAP T&R RAD CER.2NPO 4 2023 W600 220R0 1%FLAME PROOF T&R RES 4 7681 W125 8K25 1% 0805 SMT RES 2 5206 __1N 400V 5%CAP T&R RAD .2FLM 2 2026 W250 332R0 1%FLAME PROOF T&R RES 2 7625 W100 10K0 1% 0805 SMT RES 23 5208 __2N2 400V 5%CAP T&R RAD .2FLM 4 2027 W250 390R 5%FLAME PROOF T&R RES 2 7628 W100 15K0 1% 0805 SMT RES 8 6451 __4N7 250V 20%CAP BLK 'Y' 10MM AC 1 5015 W250 475R 0.1% *** T&R RES 2 7823 W100 18K2 1% 0805 SMT RES 4 5433 __5N6 50V 10%CAP T&R BEAD X7R 4 4873 W250 680R 5% T&R RES 1 7636 W100 27K4 1% 0805 SMT RES 2 5210 _22N 100V 10%CAP T&R RAD .2FLM 6 2030 W600 681R 1%FLAME PROOF T&R RES 2 7863 W125 33K 5% 0805 SMT RES 6 5840 _22N 400V 10%CAP BLK RAD POLY FLM 2 2032 W250 1K 2%FLAME PROOF T&R RES 2 8135 W125 47K 5% 0805 SMT RES 8 5212 100N 63V 5%CAP T&R RAD .2FLM 4 2033 W600 1K 2%FLAME PROOF T&R RES 4 7824 W125 47K5 1% 0805 SMT RES 2 5212 100N 63V 5%CAP T&R RAD .2FLM 2 4981 W250 1K 5%MINI T&R RES 1 8051 W125 68K 5% 0805 SMT RES 2 5314 100N 50V 10%CAP T&R BEAD X7R 3 4791 W250 1K54 1% T&T RES 4 7626 W100 100K0 1% 0805 SMT RES 2 5231 220N 63V 5%CAP T&R RAD .2FLM 1 6104 W250 2K2 5%MINI T&R RES 2 7864 W125 100K 5% 0805 SMT RES 4 5233 330N 63V 5%CAP T&R RAD .2FLM 4 4764 W250 2K74 0.1% *** T&R RES 2 8060 W100 220K 5% 0603 SMT RES 2 5240 680N 63V 10%CAP T&R RAD .2FLM 6 6124 W250 3K 5%MINI T&R RES 4 7645 W100 475K 1% 0805 SMT RES 4 5266 680N 250V 20%CAP BLK 'X2' 27MM AC 1 6136 W250 3K3 5%MINI T&R RES 1 7648 W100 10M 1% 0805 SMT RES 8 5258 __4U7 63V 20%CAP T&R 8X7MM .2EL 2 4982 W250 4K7 5%MINI T&R RES 3 7805 MMBT3906LT1 PNP SOT-23 SMT T&R 7 5852 _10U 35V 20%CAP T&R 05X05MM EL 2 4639 W250 4K99 1% T&R RES 4 7838 MMBT3904 NPN SOT-23 SMT 8 5945 _10U 63V 20%CAP T&R RAD .2EL 3 4962 2W00 5K1 5% T&R RES 12 8663 11/64 NYLON SPACER (MICRO PLASTIC) 48 5961 _33U 16V 20%CAP T&R RAD .2IN NP 6 5016 1W00 9K760 0.5% *** T&R RES 2 8981 RUBBER WASHER .312OD .150ID .093TH 14 5961 _33U 16V 20%CAP T&R RAD .2IN NP 3 4806 2W00 10K0 5% T&R RES 12 8485 #6 SPLIT WASHER ZINC 1 5879 100U 16V 20%CAP T&R 8X7MM .2EL 6 4829 W250 10K 5% T&R RES 2 8818 3/4 OD X 3/8 ID X .080 THICK WASHER 2 5630 330U 25V 20%CAP BLK 10X13MM EL 4 6116 W250 10K0 1%MINI MF T&R RES 11 3440 4PDT MINI VERT ALT SWITCH 1 5618 470U 25V 20%CAP BLK 10X15MM EL 1 4775 W250 14K0 1% T&R RES 2 3425 DPDT PUSH SW PCMT BREAK B4 MAKE 1 5899 3300U 100V 20%CAP BLK 25X50MM ELS 8 4630 W500 15K 5% T&R RES 4 3522 DPDT MINI PC VERT SNP AL 5896 4700U 80V 20%CAP BLK 25X50MM ELS 6 4979 W250 15K 5%MINI T&R RES 4 3688 DPDT ROKR SW QUIK 250"AC/25A ON-OFF 1 5898 8200U 50V 20%CAP 25X50MM ELS 4 6556 W250 15K0 1%MINI T&R RES 2 3887ADHESIVE LINED GROMMET EDGING 2 2340 _20K 15C R/A 12MM DUAL 21DET P34 2 6118 W250 22K 5%MINI T&R RES 4 CH1418 XFMR:AP4 4520 _10K TRIM POT 2 4902 W250 24K 5% T&R RES 4 9176AP4K FRONT PANEL ALUM. DIE CAS 2448 15.00 AMP CIRCUIT BREAKE 3820 ___4UH COIL 14AWG ZOBEL HORIZONTAL 2 4890 W250 30K 5% T&R RES 2 3441 CLIP 250X032 16-14AWG RIGHT ANGLE 4 4840 W250 33K 5% T&R RES 2 3492 GROUND LUG FOR NO8-10 STUD 1 4834 W250 47K 5% T&R RES 2 3526 CLIP 250X032 12-10AWG DISCO-LOK 3 4877 W250 49K90 0.1% T&R RES 2 3618 STAR RING TERMINAL14-16AWG #10SCREW 4 4772 W250 82K5 1% T&R RES 4 3410 RED:LEFT/BLACK:RIGHT BIND POST TPP5 1 6120 W250 100K 5%MINI T&R RES 5 3415 RED:RIGHT/BLACK:LEFT BIND POST TPP5 1 6126 W250 220K 5%MINI T&R RES 2 3498 1/4" JCK PCB MT HORZ 4 6145 W250 249K 1%MINI T&R RES 2 6956 SPKON 4C PCB MT HORZ GRY #4 2 3700 RELAY 2C 01AMP DC24 015MA PC-S 2 3922 XLR FEML PCB MT HORZ THIN SNAP-IN 2 4094 RELAY 1C 16AMP DC12 034MA PC-C 1 4056 2 CIR XH-HEADER 0.098IN 2 8729 #4 X 3/8 FLAT QUAD TYPE A JS500 BLK 8 2327 6 CIR XH-HEADER 0.098IN 2 8799 #6 X 1/4 PAN PH TYPE B JS500 2 2327 6 CIR XH-HEADER 0.098IN 2 8865 4-40 X 5/16 PAN PH MS JS500 2 2328 8 CIR XH-HEADER 0.098IN 1 8822 6-32 X 1/4 PAN PH MS ZN C/W SPLIT_W 4
2 8800 6-32 KEPS NUT ZINC 1 7668 MC33079D QUAD OPAMP SMT SO14 3
1 6129 W250 27K 5%MINI T&R RES 1
4 8809 10-32 X 1/4 PAN PH TAPTITE JS500 8
1 7604 180P 50V 5%CAP 0805 SMT NPO 6
4 7693 __1N 50V 5%CAP 0805 SMT NPO 2
1 7615 MMSZ46BLT1 16V0 0W35 5% SMT ZEN 2
1 7659 LM339M QUAD SS COMP SMT SO-14 2
14
2
2
1 1
M1575 REF Parts Reference List 9/30/2014
F
A
RE
I-ASS M1575-59 AP4K INTERFACE/DISPLAY PCB C42 5961 _33U 16V 20%CAP T&R RAD .2IN NP C75 5240 680N 63V 10%CAP T&R RAD .2FLM C76 5240 680N 63V 10%CAP T&R RAD .2FLM C77 5240 680N 63V 10%CAP T&R RAD .2FLM C78 5240 680N 63V 10%CAP T&R RAD .2FLM C200A 5961 _33U 16V 20%CAP T&R RAD .2IN NP C200B 5961 _33U 16V 20%CAP T&R RAD .2IN NP C25A 5212 100N 63V 5%CAP T&R RAD .2FLM C25B 5212 100N 63V 5%CAP T&R RAD .2FLM C31A 5233 330N 63V 5%CAP T&R RAD .2FLM C31B 5233 330N 63V 5%CAP T&R RAD .2FLM C38A 5240 680N 63V 10%CAP T&R RAD .2FLM C38B 5240 680N 63V 10%CAP T&R RAD .2FLM C39A 5233 330N 63V 5%CAP T&R RAD .2FLM C39B 5233 330N 63V 5%CAP T&R RAD .2FLM C3A 5852 _10U 35V 20%CAP T&R 05X05MM EL C3B 5852 _10U 35V 20%CAP T&R 05X05MM EL P1 2340 _20K 15C R/A 12MM DUAL 21DET P34 P2 2340 _20K 15C R/A 12MM DUAL 21DET P34 PCB1 M1575BLANK 2_OZ 2SD 115.47SQIN 6PER AP4K S2 3522 DPDT MINI PC VERT SNP ALT S4 3440 4PDT MINI VERT ALT SWITCH S5 3522 DPDT MINI PC VERT SNP ALT W1 2328 8 CIR XH-HEADER 0.098IN W8 2327 6 CIR XH-HEADER 0.098IN W12 2327 6 CIR XH-HEADER 0.098IN W20 3596 36PIN BREAKAWAY .15GOLD .100
YS # Description
M1530 REF Parts Reference List 9/30/2014
nREF
nREF
nREF
n
REFYS # Descriptio
C1 6451 __4N7 250V 20%CAP BLK 'Y' 10MM AC C44A 5879 100U 16V 20%CAP T&R 8X7MM .2EL D41B 6934 MR854 400V 3A0 DIODE FASREC Q4 6931 IRFP140N TO247 NCH MFET TM C2 5896 4700U 80V 20%CAP BLK 25X50MM ELS C44B 5879 100U 16V 20%CAP T&R 8X7MM .2EL D41B1 6934 MR854 400V 3A0 DIODE FASREC Q5 6932 IRFP9140N TO247 PCH MFET TM C3 5266 680N 250V 20%CAP BLK 'X2' 27MM AC C45A 5258 __4U7 63V 20%CAP T&R 8X7MM .2EL D42A 6934 MR854 400V 3A0 DIODE FASREC Q6 6932 IRFP9140N TO247 PCH MFET TM C4 5961 _33U 16V 20%CAP T&R RAD .2IN NP C45B 5258 __4U7 63V 20%CAP T&R 8X7MM .2EL D42B 6934 MR854 400V 3A0 DIODE FASREC Q7 6932 IRFP9140N TO247 PCH MFET TM C5 5961 _33U 16V 20%CAP T&R RAD .2IN NP D1 6436 1N753ARL 6V2 0W5 ZENER 5% T&R D43A 6934 MR854 400V 3A0 DIODE FASREC Q8 6932 IRFP9140N TO247 PCH MFET TM C6 5412 220P 100V 10%CAP T&R BEAD NPO D2 6825 1N4148 75V 0A45 DIODE T&R D43B 6934 MR854 400V 3A0 DIODE FASREC Q9 6931 IRFP140N TO247 NCH MFET TM C7 5417 330P 50V 10%CAP T&R BEAD NPO D3 6825 1N4148 75V 0A45 DIODE T&R D44A 6934 MR854 400V 3A0 DIODE FASREC Q10 6931 IRFP140N TO247 NCH MFET TM C8 5206 __1N 400V 5%CAP T&R RAD .2FLM D4 6825 1N4148 75V 0A45 DIODE T&R D44B 6934 MR854 400V 3A0 DIODE FASREC Q11 6931 IRFP140N TO247 NCH MFET TM C9 5208 __2N2 400V 5%CAP T&R RAD .2FLM D5 6825 1N4148 75V 0A45 DIODE T&R D45A 6825 1N4148 75V 0A45 DIODE T&R Q12 6931 IRFP140N TO247 NCH MFET TM C10 5208 __2N2 400V 5%CAP T&R RAD .2FLM D6 6825 1N4148 75V 0A45 DIODE T&R D45B 6825 1N4148 75V 0A45 DIODE T&R Q13 6932 IRFP9140N TO247 PCH MFET TM C11 5816 680P 100V 5%CAP T&R RAD CER.2NPO D7 6825 1N4148 75V 0A45 DIODE T&R D46A 6825 1N4148 75V 0A45 DIODE T&R Q14 6932 IRFP9140N TO247 PCH MFET TM C12 5630 330U 25V 20%CAP BLK 10X13MM EL D8 6825 1N4148 75V 0A45 DIODE T&R D46B 6825 1N4148 75V 0A45 DIODE T&R Q15 6932 IRFP9140N TO247 PCH MFET TM C13 5630 330U 25V 20%CAP BLK 10X13MM EL D9 6825 1N4148 75V 0A45 DIODE T&R D47A 6825 1N4148 75V 0A45 DIODE T&R Q16 6932 IRFP9140N TO247 PCH MFET TM C14 5433 __5N6 50V 10%CAP T&R BEAD X7R D10 6438 1N4007 1000V 1A0 DIODE T&R D47B 6825 1N4148 75V 0A45 DIODE T&R Q17 5104 MPSA56 TO92 PNP TRAN T&R TA C15 5433 __5N6 50V 10%CAP T&R BEAD X7R D11 6438 1N4007 1000V 1A0 DIODE T&R D49A 6450 1N5242B 12V0 0W5 ZENER 5% T&R Q18 5103 MPSA06 TO92 NPN TRAN T&R TA C16 5961 _33U 16V 20%CAP T&R RAD .2IN NP D12 6825 1N4148 75V 0A45 DIODE T&R D49B 6450 1N5242B 12V0 0W5 ZENER 5% T&R Q19 5104 MPSA56 TO92 PNP TRAN T&R TA C17 5961 _33U 16V 20%CAP T&R RAD .2IN NP D13 6825 1N4148 75V 0A45 DIODE T&R D50A 6425 BAV21 200V 0A25 DIODE T&R Q20 5103 MPSA06 TO92 NPN TRAN T&R TA C18 5206 __1N 400V 5%CAP T&R RAD .2FLM D14 6825 1N4148 75V 0A45 DIODE T&R D50A1 6425 BAV21 200V 0A25 DIODE T&R Q21 5105 MPSA13 TO92 NPN DARL T&R TA C19 5412 220P 100V 10%CAP T&R BEAD NPO D15 6825 1N4148 75V 0A45 DIODE T&R D50A2 6425 BAV21 200V 0A25 DIODE T&R Q22 5105 MPSA13 TO92 NPN DARL T&R TA C20 5417 330P 50V 10%CAP T&R BEAD NPO D16 6825 1N4148 75V 0A45 DIODE T&R D50B 6425 BAV21 200V 0A25 DIODE T&R Q23 6988 MJL21194 TO3P NPN TRAN TK C21 5433 __5N6 50V 10%CAP T&R BEAD X7R D17 6825 1N4148 75V 0A45 DIODE T&R D50B1 6425 BAV21 200V 0A25 DIODE T&R Q24 6991 MJL21193 TO3P PNP TRAN TK C22 5433 __5N6 50V 10%CAP T&R BEAD X7R D18 6825 1N4148 75V 0A45 DIODE T&R D51A 6425 