Safety Precautions
z Do not subject the device to severe impact or drop it from heights.
z Do not use the device in extreme hot or cold, dusty or damp conditions. Do not
expose it to direct sunlight.
z Avoid using the device near strong magnetic fields.
z Normal functioning of the product may be disturbed by ESD. If so, simply reset
and restart the device following the instruction manual. During file transmission,
please handle with care and operate in a static-free environment.
z Keep the device away f rom water and other liquids. In the event that water or
other liquids enter the device, power off the product immediately and clean the
device.
z Do not use chemicals to clean the device in order to avoid corrosion. Clean it
with a dry cloth.
z Do not install this equipment in a confined space such as a book case or similar
unit. The ventilation should not be impeded by covering the ventilation openings
with items such as newspaper, table-cloths, curtains etc.
z No naked flame sources, such as lighted candles, should be placed on the
apparatus.
z Attention should be drawn to environmental aspects of battery disposal.
z Use the apparatus in moderate climates.
z We are not responsible for damage or lost data caused by malfunction, misuse,
modification of the device or battery replacement.
z Do not attempt to disassemble, repair or modify the product. This will invalidate
the warranty.
z If the device will not be used for an extended period of time, please charge the
battery at least once per month to maintain battery life.
z Charge the battery if:
a) The battery level icon displays
b) The device powers off automatically when restarted.
c) There is no response when pressing keys with keys unlocked and battery full.
z Do not interrupt the connection when the device is being formatted or
transferring files. Otherwise, data may be corrupted or lost.
z When the device is used as a portable HD, please use only per the instructions.
Otherwise, permanent data loss could occur.
z Please use and install data using the attachments/accessories provided and only
according to the manufacturer’s instruction.
z Please refer to the information on the bottom of the device for electrical and
safety information before installing data or operating the device.
(An empty battery)
1
To reduce the risk of fire or electric shock, do not expose this device to rain or
z
moisture. The device should not be exposed to dripping or splashing. Never
place objects filled with liquids, such as v ases, on the device.
z There is danger of explosion if the battery is replaced incorrectly. Replace only
with the same or equivalent type.
z The battery (battery or batteries or battery pack) should not be exposed to
excessive heat such as sunlight, fire or the like.
z Please follow responsible procedures for battery disposal.
z If the power adaptor disconnected from the device, the device will remain
operable as long as the battery has sufficient charge.
z The power adaptor is a CLASS II apparatus with double insulation, and no
external ground is provided.
z Safety symbol explanation:
- The lightning flash with arrowhead symbol within an equilateral triangle is
intended to alert the user to the presence of non-insulated “dangerous
voltage” within the product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock.
- To reduce the risk of electric shock, do not remove the cover (or back) as
there are no user-serviceable parts inside. Refer servicing to qualified
personnel.
- The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and maintenance instructions in
the literature accompanying the device.
-
Correct Disposal of this product. This marking indicates that this
product should not be disposed of with other household waste in the EU. To
prevent possible harm to the environment or human health from
uncontrolled waste disposal, recycle it responsibly to promote the
sustainable reuse of material resources. To dispose of your used device,
please use the return and collection systems available in your area or
contact the retailer where the product was purchased. They can take this
product for safe environmental recycling.
z This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
z CE in which countries where the product may be used freely: Germany, UK, Italy
2
, Spain, Belgium, Netherlands, Portugal, Greece, Ireland, Denmark, Luxembour
Listening Cautions
g, Austria, Finland, Sweden, Norway and Iceland. In France,
except the channel 10 through 13, law prohibits the use of other channels.
z This product respects the current regulations f or limiting the output volume of
consumer audio devices to a safe level. By listening to your device with
headphones or earbuds at high volumes, you run the risk of permanent damage
to your ears. Even if you get used to listening at high volumes and it seems
normal to you, you still risk the possibility of damaging your hearing. Reduce the
volume of your device to a reasonable level to avoid permanent hearing damage.
If you hear ringing in your ears, reduce the volume or shut off your device. This
device has been tested with the supplied earphones. In order to preserve your
hearing, it is advised that you use only the following headphone models: the
earphones supplied with your device, or any other headphones that respect the
current regulations. Other types of headphones may produce higher volume
levels.ాAt full power ,the prolonged listening of the walkman can damage the ear
of the useి
z Maximum output voltage<=150mv
z Do not use while operating a motorized vehicle. It may create a traffic hazard
and is illegal in many areas.
z You should use extreme caution or temporarily discontinue use in potentially
hazardous situations created by obstructed hearing.
z Even if your headphones or earphones are the open-air type designed to let you
hear outside sounds, don’t turn up the volume so high that you can’t hear what’s
around you.
z Sound can be deceiving. Over time your hearing “comfort level” adapts to higher
volumes of sound. What sounds “normal” can actually be loud and harmful to
your hearing. Guard against this by setting the volume of your device at a s afe
level BEFORE your hearing adapts.
To establish a safe volume level:
a. Start your volume control at a low s etting.
b. Slowly increase the sound until you can hear it comfortably and clearly,
and without distortion. Once you have established a comfortable sound
level, leave it there.
This manual may not reflect your actual device’s operat ion. All information is subject to change
without prior notification. Please follow your actual device’s operational procedures.
3
Table of Content
Safety Precautions............................................................................................ 1
Listening Cautions ............................................................................................ 3
Feature Summary ............................................................................................. 5
Accessories...................................................................................................... 5
Buttons & Ports................................................................................................. 5
Charging Battery............................................................................................... 6
Installing Memory Card.....................................................................................6
Transferring Files .............................................................................................. 7
Turning On/Off..................................................................................................7
Home Screen....................................................................................................8
Unlocking the Screen...................................................................................... 10
Touch Screen & Buttons Usage ...................................................................... 10
Accessing Internet .......................................................................................... 10
Reading E-Books............................................................................................ 13
Accessing online Bookstore............................................................................ 17
Playing Music ................................................................................................. 19
Playing Video.................................................................................................. 21
Viewing Photos............................................................................................... 23
Exploring Files ................................................................................................ 25
Sending/Receiving E-mails............................................................................. 29
Reading Office Document ............................................................................... 31
Managing 3
Managing Tasks.............................................................................................. 33
System Settings.............................................................................................. 33
Asking for Help ............................................................................................... 34
Troubleshooting..............................................................................................35
Specifications..................................................................................................35
FCC Statement...............................................................................................37
rd
Party Applications...................................................................... 32
4
Feature Summary
Wi-Fi Connectivity
With the latest Wi-Fi technology, this device can connect you to the Internet wherever
you are.
