It is a simple single phase four module Din-Rail meter, which only have kWh measurement. It is
widely used in Sub-metering system. This meter is very popular worldwide. Moreover, it is
convenient to install with only 0.3092 kg and 76mm Width.
2.
Technical
2.
Technical
2.
2. Technical
Technical Parameters
Voltage: 2 3 0V
Current : 10 ( 10 0)A
Accuracy class : 1.0
Standard: IEC62052-11, IEC62053-21
Frequency : 50-60Hz
Impulse constant : 1 6 00imp/kWh
Display : Counter 5+ 1
Power consumption : ≤
Starting current : : 0.004Ib
Working Temperature: -2 5 ～ 70 ℃
Storage T emperature: - 40 ～ 80 ℃
Average humidity value of year : 75%
Maximal humidity value: 95%
Parameters
Parameters
Parameters
8VA
≤ 0.4W
3.
Description
3.
Description
3.
3. Description
Description
A
1
A Impulse Output
Material
Material
Material
Material
Case Grey flame resistant ABS
Terminal cover Grey flame resistant ABS
Base Bottom Grey flame resistant ABS
4.
Connection
4.
Connection
4.
4. Connection
Connection Diagram
Diagram
Diagram
Diagram
5.
Meter
5.
Meter
5.
5. Meter
Meter Dimensions
Dimensions
Dimensions
Dimensions
76mm
Height 100mm
Width 76mm
Depth 65mm
Weight 0.3092 kg(Net)
4 5 m m
1 0 0 m m
6mm 5
3 6 m m
2
