Yifang Digital Technology NX16A11264 User Manual

Safety Precautions

z Do not subject the device to severe impact or drop it from heights. z Do not use the device in extreme hot or cold, dusty or damp conditions. Do not

expose it to direct sunlight.

z Avoid using the device near strong magnetic fields. z Normal functioning of the product may be disturbed by ESD. If so, simply reset

and restart the device following the instruction manual. During file transmission, please handle with care and operate in a static-free environment.

z Keep the device away from water and other liquids. In the event that water or

other liquids enter the device, power off the product immediately and clean the device.

z Do not use chemicals to clean the device in order to avoid corrosion. Clean it

with a dry cloth.

z Do not install this equipment in a confined space such as a book case or similar

unit. The ventilation should not be impeded by covering the ventilation openings with items such as newspaper, table-cloths, curtains etc.

z No naked flame sources, such as lighted candles, should be placed on the

apparatus.

z Attention should be drawn to environmental aspects of battery disposal. z Use the apparatus in moderate climates. z We are not responsible for damage or lost data caused by malfunction, misuse,

modification of the device or battery replacement.

z Do not attempt to disassemble, repair or modify the product. This will invalidate

the warranty.

z If the device will not be used for an extended period of time, please charge the

battery at least once per month to maintain battery life.

z Charge the battery if:

a) The battery level icon displays (An empty battery) b) The device powers off automatically when restarted. c) There is no response when pressing keys with keys unlocked and battery full.

z Do not interrupt the connection when the device is being formatted or

transferring files. Otherwise, data may be corrupted or lost.

z When the device is used as a portable HD, please use only per the instructions.

Otherwise, permanent data loss could occur.

z Please use and install data using the attachments/accessories provided and only

according to the manufacturer’s instruction.

z Please refer to the information on the bottom of the device for electrical and

safety information before installing data or operating the device.

z To reduce the risk of fire or electric shock, do not expose this device to rain or

moisture. The device should not be exposed to dripping or splashing. Never place objects filled with liquids, such as vases, on the device.

z There is danger of explosion if the battery is replaced incorrectly. Replace only

with the same or equivalent type.

The battery (battery or batteries or battery pack) should not be exposed to

excessive heat such as sunlight, fire or the like.

z Please follow responsible procedures for battery disposal. z If the power adaptor disconnected from the device, the device will remain

operable as long as the battery has sufficient charge.

z The power adaptor is a CLASS II apparatus with double insulation, and no

external ground is provided.

z Safety symbol explanation:

- The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of non-insulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock.

- To reduce the risk of electric shock, do not remove the cover (or back) as there are no user-serviceable parts inside. Refer servicing to qualified personnel.

- The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance instructions in the literature accompanying the device.

- Correct Disposal of this product. This marking indicates that this product should not be disposed of with other household waste in the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To dispose of your used device, please use the return and collection systems available in your area or contact the retailer where the product was purchased. They can take this product for safe environmental recycling.

z This equipment should be installed and operated with minimum distance 20cm

between the radiator & your body.

z CE in which countries where the product may be used freely: Germany, UK, Italy,

Spain, Belgium, Netherlands, Portugal, Greece, Ireland, Denmark, Luxembourg, Austria, Finland, Sweden, Norway and Iceland.

Listening Cautions

z This product respects the current regulations for limiting the output volume of

consumer audio devices to a safe level. By listening to your device with headphones or earbuds at high volumes, you run the risk of permanent damage to your ears. Even if you get used to listening at high volumes and it seems normal to you, you still risk the possibility of damaging your hearing. Reduce the volume of your device to a reasonable level to avoid permanent hearing damage. If you hear ringing in your ears, reduce the volume or shut off your device. This device has been tested with the supplied earphones. In order to preserve your hearing, it is advised that you use only the following headphone models: the earphones supplied with your device, or any other headphones that respect the current regulations. Other types of headphones may produce higher volume levels.（At full power ,the prolonged listening of the walkman can damage the ear of the use）

z Do not use while operating a motorized vehicle. It may create a traffic hazard

and is illegal in many areas.

z You should use extreme caution or temporarily discontinue use in potentially

hazardous situations created by obstructed hearing.

z Even if your headphones or earphones are the open-air type designed to let you

hear outside sounds, don’t turn up the volume so high that you can’t hear what’s around you.

z Sound can be deceiving. Over time your hearing “comfort level” adapts to higher

volumes of sound. What sounds “normal” can actually be loud and harmful to your hearing. Guard against this by setting the volume of your device at a safe level BEFORE your hearing adapts.