7.0” Touch Screen
Touch or slide your finger on the screen, the screen responds instantly.
Third-party Application Support
With the built-in Android
applications in this device.
Built-in G-sensor
The screen changes to landscape or portrait automatically when the device rotates.
Entertainment
You can enjoy music, movies, pictures and e-books with the Mobile NextBook.
Office Document Reader
With the built-in OfficeSuite, you can read documents in Word, Excel, PPT etc.
TM
OS, you can install a large number of third-party
Accessories
z USB Cable
z Power Adaptor
z Pouch
Buttons & Ports
Front View
a. Touch Screen
b. Charge LED
a
bc de f
c. Search – Go to Google Search page
d. Home – Go to the Home Screen.
e. Menu – Display menu options.
f. ESC – Return
5
Bottom View
g
j
i
k
h
g. Power-IN port – connects to any standard electric source through the provided
AC adaptor.
h. SD Card Slot – accommodates any standard SD memory card.
i. Earphone Port – connects to stereo earphones (not provided with the unit.)
j. USB Port – connects to a computer through the USB cable.
k. Power Button/Charge Indicator – pressandholdtoturnonoroffthedevice;
briefly press to turn the screen on or off.
Rear View
l. Reset pin hole – used to reset your
device if the device freezes.
m. Built-in Speakers
m
ll
Charging Battery
The device has a built-in rechargeable battery. No extra battery installation is required.
Just charge the device when it indicates low battery.
To charge the battery, connect the device to any standard wall outlet via the DC-IN
port using the power adaptor. It takes about 5 hours to fully charge the battery. When
the battery is fully charged, the charge indicator at the left bottom should light up in
green. During charging, the indicator lights up in red.
Note:
a. You are strongly recommended to charge the battery immediately when the device
indicates the battery is lower than 15%!
b. You can operate the device even when it is being charged. But for extended battery life, it is
suggested NOT to use the device when it is charging.
c. It is recommended to charge the battery before you use the device for the first time.
d. For maximum performance, lithium-ion batteries need to be used often. If you don’t use the
device often, be s ure to recharge the battery at least once per month.
Installing Memory Card
This device can read files directly from memory card.
To use a memory card, find the card slot at the bottom of the device and then insert
the memory card into the slot in the correct orientation. To access the files stored in
the m emory card, enter the Explorer mode by tapping the Explorer icon and select
6
the “SD Card” directory.
Transferring Files
Before reading or playing files, you need to transfer media files from a computer to the
device.
(1) Connect the device to a computer with the supplied USB cable.
(2) Drag from the top bar downwards to display the USB notification message as
shown.
(3) Choose “USB Connected” and then tap “Turn on USB storage” to connect the
device to computer.
(4) Once connected, two removable disk drives will show on your computer. One
represents the internal memory of the device, and the other represents the
memory card inserted into the device. Now you can copy files from or to these disk
drives just as you would on your hard drive.
(5) Disconnect the device from the PC safely.
a) Left-click the
b) Click the pop-up mini-window message of “Stop the USB Mass Storage
Device – Drive (X).”
c) Disconnect the device from the computer.
Note: The pre-installed applications and Andro id OS occupy a considerable part of capacity –
nearly more than 1GB, it is normal that you see huge difference between available memory space
and total capacity.
Drag downwards
icon at the right bottom corner of the computer desktop.
Turning On/Off
To turn on the device, press and hold the Power button on the unit until you see the
boot-up screen then release. It may take a few minutes to start up the s ystem, please
wait before you proceed.
To turn off the device, press and hold the Power button until you see the option
“Power Off”, tap on “Power Off” and then tap on “OK”.
Tip: This device will sleep with the scree n off if it stays inactive for a few seconds. You can briefly
press the Power button to turn on the screen and wake it up.
7
Weather forecast – worldwide
cities (required Wi-Fi connection)
y You can change the city by tapping
the city name.
y You can change the temperature
unit by tapping the temperature.
Default shortcuts
Tap on an icon to open the
corres ponding application.
You can add or remove shortcuts,
see “Customizing the Home
Screen items” on the next page.
Home Screen
Current Time
Ebook Reader / Applications
/Setting/Help shortcuts
Shortcuts to system settings,
applications, ebook reader and help
WiFi connection
Go to Home Screen
Drag the top bar downwards to
display the notification message
Batterylevel
Time
Vol ume
down/up
Return
Display menu
options
The extended Home Screen
Slide your finger horizontally on the screen to go to the left or right panel of the extended
Home Screen.
Customize the Home Screen
You can customize the Home Screen by adding/removing shortcuts and widgets,
changing the wallpaper.
y To add a Home Screen item (shortcuts, widgets, folders etc.), tap on the Menu icon
8
and then select “Add” . You can also hold your finger on the screen and then
choose an item from the list.
y You can add a folder onto the Home Screen by holding your finger on the s creen
and then choose Folders Æ New Folder. You can drag shortcuts or widgets to the
folder.
To rename the folder, a) tap to open the folder, b) hold your finger on the title bar of
the opened folder until the Rename window pops up, c) input folder name.
y To move a Home Screen item, hold your finger onto it until it is highlighted, then
drag it to the desired location, and release it.
y To remove a Home Screen item, hold your finger onto it until it is highlighted, drag it
to the recycle bin which turns from the Application Tab, and then release your
finger.
y To change the wallpaper, from the Home Screen, tap on the Menu icon
of options appears. Tap on “Wallpaper” and then choose a picture as the desktop
wallpaper.
y To change the System Settings, from the Home Screen, tap on the Menu icon
and then tap on “Settings”
& Display”, “Date & Time”, etc. For more information on the different settings, see
the System Settings section.