BAV21 200V 0A25 DIODE T&R Q25 6932 IRFP9140N TO247 PCH MFET TM C23 5208 __2N2 400V 5%CAP T&R RAD .2FLM D19 6825 1N4148 75V 0A45 DIODE T&R D51B 6425 BAV21 200V 0A25 DIODE T&R Q26 6932 IRFP9140N TO247 PCH MFET TM C24 5208 __2N2 400V 5%CAP T&R RAD .2FLM D20 6438 1N4007 1000V 1A0 DIODE T&R D51B1 6425 BAV21 200V 0A25 DIODE T&R Q27 6931 IRFP140N TO247 NCH MFET TM C25 5630 330U 25V 20%CAP BLK 10X13MM EL D21 6438 1N4007 1000V 1A0 DIODE T&R D52A 6425 BAV21 200V 0A25 DIODE T&R Q28 6931 IRFP140N TO247 NCH MFET TM C26 5630 330U 25V 20%CAP BLK 10X13MM EL D22 6934 MR854 400V 3A0 DIODE FASREC D52B 6425 BAV21 200V 0A25 DIODE T&R Q29 6932 IRFP9140N TO247 PCH MFET TM C27 5816 680P 100V 5%CAP T&R RAD CER.2NPO D23 6934 MR854 400V 3A0 DIODE FASREC D52B1 6425 BAV21 200V 0A25 DIODE T&R Q30 6932 IRFP9140N TO247 PCH MFET TM C28 5945 _10U 63V 20%CAP T&R RAD .2EL D24 6825 1N4148 75V 0A45 DIODE T&R D53A 6425 BAV21 200V 0A25 DIODE T&R Q31 6931 IRFP140N TO247 NCH MFET TM C29 5945 _10U 63V 20%CAP T&R RAD .2EL D25 6825 1N4148 75V 0A45 DIODE T&R D53B 6425 BAV21 200V 0A25 DIODE T&R Q32 6931 IRFP140N TO247 NCH MFET TM C30 5945 _10U 63V 20%CAP T&R RAD .2EL D26 6425 BAV21 200V 0A25 DIODE T&R D54A 6425 BAV21 200V 0A25 DIODE T&R Q35 6916 TIP107 TO220 PNP TRAN DARL TE C31 5231 220N 63V 5%CAP T&R RAD .2FLM D27 6425 BAV21 200V 0A25 DIODE T&R D54B 6425 BAV21 200V 0A25 DIODE T&R Q36 5113 MPSA42 TO92 NPN TRAN T&R TA C32 5898 8200U 50V 20%CAP 25X50MM ELS D28 6934 MR854 400V 3A0 DIODE FASREC D55A 6425 BAV21 200V 0A25 DIODE T&R Q38 6517 BTB24-600 TO220AB 25A TRIAC 600V C33 5898 8200U 50V 20%CAP 25X50MM ELS D29 6934 MR854 400V 3A0 DIODE FASREC D55A1 6425 BAV21 200V 0A25 DIODE T&R Q39 5103 MPSA06 TO92 NPN TRAN T&R TA C34 5896 4700U 80V 20%CAP BLK 25X50MM ELS D32 6438 1N4007 1000V 1A0 DIODE T&R D55A2 6425 BAV21 200V 0A25 DIODE T&R Q40 6517 BTB24-600 TO220AB 25A TRIAC 600V C35 5896 4700U 80V 20%CAP BLK 25X50MM ELS D33 6438 1N4007 1000V 1A0 DIODE T&R D55B 6425 BAV21 200V 0A25 DIODE T&R Q41 5190 MBS4992 TO92 8V5 DIAC T&R C36 5899 3300U 100V 20%CAP BLK 25X50MM ELS D34 6438 1N4007 1000V 1A0 DIODE T&R D55B1 6425 BAV21 200V 0A25 DIODE T&R Q42 5190 MBS4992 TO92 8V5 DIAC T&R C37 5899 3300U 100V 20%CAP BLK 25X50MM ELS D35 6438 1N4007 1000V 1A0 DIODE T&R D62A 6825 1N4148 75V 0A45 DIODE T&R Q10A 5103 MPSA06 TO92 NPN TRAN T&R TA C38 5896 4700U 80V 20%CAP BLK 25X50MM ELS D56 6825 1N4148 75V 0A45 DIODE T&R D62B 6825 1N4148 75V 0A45 DIODE T&R Q10B 5103 MPSA06 TO92 NPN TRAN T&R TA C39 5899 3300U 100V 20%CAP BLK 25X50MM ELS D57 6825 1N4148 75V 0A45 DIODE T&R D63A 6824 1N5246B 16V0 0W5 ZENER 5% T&R Q11A 5104 MPSA56 TO92 PNP TRAN T&R TA C40 5879 100U 16V 20%CAP T&R 8X7MM .2EL D58 6825 1N4148 75V 0A45 DIODE T&R D63B 6824 1N5246B 16V0 0W5 ZENER 5% T&R Q11B 5104 MPSA56 TO92 PNP TRAN T&R TA C41 5879 100U 16V 20%CAP T&R 8X7MM .2EL D59 6772 BRIDGE 25A 400V WIRE LEAD SIP D63B1 6824 1N5246B 16V0 0W5 ZENER 5% T&R Q12A 6988 MJL21194 TO3P NPN TRAN TK C42 5212 100N 63V 5%CAP T&R RAD .2FLM D60 6772 BRIDGE 25A 400V WIRE LEAD SIP D64A 6824 1N5246B 16V0 0W5 ZENER 5% T&R Q12B 6988 MJL21194 TO3P NPN TRAN TK C43 5899 3300U 100V 20%CAP BLK 25X50MM ELS D61 6772 BRIDGE 25A 400V WIRE LEAD SIP D64B 6824 1N5246B 16V0 0W5 ZENER 5% T&R Q13A 6991 MJL21193 TO3P PNP TRAN TK C44 5898 8200U 50V 20%CAP 25X50MM ELS D71 6426 1N5254B 27V0 0W5 ZENER 5% T&R D64B1 6824 1N5246B 16V0 0W5 ZENER 5% T&R Q13B 6991 MJL21193 TO3P PNP TRAN TK C45 5898 8200U 50V 20%CAP 25X50MM ELS D14A 6425 BAV21 200V 0A25 DIODE T&R D66A 6824 1N5246B 16V0 0W5 ZENER 5% T&R Q16A 6808 MJE15032 TO220 NPN TRAN TE C46 5212 100N 63V 5%CAP T&R RAD .2FLM D14B 6425 BAV21 200V 0A25 DIODE T&R D66B 6824 1N5246B 16V0 0W5 ZENER 5% T&R Q16B 6808 MJE15032 TO220 NPN TRAN TE C47 5618 470U 25V 20%CAP BLK 10X15MM EL D15A 6425 BAV21 200V 0A25 DIODE T&R D66B1 6824 1N5246B 16V0 0W5 ZENER 5% T&R Q17A 6809 MJE15033 TO220 PNP TRAN TE C48 5314 100N 50V 10%CAP T&R BEAD X7R D15B 6425 BAV21 200V 0A25 DIODE T&R D67A 6824 1N5246B 16V0 0W5 ZENER 5% T&R Q17B 6809 MJE15033 TO220 PNP TRAN TE C49 5896 4700U 80V 20%CAP BLK 25X50MM ELS D18A 6824 1N5246B 16V0 0W5 ZENER 5% T&R D67B 6824 1N5246B 16V0 0W5 ZENER 5% T&R Q26A 6988 MJL21194 TO3P NPN TRAN TK C50 5899 3300U 100V 20%CAP BLK 25X50MM ELS D18B 6824 1N5246B 16V0 0W5 ZENER 5% T&R D67B1 6824 1N5246B 16V0 0W5 ZENER 5% T&R Q26B 6988 MJL21194 TO3P NPN TRAN TK C51 5899 3300U 100V 20%CAP BLK 25X50MM ELS D19A 6824 1N5246B 16V0 0W5 ZENER 5% T&R D70A 6825 1N4148 75V 0A45 DIODE T&R Q26B1 6988 MJL21194 TO3P NPN TRAN TK C52 5896 4700U 80V 20%CAP BLK 25X50MM ELS D19B 6824 1N5246B 16V0 0W5 ZENER 5% T&R D70B 6825 1N4148 75V 0A45 DIODE T&R Q27A 6991 MJL21193 TO3P PNP TRAN TK C54 5314 100N 50V 10%CAP T&R BEAD X7R D20A 6934 MR854 400V 3A0 DIODE FASREC D71A 6425 BAV21 200V 0A25 DIODE T&R Q27B 6991 MJL21193 TO3P PNP TRAN TK C55 5314 100N 50V 10%CAP T&R BEAD X7R D20B 6934 MR854 400V 3A0 DIODE FASREC D71B 6425 BAV21 200V 0A25 DIODE T&R Q27B1 6991 MJL21193 TO3P PNP TRAN TK C56 5899 3300U 100V 20%CAP BLK 25X50MM ELS D21A 6934 MR854 400V 3A0 DIODE FASREC D72A 6825 1N4148 75V 0A45 DIODE T&R Q30A 5105 MPSA13 TO92 NPN DARL T&R TA C57 5899 3300U 100V 20%CAP BLK 25X50MM ELS D21B 6934 MR854 400V 3A0 DIODE FASREC D72B 6825 1N4148 75V 0A45 DIODE T&R Q30B 5105 MPSA13 TO92 NPN DARL T&R TA C59 5816 680P 100V 5%CAP T&R RAD CER.2NPO D21B1 6934 MR854 400V 3A0 DIODE FASREC D73A 6425 BAV21 200V 0A25 DIODE T&R Q31A 5101 BC550C TO92 NPN TRAN T&R TB C61 5816 680P 100V 5%CAP T&R RAD CER.2NPO D22A 6934 MR854 400V 3A0 DIODE FASREC D73B 6425 BAV21 200V 0A25 DIODE T&R Q31B 5101 BC550C TO92 NPN TRAN T&R TB C69 5197 220P 100V 2%CAP T&R RAD CER.2NPO D22B 6934 MR854 400V 3A0 DIODE FASREC D8A 6450 1N5242B 12V0 0W5 ZENER 5% T&R Q36A 6619 _10K 3% THERMISTOR VISH NTC C70 5197 220P 100V 2%CAP T&R RAD CER.2NPO D22B1 6934 MR854 400V 3A0 DIODE FASREC D8B 6450 1N5242B 12V0 0W5 ZENER 5% T&R Q36B 6619 _10K 3% THERMISTOR VISH NTC C71 5197 220P 100V 2%CAP T&R RAD CER.2NPO D23A 6934 MR854 400V 3A0 DIODE FASREC D9A 6486 1N5244B 14V0 0W5 ZENER 5% T&R Q7A 5106 MPSA63 TO92 PNP DARL T&R TA C72 5197 220P 100V 2%CAP T&R RAD CER.2NPO D23B 6934 MR854 400V 3A0 DIODE FASREC D9B 6486 1N5244B 14V0 0W5 ZENER 5% T&R Q7B 5106 MPSA63 TO92 PNP DARL T&R TA C79 5961 _33U 16V 20%CAP T&R RAD .2IN NP D23B1 6934 MR854 400V 3A0 DIODE FASREC J2 3922 XLR FEML PCB MT HORZ THIN SNAP-IN R1 6129 W250 27K 5%MINI T&R RES C80 5961 _33U 16V 20%CAP T&R RAD .2IN NP D24A 6824 1N5246B 16V0 0W5 ZENER 5% T&R J3 3922 XLR FEML PCB MT HORZ THIN SNAP-IN R2 6136 W250 3K3 5%MINI T&R RES C10A 5212 100N 63V 5%CAP T&R RAD .2FLM D24B 6824 1N5246B 16V0 0W5 ZENER 5% T&R J4 3498 1/4 JCK PCB MT HORZ " R3 2044 W250 100R0 FUSIBLE T&R RES C10A1 5210 _22N 100V 10%CAP T&R RAD .2FLM D25A 6824 1N5246B 16V0 0W5 ZENER 5% T&R J5 3498 1/4 JCK PCB MT HORZ " R5 4764 W250 2K74 0.1% *** T&R RES C10A2 5210 _22N 100V 10%CAP T&R RAD .2FLM D25B 6824 1N5246B 16V0 0W5 ZENER 5% T&R J6 3498 1/4 JCK PCB MT HORZ " R6 4877 W250 49K90 0.1% T&R RES C10B 5212 100N 63V 5%CAP T&R RAD .2FLM D26A 6825 1N4148 75V 0A45 DIODE T&R J7 3498 1/4 JCK PCB MT HORZ " R7 5015 W250 475R 0.1% *** T&R RES C16A 5210 _22N 100V 10%CAP T&R RAD .2FLM D26B 6825 1N4148 75V 0A45 DIODE T&R J3A 6956 SPKON 4C PCB MT HORZ GRY #4 R8 5016 1W00 9K760 0.5% *** T&R RES C16B 5210 _22N 100V 10%CAP T&R RAD .2FLM D27A 6825 1N4148 75V 0A45 DIODE T&R J3B 6956 SPKON 4C PCB MT HORZ GRY #4 R9 6116 W250 10K0 1%MINI MF T&R RES C17A 5210 _22N 100V 10%CAP T&R RAD .2FLM D27B 6825 1N4148 75V 0A45 DIODE T&R K1 4094 RELAY 1C 16AMP DC12 034MA PC-C R10 6104 W250 2K2 5%MINI T&R RES C17B 5210 _22N 100V 10%CAP T&R RAD .2FLM D28A 6425 BAV21 200V 0A25 DIODE T&R K2 3700 RELAY 2C 01AMP DC24 015MA PC-S R11 2026 W250 332R0 1%FLAME PROOF T&R RES C1A 5412 220P 100V 10%CAP T&R BEAD NPO D28B 6425 BAV21 200V 0A25 DIODE T&R K3 3700 RELAY 2C 01AMP DC24 015MA PC-S R12 2044 W250 100R0 FUSIBLE T&R RES C1B 5412 220P 100V 10%CAP T&R BEAD NPO D29A 6425 BAV21 200V 0A25 DIODE T&R L1A 3820 ___4UH COIL 14AWG ZOBEL HORIZONTAL R13 2039 W250 22R0 FUSIBLE T&R RES C24A 5840 _22N 400V 10%CAP BLK RAD POLY FLM D29B 6425 BAV21 200V 0A25 DIODE T&R L1B 3820 ___4UH COIL 14AWG ZOBEL HORIZONTAL R14 2044 W250 100R0 FUSIBLE T&R RES C24B 5840 _22N 400V 10%CAP BLK RAD POLY FLM D30A 6934 MR854 400V 3A0 DIODE FASREC P1A 4520 _10K TRIM POT R15 2044 W250 100R0 FUSIBLE T&R RES C2A 5412 220P 100V 10%CAP T&R BEAD NPO D30B 6934 MR854 400V 3A0 DIODE FASREC P1B 4520 _10K TRIM POT R16 2039 W250 22R0 FUSIBLE T&R RES C2B 5412 220P 100V 10%CAP T&R BEAD NPO D31A 6934 MR854 400V 3A0 DIODE FASREC Q1 6931 IRFP140N TO247 NCH MFET TM R17 4775 W250 14K0 1% T&R RES C43A 5879 100U 16V 20%CAP T&R 8X7MM .2EL D31B 6934 MR854 400V 3A0 DIODE FASREC Q2 6931 IRFP140N TO247 NCH MFET TM R18 2027 W250 390R 5%FLAME PROOF T&R RES C43B 5879 100U 16V 20%CAP T&R 8X7MM .2EL D41A 6934 MR854 400V 3A0 DIODE FASREC Q3 6931 IRFP140N TO247 NCH MFET TM R19 2010 W600 10R0 2%FLAME PROOF T&R RES
