Yifang Digital Technology SW302 Users Manual

Packing contents

enclosed in the device.

1. Pedometer 2. AC-DC Power adapter 3. Charging box

2. Wrist strap (Silicon gel)

Product Overview

Pedometer

1. Ornamental lens –covers
four LED indicators.

2. Contact points for charging

Note: There is one motor

Charging box

3. Micro USB port

4. Contact points for charging

Wrist strap (Silicon Gel)

5. Fixing buckle

6. Slot for holding the unit

7. Positioning holes

LED Indication

There are four white LED indicators inside the device indicating the battery level
and amount of exercise, accompanied with motor vibration:

1) Indicating Battery Level
During charging:
When the battery level is less than 25 per cent, the 4 LED will light one by one
repeatedly;
When the battery level is between 25-50 percent, LED 1 will keep lighting,
with the other 3 lighting one by one repeatedly;
When the battery level is between 50-75 percent, LED 1 and LED 2 will keep
lighting, with other 2 lighting one by one repeatedly;
When the battery level is over 75 percent but less than 100 percent, LED 1,
LED 2 and LED 3 will keep lighting, with LED 4 blinking;
When the batter level is full, i.e. it reaches 100 percent, the 4 LEDs all will
keep lighting before the power adapter is disconnected.
Note:
a. Once the battery level is less than 20 percent, 4 LEDs will light together;
b. Once the power adapter is disconnected after the battery has been fully

charged, all LEDs will go out immediately.

2) Indicating the Amount of Exercise
In the case that you have preset a target amount of exercise on the device:
If only 25 percent of the target amount reached, only LED 1 will light with
motor vibrating;
If half the target amount reached, only LED 1 and LED 2 will light with motor
vibrating;
If 75 percent of the target amount reached, LED 1, LED 2 and LED 3 will light
with motor vibrating;
Once the total target has been reached, 4 LEDs will light for 10 seconds, with
motor vibrating.

Note: In the case that user has set no target amount of exercise, the 4 LED will
not respond.