. Choose a category: “Wireless & Networks”, “Sound
,alist
Weather Forecast Setting
y You can choose a worldwide city you are interested in by tapping
the weather forcast indicator. Locate the city by selecting the state
where the city is and then selecting the city, or inputing the city
name directly in the “Search City” filed.
y You can change the default temperature unit by checking or
unchecking the “Use Celsius” option.
Display all Applications
The device has many useful applications pre-installed. You can tap the Application
Tab
to display them.
,
9
Unlocking the Screen
y
y
y
y
y
y
y
The screen will lock itself after standing by for a few
seconds. You need to unlock the screen by dragging the
lock icon
to use the device.
Note: Dragging the
to the arrow direction before you continue
icon to the arrow direction will mute the sound.
Touch Screen & Buttons Usage
Main Touch Screen Actions
In different applications, you can go back one level in the interface by tapping on
the Back icon
Wherever you are in the interface, you can go back directly to the Home screen
by tapping on the Home icon
In different applications, you can tap the Menu icon to display menu
options.
While playing a video or song, you can pause/resume it by tapping on the Pause
/Play icon.
Other Touch Screen Actions
When watching a video or listening to music,
you can tap on the progression bar to go
directly to a different location in the video or
song. You can also use your finger to drag the cursor in the
progression bar to another location in the video or song.
In different browsers (File, Music, Video, Photo, etc.), you can
hold your finger on the screen and then drag up and down to
scroll the file list up and down.
In some browsers (File, Music, Video, Photo, W eb etc.), you may hold your
finger on an item to display options.
(in the top right corner of the screen).
(in the top left corner of the screen).
Accessing Internet
Your NextBook features built-in Wi-Fi technology so that you can access the internet
over Wi-Fi network.
First of all, you need to configure a Wi-Fi network. For the Wi-Fi configuration
procedure to work, you need to be in a Wi-Fi zone that will allow you to connect to it.
Every time your NextBook is in range of a network that you have already configured
once, it will attempt to make a connection.
10
Making WIFI Connection
(1) In the Home screen, tap on the WiFi icon.
(2) Tap on the “Wi-Fi” setting to turn on the Wi-Fi.
(3) Tap the “Wi-Fi settings”, your NextBook will scan
automatically for available WiFi networks and
display them. The list of available networks
shows all the wireless networks in range of your
device.
Note:
a) The available network list is constantly refreshed automatically.
b) When the Wi-Fi is enabled, your NextBook will connect automatically to your configured
networks when they are in range.
c) If your NextBook finds a network that has never been configured, it will display a notification
icon.
(4) Tap on the network you want to connect to, enter the required network informa-
tion (password) and then tap on “Connect”. Your NextBook will now attempt to
establish a connection to that WiFi hot spot with the network parameters you
entered. If the connection is successful, the message Connected to XXX will
appear under the WIFI setting.
Advanced Connection
To manually scan for available Wi-Fi networks,
(1) In the “Wi-Fi settings” screen, tap the Menu icon
, and then tap “Scan.”
(2) If the Wi-Fi network you want to connect to does not appear in the list, scroll down
the screen, then tap “Add a Wi-Fi network.” Enter the required information, and
then tap “Save.”
To set up IP address manually, tap the Menu icon
, tap “Advanced” and then input
all required net work parameters (“Regulatory domain,” “IP address,” etc). You can
obtain these parameters from the network administrator.
Launching the Web browser
Tap the Applications icon to display all applications, and then tap the Browser icon
to launch the Web browser.
If you are already connected to a network, the W eb browser will simply open and you
can start browsing the Web. To access a new website, tap the Menu icon
display the menu, and then select “Go” to input another address.
Note: Not all wireless networks offer access to the Internet. Some Wi-Fi networks only link several
computers together, without any Internet connect ion.
to
11
Using the Virtual Keyboard
y
y
y
y
y
y
Tapping on any text input field can open the virtual board. With the virtual keyboard,
you can enter a website address or any text required.
Indications
a. Caps Lock
b. Backspace.
c. Number and Characters
a
c
d
b
e
Selecting Input Method
If you have installed more than one input method in this device, you can select one
method by a) holding the
choosing “Input Method” and then choosing your desired one.
button until the Android keyboard settings appear; b)
Inputting special characters
To input a special character like “à”, hold your finger on “a” to see a special character
keyboard and then slide your finger to a character on the keyboard. Release your
finger if you see two lines appear on the character.
/Letter Keyboard Switch.
d. Space
e. Enter
Using the Web Browser
You can scroll the screen up and down by tapping on the page
and dragging it up or down (be careful not to tap a link until you
are ready!).
To open a link, simply tap it.
You can open several web pages at a time, view them all at once
on the screen, and then tap one of them to view it in full screen.
To go back to the previous page that you browsed, tap the Back
icon
To display the available menu items, tap the Menu icon .
To go back directly to the Home screen, tap the Home icon .
.
12
y
Depending on where you are in the web browser, holding down on an item will
y
give you access to more options.
To fill in a text field, tap in the field, then use the virtual keyboard to type in the
required text.
Web Browser Menu Items
When you are viewing a page, you can tap the menu icon to display the menu
items.
New window
Bookmarks Will open the “Bookmarks” manager. You will see three tabs:
Refresh/
Stop
Windows When you have several windows currently opened, tap “Windows”to
Forward
More
Allows you to open new windows.
“Bookmarks,” “Most visited,” and “History.”
“Bookmarks” shows you a list of bookmarks. Just tap one of them to
open it in the current window. Holding down a bookmark will give you
access to several options (you will be able to edit it, rename it, delete
it,etc.).YoucanalsousetheMenuicon
bookmark the last-viewed page.
“Most visited”and“History” allow you to access your “Most visited”
sites and your visit history. In the “History” tab, the Menu icon
allows you to clear the history.
“Stop” will stop loading the web page, if it is currently loading.
“Refresh” will refresh the current web page, if it has stopped loading.
display them all at once on the screen. Just tap one of the small
windows to view it in full screen, or tap the Close icon in the small
windowtoclosethewindow.
Will go to the next page that you browsed.