YS # Descriptio
YS # Descriptio
YS # Descriptio
Page 1 of 2
M1530 REF Parts Reference List 9/30/2014
nREF
nREF
n
REFYS # Descriptio
R20 2010 W600 10R0 2%FLAME PROOF T&R RES R119B 2019 W125 100R0 1%FLAME PROOF T&R RES R75A 4962 2W00 5K1 5% T&R RES R21 2010 W600 10R0 2%FLAME PROOF T&R RES R119B1 2019 W125 100R0 1%FLAME PROOF T&R RES R75A1 4962 2W00 5K1 5% T&R RES R22 2010 W600 10R0 2%FLAME PROOF T&R RES R120A 2019 W125 100R0 1%FLAME PROOF T&R RES R75A2 4962 2W00 5K1 5% T&R RES R23 2032 W250 1K 2%FLAME PROOF T&R RES R120B 2019 W125 100R0 1%FLAME PROOF T&R RES R75B 4962 2W00 5K1 5% T&R RES R24 2030 W600 681R 1%FLAME PROOF T&R RES R120B1 2019 W125 100R0 1%FLAME PROOF T&R RES R75B1 4962 2W00 5K1 5% T&R RES R25 4979 W250 15K 5%MINI T&R RES R121A 2019 W125 100R0 1%FLAME PROOF T&R RES R76A 2008 1W00 10R 5%FLAME PROOF T&R RES R26 4979 W250 15K 5%MINI T&R RES R121B 2019 W125 100R0 1%FLAME PROOF T&R RES R76B 2008 1W00 10R 5%FLAME PROOF T&R RES R27 6120 W250 100K 5%MINI T&R RES R121B1 2019 W125 100R0 1%FLAME PROOF T&R RES R77A 2008 1W00 10R 5%FLAME PROOF T&R RES R28 6120 W250 100K 5%MINI T&R RES R124 6120 W250 100K 5%MINI T&R RES R77B 2008 1W00 10R 5%FLAME PROOF T&R RES R29 6116 W250 10K0 1%MINI MF T&R RES R126A 2019 W125 100R0 1%FLAME PROOF T&R RES R78A 4748 2W00 3R9 5% T&R RES R30 4877 W250 49K90 0.1% T&R RES R126B 2019 W125 100R0 1%FLAME PROOF T&R RES R78B 4748 2W00 3R9 5% T&R RES R31 6104 W250 2K2 5%MINI T&R RES R126B1 2019 W125 100R0 1%FLAME PROOF T&R RES R93A 4745 5W0 0R1 5% BLK RES R32 4764 W250 2K74 0.1% *** T&R RES R127A 2019 W125 100R0 1%FLAME PROOF T&R RES R93B 4745 5W0 0R1 5% BLK RES R33 5015 W250 475R 0.1% *** T&R RES R127B 2019 W125 100R0 1%FLAME PROOF T&R RES R93B1 4745 5W0 0R1 5% BLK RES R34 5016 1W00 9K760 0.5% *** T&R RES R1A 4639 W250 4K99 1% T&R RES R94A 4745 5W0 0R1 5% BLK RES R35 2026 W250 332R0 1%FLAME PROOF T&R RES R1B 4639 W250 4K99 1% T&R RES R94B 4745 5W0 0R1 5% BLK RES R36 2044 W250 100R0 FUSIBLE T&R RES R282 4630 W500 15K 5% T&R RES R94B1 4745 5W0 0R1 5% BLK RES R37 2039 W250 22R0 FUSIBLE T&R RES R284 4630 W500 15K 5% T&R RES R95A 2005 1W00 0R47 5%FLAME PROOF T&R RES R38 2044 W250 100R0 FUSIBLE T&R RES R285 4630 W500 15K 5% T&R RES R95B 2005 1W00 0R47 5%FLAME PROOF T&R RES R39 2044 W250 100R0 FUSIBLE T&R RES R286 4630 W500 15K 5% T&R RES R96A 2005 1W00 0R47 5%FLAME PROOF T&R RES R40 2039 W250 22R0 FUSIBLE T&R RES R2A 4639 W250 4K99 1% T&R RES R96B 2005 1W00 0R47 5%FLAME PROOF T&R RES R41 2027 W250 390R 5%FLAME PROOF T&R RES R2B 4639 W250 4K99 1% T&R RES R97A 4772 W250 82K5 1% T&R RES R42 4775 W250 14K0 1% T&R RES R31A 4829 W250 10K 5% T&R RES R97B 4772 W250 82K5 1% T&R RES R43 4979 W250 15K 5%MINI T&R RES R31B 4829 W250 10K 5% T&R RES R98A 4772 W250 82K5 1% T&R RES R44 2010 W600 10R0 2%FLAME PROOF T&R RES R32A 6118 W250 22K 5%MINI T&R RES R98B 4772 W250 82K5 1% T&R RES R45 2010 W600 10R0 2%FLAME PROOF T&R RES R32B 6118 W250 22K 5%MINI T&R RES S1 3425 DPDT PUSH SW PCMT BREAK B4 MAKE R46 2010 W600 10R0 2%FLAME PROOF T&R RES R33A 6124 W250 3K 5%MINI T&R RES U1 6804 MC33079P IC QUAD OP AMP R47 2010 W600 10R0 2%FLAME PROOF T&R RES R33B 6124 W250 3K 5%MINI T&R RES U3 6804 MC33079P IC QUAD OP AMP R48 2032 W250 1K 2%FLAME PROOF T&R RES R34A 6124 W250 3K 5%MINI T&R RES U4 6882 TL072CP IC FET DUAL OP AMP R49 2030 W600 681R 1%FLAME PROOF T&R RES R34B 6124 W250 3K 5%MINI T&R RES U5 6871 MC7915CT TO220 N 15V0 REG V2 R50 4979 W250 15K 5%MINI T&R RES R3A 6116 W250 10K0 1%MINI MF T&R RES U6 6872 MC7815CT TO220 P 15V0 REG V1 R51 4745 5W0 0R1 5% BLK RES R3B 6116 W250 10K0 1%MINI MF T&R RES U8 6880 4N35 OPTO-COUPLER R52 4981 W250 1K 5%MINI T&R RES R43A 2033 W600 1K 2%FLAME PROOF T&R RES U9 6880 4N35 OPTO-COUPLER R53 6120 W250 100K 5%MINI T&R RES R43B 2033 W600 1K 2%FLAME PROOF T&R RES U10 6804 MC33079P IC QUAD OP AMP R54 6120 W250 100K 5%MINI T&R RES R44A 2033 W600 1K 2%FLAME PROOF T&R RES U11 6804 MC33079P IC QUAD OP AMP R55 4745 5W0 0R1 5% BLK RES R44B 2033 W600 1K 2%FLAME PROOF T&R RES W2 4163 5 PIN POWER PIN HEADER MALE POLZED R56 2019 W125 100R0 1%FLAME PROOF T&R RES R45A 4902 W250 24K 5% T&R RES W7 2328 8 CIR XH-HEADER 0.098IN R57 2019 W125 100R0 1%FLAME PROOF T&R RES R45B 4902 W250 24K 5% T&R RES W9 4151 4 PIN POWER PIN HEADER MALE POLZED R58 2019 W125 100R0 1%FLAME PROOF T&R RES R46A 4902 W250 24K 5% T&R RES W10 4146 3 PIN POWER PIN HEADER MALE POLZED R59 2019 W125 100R0 1%FLAME PROOF T&R RES R46B 4902 W250 24K 5% T&R RES W11 2327 6 CIR XH-HEADER 0.098IN R67 6149 W250 47K5 1%MINI MF T&R RES R4A 6116 W250 10K0 1%MINI MF T&R RES W13 2327 6 CIR XH-HEADER 0.098IN R68 4834 W250 47K 5% T&R RES R4A1 6116 W250 10K0 1%MINI MF T&R RES W15 4056 2 CIR XH-HEADER 0.098IN R69 4834 W250 47K 5% T&R RES R4B 6116 W250 10K0 1%MINI MF T&R RES W16 4056 2 CIR XH-HEADER 0.098IN R70 4873 W250 680R 5% T&R RES R51A 2023 W600 220R0 1%FLAME PROOF T&R RES ZD1 6461 1N5240BRL 10V0 0W5 ZENER 5% T&R R72 6145 W250 249K 1%MINI T&R RES R51B 2023 W600 220R0 1%FLAME PROOF T&R RES ZD10 5124 1N5338B 5V1 5W0 ZENER 5% T&R R73 6149 W250 47K5 1%MINI MF T&R RES R52A 2023 W600 220R0 1%FLAME PROOF T&R RES ZD11 6875 1N5359B 24V0 5W0 ZENER 5% T&R R74 6145 W250 249K 1%MINI T&R RES R52B 2023 W600 220R0 1%FLAME PROOF T&R RES ZD12 6440 1N750ARL 4V7 0W5 ZENER 5% T&R R80 2044 W250 100R0 FUSIBLE T&R RES R53A 4745 5W0 0R1 5% BLK RES ZD13 6875 1N5359B 24V0 5W0 ZENER 5% T&R R81 2044 W250 100R0 FUSIBLE T&R RES R53B 4745 5W0 0R1 5% BLK RES ZD2 6461 1N5240BRL 10V0 0W5 ZENER 5% T&R R82 2044 W250 100R0 FUSIBLE T&R RES R54A 4745 5W0 0R1 5% BLK RES ZD3 6824 1N5246B 16V0 0W5 ZENER 5% T&R R83 2044 W250 100R0 FUSIBLE T&R RES R54B 4745 5W0 0R1 5% BLK RES ZD4 6824 1N5246B 16V0 0W5 ZENER 5% T&R R84 2044 W250 100R0 FUSIBLE T&R RES R55A 2013 W600 22R1 1%FLAME PROOF T&R RES ZD5 6824 1N5246B 16V0 0W5 ZENER 5% T&R R85 2044 W250 100R0 FUSIBLE T&R RES R55B 2013 W600 22R1 1%FLAME PROOF T&R RES ZD6 6824 1N5246B 16V0 0W5 ZENER 5% T&R R86 2044 W250 100R0 FUSIBLE T&R RES R58A 2013 W600 22R1 1%FLAME PROOF T&R RES ZD7 5124 1N5338B 5V1 5W0 ZENER 5% T&R R87 2044 W250 100R0 FUSIBLE T&R RES R58B 2013 W600 22R1 1%FLAME PROOF T&R RES ZD8 5124 1N5338B 5V1 5W0 ZENER 5% T&R R88 4791 W250 1K54 1% T&T RES R59A 2013 W600 22R1 1%FLAME PROOF T&R RES ZD9 5124 1N5338B 5V1 5W0 ZENER 5% T&R R89 4791 W250 1K54 1% T&T RES R59B 2013 W600 22R1 1%FLAME PROOF T&R RES R90 4791 W250 1K54 1% T&T RES R66A 4806 2W00 10K0 5% T&R RES R91 4791 W250 1K54 1% T&T RES R66B 4806 2W00 10K0 5% T&R RES R99 6116 W250 10K0 1%MINI MF T&R RES R67A 4806 2W00 10K0 5% T&R RES R101 4840 W250 33K 5% T&R RES R67B 4806 2W00 10K0 5% T&R RES R101A 6126 W250 220K 5%MINI T&R RES R68A 2019 W125 100R0 1%FLAME PROOF T&R RES R101B 6126 W250 220K 5%MINI T&R RES R68B 2019 W125 100R0 1%FLAME PROOF T&R RES R102 4840 W250 33K 5% T&R RES R69A 2019 W125 100R0 1%FLAME PROOF T&R RES R103 2010 W600 10R0 2%FLAME PROOF T&R RES R69B 2019 W125 100R0 1%FLAME PROOF T&R RES R104 2010 W600 10R0 2%FLAME PROOF T&R RES R70A 4806 2W00 10K0 5% T&R RES R104A 6118 W250 22K 5%MINI T&R RES R70A1 4806 2W00 10K0 5% T&R RES R104B 6118 W250 22K 5%MINI T&R RES R70A2 4806 2W00 10K0 5% T&R RES R105 6116 W250 10K0 1%MINI MF T&R RES R70B 4806 2W00 10K0 5% T&R RES R105A 4982 W250 4K7 5%MINI T&R RES R70B1 4806 2W00 10K0 5% T&R RES R105B 4982 W250 4K7 5%MINI T&R RES R71A 4806 2W00 10K0 5% T&R RES R106 6116 W250 10K0 1%MINI MF T&R RES R71B 4806 2W00 10K0 5% T&R RES R106A 4890 W250 30K 5% T&R RES R71B1 4806 2W00 10K0 5% T&R RES R106B 4890 W250 30K 5% T&R RES R72A 4962 2W00 5K1 5% T&R RES R107 6116 W250 10K0 1%MINI MF T&R RES R72B 4962 2W00 5K1 5% T&R RES R111 4982 W250 4K7 5%MINI T&R RES R72B1 4962 2W00 5K1 5% T&R RES R115 2006 1W00 1R 5%FLAME PROOF T&R RES R73A 4962 2W00 5K1 5% T&R RES R118A 2019 W125 100R0 1%FLAME PROOF T&R RES R73B 4962 2W00 5K1 5% T&R RES R118B 2019 W125 100R0 1%FLAME PROOF T&R RES R74A 4962 2W00 5K1 5% T&R RES R119A 2019 W125 100R0 1%FLAME PROOF T&R RES R74B 4962 2W00 5K1 5% T&R RES
YS # Descriptio
YS # Descriptio
Page 2 of 2
A
1 1
INPUT A and BRIDGED
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
XLR
2 2
1/4" TRS
3 3
1/4" TRS
4 4
5 5
6 6
XLR
1/4" TRS
7 7
1/4" TRS
8 8
INPUT B
9 9
10 10
J2:A
3922
1
3
5
GND
100V220P
J4
S TR
6
--
-
2
4
1
3
5
J5
S TR
6
--
-
2
4
220P
100V
220P
100V
C72
C70
4K99 1/4W
R1A
4K99 1/4W
R2A
4K99 1/4W
R1B
4K99 1/4W
R2B
.