To establish a safe volume level:

a. Start your volume control at a low setting. b. Slowly increase the sound until you can hear it comfortably and clearly,

and without distortion. Once you have established a comfortable sound level, leave it there.

This manual may not reflect your actual device’s operation. All infor mation is subject to change without prior notification. Please follow your actual device’s operational procedures.

Table of Content

Safety Precautions ........................................................................... 1

Listening Cautions ............................................................................ 3

Packing Contents ............................................................................. 5

Features & Functionality ..................................................................... 5

Basic Connections ........................................................................... 6

Basic Operation ............................................................................... 9

Maintenance ................................................................................. 12

Major Specifications ....................................................................... 14

FCC Statement ............................................................................. 14

Frequently Asked Questions(FAQ) ....................................................... 16

Congratulations! Windows 10, the state-of-the-art operating system from Microsoft, is preinstalled on your tablet PC. When you get your device, be sure to check the following items are enclosed in the package:

z Main Unit ● Power Adaptor ● Keyboard ● User’s Manual

Features & Functionality

Overview

Packing Contents

Feature Functionality

1. Charging indicator Indicates the battery-charge status.

2. microSD card slot Reads and writes files stored on a microSD card.

3. HDMI port Connect HD television via optional HDMI cable, for

4. Micro-USB port Connect USB devices, via an optional USB conversion

5. DC-In socket Connect the supplied power adapter for charging the

6. Microphone Records sounds.

7. Audio port (3.5 mm)

8. Speaker Provides audio output.

9. Sustaining port (female) Fix and sustain the connection to external keyboard.

10. Pogo pin connector (female) Connect external keyboard

11.Front-facing camera Capture a front view picture or record videos.

12.Rear camera Captures pictures or videos.

13.Volume+/- buttons Press to increase/decrease volume

14.Power button Press and hold to turn the tablet on or off.

switching the display to wider screen.

cable, for transferring data, music, photos, videos, and so on.

battery.

Provides sound input while making calls using web-based apps. Connect a headset, headphones, microphones, or other audio equipment to listen to stereo sound, record audio, or make web phone calls.

Use while making video calls.

Press to turn the display on or off.

Note:

1. Both cameras support zoom, face tracking.

2. User can connect a keyboard and USB mouse to this tablet if necessary.

Basic Connections

Charging the tablet

Note: If using the tablet for the first time, or after a long period of idle time, charge the battery for more than half an hour before turning it on, to ensure system stability.

The tablet has a built-in rechargeable battery. Charge the device when the battery level is low.

1. Plug the power adapter into the DC-In socket.

2. Connect the power adapter to an electrical outlet and charge the tablet until the

battery is fully charged.

Caution:

1. Charge the battery in an ambient temperature of 0 °C to 35 °C.

2. Use only the supplied power adapter to charge your tablet. Using unauthorized power adapters may severely damage your tablet.

Note:

1. The battery is not fully charged when you unpack your tablet.

2. A fully discharged battery takes about 5 hours to fully charge.

3. When the battery is being charged, the LED indicator lights red, and when the battery has been fully charged, the LED indicator lights orange.

Turning On the Tablet

Note: This device has been equipped with Windows 10 system at the factory, so user need not perform Windows setup again before using for the first time.

Press and hold the Power button for 2 seconds to turn on your tablet. The lock screen appears.

Now the tablet is ready for use.

Note: If the login screen is not enabled in W ind ow s 10, yo u wi ll be ta ke n d irec t ly fro m the lock screen to the Start screen.

Turning Off the Tablet

You can turn off the tablet in two ways:

Using the Power button:

1. Press and hold the Power button for at least 4 seconds.

2. Swipe-down the shutdown confirmation screen to the bottom edge of the display

+ 11 hidden pages