Will give you access to other options (“Find on page,” “Select text,”
“Page info,” “Downloads,” “Settings” etc.).
which will allow you to
Reading E-Books
Transfer E-books from Computer
Before reading, you need to transfer or download e-books to the device. You can copy
e-books from your computer’s local drive to the device by USB connection (see the
“Transferring files” section mentioned before).
Note: Make sure your e-books are in format of PDF, EPUB, TXT, FB2, RTF or PDB supported by
the device.
Download E-books with Adobe Digital Editions
The Adobe Digital Edition application allows you download e-books protected by DRM
to your NextBook.
(1) Access the website http://www.adobe.com/products/digitaleditions/, and then
13
install the Adobe Digital Editions software following the instructions.
(2) Authorize your computer with your Adobe ID and Password.
(3) Activate your NextBook.
Connect your NextBook to computer with the USB cable and start up the Adobe
Digital Editions. Click “Authorize Device” to authorize your NextBook.
y The Adobe ID can be used only for six times. It should expire after 6 tries of authorizing device.
Later on, you need to delete the expired ID by pressing CTRL+SHIFT+D on the computer
keyboard or using the Erase Activation Record sett ing on the device and then get a new one.
y The device remembers the ebooks downloaded with the latest Adobe ID only, and will overwrite
the eBooks downloaded with the previous Adobe ID.
(4) Download DRM-protected PDF files to your computer.
Access an online bookstore and search for e-books. Choose your favorite
e-books and download them. If the e-book is protected by DRM, you should be
prompted by DRM license information. Click “Open” to start downloading the
DRM-protected e-book.
(5) Click “Purchase”, and then you should see your downloaded e-book at the right
panel of the Adobe Digital Editions user interface.
14
(6) Connect your NextBook to the computer with the USB cable, and the Adobe
Digital Editions should recognize your NextBook.
(7) Click “Purchase” to see your downloaded e-book and then drag it to your
NextBook.
Start Reading
(1) In the Home Screen, tap the E-book Reader shortcut to enter the e-book reader
mode.
(2) Tap an e-book to start reading immediately.
History and My Library
You can tap “History” to view your reading history or tap “My Library” t o enter the
e-book library. “History” shows all of the e-books that you have read by date. “My
Library” shows all of e-books stored in the device.
Note: E-book cover will show as defaulted cover by the device if the e-book has no cover data.
That’s why you see some e-book covers are the same.
15
Page Up/Down
When you are reading the e-book, you can slide your finger on the screen left and
right to page up or down.
You can let the ebook page up and down automatically by: a) tapping the Men Menu
icon
to display e-book settings; b) Tap “Auto Flip”; c) Selecting a flip interval time.
Increase Font Size
(1) When you are reading, tap the Menu icon to display e-book settings.
(2) Tap “Font Size” to adjust the font size.
(3) Tap a size that you want, and then tap “OK” to confirm.
Jump to a Page
You can directly go to a page that you have specified.
(1) When you are reading, tap the Menu icon
(2) Tap “Go to”.
(3) Tap the page number input field to display the virtual keyboard.
(4) Tap the numbers to input the page number.
(5) Once you finish inputting the page number, tap “OK” to jump to the specified page.
to display e-book settings.
Use Bookmarks
You can add, delete or load bookmarks on the page.
16
(1) When you are reading, tap the Menu icon to display e-book settings.
(2) Tap “Bookmarks” to display a bookmark menu. Use the menu to add, delete or
display bookmarks.
Show Outline of the e-book
You can view the outline of the e-book and then choose your desired chapter or
section to read.
(1) When you are reading, tap on the Menu icon
(2) Tap on “TOC” to display the outline of the e-book, and then tap the chapter that
you want to read.
to display e-book settings.
Accessing online Bookstore
Your NextBook has a built-in online bookstore - KOBO. You can purchase e-books or
download free e-books directly from the Kobo.
Note: Make sure you have configured the Wi-Fi network before accessing Kobo.
Purchase e-books from Kobo
(1) In the Home Screen, tap the “kobo”
icon.
(2) Tap “SIGN IN OR CREAT AN
ACCOUNT” to sign in.
(3) Log in with your account, and then
input your account information.
(5) Tap on BUY NOW button to start
the purchase process.
(4) Go to the book store and
search for e-books. Tap the
e-book that you want to buy.
(6) Input your payment account
information to checkout.
17
(7) Check your credit card information
and the price.
(8) Tap Buy Now to download the
e-book.
Note: The ebook won’t to be
downloaded to your Ne xtBook. They
are accessible only if you sign in
with your Kobo Account.
Read e-books in Kobo Library
E-books from Kobo are saved in Kobo library. They are unable be synchronized to the
internal memory of the device.
To read e-books that you have purchased from Kobo,
(1) Tap
to enter the Kobo library
and you should see all of your
purchased e-books.
(2) Tap an e-book and tap “Start
Reading” to read the e-book.
18
(3) During reading, you can:
y
y
y
y Turn over pages by sliding your finger left and right.
y Tap on the screen to display the control bar. By sliding the control bar, you
can go to any page in the e-book.
y Tap the Menu icon to display menu options. With these options, you can
view outline of the e-book, change the view mode (day or night m ode),
change the font size or style.
(previous/next page) (control bar) (options)
Playing Music
In the Home Screen, tap the Music icon to enter the music player mode. Optionally,
you can tap the Applications shortcut to display all applications and then tap the Music
icon to enter the music mode.
Music Library
You should enter the music library once you start the music
player. The Music Library shows your music files sorted by cat-
egories (Artist, Album, etc.) if your music files contain these
song information tags. If some of your music files do not contain
information tags, they will be classified as (Unknown) in the
Music Library. When new music is copied to the device, the
Music Library will be updated automatically.
You can drag your finger up and down on the file list to scroll
through the list.
Tap a track to play a track.
To return to the Home Screen, tap / .
Once you enter the music library, you should see the toolbar at the bottom of the
screen. Tap and hold your finger on the icon and you should see its name.
Songs
List all music files.
Artist
List music files by artist.
19
Album
y
y
y
y
y
y
V
f
Playlist
List music files by album.
List your favorite songs.
Now Playing
Go to the Now Playing screen.
