ZC179 RFID module manual
ZC179 RFID module
manual
Ver 1.54
October 27, 2016
YONGXIN ELEC, SUZHOU CN
ZC179 RFID module manual
1
CONTENT
1. GENERAL DESCRIPTION ........................................................................................................................... 2
2. PRODUCT MANIFEST ................................................................................................................................ 2
3. USER’S GUIDE .................................................................................................................................... 2
4. PRODUCT DETAILS.................................................................................................................................. 3
5. OPERATING FLOW ................................................................................................................................... 4
6. MECHANICAL STRUCTURE .......................................................................................................................... 5
7. FCC STATEMENT .................................................................................................................................... 5
ZC179 RFID module manual
2
1. GENERAL DESCRIPTION
Based on PIC12F629 microcontroller, ZC179 RFID module can be used on all
kinds of standard 125 KHz contactless IC cards. Up to 25 cards, each has
64bits unique ID, can be saved in this module.
High power relay, DC load (24V, 3A max) or AC load (277V, 10A max).
Apply to all kinds of security, ID challenge cases.
Compatible to 179 module from Welleman Inc.
2. PRODUCT MANIFEST
1 ZC179 RFID module
1 near field antenna
1 coaxial cable, connecting the RFID module and antenna.
2 standard 125KHz contactless IC card
3. USER’S GUIDE
Mode: ZC179 RFID module has two modes: security and insecurity.In
security mode, module will open the gate only when a valid card appears
on antenna. However, it will open the gate for ANY card in insecurity
mode. By adding user’s cards, ZC179 will go into security mode.
Power on: If the relay on ZC179 module pop once, it’s in the insecurity
mode, every time you turn on its power. If the relay pop twice (tick tick),
it’s in the security mode.
First time settings: Place the card on antenna, press module’s button.
The relay will pop twice and once every second after that. Release then
button after few seconds (N seconds, N<250), ZC179 module will save it.
After this interval setting, ZC179 will open the gate for N seconds, once
it confirms a valid card. Meanwhile, ZC179 will go into security mode,
after adding this card. You can add 24 more cards, each has 64 bits unique
ID.
To add cards: Place the card on antenna, press module’s button. The relay
will pop twice. If ZC179 module already has 25 cards in its memory, the
relay will pop 5 times and this card will not be added.