.
.
.
R88 1/4W 1K54
.
R89 1/4W 1K54
.
220P
C69
100V
J3:A
3922
1
3
5
J6
S TR
6
--
-
2
4
1
3
5
J7
S TR
6
--
-
2
4
R90 1/4W 1K54
.
R91 1/4W 1K54
.
220P
C71
100V
CHGND
C2A
C1A
C2B
C1B
-15V
+15V
MINI
10K0 1/4W
R4A
63V100N
C46
RAD .2in
63V 100N
C42
RAD .2in
GND
4
U4:B
V-
U4:C
V+
TL072
8
W7
MINI
10K0 1/4W
R3A
100V220P
100V220P
MINI
10K0 1/4W
R4B
10K0 1/4W
R3B
100V220P
NET00250
GND
U4:A
TL072
MINI
BSIG
-15V
GND +15V ASIG
BTEMP ATEMP
8 7 6 5 4 3 2 1
8 W7:H 8 W7:G 8 W7:F 8 W7:E 8 W7:D 8 W7:C 8 W7:B 8 W7:A
W1
8 7 6 5
M1575 1/2
4 3
INTERFACE PCB
2 1
W8
6 5 4 3 2 1
W12
6 5 4 3 2 1
W11
W13
6
6W11:F
5
A_LIMIT
6W11:E
4
SHUTDOWN_A
6W11:D
3
ATEMP
6W11:C
2
A_SIG
6W11:B
1
-A_SIG
6W11:A
6
6W13:F
5
B_LIMIT
6W13:E
4
SHUTDOWN_B
6W13:D
3
BTEMP
6W13:C
2
B_SIG
6W13:B
1
-B_SIG
6W13:A
MPSA42
Q36
5113
TO92
ZD120W5
1N750ARL 4V7
R4A1
GND
K2:A
3700
3700
K2:B
GND
GND
K3:A
3700
3700
K3:B
GND
D33
D32
AMPA+
.
47K
R68
1/4W
.
47K
R69
1/4W
AMPB+
R70 1/4W 680R
.
D35
4007
4007
D34
4007
4007
MINI
1/4W
10K0
GND
AMPA_SIGNAL
MINI
1/4W
10K0
R106
TO AMP A SHEET 2
GND
AMP-A_SIGNAL
MINI
1/4W
10K0
R107
GND
AMPB_SIGNAL
MINI
R99
10K0
1/4W
TO AMP B SHEET 3
GND
AMP-B_SIGNAL
MINI
1/4W
10K0
R105
GND
TO AMP A SHEET 2
TO AMP B SHEET 3
24V0
ZD135W0
1N5359B
11 11
GND
A
24V0
1N5359B
ZD11 5W0
B
R3
1/4W
FUSIBLE
100R0
Product
AP4K
AmpIn
Thu Jun 12, 2014 V04
Date: Rev: YsType:.
C
D
E
F
G
H
I
J
K
L
M
N
Filename:
M1530V04sch.sch2006
O
PCB# Sheet 51
M1530
P
of
Q
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
1 1
Voltage box
4148
This voltage is with S1 in 4 ohm position
D20A
R93A 0R1
5.0W
.
5.0W
L
MR854
IRFP140N Q2:A
6931 TO247
+HI
MR854
IRFP140N Q4:A 6931 TO247 +MID
D42A
MR854
MJL21194 Q26A 6988 TO3P Lo Tier+
MJL21193 Q27A 6991 TO3P Lo Tier-
D43A
IRFP9140N Q6:A 6932 TO247
-MID
D44A
MR854
IRFP9140N Q8:A 6932 TO247
-HI
+12.3V +11.8V
This voltage is with S1 in 2 ohm position
D
IRFP140N
Q28:A 6931
N
D41A
G
ZD6 0W5
1N5246B 16V0
TO247 +HI
S
MR854
D22
D21A MR854
N
G
ZD5 0W5
1N5246B 16V0
D
S
IRFP140N Q27:A 6931 TO247 +MID
D23
MR854
MR854
MJL21194 Q23 6988 TO3P Lo Tier+
R51 0R1
5.0W
.
.
0R1
5.0W
R55
MJL21193 Q24 6991 TO3P
Lo Tier-
D28
D22A
1N5246B
1N5246B
MR854
D23A
MR854
0W5
ZD40W5 16V0
G
ZD3 16V0
G
M
MR854
IRFP9140N Q25:A 6932
P
TO247
-MID
DS
NET00050
D29
MR854
IRFP9140N Q26:A 6932 TO247
-HI
DS
N
W1 SPEAKERS
1
+170V +125V
+170V
+95V +69V
+95V
B-OUT
2
OUTPUT A B BRIDGED
J3A:A
SPEAKON 4C H
6956
1+
1_
J3A:B
+46V
+46V +33V
BLK
BLK
16 AWG
W14
16 AWG
W18
GND
MR854 D30A
L1A
R76A
C79
1.0W
10R
FLMP
GND
R78A 3R9
2.0W
.
22N
400V
8.5V
R77A 10R
1.0W
FLMP
C24A
R101 33K
1/4W
.
MBS4992 Q41:A
5190
TO92
BTB24-600BRG
Crowbar
R103 1/6W 10R0
FLMP
6517
TO220
Q38
MR854 D31A
-46V
-95V
-170V
-125V
-170V
-46V
-33V
-95V
-69V
AMPA+
4UH 3820
33U
16V
Product
AP4K
Channel A
Thu Jun 12, 2014 V04
Date: Rev: YsType:. Filename:
M1530V04sch.sch2006
O
PCB# Sheet 52
M1530
P
4 W1:A
4 W1:B
2+
G
GND
2_
MT1 MT2
of
Q
6880
6880
6
4N35
4N35
U8:B R27 100K
1/4W
2 2
A_LIMIT
MINI
5 4
1
U8:A
2
D6
4148D94148D84148
D7
4148
D5
D4
Amp A
4148
GND
R5
1/4W
D72A
C6
C7
R12
1/4W
100R0
FUSIBLE
R80
1/4W
100R0
FUSIBLE
R81
1/4W
100R0
FUSIBLE
2K74
R7
1/4W
475R0
0.1%
0.1%
U1:A
MC33079P
100V220P
50V330P
R18 390R
1/4W
FLAME PROOF
U3:A
MC33079P
U3:B
MC33079P
U3:C
MC33079P
U3:D
MC33079P
C10A 100N
63V
Q7A
5106
R14
1/4W
100R0
FUSIBLE
R15
1/4W
100R0
FUSIBLE
R82
1/4W
100R0
FUSIBLE
R83
1/4W
100R0
FUSIBLE
R11
1/4W
332R0
FLMP
TO92
MPSA63
22N
C10A1
100V
4007 D11
10K
Lin
4520
P1A VBE
10K
R31A
D2
TO92
MPSA56
R21 1/6W 10R0
FLMP
R22 1/6W 10R0
FLMP
C14
C59 100V680P
1/4W
C15
R16
1/4W
22R
FLMP
R13 22R
FLMP
FLAME PROOF
4
11
4148
1/4W
50V5N6
V+
V-
R23 1K
U3:E
50V5N6
C11
+12.3V +11.8V
-14.5V
-13.8V
100V680P
MPSA06
R24 681R
1/8W
FLMP
4
11
TO92
D26A
4148
V+
U1:E
V-
D27A
4148
R19 1/8W 10R0
FLMP
R20 1/8W 10R0
FLMP
Q18 5103
R25 15K
1/4W
MINI
330U
25V
330U
25V
C12
C13
R33A 3K
1/4W
MINI
1N5242B D8A 12V0 0W5
1N5244B D9A 14V0 0W5
R34A 3K
1/4W
MINI
BAV21
D52A R75A
2.0W 5K1 R75A1
.
R74A
2.0W 5K1
.
BAV21
D54A
C16A
C17A
4148 D3
5104
Q17
M
2N2
.
400V
C9
1/4W
R32A 22K
1/4W
MINI
R17 14K0
1/4W
.
4007 D10
1/4W
R26 15K
MINI
2N2
400V
GND
C10
3 3
AMPA_SIGNAL
C4
TO AMPIN SHEET 1
4 4
AMP-A_SIGNAL
R6
1/4W
16V33U
49K90
.
R9 10K0
1/4W
MINI
C5
R10 2K2
1/4W
MINI
C8
400V1N
R8
1.0W
16V33U
9K76
0.5%
U1:B
5 5
MC33079P
U1:C
MC33079P
6 6
U1:D
MC33079P
7 7
8 8
4148
9 9
A_LIMIT
R67
10 10
GND
15K0
1/4W
MINI
1/4W
R72 249K
.
D55A BAV21
R72A
2.0W 5K1
.
R73A
2.0W 5K1
.
D53A BAV21
100V22N
Q10A
5103
Q11A
5104
100V22N
.
10K
2.0W R70A1 BAV21
D50A1
R66A
2.0W 10K
D29A
BAV21
MPSA06
.
2.0W 5K1
.
BAV21
D50A2
TO92
R4 1R
1/4W
FLMP
R60 1R
1/4W
FLMP
MPSA56
TO92
R59A
1/6W 22R1
FLMP
R70A2
R58A 1/6W 22R1
FLMP
R75A2
2.0W
D55A1
BAV21
D28A BAV21
R67A
2.0W 10K
.
10K
2.0W
5K1
.
.
D55A2
BAV21
.
10K
2.0W
R70A
BAV21
D50A
1/6W
100R0
FLMP
R43A 1K
1/8W
FLMP
D14A BAV21
D15A BAV21
R44A 1K
1/8W
FLMP
D51A BAV21
R97A 1/4W 82K5
R45A 1/4W
24K R46A
1/4W
24K
10K
2.0W
.
.
.
R98A 1/4W 82K5
1/6W
100R0
.
R56
1/6W
100R0
FLMP
R120A
1/8W
100R0
FLMP
R69A
1/8W
100R0
FLMP
R121A
1/8W
100R0R57
FLMP
R127A
1/8W
100R0
FLMP
.