Music Library Menu
In the library, holding your finger on a track can display the
following menu options.
Play – start playing the song
Add to playlist – add the song to the playlist.
Delete – delete the song.
Search – search for information about the song.
Shuffle Tracks
In the library, tap the Menu icon to display options – Party shuffle and Shuffle all.
Party shuffle – shuffle tracks in the current directory.
Shuffle all – shuffle all tracks stored in the device.
Playback Screen
D 3UHYLHZ WKH OL
E 6KXIIOH WUDFNV 1RW VKXIIOH
a
b
d
c
e
g
To pause or resume the playback, tap on the Pause / Play icon.
To play the previous/next song, tap on / .
You can tap on the progression bar to go directly to a different location in the
j
i
h
k
song. You can also drag the cursor in the progression bar to another location in
the song.
Tap to adjust the volume.
To preview songs on the list, tap , and then tap a song for preview.
To change the repeat mode, tap .
F 5HSHDW WUDFNV1RW UHSHDW
G $OEXP FRYHU
H $UWLVW 1DPH
I $OEXP 1D PH
J 7UDFN 1DPH
K 3UHYLRXV WUDFN5HZLQG
L 3 OD\3DXVH
M 1H[W WUDFN)DVW )RUZDUG
N 3 URJUHVVLRQ ED U
O $ GG WKH WUDFN WR SOD\OLVW
20
y
To display menu options, tap .
y
y
y
y
y
Tapping continuously on the track title can search for the information about the
track from the Internet.
To go back directly to the Home screen, tap on the Home icon or Return
icon
.
Playing Menu
When the track is playing, you can tap the Menu icon to
display the following menu options.
Library – go back to the music library.
Party shuffle – shuffle all tracks in the current directory.
Add to playlist – add the track to the playlist.
Delete – delete the song.
Sound effects – change equalizer mode.
Playlist
The playlist is a list of audio tracks that you have added
manually.
To play the playlist,
(1) In the Music Library, tap the Playlist icon
the playlist. All songs that you have added are listed.
(2) Tap a song to start playing.
to display all
Playing Video
In the Home Screen, tap the Video Player icon to enter the video player mode.
Optionally, you can tap the Applications shortcut to display all applications and then
tap the Video Player icon to enter the video mode.
Navigate through Video Files
You should see the video list when you enter the video player.
You can drag your finger up and down on the video list to scroll the video list up
and down.
Tap a video to start playing.
You can go back directly to the Home screen by tapping on the Return icon
or Home icon .
21
Playback Screen
y
y
y
y
y
y
y
y
y
a. VOL-
b. Progression bar
c. VOL+
d. Bookmark
e. Brightness
f. Previous video/Rewind
a
b
defghijk
Tap on the / icon to pause/resume the video,
Tap on “ ” to display the menu items.
Tap on the progression bar to go directly to a different location in the video. You
can also use your finger to drag the cursor in the progression bar to another
location in the video.
Tap on / to adjust the volume.
Tap on “ ” to set a bookmark at the current spot in the video. Please note only
one bookmark can be set for one video, and the new bookmark should cover the
old one. To resume playing a video from the bookmark, go to the Home Screen,
enter the Video Player, and tap on the bookmarked video. You should be
prompted to “Play from beginning” and “Play from bookmark”. Select “Play from
bookmark”. In default, the video plays from beginning. To remove the bookmark,
tapon“
Tap on to adjust the brightness of screen.
Tap on / to play the previous or next video.
Tap on to change the aspect ratio of screen.
Tap on to stop playing and return the video list.
Note: Some video files may not be play ed correctly with the device. Refer to the Technical
Specifications at the end of the manual, and make sure the video resolution, encoding format or file
type is supported.
” to display the menu, and then choose “Delete Bookmark”.
g. Play/Pause
c
h. Next video / Fast forward
i. View Mode
j. Exit
k. Video settings
Video Playback Settings
Tap on the icon to display the video settings.
Delete BookMark and
Play from beginning
Delete Bookmark Delete the video bookmark.
Play Mode
Delete bookmark and play from beginning.
Single – plays the current video and then stops
22
after playing.
Repeat One – Repeat the current video.
Repeat All – Repeat all videos.
Help Get instructions on playing video.
Return Exit from the menu.
Viewing Photos
In the Home Screen, tap the Gallery icon to enter the photo viewer mode. Optionally,
you can tap the Applications shortcut to display all applications and then tap the
Gallery icon to enter the photo Gallery.
Viewing Photo
(1) Folders containing photos should be listed once you enter the Gallery. Tap a
folder to open it.
(2) Photos in the opened folder are listed in thumbnail. You can slide your finger on
the screen or tap
(3) You can tap the Thumbnail/Group toggle button
thumbnails or group photos by date.
to browse photo thumbnails.
to display photo
23
(4) Tap a photo thumbnail to view the photo in full screen.
(5) To display the previous/next picture, slide your finger on the screen horizontally.
(6) To zoom in or out the picture, pinch your finger on the picture.
Display Toolbar
When you are viewing the picture, you can tap on the screen or the Menu icon to
show a floating menu.
Start slideshow Displaymenu options
24
Zoom in/Out
Tapping “Menu” can display other menu options.
Send picture to
friend by e-mail
(email account
login required)
Information about the picture
Set the picture as desktop background
Crop a part from the picture
Rotate the picture left
Rotate the picture right
Delete
Slide Show
To start an automatic slideshow, tap on the screen t o s how a floating menu, and then
tap the Slideshow menu on the toolbar. To stop the slideshow, tap the screen.
Exploring Files
You can explore files and folders with the Explorer and Astro application. In the Home
Screen, tap the Applications shortcut to display all applications and then tap the
Explorer icon or ASTRO to enter the file explorer mode.
25
Using the Explorer
y
y
y
y
y
y
y
Navigate through Files and Folders
You can drag your finger up and down to scroll the file list up
and down.
To open a file or folder, tap the file/folder.
Tap the m enu icon , you can manage the applications
(see details in the “Managing 3
You can go back or forward one level in the interface by
tapping on the Back icon
You can go back one level in the directory by tapping on the
LevelUp button
Wherever you are in the interface, you can go back directly to
.
the Home screen by tapping on the Return icon
Tap the Home icon to go to the root directory.
Using the Toolbar
You can use the toolbar to navigate through your device’s int ernal memory/ memory
card and delete or copy files.
Tapping on the grey area can hide/display the toolbar.
Sliding your finger on the toolbar can scroll through all tools.
rd
party Applications” section).
or Next icon .
or Home icon .
Home
LevelUp
Multi
Editor
Back
Next
Go to the Home Screen.
Go back one level in the directory.
Select more than one file.
Copy, delete, move, paste or rename the file or folder.
Go back one level in the interface.
Go forward one level in the interface.
Copy/Move Files and Folders
(1) In the file list, scroll up and down by sliding your finger to select
the file/folder that you want to copy or move.
(2) Hold the selected file/folder until a pop-up menu appears.
(3) Select “Copy” or “Move” from the pop-up menu.
(4) Navigate to the location where you wish to copy or move the
file/folder to.
(5) Select the Editor icon
from the toolbar and then choose “Paste.”
26
Delete Files and Folders
y
y
y
y
y
y
y
(1) In the file list, scroll up and down the list by sliding finger to select the file/folder
that you want to delete.
(2) Hold the selected file/folder until a pop-up menu appears.
(3) Select “Delete” from the pop-up menu, then select “Delete” to confirm or
“Cancel” to quit.
Rename Files and Folders
(1) In the file list, scroll up and down the list by sliding finger to select the file/folder
that you want to rename.
(2) Hold the selected file/folder until a pop-up menu appears.
(3) Select “Rename” from the pop-up menu.
(4) Tap the input field to display the virtual keyboard, and then choose letters from
the virtual keyboard to rename the file/folders.
(5) Tap “OK” to confirm the new name.
Select Multiple Items
You can select more than one file or folder together.
(1) In the top toolbar, tap the Multi icon “
(2) Tap the files/folders you want to choose. The file/folder name turns red when
selected. (To deselect the file/folder, tap it again.)
(3) Once you finished selection, you can delete, copy or move the selected files by
tapping on the Editor icon
.
.”
Using the ASTRO
Navigate through Files and Folders
You can drag your finger up and down to scroll the file list up
and down.
To open a file or folder, tap the file/folder.
Tap the menu icon , you can manage the applications
(see details in the “Managing 3
You can go back or forward one level in the interface by
tapping on the Back icon
You can go back one level in the directory by tapping on the
LevelUp button
Wherever you are in the interface, you can go back directly to the Home screen by
tapping on the Return icon
Tap the Home icon to go to the root directory.
.
rd
party Applications” section).
or Next icon .
or Home icon .
27
Using the Toolbar
You can use the toolbar to navigate through your device’s internal memory/ memory
card and delete or copy files.
Tapping on the grey area can hide/display the toolbar.
Sliding your finger on the toolbar can scroll through all tools.
Home
Up
Multi
Edit
Search
Back
Next
View
Sort
Prefs
Network
Go to the Home Screen.
Go back one level in the directory.
Select more than one file.
Copy, delete, move, paste or rename the file or folder.
Search for a specific file or folder
Go back one level in the interface.
Go forward one level in the interface.
Display files and folders in list or icons.
Sort files and folders by name, date, size or file type.
Preferences for the ASTRO
Enable the Wi-Fi network or Bluetooth.
Copy/Move Files and Folders
(1) Navigate through the file/folder and locate the file/folder you want.
(2) Tap the Multi icon
and then tap the file(s) /folder(s) that you want. You can
select multiple items by tapping. To deselect the item(s), tap the Cancel icon
(3) Select “Copy” or “Move” from the pop-up menu.
(4) Navigate to the location where you wish to copy or move the file/folder to.
(5) Select the Edit icon
from the toolbar and then choose “Paste.”
Delete Files and Folders
(1) Navigate through the file/folder and locate the file/folder you want.
(2) Tap the Multi icon
and then tap the file(s) /folder(s) that you want. You can
select multiple items by tapping. To deselect the item(s), tap the Cancel icon
(3) Select “Delete” from the pop-up menu and then select “Delete” to confirm.
Compress Files/Folder with Zip
(1) Navigate through the file/folder and locate the file/folder you want.
(2) Tap the Multi icon
and then tap the file(s) /folder(s) that you want. You can
28
select multiple items by tapping. To deselect the item(s), tap the Cancel icon
(3) Select “Zip” from the pop-up menu.
(4) Enter a name for the zip file and then tap “Create”.
File Options
You can hold your finger on an item to display the following
options:
Details – file information
Open As – open the file with another application.
Edit – copy, delete, move, zip the file
Send – send the file by e-mail (email account login required.)
Set As – set the file as desktop
Sending/Receiving E-mails
This device has an E-mail application pre-installed. You can send or receive e-mails
from the Internet at any time with this device. Make sure you have an Internet
connection before using the email service.
In the Home Screen, tap the Applications shortcut to display all applications and then
tap the Email icon to launch the e-mail application.
Setup Email Account
First you need to setup an E-mail account for receiving or sending emails.
(1) Start up the email application by tapping the Email application icon and you are
prompted to setup an account.
(2) Input your email address and login password. You can set the account as default
by selecting the option “Send email from this account by default”.
(3) Tap “Manual Setup” to set the email server information.
(4) Choose the server type from POP3, IMAP or Exchange for incoming emails. To
know what type of your email server is, you can consult the service provider,
network administrator or search for information in the Internet.
(5) Input required information (server, port etc.). You
can obtain the information from the service
provider, network administrator or the Internet.
(6) Choose the server type for outgoing emails, and
input required server information.
(7) Click “Next” to continue. Your NextBook will check the server settings. When it
29
prompts you that “Your account is set up, and email is on its way”, your account is
y
y
y
set up successfully.
(8) Input your name and then tap on “Done” to finish.
Note: If you have more than one accou nt, every time when you start up the email ap plication, you
enter the default email account.
Manage Accounts
You can setup more than one account and manage these accounts by checking
information about the account, adding another account or deleting an account.
Add another Account
Following these steps to add another account if you want.