R52A 1/8W
220R0
FLMP
Neg Driver MJE15033 Q17A 6809 TO220
R58
FLMP
Pos Driver MJE15032 Q16A 6808 TO220
R51A 1/8W
220R0
FLMP
-46V
+46V
R126A
1/8W
100R0 R118A
1/8W
100R0
R68A 1/8W
100R0
R119A
1/8W
100R0R71A
1/6W
100R0
1N5246B D19A
1N5246B D18A 16V0 0W5
R96A
1.0W 0R47
FLMP
R95A
1.0W 0R47
FLMP
FLMP
FLMP
1N5246B D25A
FLMP
FLMP
R59
FLMP
0W5
D71A BAV21
R55A 22R1
1/8W
FLMP
D73A
BAV21
1N5246B D24A 16V0 0W5
D
N
G
S
16V0
D
N
G
S
R53A 0R1
5.0W
.
.
0R1
5.0W
R54A
P
G
DS
COM3-_A
16V00W5
P
G
DS
IRFP140N
Q1:A 6931 TO247 +HI
IRFP140N Q3:A 6931 TO247
+MID
MJL21194 Q12A 6988 TO3P Lo Tier+
R49A 1R
1.0W
FLAMEPROOF
R50A 1R
1.0W
FLAMEPROOF
MJL21193 Q13A 6991 TO3P Lo Tier-
1N5246B 16V0
IRFP9140N Q5:A 6932 TO247
-MID
IRFP9140N Q7:A 6932 TO247
-HI
D63A 0W5
D64A 0W5
0W5
1N5246B
0W5
D
N
G
S
1N5246B 16V0
D
N
G
S
1N5246B 16V0
.
0R1
R94A
D66A
P
G
DS
COM4-_A
16V0 D67A
P
G
DS
BIAS SET 7 TO 10 mV COLD AMP
11 11
A
B
C
D
E
F
G
H
I
J
K
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
1 1
6880
6880
6
4N35
4N35
1
U9:A
2
B_LIMIT
R28 100K
1/4W
MINI
GND
U9:B
5 4
2 2
AMPB_SIGNAL
C16
3 3
TO AMPIN SHEET 1
4 4
AMP-B_SIGNAL
R30
1/4W
16V33U
49K90
.
R31 2K2
1/4W
MINI
R29 10K0
1/4W
MINI
C17
C18
400V1N
R34
1.0W
16V33U
9K76
0.5%
U10:B
5 5
MC33079P
U10:C
6 6
MC33079P
U10:D
MC33079P
7 7
8 8
9 9
B_LIMIT
10 10
R74
R73
249K
15K0
1/4W
1/4W
.
MINI
GND
11 11
A
B
D13
4148
R36
1/4W
100R0
FUSIBLE
R84
1/4W
100R0
FUSIBLE
R85
1/4W
100R0
FUSIBLE
4148
NET00103
C
D12
4148
D16
4148
D17
4148
D72B
NET00169
D14 4148
R32 1/4W 2K74
0.1%
C19
100V220P
R33 1/4W
475R0
0.1%
C20
50V330P
R41 1/4W
390R
FLAME PROOF
D15
4148
U10:A
MC33079P
C10B
63V
U11:A
MC33079P
U11:B
MC33079P
U11:C
MC33079P
U11:D
MC33079P
100N
D
Q7B
5106
MPSA63
22N
C10A2
R38
1/4W
100R0
FUSIBLE
R39
1/4W
100R0
FUSIBLE
R86
1/4W
100R0
FUSIBLE
R87
1/4W
100R0
FUSIBLE
1/4W
332R0
TO92
R35
FLMP
100V
10K
Lin
4520
P1B VBE
10K
R31B
4007 D20
.
Voltage box
Amp B
This voltage is with S1 in 4 ohm position
+12.3V +11.8V
This voltage is with S1 in 2 ohm position
W1 SPEAKERS
4
4 W1:D
+170V +125V
.
10K
.
.
D51B BAV21
R72B
2.0W 5K1
R73B
2.0W
5K1
D53B BAV21
C16B
C17B
.
.
2.0W
R70B1
D50B1
100V22N
Q10B
5103
Q11B
5104
100V22N
BAV21
R66B
2.0W 10K
D29B
BAV21
R75B1
2.0W 5K1
.
BAV21
D52B1
MPSA06
.
TO92
R61 1R
1/4W
FLMP
R62 1R
1/4W
FLMP
MPSA56
TO92
R59B 1/6W 22R1
FLMP
R58B 1/6W 22R1
FLMP
D51B1
BAV21 R72B1
2.0W 5K1
D28B BAV21
.
R67B
2.0W 10K
.
.
10K
2.0W
R70B
BAV21
D50B
R121B1
1/8W
100R0
FLMP
R43B 1K
1/8W
FLMP
D14B BAV21
D15B BAV21
R44B 1K
1/8W
FLMP
D18
4148
4148
D19 C61
TO92
5104
Q19
MPSA56
R44 1/6W 10R0
FLMP
M
1/4W
R32B 22K
1/4W
MINI
R42 14K0
1/4W
.
4007 D21
1/4W
R43 15K
MINI
2N2
400V
2N2
400V
C23
GND
C24
R45
1/6W
10R0
FLMP
C27
100V680P
100V680P
MPSA06
Q20 5103
TO92
R48
R49
1K
681R
1/4W
1/8W
FLAME PROOF
4
V+
V-
11
FLMP
R37
1/4W
22R
FLMP
R46 1/8W 10R0
FLMP
D26B
4148
C21
+12.3V +11.8V
50V5N6
4
V+
U11:E
U10:E
V-
11
-14.5V
-13.8V
C22
50V5N6
R40
1/4W
22R TO220
FLMP
R47 1/8W 10R0
FLMP
D27B
4148
R50 15K
1/4W
MINI
330U
25V
330U
25V
C25
C26
R33B 3K
1/4W
MINI
1N5242B D8B 12V0 0W5
1N5244B D9B 14V0 0W5
R34B 3K
1/4W
MINI
BAV21
D52B R75B
2.0W 5K1
R74B
2.0W 5K1
BAV21
D54B
D55B1
BAV21
.
10K
2.0W
R71B1
R97B 1/4W 82K5
.
R45B
1/4W
24K
.
R46B
1/4W
24K
.
R98B
1/4W 82K5
Neg Driver
R126B1
1/8W
100R0
FLMP
D55B BAV21
.
10K
2.0W
R71B
R120B1
1/8W
100R0
FLMP
R120B
1/8W
100R0
FLMP
R69B
1/8W
100R0
FLMP
R121B
1/8W
100R0
FLMP
R127B
1/8W
100R0
FLMP
Pos Driver MJE15032
Q16B
6808
TO220
R96B
1.0W 0R47
FLMP
R51B 1/8W
220R0
FLMP
-46V
+46V
.
R52B 1/8W
220R0
FLMP
R95B
1.0W
0R47
MJE15033 Q17B
6809
1N5246B
1N5246B
FLMP
R126B
1/8W
100R0 R118B
1/8W
100R0
R68B 1/8W
100R0
FLMP
R119B
1/8W
100R0
R119B1
1/8W
100R0
FLMP
FLMP
FLMP
FLMP
D19B
16V0
0W5
D18B
16V0
0W5
D71B BAV21
R55B
22R1
FLMP
D73B
BAV21
1N5246B D24B 16V0 0W5
1N5246B D25B 16V0 0W5
N
G
N
G
0R1
R53B
0R1
R54B
1/8W
G
G
D
IRFP140N Q9:A 6931 TO247
+HI
S
D63B 0W5
D
IRFP140N Q11:A 6931 TO247
+MID
S
D64B 0W5
MJL21194 Q12B 6988 TO3P Lo Tier+
.
FLAMEPROOF
1R
5.0W
1.0W
R49B
.
5.0W
R50B 1R
1.0W
FLAMEPROOF
MJL21193 Q13B 6991 TO3P Lo Tier-
1N5246B 16V0
IRFP9140N Q13:A 6932
P
TO247
-MID
DS
1N5246B 16V0
IRFP9140N
Q15:A 6932
P
TO247
-HI
DS
0W5
0W5
D
N
G
S
1N5246B 16V0
D
N
G
S
1N5246B 16V0
.
0R1
5.0W
R93B
.
0R1
5.0W
R94B
D43B
D66B
MR854
P
G
DS
D67B
P
G
DS
IRFP140N Q10:A 6931 TO247
+HI
D41B
MR854
IRFP140N Q12:A 6931 TO247 +MID
D42B
MR854
MJL21194 Q26B 6988 TO3P Lo Tier+
MJL21193 Q27B 6991 TO3P Lo Tier-
D22B
MR854
IRFP9140N Q14:A 6932 TO247
-MID
D44B
MR854
IRFP9140N
Q16:A 6932 TO247
-HI
16V0
D20B MR854
D21B
D64B1 0W5
MR854
1N5246B 16V0
0W5
D23B
MR854
1N5246B
0W5
16V0 D67B1
D
N
G
S
D63B1
0W51N5246B
D
N
G
S
1N5246B 16V0
.
0R1
5.0W
R93B1
.
0R1
5.0W
R94B1
D66B1
P
G
DS
P
G
DS
IRFP140N Q32:A 6931 TO247
+HI
MR854
IRFP140N Q31:A 6931 TO247 +MID
D21B1
MR854
MJL21194 Q26B1 6988 TO3P Lo Tier+
MJL21193 Q27B1 6991 TO3P Lo Tier-
D22B1
MR854
IRFP9140N Q30:A 6932 TO247
-MID
IRFP9140N Q29:A 6932 TO247
-HI
D41B1
D23B1
MR854
+170V
+95V +69V
+95V
+46V +33V
+46V
MR854 D30B
MR854 D31B
-46V
-46V
-33V
-95V
-95V
-69V
-170V
-125V
-170V
B-OUT
AMPB+
L1B 4UH 3820
33U
16V
C80
R76B 10R
1.0W
FLMP
R77B 10R
1.0W
FLMP
R78B 3R9
2.0W
.
22N
400V
GND
R102 33K
1/4W
.
MBS4992 Q42:A
8.5V
5190 TO92
BTB24-600BRG
C24B
Crowbar
R104 1/6W 10R0
FLMP
TO220
6517
Q40
BLK
BLK
GND
GND
16 AWG
W17
16 AWG
W19
G
3
4 W1:C
J3B:A
OUTPUT B
SPEAKON 4C H
6956
1+
1_
2+
SPEAKON 4C H
OUTPUT B
J3B:B
MT1 MT2
2_
6956
Product
AP4K
BIAS SET 7 TO 10 mV COLD AMP
E
F
G
H
I
J
K
L
M
N
Channel B
Thu Jun 12, 2014 V04
Date: Rev: YsType:. Filename:
M1530V04sch.sch2006
O
PCB# Sheet 53
M1530
P
of
Q
A
1 1
2 2
B
C
D
E
F
+15V
6619
10K NTC
Q36A
G
4148
CHANNEL A
D62A
H
I
J
+15V
Q36B
NTC 10K
6619
K
D62B 4148
CHANNEL B
L
M
N
O
P
Q
Z_LIMIT
1N5240BRL ZD1 10V0 0W5
D26 BAV21
Q30B
5105
D70B 4148
SHUTDOWN_B
K3:C
MPSA13
TO92
GND
R106B 30K
1/4W
.
-46V
+46V
C45B
100U
16V
R101B 220K
1/4W
MINI
C43B
Q31B
5101
3700
R105B
1/4W
4K7
MINI
63V 4U7
4148 D45B
AMP B RELAY CONTROL
BC550C
TO92 C44B
100U
16V
1N5242B D49B 12V0 0W5
D46B
R104B 22K
1/4W
MINI
4148
3 3
R106A
1N5242B
30K
D49A
1/4W
.
12V0 0W5
-46V
4 4
K2:C
5 5
MPSA13
Q30A
5105
TO92
6 6
D70A 4148
3700
D47A 4148 4148D47B
63V 4U7
R105A
1/4W
4K7
MINI
GND
C45A
4148 D45A
+46V
100U
16V
R101A 220K
1/4W
MINI
C43A
Q31A
5101
BC550C
TO92 C44A
100U
16V
D46A
R104A 22K
1/4W
MINI
4148
AMP A RELAY
7 7
SHUTDOWN_A
CONTROL
Z_LIMIT
1N5240BRL ZD2 10V0 0W5
D27 BAV21
D1 0W5
MINI
100K
R124
1/4W
FAN CONTROL
W15:A2
+46V
470U
C47
D56
4148
D57
4148
D58
4148
100N
50V
25V
C48
GND
FLMP
1R
1.0W
R115
Fan Ctrl TIP107 Q35 6916 TO220
MINI
27K
1N5254B
1/4W
R1
MPSA06
1N753ARL 6V2
TO92
5103
D71
27V0
0W5
R111
1/4W
4K7Q39
MINI
MINI
3K3
1/4W
R2
W15:B2
W16:A2 W16:B2
FAN
FAN
FAN1
FAN2
8 8
4094
4148
9 9
10 10
D24
MPSA13
Q21
5105
K1:B
TO92
GND
+15V
63V 220N
C31
D25 4148
10U
63V
C29
R53 100K
1/4W
MINI
Q22
5105
MPSA13
TO92
4ohms / 2ohms
S1:A
GND
R52
1/4W
1K
MINI
10U
C30
63V
POWER RELAY CONTROL
S1:B
3425
R54 100K
1/4W
MINI
10U
63V
Z_LIMIT
C28
Product
AP4K
11 11
A
B
C
D
E
F
G
H
I
J
K
L
M
N
Fan Control
Thu Jun 12, 2014 V04
Date: Rev: YsType:. Filename:
M1530V04sch.sch2006
O
PCB# Sheet 54
M1530
P
of
Q
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
ZD7 5W0
1N5338B5V1
ZD95W0
Voltage box
This voltage is with S1 in 4 ohm position
125Vac
90Vac
This voltage is with S1 in 2 ohm position
+170V +125V
+170V
+95V +69V
+95V
U6
MC7815CT
IN
OUT
Pos 15v
REF
6872 {Watts}
6871
REF
Neg 15v
IN
MC7915CT
U5
TO220
TO220 {Watts}
OUT
100U
16V
100U
16V
C41
C40
-170V
-125V
-170V
100N
50V
100N
50V
-95V
-95V
-69V
C55
GND
C54
+46V +33V
+46V
+15V
-15V
-46V
-46V
-33V
1 1
S6 THERMAL BREAKER
NA 15A
2 2
IEC_RECT
CE 8A
Thermal Breaker
S6
3 3
4 4
5 5
W300
GND
YS#2448 YS#2408
DPDT Switch
S3
C1
4N7
250V
GND
250V
680N
W2
1
5 W2:A
2
BLK
4094
ORN
K1:A
W290
C3
3 4 5
5 W2:B 5 W2:C 5 W2:D 5 W2:E
CH1418E EUROPEAN CH1418 NA
VIO_
GRY_
ORN
BLK
BLU
RED_
YEL
RED
GRY
VIO
1
1
3575
2
4096
C35
25X50MM
3300U
C36
100V
3300U
C37
100V
4700U
80V
25X50MM
25X50MM
C38
3300U
C39
100V
3300U
C43
100V
15K 1/2W R284
15K 1/2W R285
.