(1) Launch the email application and then tap on the Menu icon
menu item. Choose “Accounts” to display accounts.
(2) Tap on the Menu icon
account”.
(3) Follow the steps of setting up a Email Account to add an account.
Delete an Email Account
(1) When you are in the email box, tap on the Menu icon to display the menu
items.
(2) Tap on “Accounts” to display all email accounts.
(3) Hold your tap on the account that you want to delete until a menu pop up.
(4) Tap on “Remove Account”ˈand then tap on “OK” to confirm.
Check the Account Setting
(1) When you are in the email box, tap on the Menu icon to display the menu
items.
(2) Tap on “Accounts” to display all email accounts.
(3) Hold your tap on the account that you want to check until a menu pop up.
(4) Tap “Account settings”ˈand then you should see all setting information about the
account. You can edit these settings as you want.
to display the menu item, and then choose “Add
to display the
View Emails
You should enter your mailbox when you start up the email application.
In the mailbox, you can slide your finger up and down to scroll through the email
list.
Tap on an email to open it.
Holding your tap on the email can display a menu. With the menu, you can open,
reply, forward or delete the email.
30
Email Menu Items
In the email list, tap on the Menu icon to display the menu.
Refresh
Compose
Folders
Accounts
Account Settings
Refresh the emails.
Compose a new email.
Go back to email box.
View all email accounts.
Check your account settings.
Reading Office Document
The device provides support to Microsoft Office document with its
built-in OfficeSuite application. You can read documents in Word,
Excel or PPT etc.
(1) Copy Office documents to the device by USB connection.
(2) Launch the OfficeSuite application.
(3) Locate an Office document with the file explorer.
(4) Tap the document to open it. On the opening page, you can
slide your finger up and down to turn over the page.
(5) You can tap the Menu icon to display menu options. With these options, you can
search for specific texts or count words in the document.
31
Managing 3rdParty Applications
y
Your NextBook provides support to many useful third-party applications. You can
purchase the applications to add more functions to your device. They are available
online at the Internet or directly on your product.
Pre-installed Applications
The device has pre-installed applications when it was manufactured. You can see
them by tapping the Applications icon
browser, alarm clock, calculator etc.
Install Applications
You can install applications manually following these steps:
(1) Download the installation file directly from the built-in application library (e.g.
SLIDEME). Make sure the file is in format of .apk which is supported by your
NextBook system.
(2) Connect your NextBook to computer with the USB cable.
(3) Copy the installation file to your NextBook.
(4) Disconnect your NextBook form the computer.
(5) Turn on your NextBook and enter the file explorer mode with the Explorer.
(6) Locate the installation file and open it.
(7) Follow the on-screen instructions to install the application.
(8) Once the application is installed successfully, you c an find it in the application tab.
Uninstall Applications
(1) Tap the Settings shortcut in the Home Screen to display all system settings.
(2) Select “Applications”.
(3) Select “Manage Applications”.
(4) Tab on the application that you want to uninstall.
(5) Tab on “Uninstall” to uninstall the application.
Note:
You cannot uninstall the pre-installed applications.
. They are video player, audio player,
32
y
Some of the applications developed for Android mobile might not run properly in the NextBook.
y
y
y
y
Please consult the respective software developer for further information.
Managing Tasks
Your NextBook can handle multiple tasks at the same time. For example, you can
view photos while listening to music. Multitasking is helpful but inefficient if too many
tasks are running. In order to save system memory and enhance system performance,
you can end some tasks that you don’t use at the moment.
(1) Tap “Advanced Task Killer”
application.
(2) Tap the task that you want to
end.
(3) Tap “KILL selected apps” to end the task.
System Settings
In the Home screen, tap “Settings” and choose a category: “Wireless & Networks,”
“Sound & Display,” “Date & Time,” etc.
When a down arrow appears on the right of a parameter, this means that this
setting includes sub-parameters. Tap it to display the list of sub-parameters.
When a check box appears on the right of a parameter, tap it to enable or disable
this option.
When it is possible, you can use your finger t o scroll the screen up and down t o
reveal settings that you don’t initially see.
When you have finished adjusting your settings, tap the Back icon to go back
to the list of settings, or tap the Home icon
Your settings are saved instantly.
Wireless &
networks
Sound Silent Mode – mute sound except of media and alarm.
Wi-Fi – tap on this line to enabl e or disable the Wi -Fi connection.
Wi-Fi settings – allows you to set up and manage your Wi-Fi networks.
Notification Ringtone – Set your default notifi cation ringtone.
Audible touch tones – enables/disables sound w hen dialing.
Audible selection – enables/disables the touchscreen click sound.
Screen lock sounds – enable/disable sound when locking or unlocking
to go directly to the Home screen.
33
the screen.
This setting allows you back up or restore your system settings or data.
Display Brightness –allows you to adjust the brightness of the scree n.
Location &
Security
Applications
Privacy
Storage
Language &
keyboard
Date & Time
Update Media
Library
Erase activation
record
About Device
Auto-rotate scr een – switch the screen orientation automatically when
the device rotates.
Animation –enables/di sabl es the display of animations when opening
and closi ng applications.
Screen ti meout –allows you to adjust the delay before the screen
automatically turns off and locks itself. To turn the screen back on,
press the Power button once, and press it again to unlock the screen.
This screen gives you the possibility to allow certain Android
applications to determine your current location. You can also define a
screen unlock pattern and other security parameters.
This screen allows you to manage your Androi d applications. You can
view informati on about all the applications installed on your device.
This setti ng allows you un-mo unt the SD card or check SD card and
internal storage space.
Set your preferred language and region, and configure text settings for
faster and more accurate text input.
This setting allows you set up the date, time, time zone and formats.
Update the media library of your NextBook manually.
Used to erase record of DRM activations.
Display i nformation about your Ne xtBook system.
Asking for Help
You may have questions when using the device or want to know more about the
product. For your convenience, the device provides shortcut to User Guide and
Frequently Asked Questions. You can get help by tapping the Help icon in the Home
Screen.
34
y
y
Frequently Asked Questions
Terminate inactive applications
Software Version information
User Guide
Troubleshooting
Upgrade the system
automatically once a
software update is detected
online.