8200U
C33
25X50MM
50V
8200U
C32
25X50MM
50V
.
ZD8 5W0
8200U
C44
50V
8200U
C45
50V
1N5338B 5V1
1N5338B5V1
ZD105W0
1N5338B 5V1
R282 1/2W
4700U
C2
80V
15K
.
3300U
100V
3300U
100V
4700U
80V
C50
C51
4700U
80V
125Vac
90Vac
1
3W10:A
3
2
4
3
3W10:B
3W10:C
4W9:A 4W9:B 4W9:C 4W9:D
0Vac
2
3
1 2 3 4
90Vac
125Vac
70Vac 50Vac
34Vac 25Vac
25Vac 34Vac
50Vac 70Vac
GND
D59
D61
SIP
BRIDGE
6772
BRIDGE
BRIDGE
6772
SIP 6772
SIP
D60
C49
C52
3300U
C57
100V
3300U
C56
100V
4700U
80V
4700U
80V
C34
R286 1/2W
15K
.
6 6
IRF720 IRF822 IRF830
CB
IRF4905 IRF5210 IRL2910 MTP2P50E MTP8P20 MTP10N15 MTP12P10 MTP23P06
DS
G
TO-220
BC550C BC560C
BE
C
TO-92
2N5401
2N5551 MPSA06 MPSA13 MPSA43 MPSA56 MPSA63
BC
E
TO-92
7 7
M1530 PCB_DATABASE_HISTORY
MODEL(S):-
DATE DESCRIPTION OF CHANGE
#
1
22/03/2013
2
10-DEC-2013 V03 PC8598: Add 4 pin connector #4151 for output. GG
8 8
9 9
10 10
3 4
27-MAR-2014 V04 PC8630: Add a hole for a support brace. GG D
5
D
6 7
D
8
D
9
D
10
D
11
D
12
D
13
D
AP4K
VER# V01 RELEASED
V0220/06/2013
MINOR CHANGES FOR PRE PRODUCTION RUN
V
N
V
N
V
N
V
N
V
N
V
N
V
N
V
N
V
N
6880_PC
6884_PC
BD139 BD140 BD237
BD238 MJE270 MJE271 MJE340 MJE350
E
TO-126
Product
AP4K
11 11
A
B
C
D
E
F
G
H
I
J
K
L
M
N
Power Supply
Thu Jun 12, 2014 V04
Date: Rev: YsType:. Filename:
M1530V04sch.sch2006
O
PCB# Sheet 55
M1530
P
of
Q
SCORE
SCORE
BlankSize - 18000x11725
BlankSize - 18000x11725
SCORE
J3A
FLAT SIDE UP
4007
D11
R13
22R100R0
5N6
C14
R80
100R0
R81
R8
SPEAKON 4C H
+2
-2 -1 +1
OUTPUT A+B
30K
R106A
5106
MPSA63
Q7A
C10A1
22N
D71A
BAV21
R31A
22K
332R0
100R0
10K
R11
R12
R32A
U1
R10
2K2
MC33079P
C8
1N
9K76
1.0W
R76A
10R
3820
4UH
1.0W
BLK
100R0
R127A
R96A
0R47
1.0W
1.0W
R68A
100R0
330U
390R
10K0
Q30A
R9
16V 33U
4151
R95A
R67A
D28A
BAV21
25V
5630
2N2
C10
1
10K
R20R19
10R0
4U7
C45A
2.0W
10R0
MPSA13
63V
SPEAKERS
RED BLK BLK
R72A
D55A
5K1
BAV21
12V0
330U
R16
22R
10R0
C15
R22
D45A
4K7
R105A
R107
L1A
10K
Q36A
6619
Q1
69316931
16V0
100R0
IRFP140NIRFP140N
..
R69A
D19A
6934
BAR DOWN
D20A
Q3
16V0
D18A
6934
BAR DOWN
D21A
MR854 MR854
6988
Q12A
R55A
MJL21194
.
22R1
6991
Q13A
0R47
MJL21193
.
D22AD23A
MR854
BAR DOWNBAR DOWN
6934
Q5
D24A
R126A
6932
16V0
100R0
MR854
6934
6932
IRFP9140N IRFP9140N
..
Q7
D25A
.
Q16A
6808
MJE15032
16V0
.
Q17A
6809
MJE15033
C12
D73A
BAV21
D10
4007
R17
R18
C10A
10K
14K0
100N
P1A
R21
10R0
C4
2N2
33U
C9
16V
49K90
2K74
475R0
R6
220P
330P
R5
R7
C6
C5
C7
CLINCH ORIGIN
VCD
INSERT
ORIGIN
M1530
W18
25V
5630
10K0
1.0W
2.0W
5N6
4148
C43A
100U
K2
10R
R77A
R74A
D54A
BAV21
D8A
C13
100R0
R82
16V
3700
R76B
W19
5K1
D9A
100R0
R83
10R
1.0W
BLK
R66A
D29A
2.0W BAV21
14V0
MC33079P
Q31A
RELAY 2C
10K0
SPEAKON 4C H
R77B
1.0W
YEL
10R
3820
4UH
L1B
4
300
W1
69566956
+2
-2 -1 +1
OUTPUT B
J3B
Q2Q4
16V016V0
100R0100R0
IRFP140NIRFP140N
..
D63AD64A
R120AR121A
6934
BAR DOWN
D41A
MR854
6934 69316931
BAR DOWN
D42A
MR854
6988
Q26A
MJL21194
.
6991
Q27A
MJL21193
.
6934
D43A
MR854
BAR DOWN
Q6
D66A
MR854
D44A
6934
BAR DOWN
R119A R118A
D67A
6932 6932
100R0 100R0
16V0 16V0
IRFP9140N IRFP9140N
..
Q8
D26A
4148
U3
10K
82K5 82K5
100U
BC550C
2.0W
R98A
R97A
C44A
16V
R106
R71A
D51A
10K
2.0W
BAV21
R34A
D72A
100R0
100R0
4148
R15
R14
R104A
22K
D46A
4148
NOC NC
D47A
V04
R73A
D53A
BAV21
3K
D27A
4148
12V0
4148
4148
R101A
D70A
5K1
15K
R26
24K
220K
2.0W
BAV21
D15A
R46A
D49A
100K
D52A
BAV21
3K
R33A
C59
680P
Q17
R27
R67
R75A
15K0
5K1
15K
R25
U8
4N35
2.0W
R59A
MPSA56
C11
680P
Q18
6880
R70A
D50A
10K
2.0W
BAV21
1K 22R1
22N
1K
R43A
BAV21
D14A
MPSA06
4148
D3
AP4K
R44A
C17A
4148
D2
R70A2
D55A2
BAV21
1K
R23
2.0W
249K 681R
Q11A
R60
1R 10K
4148 4148 4148 4148 4148 4148
MR854
MR854
.
.
69346934
MR854 MR854
BAR DOWN
R75A2
D55A1
BAV21
MPSA56
R4
1R
IRFP140NIRFP140N
6934
6934 6931
6988
MJL21194
6991
MJL21193
IRFP9140N
BAR DOWN
IRFP9140N
Q10A
MPSA06
250V
4N7
6451
R
T
V
250V 680N
5266
R
C3
T
V
C1
300
15
D30A
R51
4745
4745
3K3
5.0W
D56 D58
D71
R2
0R1
MR854
6934
C44
C45
T
R
V
15K
R285
C47
5618
W2
T
R
V
+
BTB24-600BRG
Q38
MR854
1/2W
470U
25V
R
5898
AC AC
6772
TO220
5898
6934
4056
XFMR PRIMARY
R78A
3R9
C79
R284
1/2W
0R1
5.0W
22N
6
1
15K
4745
4745
R54A
R70A1
D50A1
BAV21
R52A R51A R58A
2327
W11
5.0W
0R1
2.0W
33U
10K
TIP107
16V
MBS4992
6916
Q35
MPSA06
2.0W 400V
5840
22N
C24A
R101
33K
R103
10R0
Q41
R93A
0R1
0R1
4745
5.0W
0R1
4745
5.0W
5.0W
R94A
R55
R115
1R
1.0W 4148
D57
4148
C48
4148
.
27V0
100N
R1
27K
4K7
R111
Q39
Q28Q27
16V0
100R0
..
R56
ZD6
BAR DOWN
D22
R57
ZD5
6931
16V0
100R0
R53A
BAR DOWN
D23
R49A
1R
1.0W
Q23
1R
1.0W
Q24
R50A
D28
R58
ZD4
6932
100R0
16V0
Q25
D29
R59
ZD3
6932
100R0
16V0
..
Q26
R75A1
D50A2
5K1
2.0W
5K1
2.0W BAV21
220R0
220R0
22R1
C16A
24K
R45A
R72
R24
D4
D7
D5
D9
D8
D6
K1
C1
NC1
T
V
4163
NO1
T
R
V
8200U
50V
C33
PC-C
C2
RELAY 1C
NC2NO2
R
0
0
2
8
V
0
5
8
9
8
5
T
R
V
C50
BRIDGE
.
6517
-
D61
300
4
C51
8200U
T
R
V
50V
R
8200U
5898 5896
D31A
50V
T
R
V
C32
1 2
W16
R53
100K
4094
Low/High Power
C49
T
V
U
5899
XFMR Secondary
5899
T
V
T
R
R
V
C52
3300U 100V
+
W9
R
3300U 100V
T
V
DPDT PUSH
4148
D24
S1
T
R
V
T
R
V
..
6772
T
V
Q22
MPSA13
3425
Q21
MPSA13
ZD1 D25
220N
C31
T
R
V
4700U
80V
5896
T
R
V
C36
AC AC
1
C43
T
R
V
4700U
80V
T
R
V
Yorkville
C
2ozCopper
BEC LOC
5899
4151
2012
10V0 4148
D60
5899
C2
D62A
C35
.BRIDGE.
1K
R52
4148
100K
4148
T
R
V
T
R
V
3300U
100V
-
BLK
AMP A-
R
3300U
100V
T
R
V
R54
D62B
T
V
W14
10U
10U
63V
C29
63V
C30
10U
C28
R124
63V
5896
W17
C37
5896
D1
6V2
100K
BAV21
10V0
BAV21
ZD2
D26
T
R
V
4700U
80V
T
R
V
C57
+
6772
BLK
XFMR Secondary
AMP B-
4146
1
T
R
V
4700U
80V
T
R
V
Into Wave
3922
D27
2
INPUT A
C38
5896
T
R
V
T
R
V
3300U
5899
100V
C39
.
AC AC
.BRIDGE
D59
3
300
W10
T
R
V
3300U
5899
100V
T
R
V
T
R
V
5896
4700U
R
C34
Into Wave
J2
R
4700U
80V
-
80V
T
V
4056
SCORE
R88
INPUT A
R78B
2.0W 3R9
5840
3498
2328
W7
-
-
1K54
-
J5
8
R282
15K
1/2W
-
-
-
3498
J4
INPUT A
T
V
D30B
6934
MR854
T
R
V
3300U
100V
5899
22N
400V
C24B
1
M1530
T
R
V
Q42
C80
33U 16V
MBS4992
Q40
.
6517
TO220
BTB24-600BRG
C56
AP4K
V04
R102
33K
R93B
R53B R93B1
R104
10R0
0R1
4745
5.0W
5.0W
1R
1.0W
4745
0R1
5.0W
4745
R121B1
0R1
R1A
C69
4K99
R89
10K0
R4A
220P
1K54
220P 220P
4K99
220P
10K0
C70
R2A
R3A
C1A
..
Q32Q31
100R0
IRFP140NIRFP140N
69316931
D63B1
R120B1
6934
BAR DOWN
D41B1
MR854
100R0
16V0
D64B1
6934
MR854
BAR DOWN
D21B1
.
6988
Q26B1
MJL21194
R54B
.
R50B
1R
R126B1
100R0
R119B1
100R0
5K1
R61
MPSA56
6
2327
1
D66B1
2.0W
Q10B
1.0W
N
D22B1
W O
D R A B
Q30 Q27B1
16V0
6934
D23B1
D67B1
..
16V0 16V0
Q29
R72B1
D52B1
BAV21
MPSA06
Q11B
R73
15K0
6932 6932
5K1
1R
R44B
BAV21
BAV21
249K 100K
4N35
6991
MJL21193
MR854 MR854
6934
BAR DOWN
IRFP9140N IRFP9140N
R71B1
D51B1
2.0W
2.0W
BAV21
R58B
22R1
22N
1K
R43B R62
1R
1K 82K5
D14B D15B
R74
R28
D18
D16
6880
D15
D12
U9
D13
D14
T
R49B
R
V
5899
3300U
100V
D31B
MR854
6934
15K
1/2W
R286
1 2
W15
C41
100U
C40
100U
16V
16V
5.0W
R94B
5124
5124
ZD7
ZD8
4745
5V1
5V1
0R1
C55
100N
100N
C54
5.0W
R94B1
5V1
6872
5V1
4745
5124
ZD10
ZD9
5124
0R1
U6
.
.
6871
U5
R51B R52B R59B
5.0W
MC7815CT
MC7915CT
R70B1
2.0W
R45B
R46B
4745
10K
220R0
220R0
22R1
C17B
0R1
R75B1
D50B1
BAV21
22N
24K 24K
W13
100N 100N
10K
C16B
4148
4148
4148
4148
C2A
C2B
TL072
R70B
D55B1
BAV21
3K
R97B
C27
680P
4148
4148
4148
U4
2.0W
R34B
R68
C46 C42
R69
10K
Q20
15K
4148
D17
4K99
10K0
220P
D50B
BAV21
3K
R43
MPSA06
R1B
10K0
R3B
R75B
R48
D45B
47K 47K
4148
D19
5K1
R33B
4148
Q19
220P
C1B
2.0W
4148
681R
MPSA56
1K
16V
16V
C71
R90
R91
R4B
220P
1K54
1K54
220P
4K99
C72
D35
4007
R2B
4007 4007 4007
D34
..
Q10Q12
16V016V0
100R0100R0
6931
D63BD64B
R120B
6934
INPUT B
D32 D33
IRFP140NIRFP140N
BAR DOWN
3498
680R 4V7
10K0
R70
R4A1
-
-
-
J6
INPUT B
Q36
ZD12
MPSA42
MR854
6931
R121B
BAR DOWN
6934
D42B D41B
MR854
.
Q26B
MJL21194
6988
.
6991
Q27B
MJL21193
D43BD44B
MR854
6934
BAR DOWN
Q14
D66B
R118B
16V0
IRFP9140N
100R0
6932
6934
BAR DOWN
MR854
..
R119B
D67B
6932
16V0
100R0
IRFP9140N
Q16
R73B
D52B
5K1
BAV21
15K
R50
D27B
R49
22K
R104B
100U
100U
4K7
R105B
D26B
C44B
C43B
2.0W
680P
R71B
D53B
BAV21
D49B
12V0
C61
BC550C
Q30B
MPSA13
R98B
D46B
2.0W
D9B
4148
Q31B
10K
82K5
R99
D47B
D55B
BAV21
D70B
4148
R66B
14V0
C22
5N6
R42
63V
4148
10K
R40
22R
14K0
R86
4U7
10K0
3700
K3
R74B
D29B
2.0W BAV21
5630
25V
330U
C26
R87
100R0
100R0
C45B
NOC NC
RELAY 2C
10K0
5K1
D54B
2.0W BAV21
12V0
MC33079P
U11
220K
R72B
R105
5K1
5630
330U
R101B
2.0W
25V
C25
D72B
4148
R67B
D51B
BAV21
D8B
R38
100R0
R44
C24
-
-
-
3498
J7
ZD13 ZD11
R106B
30K
Q9
..
16V0
100R0
69316931
D19B
R69B
BAR DOWN
IRFP140NIRFP140N
3922
2
J3
INPUT B
R3
100R0 24V0
6875 6875
24V0
10K
Q36B
6619
MR854
Q11
16V0
100R0
D18B
R127B
BAR DOWN
6934 6934
D21B D20B
MR854
.
R55B
R96B
Q12B
MJL21194
22R1
1.0W
0R47
6988
.
Q13B
1.0W
R95B
0R47
MJL21193
Q7B
5106
MPSA63
6991
D22B
BAR DOWN
MR854
6934
D24B
R126B
16V0
100R0
Q13
BAR DOWN
MR854
D23B
D25B
R68B
..
16V0
100R0
IRFP9140N IRFP9140N
6932 6932
Q15
.
Q16B
100R0
R84
16V 33U
C16
R47
10R0
100R0
C10B
6808 6934
MJE15032
.
Q17B
6809
MJE15033
22N
BAV21
390R
R41
U10
10K
R31B
C20
22K
R32B
330P
33U 16V
R36
R33
475R0
C17
D20
4007
100R0
R35
2K74
R32
332R0
C21
C19
220P
R37
5N6
1.0W
2K2
R31
R30
D73B
D71B
10K
P1B
100N
49K90
R29
C10A2
MC33079P
1N
C18
10K
2.0W
R39
100R0
R45
10R0
C23
2N2
BAV21
4007
D21
R85
10R0
2N2
D28B
BAV21
R46
10R0
10K0
FLAT SIDE UP
22R
9K76
R34
SEE LAYOUT DOCUMENTATION
SEE LAYOUT DIAGRAM
M1530
MODEL(S):-
DATE
#
1 2
20-JUN-2013 V02
3
10-DEC-2013 V03 PC8598: Add 4 pin connector #4151 for output. GG 27-MAR-2014
4
D
5 6
D
7
D
8
D
9
D
10
D
11
D
12
D D
13
AP4K
VER# DESCRIPTION OF CHANGE V0122-MAR-2013
V04 V V V V V V V V V
PCB Database History
RELEASED MINOR CHANGES FOR PRE PRODUCTION RUN
PC8630: Add a hole for a support brace. GG N N N N N N N N N
SEE HISTORY
M1530 PRODUCTION NOTES
V04
1. RTV MUST BE ADDED TO THE FOLLOWING COMPONENTS C2, C28, C29, C30, C32, C33, C34, C35, C36, C37, C38, C39, C43, C44, C45, C49, C50, C51, C52, C56, C57, BETWEEN C1 AND C3, BETWEEN L1A AND J3A, BETWEEN L1B AND J3B.
2. MOUNT BRIDGE RECTIFIER HEATISINK BEFORE WAVE SOLDER.
3. ADD TWO #8663 SPACERS UNDER EACH #6931 AND #6932 TRANSISTORS.
4. CLIP LEADS SHORT ON ALL POWER TRANSISTORS AND DIODES.
5. ADD JUST A VERY SMALL AMOUNT OF RTV UNDER STONE RESISTORS.
6. DO NOT ADD RTV IN BETWEEN POWER SUPPLY CAPS.
7. BREAK THE CHASSIS CONNECTION OF J2 AND J3 AS SHOWN:
LEAD/PIN REFERENCE
IRF720 IRF822 IRF830 IRF4905 IRF5210 IRL2910 MTP2P50E MTP8P20 MTP10N15L MTP12P10 MTP23P06
D
GS
TO-220
BD139 BD140 BD237
BD238 MJE270 MJE271 MJE340 MJE350
EBC
TO-126
2N5401
2N5551 MPSA06 MPSA13 MPSA43 MPSA56 MPSA63
ECB
TO-92
BC550C BC560C
CEB
TO-92
1
2
3 NC
6
5
4
4N35 NE5532N
1
2
3
4
-V
+V
A
B
8
7
6
5
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11
12
12
13
13
14
14
15
15
16
16
17
17
K K
J J
I I
H H
G G
F F
E E
D D
C C
B B
A A
Product(s):
M1575 2 5
Sheet OfPCB#: Rev#:
V01
Potentiometer and LED VU Board
Description:
AP4K
Yorkville Sound Ltd.
550 Granite Court Pickering, ON Canada L1W 3Y8 www.yorkville.com
EML Rev#:
01
PreAmp.SchDocModified: File:8/29/2013 Tmp Date: 03/15/2013
ASIG
A_LIMIT_SEND
SHUTDOWN_A
-B_SIG
B_SIG
-A_SIG
A_SIG
B_SIG
BTEMP
-B_SIG
B_LIMIT
SHUTDOWN_B
-A_SIG A_SIG
A_LIMIT
SHUTDOWN_A
B_SIG
LIMIT_B_SEND
B_CLIP_SEND
A_LIMIT_SEND
A_CLIP_SEND
BTEMP ATEMP
NET00250
ASIG
LIMIT_B_SEND
SHUTDOWN_B
ATEMP
A_SIG
BSIG
BSIG
W125
47K
R6B
50V180P
C55A
63V330N
C39B
1/8W
10K0
R92
B_CLIP_SEND
63W12C
6
5
W12E
6
2
W8B
6
4
W8D
9
9
W20I
9
7
W20G
9
4
W20D
9
2
W20B
8
2
W1B
8
4
W1D
8
7
W1G
MMBT3906LT1
Q22B
35V
10U
C3B
W125
100K
R56B
35V
10U
C3A
1/8W
8K25
R5B
0.1W
18K2
R8B
1/8W
15K0
R12B
1/8W
8K25
R5A
0.1W
18K2
R8A
W125
2K2
R100
50V180P
C55B
1/8W
10K0
R7B
1/8W
15K0
R15B
1/8W
10M
R11B
1/8W
10K0
R7A
1/8W
15K0
R15A
1/8W
475K
R96
W125
4K7
R92B
W125
33K
R90B
1/8W
100R
R9B
1/8W
100R
R10B
63V 680N
C75
63V330N
C39A
W125
33K
R90A
1/8W
100R
R10A
1/8W
100R
R9A
1/8W
475K
R97
CDSF4148
D40B
W125
33K
R91B
4PDT MINI 3440
NO
COM
NC
S4B
CDSF4148
D40A
1N
50V
C46
1/8W
10K0
R61
W125
33K
R68
1/8W
10K0
R4
1/8W
10K0
R3
1N
50V
C53
W125
33K
R69
1/8W
27K4
R64
CDSF4148
D31
1/8W
27K4
R65
CDSF4148
D30
1/8W
249R0
R63
A_CLIP_SEND
6
2
W12B
6
1
W12A
6
1
W8A
6
3
W8C
6
4
W12D
6
6
W12F
9
8
W20H
9
6
W20F
9
5
W20E
6
5
W8E
9
3
W20C
1
9 W20A
8
1
W1A
8
3
W1C
8
6
W1F
8
8
W1H
8
5
W1E
MMBT3906LT1
Q22A
7805
W125
100K
R56A
W125
2K2
R98
1/8W
15K0
R12A
1/8W
10M
R11A
63V 680N
C77
1/8W
475K
R94
W125
4K7
R92A
MC33079D
+
5
-
6
7
U15B
1/8W
475K
R95
MC33079D
+
12
-
13
14
U15D
W125
33K
R91A
100N 100V
C60
1/8W
249R0
R62
63V330N
C31B
63V680N
C38B
W125
100K
R79B
W125
47K
R6A
W125
100K
R79A
20K R/A
Volume B
2340
T B
P2A
50V180P
C4B
LM13700MX
BIAS
15
12
+
14
-
13
16
U2BB
1/8W
10K0
R93
63V 680N
C76
20Hz/50Hz
4PDT MINI
3440
NO
COM
NC
S4A
63V330N
C31A
TL072
+
5
-
6
7
U14B
63V680N
C38A
50V180P
C4A
LM13700MX
BIAS
15
12
+
14
-
13
16
U2AB
10V0
ZD11
16V33U
C42
1/8W
10K0
R60
W125
4K7
R66
MMBT3904
Q34
MMBT3904
Q33
DOWN
UP
Limiter In/Out
3522
NO
COM
NC
S5A
63V
100N
C25B
DOWN
UP
Limiter In/Out
3522
NO
COM
NC
S5B
63V
100N
C25A
4PDT MINI
3440
NO
COM
NC
S4D
63V 680N
C78
20Hz/50Hz
4PDT MINI
3440
NO
COM
NC
S4C
TL072
+
3
-
2
1
U14A
Stereo/Bridge
DPDT MINI
3522
NO
COM
NC
S2A
MC33079D
+
5
-
6
7
U13B
100N 100V
C58
20K R/A
Volume A
2340
T B
P1A
MC33079D
+
10
-
9
8
U7C
MC33079D
+
10
-
9
8
U13C
NET00002
NET00004
NET00005
NET00008
NET00010
NET00011
NET00012
NET00058
NET00077
NET00089
NET00091
NET00102
NET00104
NET00115
NET00122
NET00123
NET00167
NET00187
NET00190
NET00191
NET00193
NET00196
NET00217
NET00218
NET00219
NET00221
NET00222
NET00223
NET00224
NET00225
NET00226
NET00227
NET00228
NET00229
NET00230
NET00231
NETB00004
NETB00005
NETB00008
NETB00010
NETB00011
NETB00012
NETB00121
NETB00122
1/8W
10M
R100A
1/8W
10M
R100B
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
+15V
+15V
+15V -15V
+15V
-15V
+15V
-15V
+15V
+15V
+15V
LM13700MX
BIAS
2
5
+
3
-
4
1
U2AA
LM13700MX
BIAS
2
5
+
3
-
4
1
U2BA
1/8W
15K0
R150A
1/8W
100R
R105A
1/8W
100R
R96A
1/8W
10M
R110A
1/8W
10M
R101A
1/8W
15K0
R150B
1/8W
100R
R102B
1/8W
100R
R96B
1/8W
10M
R110B
1/8W
10M
R101B
1/8W
15K0
R120A
1/8W
15K0
R122B
1/8W
100R
R95A
1/8W
100R
R97A
1/8W
100R
R95B
1/8W
100R
R97B
GND
GND
1/8W
10K0
R70A
1/8W
10K0
R70B
0.1W
18K2
R80B
50V180P
C40B
W125
47K
R60B
0.1W
18K2
R80A
50V180P
C40A
W125
47K
R60A
Stereo/Bridge
DPDT MINI
3522
NO
COM
NC
S2B
CDSF4148
D100
CDSF4148
D101
1/8W
10K0
R4A2
W125
1K5
R71
MMBT3906LT1
Q37
BTEMP
ATEMP
NET00250
+15V
-15V
MC33079D
+
3
-
2
1
U15A
MC33079D
+
3
-
2
1
U7A
MC33079D
+
12
-
13
14
U7D
MMBT3904
Q51B
MMBT3904
Q53B
MMBT3904
Q52B
MMBT3906LT1
Q50B
CDSF4148
D201B
CDSF4148
D200B
CDSF4148
D202B
CDSF4148
D203B
CDSF4148
D204B
CDSF4148
D207B
CDSF4148
D208B
CDSF4148
D205B
CDSF4148
D206B
W125
47K
R205B
1/8W
10K0
R209B
1/8W
10K0
R208B
W125
47K
R204B
1/8W
10K0
R203B
1/8W
1K0
R201B
1/8W
1K0
R202B
1/8W
10K0
R200B
1/8W
2K0
R206B
1/8W
2K0
R207B
1/8W
10K0
R210B
W100
220K
R212B
16V
33U
C200B
50V100P
C201B
50V100P
C202B
100V100N
C203B
GND
1/8W
10K0
R211B
+15V
GND
NET00500
MC33079D
+
10
-
9
8
U15C
MC33079D
+
12
-
13
14
U13D
MC33079D
+
3
-
2
1
U13A
MMBT3904
Q51A
MMBT3904
Q53A
MMBT3904
Q52A
MMBT3906LT1
Q50A
CDSF4148
D201A
CDSF4148
D200A
CDSF4148
D202A
CDSF4148
D203A
CDSF4148
D204A
CDSF4148
D207A
CDSF4148
D208A
CDSF4148
D205A
CDSF4148
D206A
16V0
ZD200A
16V0
ZD201A
W125
47K
R205A
1/8W
10K0
R209A
1/8W
10K0
R208A
W125
47K
R204A
1/8W
10K0
R203A
1/8W
1K0
R201A
1/8W
1K0
R202A
1/8W
10K0
R200A
1/8W
2K0
R206A
1/8W
2K0
R207A
1/8W
10K0
R210A
W100
220K
R212A
16V
33U
C200A
50V
100P
C202A
50V100P
C201A
100V
100N
C204A
GND
1/8W
10K0
R211A
BTEMP ATEMP
A_LIMIT
+15V
GND
GND
B_LIMIT
GND
66W8F
NET00073
50V100P
C205
SHUTDOWN_B
SHUTDOWN_B
SHUTDOWN_A
SHUTDOWN_A
50V100P
C206
47P
50V
C207
47P 50V
C208
W125
68K
R215A
W125
68K
R215B
50V470P
C215A
50V470P
C215B
W20
W1
W8
W12
To W1D on display board. See sheet 2.