Troubleshooting
Reset this device
In the event that the device freezes, you can force the device to shut down by
holding the Power button for 15 seconds.
If the Power button does not reset your device, use the “pinhole reset” button,
located on t he back the device.
Specifications
Item Description
CPU
Built-in operating
system
Hardware IBM PC or compatible PC, Note-book or Macintosh with USB port
Internal Memory 2GB(256MB for apps installation, 1.2GB for internal system use) or above
Memory Card type SD card: 1GB, 2GB, 4GB (SDHC), 8GB (SDHC)
Operation System Windows2000/XP/Vista/windows 7/Linux2.4/ MAC OS 10.4 above
USB Interface USB2.0 High speed
Output Port 3.5mm earphone port, built-in speakers
E-book Format EPUB, PDF, TXT, FB2, RTF, PDB
Based on ARM926EJ (CPU+DPS)
Main CPU frequency: 600MHz
Auxiliary CPU Frequency(DSP digital command control): 560MHz
Android OS 2.3
35
Interface
Connection Agreement WiFi (802.11 b/g)
G-sensor Support 360 spin
E-Book
Photo Format
Audio
Video
Read speed 8.7-9MB/S (MLC flash)
File
Format
Coding
Format
File
Format
Coding
Format
File
Format
Coding
Format
USB2.0 High speed
SD (compatible SDHC)
3.5mm Earphone
˅
PDF/EPUB/TXT/FB2/PDB/RTF
PDF / EPUB Format: .Open; .Adobe DRM (For License)
TXT / FB2/PDB/RTF Format: .Open
JPEG(Baseline) : Max. 2Mpels
BMP
GIF Static
˅
PNG
MP3/WMA/WAV/OGG/FLAC/APE/AAC
MP3˄MPEG1/2/2.5 Audio Layer 1/2/3˅˖848KHZ/8320Kbps,CBR and
VBR
WMA˄Version4,4.1,7,8,9˅˖848KHZ/8320Kbps
WAV˄MS-ADPCM, IMA-ADPCM, PCM˅˖848KHZ
OGG˄Q1- Q10˅˖848KHZ
FLAC˄Q1- Q10˅˖848KHZ
APE˄Version 3.95,3.97,3.98,3.99,normal and fast˅:848KHZ
AAC(ADIF, ATDS Header AAC-LC and AAC-HE): 848KHZ
AVI, 3GP, MP4, RM, R MVB, FLV, MKV, MOV, WMV
AVI˄MPEG4
ASP/XVID/DIVX3/4/5
3GP/MP4(H.264/H.263/M
PEG4/XVID/DIVX3/4/5)
RM/RMVB(Real video
8/9/10)
FLV(Sorenson H.263,
H.264)
MKV(H.264/MPEG4
ASP/XVID/DIVX3/4/5)
MOV(MPEG4, H.264,
H.263)
WMV WMV v9: 1280*720/25FPS˄Max
˅
1280*720/25FPS˄Max
Audio Codec˖MP1/MP2/MP3/AC3/AAC
˅
MPEG4/XVID/DIVX3/4/5:1280*720/25FPS
Max
˄
˅
H.264:1280*720/25FPS˄Max
H.263:640*480/25FPS˄Max
Audio Codec˖MP2/MP3/AC3/AAC/AMR
1280*720/25FPS˄Max
Audio Codec˖MP3/AAC
H.263: 720*480/25FPS (Max)
H.264: 1280*720/25FPS˄Max
Audio Codec˖MP3/AAC
MPEG4/XVID/DIVX3/4/5:
1280*720/25FPS˄Max
H.264: 1280*720/25FPS˄Max
Audio Codec˖MP1/MP2/MP3/AC3/AAC
MPEG4:1280*720/25FPS˄Max
H.264:1280*720/25FPS˄Max
˅
˅
˅
˅
˅
˅
˅
˅
˅
˅
36
Write speed 4.5-4.8MB/S (MLC flash)
Battery Charge Time About 5 Hours
Battery Life
Display 7.0-inch TFT LCD, Touchpad (capacitive touch pad), 800X600 pixels.
SNR 90dB above
Frequency Response
Range
Power Supply
Storage Temp. -20ć +65ć
Ambient Temp. 0ć +50ć
Operation Relative
Humidity
Storage Relative
Humidity
About 7 hours of music playback;
About 6 hours of video playback;
About 6 hours of web browsing.
20Hz—20KHz
Rechargeable lithium-ion polymer battery;
AC Adapter: AC Input 100-240V50/60Hz, DC Output 5V/2A
20% 90%˄40ć˅
20% 93%˄40ć˅
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B dig-
ital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provi-
de reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interferen-
ce to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the r
eceiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
Caution:
ufacturer could void your authority to operate this equipment.
Any changes or modifications to this device not explicitly approved by man
USA
This device complies with Part 15 of the FCC Rules. Operation is subject to the follo-
wing two conditions:
(1) this device may not cause harmful interference, and
37
(2) this device must accept any interference received, including interference that may
cause undesired operation.
FCC RF warning statement:
The device has been evaluated to meet general RF exposure requirement. The
device can be used in portable exposure condition without restriction.
38
Other names of systems and products mentioned in these instructions are usually the
registered trademarks or trademarks of the manufacturers who developed the system
or product concerned. The
TM
and marks are not used to identify registered
trademarks and trademarks in these instructions.
This manual was correct and complete at the time of printing. However, new
specifications and updates can occur at any time without prior notice. No part of this
manual may be copied, republished, reproduced, transmitted or distributed in any way
without prior written consent of E Fun. Any unauthorized distribution of this manual is
expressly forbidden.
E Fun may find it necessary to modify, amend or otherwise change or update this
manual. We reserve the right to do this at any time, without any prior notice. All
specifications and features are subject to change without notice. All screen shots
shown are simulated and may not represent the actual screen on production units
sold to consumers.
For instruction manuals, updated drivers or other information, be sure to visit our
website at:
www.nextbookusa.com
Or write t o us at:
EFun
136 N. Grand Avenue # 148
West Covina, CA 91791
USA
Copyright
2011
39
Loading...