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11
12
12
13
13
14
14
15
15
16
16
17
17
K K
J J
I I
H H
G G
F F
E E
D D
C C
B B
A A
Display
Section:
Product(s):
Display.SchDoc
M1575 3 5
Sheet OfPCB#: Rev#:
Modified:
V01
File:8/29/2013
AP4K
EML Rev#:
01
Tmp Date: 03/15/2013
RED
Clip B
LDB5D
RED
Clip A
LDA5D
GRN
0dB
LDA3D
GRN
-6dB
LDA2D
GRN
-40dB
LDA1D
GRN
0dB
LDB3D
GRN
-6dB
LDB2D
GRN
-40dB
LDB1D
OUT
1
-IN
6
+IN
7
LM339D
U1DA
LM339D
OUT
2
-IN
4
+IN
5
U1DB
LM339D
OUT
13
-IN
10
+IN
11
U1DC
LM339D
OUT
14
-IN
8
+IN
9
U1DD
LM339D
V+
3
GND
12
U1DE
LM339D
OUT
2
-IN
4
+IN
5
U2DB
LM339D
OUT
13
-IN
10
+IN
11
U2DC
LM339D
V+
3
GND
12
U2DE
YEL
Limit B
LDB4D
YEL
Limit A
LDA4D
MMBT3906LT1
Q2D
MMBT3906LT1
Q1D
1/8W
475R0
R8D
0.1W
10R0
R10D
1/4W
619R0
R9D
1/8W
2K0
R11D
1/8W
2K0
R12D
0.1W
7K50
R7D
GND
1/8W
249R0
R14D
1/8W
249R0
R15D
1/8W
2K0
R13D
GRN
Power
LD1D
W125
47R
R16D
GND
100N 25V
C1D
100N
25V
C2D
100N
25V
C3D
100N
25V
C4D
1/8W
100K0
R2D
1/8W
100K0
R5D
+
3
-
2
1
TL072
U3DA
+
5
-
6
7
TL072
U3DB
V+
8
V-
4
TL072
U3DC
1/8W
47K5
R1D
1/8W
47K5
R4D
1/8W
475R0
R3D
1/8W
475R0
R6D
CDSF4148
D4D
CDSF4148
D2D
CDSF4148
D1D
CDSF4148
D3D
GND
GND
GND
GND
Clip A
Clip B
Limit A
Limit B
Sense B
Sense A
10U
16V
C5D
10U 16V
C6D
1
9W1DA
2
9W1DB
3
9W1DC
4
9W1DD
5
9W1DE
6
9W1DF
7
9W1DG
8
9W1DH
9
9W1DI
Sense B
Sense A
GND
Clip A
Limit A
Limit B
Clip B
Limit A
Limit B
Clip B
Clip A
Sense A
Sense B
+15V
-15V
+15V
+15V
+15V
+15V
-15V
-15V
W1D
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11
12
12
13
13
14
14
15
15
16
16
17
17
K K
J J
I I
H H
G G
F F
E E
D D
C C
B B
A A
Assembly Documentation
Section:
Product(s):
Assembly.SchDoc
M1575 4 5
Sheet OfPCB#: Rev#:
Modified:
V01
File:8/29/2013
AP4K
EML Rev#:
01
Tmp Date: 03/15/2013
1. PCBSA: Bend C200A and C200B down.
2. PCBSA: Do not insert W1D.
3. PCBSA: After wave soldering, break out display board and solder onto pot board.
SPECIAL PRODUCTION NOTES
PCB ASSEMBLY DOCUMENTATION
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11
12
12
13
13
14
14
15
15
16
16
17
17
K K
J J
I I
H H
G G
F F
E E
D D
C C
B B
A A
Design Information And History
Section:
Product(s):
History.SchDoc
M1575 5 5
Sheet OfPCB#: Rev#:
Modified:
V01
File:8/29/2013
AP4K
EML Rev#:
01
Tmp Date: 03/15/2013
CHANGE HISTORY POTENTIOMETERS AND KNOBS
DESIGN HISTORY AND INFORMATION
THIS SHEET CONTAINS EXTRA INFORMATION ABOUT THE DESIGN AS WELL AS A HISTORY TABLE.
.V01 FIRST PRODUCTION RELEASE. - ML
R212A and R212B changed to 220K (SM8060). - ML . . . . . . . . . . .
. . . . . . . . . . . .
26-JUN-2013
13
10
7
4
1
9
11 12
8
#
2 3
5 6
VER#DATE DESCRIPTION OF CHANGE
. . . . . . . . .
29-AUG-2013 .
.
PC#
8573 . . . . . . . . . . .
.. .
. . . . . . . . . . . .
. . . . . . . . . . . .
.
13
10
7
4
1
9
11 12
8
#
2 3
5 6
VER#DATE DESCRIPTION OF CHANGE
. . . . . . . . .
. .
.
PC#
. . . . . . . . . . . .
.. .
. . . . . . . . . . . .
. . . . . . . . . . . .
.
13
10
7
4
1
9
11 12
8
#
2 3
5 6
VER#DATE DESCRIPTION OF CHANGE
. . . . . . . . .
. .
.
PC#
. . . . . . . . . . . .
"STYLE_P34"
P1 P2 . .
100212340 2340 . . . . . . . . . .
10021
.
.
.
.
.
.
.
.
.
.
VOLUME A
REF POT#FUNCTION KNOB#
POTENTIOMETERS AND KNOBS
. . . . . . . . .
VOLUME B .
.. .
. . . . . . . . .
STYLE
P34 P34 . . . . . . . . . . .
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11
12
12
13
13
14
14
15
15
16
16
17
17
K K
J J
I I
H H
G G
F F
E E
D D
C C
B B
A A
ECAD Incidentals
Section:
Product(s):
ECO.SchDoc
M1575 6 5
Sheet OfPCB#: Rev#:
Modified:
V01
File:8/29/2013
AP4K
EML Rev#:
01
Tmp Date: 03/15/2013
PANEL PARTS
Panel Fiducials
CF1 CF2
i
Not Routed
NET00211 NET00234 NET00209 NET00207
NET00212 NET00208
D
20K
R/A
Function
2340
TB
P2B
LM13700MX
Dual VCA {Function}
7828
8
7
(VCC)
U2BC
D
20K
R/A
Function
2340
TB
P1B
LM13700MX
Dual VCA {Function}
7828
9
10
(VCC)
U2BD
LM13700MX
Dual VCA {Function}
7828
8
7
(VCC)
U2AC
LM13700MX
Dual VCA {Function}
7828
9
10
(VCC)
U2AD
D
20K
R/A
Function
2340
P2C
D
20K
R/A
Function
2340
P1C
GND
GND
EC13EC12EC11EC10
Mounting Holes
GND
GND
MC33079D
7668
V+
4
V-
11
U15E
MC33079D
7668
V+
4
V-
11
U7E
TL072
7669
V+
8
V-
4
U14C
LM13700MX
{Function}
7828
V+
11
V-
6
U2AE
MC33079D
7668
+
5
-
6
7
U7B
MC33079D
7668
V+
4
V-
11
U13E
NET00006
+15V
-15V
+15V
-15V
+15V
-15V
+15V
-15V
+15V
-15V
GND
LM13700MX
{Function}
7828
V+
11
V-
6
U2BE
+15V
-15V
AI-ASSY1 PCB1
B_SIG
BTEMP
-B_SIG
B_LIMIT
SHUTDOWN_B
-A_SIG A_SIG
A_LIMIT
SHUTDOWN_A
ATEMP
GND
GND
N18
N19
N20
N21
N22
N23
N24
N25
N26
N27
N28
N29
SHUTDOWN_B
SHUTDOWN_A
B_SIG
LIMIT_B_SEND B_CLIP_SEND
A_LIMIT_SEND
A_CLIP_SEND
A_SIG
GND
+15V
-15V
N9 N10 N11 N12 N13 N14 N15 N16 N17
BTEMP ATEMP
NET00250
ASIG
BSIG
GND
+15V
-15V
N1
N2
N3
N4
N5
N6
N7
N8
OUT
1
-IN
6
+IN
7
LM339D
U2DA
LM339D
OUT
14
-IN
8
+IN
9
U2DD
GND
GND
1
A A
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
PCB ASSEMBLY DOCUMENTATION
B B
SPECIAL PRODUCTION NOTES
1. PCBSA: Bend C200A and C200B down.
C C
2. PCBSA: Do not insert W1D.
3. PCBSA: After wave soldering, break out display board and solder onto pot board.
D D
E E
F F
G G
H H
I I
J J
Section:
K K
1
2
3
4
5
6
7
8
9
10
11
12
13
Product(s):
Modified:
14
Assembly Documentation
AP4K
M1575 4 5
15
V01
Assembly.SchDoc
File:8/29/2013
EML Rev#:
16
01
Sheet OfPCB#: Rev#: Tmp Date: 03/15/2013
17
1
A A
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
DESIGN HISTORY AND INFORMATION
B B
CHANGE HISTORY POTENTIOMETERS AND KNOBS
C C
D D
E E
F F
G G
1
26-JUN-2013 29-AUG-2013
2
.
3
.
4
.
5
.
6
.
7
.
8
.
9
.
10
.
11
.
12
.
13
# 1
. .
2
.
3
.
4
.
5
.
6
.
7
.
8
.
9
.
10
.
11
.
12
.
13
# 1
. .
2
.
3
.
#
10 11 12 13
4
.
5
.
6
.
7
.
8
.
9
. . . .
H H
I I
VER#DATE DESCRIPTION OF CHANGE
. . . . . . . . . . . .
VER#DATE DESCRIPTION OF CHANGE
. . . . . . . . . . . .
VER#DATE DESCRIPTION OF CHANGE
. . . . . . . . . . . .
PC#
.V01 FIRST PRODUCTION RELEASE. - ML 8573 . . . . . . . . . . .
R212A and R212B changed to 220K (SM8060). - ML . . . . . . . . . . .
PC#
.. . . . . . . . . . . . . .
. . . . . . . . . . . .
PC#
.. . . . . . . . . . . . . .
. . . . . . . . . . . .
POTENTIOMETERS AND KNOBS
REF POT#FUNCTION KNOB#
P1
VOLUME A P2 . . . . . . . . . .
VOLUME B
.
.
.
.
.
.
.
.
.
.
2340 . . . . . . . . . .
.
STYLE
P34 P34 . . . . . . . . . . .
100212340 10021 . . . . . . . . . . .. .
"STYLE_P34"
J J
Section:
THIS SHEET CONTAINS EXTRA INFORMATION ABOUT THE DESIGN AS WELL AS A HISTORY TABLE.
K K
1
2
3
4
5
6
7
8
9
10
11
12
13
Product(s):
Modified:
14
Design Information And History
AP4K
M1575 5 5
15
History.SchDoc
File:8/29/2013
V01
EML Rev#:
16
01
Sheet OfPCB#: Rev#: Tmp Date: 03/15/2013
17
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
